Service Manual
COMBO
TIMELAPSE VCR
Model : DQ-K2121N-P
Caution :
In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the latest
parts information,please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
S/M No. :VKB2121NN0
July. 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DQ-K2121N-P and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DQ-K2121N-P

Summary of Contents for Daewoo DQ-K2121N-P

  • Page 1 S/M No. :VKB2121NN0 Service Manual COMBO TIMELAPSE VCR Model : DQ-K2121N-P Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    CONTENTS SAFETY&PRECAUTIONS ............................2 FEATURES & SPECIFICATION..........................4 EXTERNAL VIEWS..............................8 FRONT VIEWS .......................................8 BACK VIEWS ......................................9 REMOCON ......................................10 ALIGNMENT INSTRUCTIONS..........................11 ELECTRICAL ADJUSTMENT ..........................12 CIRCUIT OPERATION............................16 CIRCUIT INFORMATION............................22 CONNECTION DIAGRAM(DQ-K2121N(D)-P)............................22 POWER SCHEMATIC DIAGRAM(DQ-K2121N(D)-P) ...........................23 RECODER A/V SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)........................24 SERVO/SYSCON SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)......................25 FBT/CRT SCJE,ATOC DIAGRAM(DQ-K2121N(D)-P) ..........................26 LOGIC SCHEMATIC DIAGRAM(DQ-K2121N(D)-P) ..........................27 JACK/AUDIO SW SCHEMATIC DIAGRAM(DQ-K2121N(D)-P) ......................28 MULTIPLEXER SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)........................29...

  • Page 3: Safety&Precautions

    SAFETY & PRECAUTIONS SAFETY CHECK AFTER SERVING Examine the area surrounding the repaired location for damage or deterioration. Observe that screw, parts and wires have been returned to original positions. Afterwards, perform the following tests and conform the specified values in order to verify compliance whit safety standards.
  • Page 4 SAFETY & PRECAUTIONS 4. Leakage current test Confirm specified or lower leakage current between B(earth ground, power cord plug prongs) and externally exposed accessi-ble parts (RF terminals, antenna terminals, video and audio input output terminals, microphone jacks, earphone jacks, etc.) Measuring method:(Power ON) Insert load Z between B(earth ground, power cord plug prongs) and exposed accessible parts.

  • Page 5: Features & Specification

    FEATURES & SPECIFICATION GENERAL FEATURE NTSC SYSTEM REMARK DESTINATION NTSC : NORTH AMERICA COLOR SIGNAL NTSC : NTSC EFFECTIVE PICTURE SIZE 14Ó -> HEIGHT : 8.27Ó(21cm), WIDTH : 11.00Ó(28cm) 20Ó -> HEIGHT : 13.27Ó(34Cm) , WIDTH : 17.09Ó(43Cm) CALENDAR 2003~2102 OSD LANGUAGE ENGLISH Only LETTER COLOR...
  • Page 6 FEATURES & SPECIFICATION FEATURE NTSC SYSTEM REMARK MENU 2. VCR Mode Set 1) Tape Search Select - Alarm Search 01/02/03 . . . 99 <First condition : - -> 01/02/03 . . . 99 <First condition : - -> - Index Serach Forward Search Reverse Search - Zero Search...
  • Page 7 FEATURES & SPECIFICATION RECORDER FEATURE NTSC SYSTEM REMARK Deck Mechanism Head Width NTSC: RÕ:48µm, L:26µm/R:26µm, LÕ:58µm Full Loading - Condition in Power off Unloading Stop ->Play Time About 1Sec FF->REW Time 3 min Under(T-120/E180 TAPE) Dew Sensor Auto Head Cleaner DLC Coated Drum Video Video Head...
  • Page 8 FEATURES & SPECIFICATION FEATURE NTSC SYSTEM REMARK Timer Auto Series Record Auto Repeat Record Yes(MENU SET) Alarm Search Yes(MENU SET) Clock Display Method 24Hours Timer Recording System With the Timer Key Alarm Recording System Yes(When the Stop Key is clear immediately) NTSC SYSTEM : 02/06/18/30H Repeat Recording System Yes(MENU SET)

  • Page 9: External Views

    EXTERNAL VIEWS 1. FRONT VIEWS F/L Door MENU/ CLEAR/ STOP PAUSE/ PIP/ REC/ STANDBY/ON ALARM SPEED ZOOM R.REC FREEZE TRK- STILL TRK+ /EJECT REC CHECK DISPLAY AUDIO/ C4 / QUAD/ C1 / C3 / C2 / TALK SET LOCK TIMER AUTO PLAY SPEED...

  • Page 10: Back Views

    EXTERNAL VIEWS 2. BACK VIEWS WARNING TAPE ALARM IN 1 IN 2 IN 3 IN 4 AUDIO MONITOR VIDEO POWER INPUT RESET AUDIO CH 1 CH 2 CH 3 CH 4 AUDIO IN (CH1~CH4, rca type) Terminal 1) N.C. 2) N.C. VIDEO IN(CH1~CH4, bnc type) 3) WARNING OUT 4) COM...

  • Page 11: Remocon

    EXTERNAL VIEWS 3. REMOCON USER REMOCON SVC MODE BY USER REMOCON * SVC MODE 1.POWER ON(EJECT) 2.Make full screen in CAM4. 3.Push "INDEX -, +, ALARM -, +" buttons in sequence within 10 seconds. 4.Press the POWER OFF key to release SVC MODE. e.20"/14"...

  • Page 12: Alignment Instructions

    ALIGMENT INSTRUCTIONS 1. VCR DECK ADJUSTMENTS 1) X-DISTANCE & P2,P3 ADJUSTMENT(S10) ¥ Connect Path JIG to connector PS 04, Playback the test tape(DN-2,7KHz) ¥ Connect oscilloscope CH1 to V.SW(PS04#2), CH2 to PB RF(PS04 #1) and trigger on CH1. ¥ Enter the service mode and select service adjustment S10 ¥...

  • Page 13: Electrical Adjustment

    ELECTRICAL ADJUSTMENT Electrical adjustments: Alignment and electrical adjustment - For these adjustments, use the equipment mentioned below and proceed by using the alignment tape and video signal. ¥ Instrument and tools required 1. Color TV . 2. Oscilloscope having 10MHz or more bandwidth. 3.
  • Page 14 ELECTRICAL ADJUSTMENT 1. SERVO/SYSCON CIRCUIT ADJUSTMENT METHOD (1) VIDEO HEAD SWITCHING POSITION Adjustment Part Checking Point Measuring Equipment Mode Test Tape R595 TJ396P502 3PIN Oscilloscope Play DN-1(Color Bar) ¥ Connection Method R595 TJ396 P502 CH-2 Oscilloscope CH-1 ¥ Adjustment Procedure 1) Play back the test tape.
  • Page 15 ELECTRICAL ADJUSTMENT 2 . MONITOR ADJUSTMENT * HOW TO ENTER THE SVC MODE 1) POWER ON(EJECT MODE) and make full screen in CAM4. 2) Push INDEX-,+,ALARM-,+ buttons in sequence within 10 seconds. Then, the screen will display FACTORY V0.1 text on the upper of the reft. 2-1 The adjustment of screen 1) Press the VOL UP, DOWN(S-BRIGHT +,-) key on the remote control to set the sub-bright.
  • Page 16 ELECTRICAL ADJUSTMENT 2-4-2 The adjustment of vertical size 1) Apply NTSC RETMA pattern. 2) Call up the SVC Mode and make full screen in C4 3) Press MENU,PIP(V-SIZE+ or V-SIZE-) key and VERT SIZE OSD will be displayed. 4) Adjust with MENU,PIP(V-SIZE+/V-SIZE-) keys so that the upper and the lower Ô+Õ marks of the RETMA pattern may be located at the boundaries of the screen.

  • Page 17: Circuit Operation

    CIRCUIT OPERATION 1. VIDEO PART 1-1) EE MODE Video Signal which is output from monitor is input into pin 36 of IC301. It is amplified 6dB by AGC, then it is output to pin 29 of IC301. The output signal is output to monitor through PJ301.. 1-2) REC MODE Video signal inputted from monitor will be recorded on the tape through head after FM modulated in IC.
  • Page 18 CIRCUIT OPERATION 2. AUDIO PART 2-1) EE MODE External AUDIO signal which is input to pin 78 of IC301 is output from pin 96 of IC301 after being ampli-fied through ALC and Line Amp. 2-2) REC MODE It will be the REC mode when REC 5V is input to base of Q206,Q202. Input signal will be replaced on the tape through R/P HEAD after being amplified and modulated with Bias Frequency.
  • Page 19 CIRCUIT OPERATION 3. SYSTEM PART 3-1) System Block DIAGRAM Terminal Jack CRT & PART DY COIL VCR Servo Syscon . OSC PART PART & High Multiplexer Volt price Part DECK K Monitor MECH K-30 u-com IC Front KEY Matrix Coil Power PART Degauss...
  • Page 20 CIRCUIT OPERATION 3-2) TIME LAPSE RECORDING METHOD The numbers of VHS 2HOUR (SP), 6HOUR (EP) REC FIELD are 60 field/sec, then it will be 1FRAME = 33.3Ms, 1FIELD = 16.65Ms. CAPSTAN MOTOR FG numbers for Time Lapse are 6HOUR(EP) = 720 numbers/sec, 2HOUR(SP) = 720*3=2160 numbers/sec.
  • Page 21 CIRCUIT OPERATION 3-3) TERMINAL PART ALARM INPUT 1,2,3,4 Connect DOOR SW&SENSOR etc and this port will be used for emergency recording by using open/ close status. N/O(NORMALY OPEN) 500ms N/C(NORMALY CLOSED) 500ms TAPE END OUT When the recording tape ends during recording, end sensor will be detected. This port is used Alarm to outsider until release the end sensor detecting.
  • Page 22 CIRCUIT OPERATION X-RAY PROTECTION CIRCUIT(DQ-K2121N-P)

  • Page 23: Circuit Information

    CIRCUIT INFORMATION 1. CONNECTION DIAGRAM(DQ-K2121N(D)-P)

  • Page 24: Power Schematic Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 2. POWER SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 25: Recoder A/V Schematic Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 3. RECODER A/V SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 26: Servo/Syscon Schematic Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 4. SERVO/SYSCON SCHEMATIC DIAGRAM(DQ-K2121N(D)-P))

  • Page 27: Fbt/Crt Scje,Atoc Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 5. FBT/CRT SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 28: Logic Schematic Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 6. LOGIC SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 29: Jack/Audio Sw Schematic Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 7. JACK/AUDIO SW SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 30: Multiplexer Schematic Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 8. MULTIPLEXER SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 31: Monitor A/V Diagram(Dq-K2121N(D)-P)

    CIRCUIT INFORMATION 9. MONITOR A/V SCHEMATIC DIAGRAM(DQ-K2121N(D)-P)

  • Page 32: Troubleshooting Flow Chart

    TROUBLESHOOTING FLOW CHART 1. VIDEO CIRCUIT A. TROUBLESHOOTING OF EE MODE Is VIDEO signal obtain from Check MUX. pin5 of P301? Is E9V supplied at Q 303? Check Q 303. Is the video signal to emitler of Q303? Check power. Is signal input into Check Q303.
  • Page 33 TROUBLESHOOTING FLOW CHART B. TROUBLESHOOTING OF RECMODE Is the video signal input into RECHECK METHOLD A. pin36.of Ic301? Is ON/OFF 5V supplied to Check ON/OFF 5V. IC301 at 5V? Is the luminance signal from pin21 of IC301 fed to pin20 of IC301? Check Q302,C311 Is the color signal from pin72 Check IC 301.
  • Page 34 TROUBLESHOOTING FLOW CHART C. TROUBLESHOOTING OF LUMINANCE IN THE PLAYMODE Is envelope output Is 5V supplied at Check power. pin 87 of IC 401?. from pin 74 of IC 301? Is SW pulse input at Check IC 501. pin 11 of IC 301?. Check P401 and DRUM head.
  • Page 35 TROUBLESHOOTING FLOW CHART D. TROUBLESHOOTING OF COLOR IN THE PLAYMODE. Is color signal from pin72 fed to pin71 Check IC 401. of IC 301? Is the signal obtained from Check IC301. pin 51 of IC 301? Is color Rotary pulse supply to Check IC 501.

  • Page 36: Servo-Syscon Circuit

    TROUBLESHOOTING FLOW CHART 2. SERVO-SYSCON CIRCUIT Playback picture Adjust tracking. is not good Noise appears Noise appears Check and re-adjust although although change the path of Deck. adjusting tracking. cassette tape. CTL HEAD height Adjust the HEAD Is CTL pulse output is normal and height and at pin 2 of P502?
  • Page 37 TROUBLESHOOTING FLOW CHART Playback picture is not good. Noise appears on the Noise appears on the Check flow A. screen on the whole. screen at the bottom Check the PG Adjustment. Is SW-pulse applied to Is sw pulse supplied Check D.PG input video IC? from pin 18 of IC501? and connector.
  • Page 38 TROUBLESHOOTING FLOW CHART Auto-stop during playback. Is reel pulse applied to Check reel sensor. pin 79 and 80 of IC501? Is D. FG applied to Check connector and pin 89 of IC501? D. FG circuits. Check IC501.
  • Page 39 TROUBLESHOOTING FLOW CHART Drum M/T loading stops. Is motor 12V supplied Check circuit adjacent from IC 503? EVER +12.4V. Check power module. Is 5.2V supplied from Check IC808. P506 pin 5? Check connector and motor.
  • Page 40 TROUBLESHOOTING FLOW CHART Capstan M/T loading stops. Check IC808. Is motor 12V supplied? Is the input of pin 6 Check circuit of C547, of P505? R548,R531,R547,R551,C548 Check R549, R552 Is pin 4 of P505 2.5V? Does pin 77 of IC501 Check IC501.
  • Page 41 TROUBLESHOOTING FLOW CHART Drum M/T and capstan M/T rotate at irregular speed. (IN REC MODE) Is C. sync applied to Check C. sync of video pin 93 of IC501? IC and pattern. Check motor Emergency mode when plugging (power cord) Is ever 5V applied? Check IC810.
  • Page 42 TROUBLESHOOTING FLOW CHART Cassette is not inserted. Check power Module. Is motor 12V supplied? CAM DATA is changed Check connector. when CST IN? Is 5V supplied at Check Deck part. pin 31 of IC501? Check pattern Check IC501. and R572.
  • Page 43 TROUBLESHOOTING FLOW CHART Power compensation does not operate. When mains is unplugged, Check C586, is 3.6V at pin 37 of IC501? C501,C515,C516 Is (sine) signal applied to Check X501. pin 38 and 39 of IC501? Check reset circuit Is 5V at pin 37 of IC501? Of IC504.

  • Page 44: Audio Circuit

    TROUBLESHOOTING FLOW CHART 3. AUDIO CIRCUIT A. TROUBLESHOOTING OF PB MODE No sound in the playback mode. Set AUDIO ON key to ON. Is AUDIO ON key set to ON? Check PJ 201 Is signal input pin 5 of IC 301? &...
  • Page 45 TROUBLESHOOTING FLOW CHART B. TROUBLESHOOTING OF REC MODE No sound in the playback mode after recording. Set AUDIO ON key to ON. Is AUDIO ON key set to ON? Is signal input pin 78 Check monitor PART. of IC301? Is the voltage above 4V Check SERVO SYSCON.
  • Page 46 TROUBLESHOOTING FLOW CHART C. TROUBLESHOOTING OF EE MODE No sound in the EE modes. Is 12V applied to pin 16 Check IC806, IC807 of IC 943,IC942? Is signal input Check Audio switch part. pin 78 of IC 301? Is signal output Check IC 301.

  • Page 47: Power Part

    TROUBLESHOOTING FLOW CHART 4. POWER PART When power is not on Check power cord AC120V at the both side and power switch. of S801? Check D801, D802,D803, DC 150V at the +side of C805 D804, R802 Oscillater Signal at the Check IC801.

  • Page 48: Monitor Part

    TROUBLESHOOTING FLOW CHART 5. MONITOR PART In case the monitor screen does not appear. DC133V at the pin10 of Check the power part. PJ801? Check T802 and Pin42 Does Q802 Oscillate? of IC401 B(+), HEAT Signal at the Check T803. PIN2,3 of PJ804? Vertical signal and Drive(+),(-) Check IC805, IC401...

  • Page 49: Mux Part

    TROUBLESHOOTING FLOW CHART 6. MUX PART Is the EE SCREEN (Monitoring screen)wrong? Video Input signal at Check video switch part. pin 3,5,7,9 of P001? VIDEO Signal at the pin30 Check IC 010, P003. of IC000? VIDEO Signal at the Check IC011. pin6 of IC012? VIDEO Signal at the pin20 Check the pattern.
  • Page 50 TROUBLESHOOTING FLOW CHART When the Rec Screen is wrong? VIDEO Signal at the Check video switch part. pin3,5,7,9 of P001 ? VIDEO Signal at the pin30 Check IC 010, P003. of IC007? VIDEO Signal at the Check IC011. pin3 of IC012? VIDEO Signal at the pin50 Check the pattern.

  • Page 51: Vct 3834 Pin Assign

    VCT 3834 PIN ASSIGN NC = Not Connected, LV = if not used Leave Vacant, X = Obligatory : connect as described in circuit diagram PinNo. Pin Name Type Connect(if not used) Descriptions Key 1 I/O ( I ) Key Matrix 1 input. Ñ> Not used (connected 3.3V) System Sel I/O ( I ) Key Matrix 2 input.
  • Page 52 VCT 3834 PIN ASSIGN PinNo. Pin Name Type Connect(if not used) Descriptions RSW1 Range Switch for Measuring ADC.Open Drain Pulldown Outputs.The switch is off while the Cutoff and the whitedrive are measured. RSW2 Range Switch for Measuring ADC.Open Drain Pulldown Outputs.The switch is off while the Cutoff is measured.

  • Page 53: Μ -Com Port Description

    µ -COM PORT DESCRIPTION Pin No. Pin Name Type Connection Short Description START SENS IN/OUT ANALOG START SENSOR VOLTAGE INPUT MD OUT IN/OUT MONITOR COMMUNICATION SIGNAL OUTPUT POWER FAIL IN/OUT POWER SUPPLY VOLTAGE LEVEL INPUT ALARM IN2 IN/OUT CAMERA2 ALARM SIGNAL INPUT CAM B IN/OUT CAM SIGNAL INPUT...
  • Page 54 µ-COM PORT DESCRIPTION Pin No. Pin Name Type Connection Short Description VIDEO IN COMPOSITE VIDEO SIGNAL INPUT LECHA WHITE LEVEL INPUT VIDEO OUT IN/OUT COMPOSITE VIDEO SIGNAL OUTPUT OSD Vcc OSD POWER SOURCE INPUT IN/OUT FILTER CONNECTION PIN FOR SLICER M CLK IN/OUT MONITOR COMMUNICATION SIGNAL OUTPUT...

  • Page 55: Components Location Guide On Pcb Bottom View

    COMPONENTS LOCATION GUIDE ON PCB BOTTOM VIEW...
  • Page 56 COMPONENTS LOCATION GUIDE ON PCB BOTTOM VIEW...
  • Page 57 COMPONENTS LOCATION GUIDE ON PCB BOTTOM VIEW...
  • Page 58 COMPONENTS LOCATION GUIDE ON PCB BOTTOM VIEW...

  • Page 59: Disassembly

    DISASSEMBLY...

  • Page 60: Electrical Partslist

    Ris a recommendable part for stock. 1. PCB MAIN AS PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK PVMCASN667 CHASSIS MAIN AS DQ-K2121N-P AL03 2291050305 FLUX LIQUID RF-800KN A0010 97SA309700 MAIN BASE AS K-MECHA AL04 2291050306 FLUX THINNER RF-800ADD...
  • Page 61 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK C002 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608 C057 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 1608 C003 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 1608 C058 HCBK473KBA C CHIP CERA...
  • Page 62 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK C119 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608 C314 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608 C120 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608 C315 CEXF1C470A C ELECTRO...
  • Page 63 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK C375 HCQK560JBA C CHIP CERA 50V CH 56PF J 1608 C475 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP C376 CEXF1H100A C ELECTRO 50V RSM 10MF (5X7) TP C476 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608 C378...
  • Page 64 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK C539 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP C839 CEYF2C101V C ELECTRO 160V RSS 100MF (16X25) C540 CEXF1H100A C ELECTRO 50V RSM 10MF (5X7) TP C841 CCXB2H101K C CERA 500V B 100PF K (TAPPING) C541 CCZB1H102K...
  • Page 65 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK D201 DZN4148Ñ- DIODE 1N4148 AUTO 52MM D838 D1N4937GÑ DIODE 1N4937G (TAPPING) D301 DZN4148Ñ- DIODE 1N4148 AUTO 52MM D839 D1N4937GÑ DIODE 1N4937G (TAPPING) D305 DZN4148Ñ- DIODE 1N4148 AUTO 52MM D851 DZN4004Ñ- DIODE 1N4004(AUTO) D431...
  • Page 66 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK I805B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN JK904 97P6315400 JACK B.N.C DBSE-9838 I805C 2291130215 GREASE SILICON G-600 JK905 97P6318300 JACK PIN DPSM-8905W I806A 4857031203 HEAT SINK AL 6063S JK906 97P6318300 JACK PIN DPSM-8905W I806B 7174300811...
  • Page 67 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK JP045 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP102 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP046 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP103 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP047 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING...
  • Page 68 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK JP158 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP214 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP159 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP215 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP160 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING...
  • Page 69 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK JP270 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP326 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP271 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP327 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP272 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING...
  • Page 70 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK JP385 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP806 85801060TA WIRE COPPER 0.6X52MM TAPING JP386 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP807 85801060TA WIRE COPPER 0.6X52MM TAPING JP387 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP808 85801060TA...
  • Page 71 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK JP913 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP969 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP914 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP970 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP915 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING...
  • Page 72 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK L440 5PB13857Ñ COIL BEAD BI3857(AXIAL) PJ201 97P885X101 CONN AS 6H/2H-8S 160/350MM RED L441 5PB13857Ñ COIL BEAD BI3857(AXIAL) PJ402 97P885X184 CONN AS 5H-5S 450MM L501 5CPX100J2T COIL PEAKING 10UH(BRN-BLK) PJ501 97P8810712 CONN AS (Y10712) 7H-7S, 120MM L502...
  • Page 73 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK Q802C 2291130215 GREASE SILICON G-600 R040 HRFS472JBA R CHIP 1/16 4.7K OHM J 1608 Q803 TKSA1013Y- KSA1013Y (TP) R041 HRFS472JBA R CHIP 1/16 4.7K OHM J 1608 Q901 TZTA1266Y- KTA1266Y- (AUTO)(1015Y) R042 HRFS472JBA R CHIP...
  • Page 74 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK R314 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J R441 HRFS223JBA R CHIP 1/16 22K OHM J 1608 R315 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J R442 HRFS201JBA R CHIP 1/16 200 OHM J 1608 R316 HRFS563JBA...
  • Page 75 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK R511 HRFS474JBA R CHIP 1/16 470K OHM J 1608 R567 RD-AZ102J- R CARBON FILM 1/6 1K OHM J R512 HRFS103JBA R CHIP 1/16 10K OHM J 1608 R568 HRFS561JBA R CHIP 1/16 560 OHM J 1608 R513 RD-AZ304J-...
  • Page 76 ELECTRICAL PARTSLIST PART-CODE PART-NAME PART-DESC REMARK PART-CODE PART-NAME PART-DESC REMARK R807 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J R918 HRFS472JBA R CHIP 1/16 4.7K OHM J 1608 R808 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J R919 HRFS472JBA R CHIP 1/16 4.7K OHM J 1608 R809 RD-4Z100J-...

  • Page 77: Inch & 20 Inch Different Partslist

    JTP 1240RHTCGR(JTP1240RHT+CAP) X503 5XJ14R31AE CRYSTAL QUARTZ HC-49/S 14.31818MHZ 30PPM SW711 5S50101012 SW TACT JTP 1240RHTCGR(JTP1240RHT+CAP) Z001 PVMPMSN667 PCB MAIN AS DQ-K2121N-P SW712 5S50101012 SW TACT JTP 1240RHTCGR(JTP1240RHT+CAP) Z0011 PVMPJ1N667 MAIN CHIP MOUNT A DQ-K2121N-P SW713 5S50101012 SW TACT JTP 1240RHTCGR(JTP1240RHT+CAP)
  • Page 78 DAEWOO ELECTRONICS Corp. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA...
