Summary of Contents for Sun Bicycles shortcut
- Page 1 Sun Shortcut Folding Bicycle Supplemental Owner’s Manual Revised 04-2017...
-
Page 2: Table Of Contents
Congratulations on the purchase of your new Sun folding bicycle. This supplemental manual provides complete instructions for the operation of the folding features for the Sun Shortcut series folding bicycles. Before riding your new bicycle please read this supplemental manual as well as the main Owner’s manual included with your new bicycle. -
Page 3: Models Covered In This Manual
SUN SHORTCUT SERIES FOLDING BICYCLES This manual covers folding and unfolding guidelines for the Sun Shortcut series folding bikes which include the Shortcut 1, Shortcut 3, and Shortcut 7 models. Shortcut 1 Shortcut 3 Shortcut 7 1-speed Internal 3-speed 7-speed... -
Page 4: Steps To Fold Your Bicycle
5 STEPS TO FOLD YOUR BICYCLE Page 4... -
Page 5: Steps To Fold Your Bicycle
5 STEPS TO FOLD YOUR BICYCLE Your bicycle can be easily folded for transport or storage by following these 5 simple steps. No tools are required for this process. 1. Fold Pedals - Fold each pedal by squeezing the inner release and then rotating the outer pedal platform down. -
Page 6: Fold And Unfold The Pedals
HOW TO FOLD AND UNFOLD THE PEDALS While riding the To unlock and fold the The outer pedal platform pedal is locked in the pedals simply insert 1-2 body will now fold 90 deg. horizontal position. fingers in the oval hole in either direction. -
Page 7: Raise And Lower The Seatpost
HOW TO RAISE AND LOWER THE SEAT POST Closed / locked To adjust seatpost height up Seatpost can now be quick-release or down swing the lever wide adjusted up or down. Do lever. open. Do not twist the lever. not raise above maximum If post moves while in closed height line marked on the position add tension to the... -
Page 8: Raise And Lower The Handlebar
HOW TO RAISE AND LOWER THE HANDLEBAR During use the quick- To adjust handlebar height Handlebar can now be release should be in the up or down swing the lever adjusted up or down. closed / locked wide open. Do not twist the Do not raise above max position. -
Page 9: Fold And Unfold The Stem
HOW TO OPEN AND CLOSE THE FOLDING STEM Slide the chrome quick- Swing quick-release lever With the connector hook release safety lock wide open to disengage disengaged you can upward. the connector hook. now fold the upper stem down to the left side of the bike. -
Page 10: Fold And Unfold The Frame
HOW TO OPEN AND CLOSE THE FOLDING FRAME Quick-release lever Rotate the quick-release Swing quick-release lever will not open when safety lock clock wise wide open. quick-release safety lock 90 deg. to reveal quick- is engaged. release lever safety post. Quick-release will not open when this is covered. - Page 11 HOW TO OPEN AND CLOSE THE FOLDING FRAME Connector hook will begin The connector hook Fold the front frame 180 to disengage from is now disengaged deg. towards the left side the frame as you swing and you can begin of the bike until the front the lever open.
-
Page 12: Warnings
WARNINGS SEATPOST • Never ride with the seatpost extended above the maximum height line. • Never ride with the seatpost inserted below the bottom level of the frame seat tube. HANDLEBAR • Never ride with the handlebar extended above the maximum height line. •... -
Page 13: Measurements
MEASUREMENTS 59” Saddle to Ground Minimum..34.0” Maximum...39.5” Saddle to Pedal Minimum..30.0” Maximum...35.5” Handlebar to Ground 43.5” Minimum..40.5” Maximum..43.5” Folded Dimensions Length...31.0” 27” Height..27.0” Width..13.3” Assembled Dimensions Length...59.0” Height..43.5” Width...22.3” 31” Page 13... -
Page 14: Width
Distributed by J&B Importers, Inc. 11925 SW 128th Street, Miami, FL 33186 Email: info@sun.bike | Web: sun.bike...
