Height adjustment, angle adjustment, rotation (long height/width)
Caution:
• Pressure from hands on the LCD panel could cause damage.
• Be careful not to allow your fingers to be pinched.
1) Height adjustment
Adjust to an easy to view height.
2) Angle adjustment
Adjust to an easy to view angle.
approx. 5
Approx. 60mm
approx. 30
approx. 45
approx. 45
LL-T2020 OUTLINE OF THE PRODUCT, NOMENCLATURE AND FUNCTION
3) Rotation (long height/width)
The display can be rotated for a long height or width to suit the dis-
played content.
• Before rotating, move the display to its uppermost position. If the dis-
play is rotated while it is set low, it will contact the stand and could
lead to damage.
• The display can only be rotated through a range of 90°. Applying
excessive force may cause malfunction.
• Do not apply excessive force when the cable is connected.
To set to long height
Gently turn in the clockwise direction (to 90°).
To set to long width
Gently turn in the counterclockwise direction (to 90°).
Note: The orientation of the display can be changed using Pivot Soft-
ware.
