Silver Cross Sleepover Instructions Manual

Sleepover body and bedside stand
Hide thumbs Also See for Sleepover:

Advertisement

Table of Contents

See also: Instruction Manual
Sleepover Deluxe
Body & Bedside Stand Instructions
Important: Keep for future reference
Please read these instructions carefully before using your new pram
Keep them in a safe place so that you may use them in the future

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sleepover and is the answer not in the manual?

Questions and answers

Related Manuals for Silver Cross Sleepover

Summary of Contents for Silver Cross Sleepover

  • Page 1 Sleepover Deluxe Body & Bedside Stand Instructions Important: Keep for future reference Please read these instructions carefully before using your new pram Keep them in a safe place so that you may use them in the future...

  • Page 2: Table Of Contents

    Although these instructions clearly outline the correct use of the Sleepover body and bedside stand they do not relate to your chosen chassis. Always read all instructions provided carefully and remember, the safety of your child is your responsibility.

  • Page 3: Box Contents

    A ........

  • Page 4: Operating The Harness

    2. operatInG tHe HarneSS To undo the harness press prongs and pull apart. The shoulder straps will then slide off the waist strap section To fasten the harness, first slide the shoulder strap clips onto the waist section. Then push the waist prongs into the central buckle.

  • Page 5: Operating The Bumper Bar

    3. operatInG tHe Bumper Bar To adjust your bumper bar press the release button on either side, located underneath the bar. Whilst pressing both buttons, pull the bumper towards the foot end of the body until you hear a click. Check that both side catches have locked.

  • Page 6: Operating The Footrest

    4. operatInG tHe footreSt To lower the footrest reach underneath the footrest and locate the release bar. Push this downwards and the footrest will lower Gently lower the footrest into the lower position. The footplate is also adjustable, so as your child grows the footplate can be stowed up under the fabric...

  • Page 7: Operating The Backrest Recline

    To adjust the seat place the palm of your hand on the hand rest and grip the release catch. Squeeze to release the catch either lift or lower. Remember when using the Sleepover in the overnight cot mode always ensure the backrest is lowered into the lowest position.

  • Page 8: Operating The Hood

    6. operatInG tHe HooD The Sleepover hood is multi positional and self tensioning in the upright position. Simply hold the front hood bar and gently lift or lower. The hood has a simple to operate vent. To open simply release the velcro pad, roll up and secure with the press stud and flap.

  • Page 9: Attaching The Body To The Stand / Chassis

    Lift the fabric flap on either side of the Sleepover body. Underneath you will discover the release handle. Always lift your Sleepover body from this point and not from any other point. Position the body so that the four locking catches on the base are directly over the top of the support bars on your stand or chassis.

  • Page 10: Detaching The Body From The Stand / Chassis

    8. DetacHInG tHe BoDy from tHe StanD / cHaSSIS Gently grip the inner release catch and slide the release hand towards the foot end of the body. Squeeze to release the body catches clear of the bars The body will now lift away from the stand/ chassis freely.

  • Page 11: Operating The Bedside Stand

    9. operatInG tHe BeDSIDe StanD The Bedside stand is for use only with the Sleepover body and with no other pram units, carrycots or Moses baskets provided by Silver Cross or any other manufacturer. Use only on a firm ground which is horizontal, level and dry.
  • Page 12 To lock the stand align the locking clip with the pin. When both sides are lined up push the clips down so that they lock. Now double check the stand is locked at both sides by lifting the top support. Always ensure the stand is only used on a stable, even floor.

  • Page 13: Preparation For Use As A Pram

    . Important Safety notIce! Only the mattress supplied with your Sleepover is to be used. Do not use any other mattress with this product. Replacement or spare mattress can only be purchased through Silver Cross, approved...
  • Page 14 A bootend apron is supplied with your Sleepover Deluxe this can be positioned over the foot end of your body unit, and held in place with the velcro tabs. Once in position use the zip to fully secure the bootend to the pram liner .
  • Page 15 10. preparatIon for uSe aS a pram (contInueD) To fully attach your hood, there are two press studs on the underside of the rear panel which attach to the head end of the Sleepover body. Slide the Sleepover apron onto the body unit.
  • Page 16 Your Sleepover body has a ventilation system located on the under side of the body. To locate open the fabric cover, and roll this away. The ventilation disc is now exposed. The level of ventilation can be adjusted by opening or closing the vent to the desired aperture required.

  • Page 17: Preparation For Use As An Overnight Cot

    11. preparatIon for uSe aS an overnIGHt cot To prepare your Sleepover body for use as an overnight cot, ensure the backrest recline is in its lowest position, extend the bumper bar and lift the foot rest, Finally attach the body unit to your bedside stand.
  • Page 18 Lift the velcro flaps on the Moses valance to allow access to fit the hood. The rear of the Moses hood can be held in position with a velcro strip Your overnight cot is now ready for use. Note : For packaging and transportation purposes your Moses valance is supplied with tempoary stitching on each of the pleats, these can be carefully removed by cutting with...

  • Page 19: Preparation For Use As A Pushchair

    12. preparatIon for uSe aS a puSHcHaIr To prepare your Sleepover body for use as a pushchair, attach the body unit to your chosen Classic / Linear chassis or bedside stand and follow the instructions below. Retract the bumper bar to its shortest position.
  • Page 20 For further information please read section 5 “Adjusting your backrest”. Adjust harness accordingly for your child. The Sleepover Deluxe is supplied with a cosy toes for optional use in pushchair mode. When using the cosy toes use the appropriate button holes to slide through the harness webbing.

  • Page 21: Fitting Your Rain Cover

    13. fIttInG your raIn cover The Sleepover Deluxe is supplied with a rain cover. Ensure the cover is fitted properly by aligning the zip with the hood peak, as illustrated. Gently pull the elasticated edge over all fabric portions of your sleepover and secure in...
  • Page 22 As with the Cot set-up, the rain cover can just as easily be used in pram set-up. Ensure the cover is fitted properly by aligning the zip with the hood peak. If using the rain cover in pushchair mode be sure to pull the rain cover over the footrest and secure in position with the velcro straps The zip around the hood allows easy access...

  • Page 23: Important Information

    Maximum weight of child: 9kg When using the sleepover as a carry cot with a mattress the depth from the top of the mattress to the top side of the body at, or at any position within 300mm from the harness attachment points, should not be reduced to less than 170mm when the mattress is in position.
  • Page 24 Filling material(s) and covering fabric(s) meet the requirements for resistance to cigarette and match ignition in the 1988 safety regulations. CARELESSNESS CAUSES FIRE Silver Cross (UK) Ltd Micklethorn Broughton Skipton North Yorkshire BD23 3JA Telephone: 01756 702412 Website: www.silvercross.co.uk...
