Gembird 3DP-i3V2-01 Getting Started Manual

3D Printer
GETTING
STARTED
GUIDE
Congratulations on your purchase of the 3DP-i3V2-01 3D Printer. You're now just moments away from printing your
first 3D model. It's important that you follow these steps carefully to ensure correct setup of your 3D Printer.
Package Contents:
1 x 3DP-i3V2-01 3D Printer (Control Box,
Extruder Tower, Heated Print Bed)
1 x Filament Spool Holder
1 x Filament Spool Stand
1 x Power Cable
1 x USB Cable
1 x 4GB MicroSD Card
1 x Scraper
1 x PTFE Tube
CONSTRUCT AND CONNECT
1 x Hex Key Set
6 x Hex Bolts
2 x Cable Ties
1 x 10m PLA Filament
2 x Print Bed Mats
1 x Instruction manual
1 x Getting Started Guide
1 x Warranty Card
Place the Control Box,
Extruder Tower and Heated
Print Bed on a clean, level
work space. Carefully remove
the cable tie that holds the
extruder in place.
NOTE: Do not pull on the
black cable guides
NOTE: Ensure workspace is at
least 1m x 1m
3DP-i3V2-01 - 3D printer for ABS/PLA filament
Insert the Heated Print Bed
lengthways through the
Extruder Tower and line up
the bolt holes. Insert the two
external bolts and tighten
using the Hex Wrench. Place
printer on its side, then insert
and tighten the two internal
bolts.
TIP: Raise the extruder and
angle the bed for easier
inserting through the Extruder
Tower
