Summary of Contents for Gembird 3D Printer Filament Dryer Box
- Page 1 3 D P r i n t e r F i l a m e n t D r y e r B o x User Guide...
- Page 3 Contents...
- Page 4 Size...
- Page 5 Size Package Size 268（L）*145（W）*272（H）mm Product Size 228（L）*125（W）*242（H）mm Max Capacity 200*73（H）mm Product Weight 850g Rated Power AC100-240V~50/60Hz Power Output DC24V~2A Power of Heater Filament Diameter 1.75mm/2.85mm/3.0mm...
-
Page 6: Button Introduction
Button Introduction... - Page 7 Four Buttons The product has four buttons, the open button the function button the up button the down button Press to switch modes and the to change the parameters The system will be in dormancy after no-operation for 5 seconds, the backlight disappears in dormant state, press any button to wake up, and then press button to set parameters or shut down ...
-
Page 8: Method Of Use
Method of use... - Page 9 Plug the Adapter into the AC100-240V ~50/60Hz power supply and plug the output terminal into the interface in the tail of box. Press the button to turn on, and enter the standby mode after turning on, the LCD displays 0000 ...
- Page 10 Level Set for Temperature&Humidity Reference Table...
- Page 11 Level Set for Temperature&Humidity Reference Table Type of filament PLA/PLA+ ABS/ABS+/PETG PVA/Nylon/PC Level Level Set for Temperature&Humidity Reference Table Level Hot plate TEMP 80℃ 85℃ 90℃ Inside TEMP 50-55℃ 55-60℃ 60-68℃ Inside humidity 15-20% 10-15% 5-8% NOTE: Above parameters in the table are testing under 20 ℃ of temperature and 62% of humidity in the room.
