Configuring Private VLANs
The following example shows how to add VLANs to the list of allowed VLANs on an Ethernet PVLAN trunk
port:
switch# configure terminal
switch(config)# interface ethernet 1/3
switch(config-if)# switchport
switch(config-if)# switchport private-vlan trunk allowed vlan 15-20

Configuring Native 802.1Q VLANs on Private VLANs

Typically, you configure 802.1Q trunks with a native VLAN ID, which strips tagging from all packets on that
VLAN. This configuration allows untagged traffic and control traffic to transit the . Secondary VLANs cannot
be configured with a native VLAN ID on promiscuous trunk ports. Primary VLANs cannot be configured
with a native VLAN ID on isolated trunk ports.
A trunk can carry the traffic of multiple VLANs. Traffic that belongs to the native VLAN is not encapsulated
Note
to transit the trunk. Traffic for other VLANs is encapsulated with tags that identify the VLAN that the
traffic belongs to.
Before You Begin
Ensure that the PVLAN feature is enabled.
Procedure
Step 1
Step 2
Step 3
Step 4
Step 5
Command or Action
Command or Action
switch# configure terminal
switch(config)# interface type
[chassis/]slot/port
switch(config-if)# switchport
switch(config-if)# switchport
private-vlan trunk native {vlan
vlan-id}
switch(config-if)# no switchport
private-vlan trunk native {vlan
vlan-id}
Cisco Nexus 6000 Series NX-OS Layer 2 Switching Configuration Guide, Release 7.x
Configuring Native 802.1Q VLANs on Private VLANs
Purpose
Purpose
Enters global configuration mode.
Selects the port to configure as a PVLAN host port.
This port can be on a FEX (identified by the chassis
option).
Note If this is a 10G breakout port, the slot/port
syntax is QSFP-module/port.
Configures the interface as a Layer 2 interface and
deletes any configuration specific to Layer 3 on this
interface.
Sets the native VLAN ID for the PVLAN trunk. The
default is VLAN 1.
(Optional)
Removes the native VLAN ID from the PVLAN trunk.
