EOS 34.GM User Manual And Assembly Instructions

Advertisement

Assembly instruction and user's manual
34.GM
G 18 = 18 kW
width=75 cm
G 27 = 27 kW
G 36 = 36 kW
width=100 cm
GB
IP x4
Druck Nr. 29342877en / 44.06
1
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 34.GM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EOS 34.GM

  • Page 1 Assembly instruction and user’s manual 34.GM G 18 = 18 kW width=75 cm G 27 = 27 kW G 36 = 36 kW width=100 cm IP x4 Druck Nr. 29342877en / 44.06...
  • Page 2 Every sauna cabin must have a fresh-air inlet and l To be used with all EOS sauna control units suitable an exhaust outlet. All ventilation inlets/outlets must for additional power control units.
  • Page 3: General Instructions

    General instructions Sauna stones Please note that optimum sauna climate conditions Sauna stones are natural materials. Check your sauna can be achieved only if the cabin ventilation (fresh air stones at regular intervals, since they are susceptible and exhaust) system, the sauna heater and the control to the effects of strong steam-water additives and may unit are designed and set to work efficiently in decompose over a long period of time.
  • Page 4 Wiring diagram for 12-27 kW sauna stove with load distribution to control unit and power control unit Power control unit LSG 18 90 7372 00 Sauna heater up to 27 kW safety contactor safety contactor Sauna control unit max. 18 kW max.
  • Page 5 Terminal connection Information diagrams Sauna heaters and leakage current Instructions Leakage current For the installation of sauna heaters, please pay attention to the DIN VDE 0100 part 703 ! This standard makes the following statement valid in your newest expenditure, since February 2006, paragraph 703.412.05;...
  • Page 6 In such cases, there can be no direct contact with our service centre about the guarantee. Date of first operation: Stamp and signature of the authorised electrician: Service address: EOS-Werke Günther GmbH Adolf-Weiß-Straße 43 35759 Driedorf, Germany Tel. +49 (0)2775 82-240 Fax+49 (0)2775 82-455 servicecenter@eos-werke.de...
