- Page 1 Junkkari CHIPPERS OPERATING INSTRUCTIONS SPARE PARTS LIST 62375 YLIHÄRMÄ FINLAND TEL. +358-(0)6-4835111 +358-(0)6-4846401...
-
Page 2: Table Of Contents
1 CONTENTS PAGE FOREWORD THE SIGN OF CAUTION TECHNICAL SPECIFICATIONS SAFETY PRECAUTIONS GENERAL SAFETY TRANSPORT AND SITE-CHANGING MAINTENANCE AND REPAIRS HYDRAULIC SYSTEM LOCATION OF SAFETY DECALS AND COMPONENTS, SERIAL NUMBER PLATE OPERATING ENVIRONMENT OBJECT OF USAGE APPLICATIONS LIMITATIONS OF USE AND PROHIBITED USES PRINCIPLE OF OPERATION TRANSPORTATION, HANDLING AND... -
Page 3: Foreword
The symbol is also used to denote any risk of danger which might befall environment or property. 3 TECHNICAL SPECIFICATONS Machine type HJ 5 M HJ 5 G Cutter flange dia. 25" (63cm) 25" (63cm) -
Page 4: Safety Precautions
5.Check the condition of the machine always at the end of a working shift. Pay special attention to the mounting and attachment points. RUN DOWN TIME Junkkari HJ 5 run down time is - loaded 10 seconds - without load 40 seconds. -
Page 5: Maintenance And Repairs
5.The manoeuvrability of the tractor during any transportation and its steering or braking characteristics may be affected adversely by trailed or hitchmounted i mplements or extra weights. It is therefore imperative to ensure that the tractor can be properly steered and braked down under all circumstances. 6.It is forbidden to carry passangers on top of a moving chipper. - Page 6 5. SAFETY DECALS AND COMPONENTS AND SERIAL NUMBER PLATE LIFTING BRACKET 4-32173 SERIAL NUMBER PLATE 1. Manufacturing year within the EC 2. Machine model 3. Serial number and year model 4. Nominal weight without accessories 5. Name of the CE plate installer 6 2 3 7 5 Y L I H Ä...
- Page 7 ÄLÄ AVAA SUOJIA KONEEN KÄYDESSÄ! ÖPPNA EJ SKYDD NÄR MASKINEN ÄR I GÅNG! DON'T OPEN THE COVER WHEN THE MACHINE IS RUNNING! VAROITUS ! VARO liikkuvia osia ! PYSÄYTÄ kone ryhtyessäsi huolto- tai korjaustyöhön PIDÄ lapset poissa koneen luota VARNING! VARNING för rörliga delar! STANNA maskinen vid service- eller reparationsarbeten! HÅLL barnen borta från maskinen!
-
Page 8: Operating Environment
6. OPERATING ENVIRONMENT OBJECT OF USAGE The purpose of a chipper is to produce chips from trees, which due to their diameter and other measurements are suitable for feeding into the chipper's feed orifice. The in-fed material must be clean. Dust, sand or soil ingredients accelerate wear on the knives very quickly. Metal bits, nails e.g., cause denting of the knives. -
Page 9: Transportation, Handling And Storage
8 TRANSPORTATION, HANDLING AND STORAGE (DISTRIBUTOR/DEALER) TRANSPORTATION Terms of delivery is free at the factory gate unless other terms are mutually agreed upon. The Distributor shall agree with the Manufacturer on the date upon which the product in question is ready for delivery at the factory. The Manufacturer shall take care of the loading of the product onto the goods vehicle ranged to fetch the product. -
Page 10: Taking A New Machine Into Use
"PTO SHAFT". HYDRAULIC SYSTEM The chipper models HJ 5 M do not require HFS use of tractor hydraulic system as the model has no actual feeder mechanism. The HJ 5G model requires, hydraulic oil from the tractors hydraulic system 1.3 - 4 gal./min (5 - 15 L/min) and a single control valve, fitted with single pressure and return connectors for its operation. -
Page 11: Pto Shaft
9.4 PTO SHAFT TYPE OF PTO SHAFT The universal drive shaft should have the capacity of trans-mitting power at a rate of 50 kW at a nominal speed of 540 rpm and to sustain a torque of 900Nm. The shaft should be fitted with an overload clutch. -
Page 12: Adjustments
10 ADJUSTMENTS PLEASE READ THESE INSTRUCTIONS VERY CAREFULLY AS THE MOST IMPORTANT POINT IN THE OPERATION OF THE CHIPPER IS THE CONDITION OF THE KNIVES AND THEIR CORRECT ADJUSTMENT. 10.1 ADJUSTMENT OF KNIFE SETTINGS The knife setting may be adjusted within the range of 5 to 18 mm. The smaller the setting, the smaller the chips the chipper produces. -
Page 13: Operating
10.2 FEED RATE ADJUSTMENT The rotational speed of the feed rollers in chipper models HJ 5 SLT and HJ 5 SL must be synchronized with the cutting speed of the cutting knives. If the feed roller rpm is too high in relation to the knife cutting speed, the roller tend to dig into the stems being fed in. -
Page 14: Maintenance
In the main, the bed knives should remain maintenance-free. CUTTING KNIFE DISC SAFETY LOCK All JUNKKARI-chippers are fitted with a safety lock for securing the cutting flange immobile while carrying out any maintenance work on the cutting knives. -
Page 15: Fault Finding Chart
13. FAULT FINDING CHART FAULT CAUSE REMEDY The chipper does not draw Dull knives Sharpen and refit in material Knife cutting as per instructions angle faulty given in the manual Knife fitted the wrong way round Uneven chip size Knife gap ('B') Adjust as per too large instructions given... -
Page 16: Terms Of Warranty
14 TERMS OF WARRANTY TERMS OF WARRANTY: 1.The manufacturer warrants the product for a period of 12 (twelve) months in agricultural use and used in the purpose to which the product is intended. 2.In communal, industrial, contract work or equivalent the warranty period is 6 (six) months.
