Philips BDP3010/F8 Service Manual

Hide thumbs Also See for BDP3010/F8:
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
BLU-RAY DISC PLAYER
BDP3010/F8 / BDP3010/F8 C

Advertisement

Table of Contents
loading

Related Manuals for Philips BDP3010/F8

Summary of Contents for Philips BDP3010/F8

  • Page 1 SERVICE MANUAL BLU-RAY DISC PLAYER BDP3010/F8 / BDP3010/F8 C...

  • Page 2: Table Of Contents

    IMPORTANT SAFETY NOTICE Proper service and repair is important to the safe, reliable operation of all P&F Equipment. The service procedures recommended by P&F and described in this service manual are effective methods of performing service operations. Some of these service special tools should be used when and as recommended.

  • Page 3: Specifications

    SPECIFICATIONS 1-1-1 E5P32SP...

  • Page 4: Laser Beam Safety Precautions

    LASER BEAM SAFETY PRECAUTIONS This BD player uses a pickup that emits a laser beam. Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin. The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30 cm away from the pickup lens when the diode is turned on.

  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Product Safety Notice Also check areas surrounding repaired locations. J. Be careful that foreign objects (screws, solder Some electrical and mechanical parts have special droplets, etc.) do not remain inside the set. safety-related characteristics which are often not K.
  • Page 6 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts, and wires have been returned to their original positions. Afterwards, do the following tests and confirm the specified values to verify compliance with safety standards. 1.

  • Page 7: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING Circuit Board Indications Pb (Lead) Free Solder 1. The output pin of the 3 pin Regulator ICs is When soldering, be sure to use the Pb free solder. indicated as shown. How to Remove / Install Flat Pack-IC Top View Bottom View 1.
  • Page 8 3. The flat pack-IC on the CBA is affixed with glue, so With Soldering Iron: be careful not to break or damage the foil of each 1. Using desoldering braid, remove the solder from pin or the solder lands under the IC when all pins of the flat pack-IC.
  • Page 9 With Iron Wire: 2. Installation 1. Using desoldering braid, remove the solder from 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder the foil of each pin of the flat pack-IC on the CBA flux which is applied to all pins of the flat pack-IC, so you can install a replacement flat pack-IC more you can remove it easily.
  • Page 10 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.

  • Page 11: Cabinet Disassembly Instructions

    CABINET DISASSEMBLY INSTRUCTIONS 1. Disassembly Flowchart Note: (1) Identification (location) No. of parts in the figures This flowchart indicates the disassembly steps to gain (2) Name of the part access to item(s) to be serviced. When reassembling, (3) Figure Number for reference follow the steps in reverse order.
  • Page 12 (S-6) [5] *BD Main CBA & BD Mechanism Assembly CN7101 (S-5) (L-1) CN6101 (L-3) CN6000 (S-7) [6] Main PCB [3] Front CBA Bracket (L-1) (L-2) [2] Front Assembly Fig. D2 * See Reference Notes 2. Fig. D4 [4] Rear Panel (S-8) (S-1) (S-2)
  • Page 13 3. How to Eject Manually 1. Remove the Top Cover , Front Assembly and BD Main CBA & BD Mechanism Assembly. 2. Slide the portion A in the direction of the arrow. 3. Pull the tray out manually and remove a disc. Portion A 1-5-3 E5P31DC...

  • Page 14: How To Initialize The Blu-Ray Disc Player

    HOW TO INITIALIZE THE BLU-RAY DISC PLAYER To put the program back at the factory-default, initialize the BD player as the following procedure. 1. Turn the power on. 2. Remove the disc on the tray and close the tray. 3. Press [1], [2], [3], [4], and [INFO] buttons on the remote control unit in that order.

  • Page 15: Firmware Renewal Mode

    FIRMWARE RENEWAL MODE Note: The file extension of the available firmware is The appearance shown in (*1) of Fig. c is “b30”. described as follows: 1. Turn the power on and remove the disc on the tray Appearance State and close the tray. Now Loading...
  • Page 16 How to Verify the Firmware Version 1. Turn the power on. 2. Remove the disc on the tray and close the tray. 3. Press [1], [2], [3], [4], and [INFO] buttons on the remote control unit in that order. Fig. h appears on the screen. "...
  • Page 17 FIRMWARE RENEWAL MODE (for User) 1. Press [ ] button to display Setup menu. 6. Firmware loading starts. Fig. f will appear on the screen and Fig. g appears on the VFD. 2. Select to Settings - Advanced Setup - Others - Software Upgrade.

  • Page 18: Troubleshooting

    TROUBLESHOOTING FLOW CHART NO.1 The power cannot be turned on. See FLOW CHART No.2 <The fuse blows out.> Is the fuse normal? Is normal state restored when once unplugged Check if there is any leak or short-circuiting on the power cord is plugged again after several seconds? primary circuit component, and service it if defective.
  • Page 19 FLOW CHART NO.6 P-ON+13V is not outputted. Is 13V voltage supplied to the emitter of Q2603? Check D1023, D1018, C1024, L1003 and their periphery circuit, and service it if defective. Check Q2601, D2601 and PWSW4 line and service Is the voltage of base on Q2603 lower than the it if defective.
  • Page 20 FLOW CHART NO.10 P-ON+1.2V is not outputted. Is 5V voltage supplied to Pin(2) of IC2601? Check D1013, D1014, C1019, C1025 and the periphery circuit, and service it if defective. Is the "H" signal inputted to the Pin(7) of IC2601? Replace IC2000. Replace IC2601.
  • Page 21 FLOW CHART NO.14 The fluorescent display tube does not light up. Is 5V voltage supplied to Pin(13, 43) of IC6001? Check the P-ON+5V line and service it if defective. Check the -FL line and service it if defective. Is approximately -24V to -28V voltage supplied to Pin(30) of IC6001? Is there approximately 500kHz oscillation to Check R6007, IC6001 and their periphery, and...
  • Page 22 FLOW CHART NO.17 The disc tray cannot be opened and closed. (It can be done using the remote control unit.) Replace the "OPEN/CLOSE" switch (SW6004). Is the normal control voltage inputted to Pin(30) of IC2000? Refer to "FLOW CHART NO.15" <The key operation is not functioning.>...
  • Page 23 FLOW CHART NO.20 Audio is not outputted normally. Set the disc on the disc tray, and playback. Replace the BD Main CBA & BD Mechanism Are the analog audio signals outputted to each pin Assembly. of CN2200? CN2200 16PIN AUDIO(L) CN2200 18PIN AUDIO(R) Are the analog audio signals inputted to each pin Check each line between each pin of CN2200...

  • Page 24: Block Diagrams

    BLOCK DIAGRAMS System Control Block Diagram 1-9-1 E5P32BLS...
  • Page 25 Digital Signal Process 1 Block Diagram 1-9-2 E5P32BLD1...
  • Page 26 Digital Signal Process 2 Block Diagram 1-9-3 E5P32BLD2...
  • Page 27 Video Block Diagram TMDS SERIALIZER TMDS ENCODER HDCP CIPHER/ ENCRYPTOR CONTROLLER AUDIO 1-9-4 E5P32BLV...
  • Page 28 Audio Block Diagram 1-9-5 E5P32BLA...
  • Page 29 Power Supply Block Diagram 1-9-6 E5P32BLP...

  • Page 30: Schematic Diagrams / Cba And Test Points

    SCHEMATIC DIAGRAMS / CBA AND TEST POINTS Standard Notes WARNING Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
  • Page 31 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQES D'INCELE N'UTILISER QUE DES FUSIBLE DE MÊME TYPE. RISK OF FIRE-REPLACE FUSE AS MARKED.
  • Page 32 AV 1/3 Schematic Diagram CAUTION ! CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. NOTE: For continued protection against fire hazard, If Main Fuse (F1001) is blown , check to see that all components in the power supply replace only with the same type fuse.
  • Page 33 AV 2/3 Schematic Diagram *1 NOTE These components (IC2001, IC2002, R5008) can be used in any models. However, you cannot mix components under Group A with the ones under Group B. You can choose either Group. The difference between Group A and Group B is shown below. Group A Group B IC2001...
  • Page 34 AV 3/3 Schematic Diagram E5P32SCAV3 1-10-5...
  • Page 35 Front Schematic Diagram FL6001 MATRIX CHART E5P32SCF 1-10-6...
  • Page 36 BD Main 1/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD1 1-10-7...
  • Page 37 BD Main 2/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD2 1-10-8...
  • Page 38 BD Main 3/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD3 1-10-9...
  • Page 39 BD Main 4/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD4 1-10-10...
  • Page 40 BD Main 5/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD5 1-10-11...
  • Page 41 BD Main 6/11 Schematic Diagram 1 NOTE: 2 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. Either IC6701 or IC6703 is used for BD MAIN CBA. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD6 1-10-12...
  • Page 42 BD Main 7/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD7 1-10-13...
  • Page 43 BD Main 8/11 Schematic Diagram E5P32SCBD8 1-10-14...
  • Page 44 BD Main 9/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD9 1-10-15...
  • Page 45 BD Main 10/11 Schematic Diagram E5P32SCBD10 1-10-16...
  • Page 46 BD Main 11/11 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC6001. IC6001 is divided into nine and shown as IC6001 (1/9) ~ IC6001 (9/9) in this BD Main Schematic Diagram Section. E5P32SCBD11 1-10-17...
  • Page 47 AV CBA Top View Because a hot chassis ground is present in the power CAUTION ! supply circut, an isolation transformer must be used. CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. Also, in order to have the ability to increase the input For continued protection against fire hazard, If Main Fuse (F1001) is blown , check to see that all components in the power supply...
  • Page 48 AV CBA Bottom View CAUTION ! PIN 9 OF PIN 16 OF PIN 24 OF PIN 7 OF CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. CN2200 CN2200 CN2200 CN2200 If Main Fuse (F1001) is blown , check to see that all components in the power supply For continued protection against fire hazard, replace only with the same type fuse.
  • Page 49 Front CBA Top View Front CBA Bottom View BE5P00F01012-B 1-10-20...

  • Page 50: Waveforms

    WAVEFORMS Pin 7 of CN2200 Pin 16 of CN2200 VIDEO-Pr/Cr VIDEO-Pr/Cr 0.2V 10µs AUDIO(L) AUDIO(L) 0.5ms 0.5ms Pin 9 of CN2200 Pin 24 of CN2200 SPDIF SPDIF 0.1µs VIDEO-Pb/Cb VIDEO-Pb/Cb 0.2V 10µs C2303 PLUS LEAD VIDEO-CVBS VIDEO-CVBS 0.5V 20µs NOTE: Input Signal (DVD) VIDEO: 75% COLOR BAR AUDIO: 1KHz, 0dB...

  • Page 51: Wiring Diagram

    WIRING DIAGRAM EXPA(-) EXPB(-) EXPA(+) EXPB(+) SA-INT PI-CONT P-ON+1.8V BDRF(+) P-ON+1.8V BDRF(-) P-ON+1.8V P-ON+5V(1) RF(+) RF(-) P-ON+5V(NU) P-ON+1.2V P-ON+10.5V P-ON+1.2V P-ON+10.5V VC-PD P-ON+1.2V P-ON+3.3V +3.3V P-ON+3.3V SDDAT1 P-ON+5V(2) SDDAT0 THERMO BD-LD SCLK2 SDDAT2 SEN-LDD FAN-VCC CD-LD SDATA2 FAN-GND SDDAT3 XRESET PD-LD SDCLK LDEN...

  • Page 52: System Control Timing Charts

    SYSTEM CONTROL TIMING CHARTS Power on Hand close [ Tray Close ] [ Tray Open ] SLED moves Start Start Start Start SLED position Hand close Tray close SLED inner initialization detection around moves SLED position Pick-up position Tray open initialization moves [ Tray Open ]...
  • Page 53 Parameter V*: Voltage T*: Event timer V0: 1.5 V T1: 0.3 s V1: 6.8 V T3: 0.4 s V2: 3.5 V T4: 2.0 s V3: -3.5 V T5: 0.2 s V4: -2.5 V T6: 3.0 s V5: -6.8 V T7: 3.0 s V6: 0.8 V T8: 2.0 s V7: -4.0 V...

  • Page 54: Ic Pin Function Descriptions

    IC PIN FUNCTION DESCRIPTIONS IC2000 (SUB MICRO CONTROLLER) Signal Function Name Signal Function 34 OUT VFD-STB VFD Serial Interface Strove Name 35 OUT VFD-CLK VFD Serial Clock IN VCC +3.3V Power Supply 36 OUT VFD-DAT VFD Serial Data IN VREF +3.3V Power Supply 37 OUT FL-SW FL On/Off Control Signal...

  • Page 55: Lead Identifications

    LEAD IDENTIFICATIONS SL431A-AT 2SA1980M Y 2SA1981Y-AT 2SA1980MG-AT 2SC5344 Y 2SC5343MG-AT STB1277LY-AT E C B R A K E C B 2SA1980SFY 2SC5343SFG SRA2205SF BD9321EFJ-E2 SRC1203MAT FA5573N-D1-TE1 PS2561A-1(W) PST8229NR PST8229UR 1: Anode 2: Cathode 3: Emitter 4: Collector 1 2 3 M38588GC-112FP BH76071FJ-E2 UTC4580TE...

  • Page 56: Exploded Views

    EXPLODED VIEWS Cabinet 2L082 2L082 2L085 2L082 BD Main CBA & BD Mechanism Assembly 2L049 2L034 2L081 2L034 2L070 2L034 2L083 2L071 AC1001 AV CBA 2L034 FM1001 F1001 Front CBA See Electrical Parts List for parts with this mark. Some Ref. Numbers are not in sequence.
  • Page 57 Packing Lower Side Upper Side X2-A S1-A S1-B Some Ref. Numbers are not in sequence. 1-16-2 E5P32PEX...
  • Page 58 BDP3010/F8 / F8 C(E5P32MD/E5P33MD) BDP3010/F8 / F8 C(E5P32MD/E5P33MD) 20090810 C1008! ELECTROLYTIC CAPACITOR ZR200TA151K16DB CA2D151DYG03 BDP3010/F8 / BDP3010/F8 C(E5P32MD/E5P33MD) C1009 ELECTROLYTIC CAP. 47UF/35V/M CEE47RENW016 C1010 METALIZED FILM CAP. 0.0022UF/400V K CT2H222DT034 Mark Models C1013 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V CHD1JK30B103...
  • Page 59 BDP3010/F8 / F8 C(E5P32MD/E5P33MD) BDP3010/F8 / F8 C(E5P32MD/E5P33MD) C2613 ELECTROLYTIC CAP. 220UF/6.3V/M/H7 CEA221ENW025 D2609 DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F C2614 CHIP CERAMIC CAP.(1608) B K 0.33UF/10V CHD1AK30B334 D2610 DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F C2615 ELECTROLYTIC CAP. 100UF/6.3V/M CEA101ENW016 D2612 DIODE SWITCHING 1N4148-F0021...
  • Page 60 BDP3010/F8 / F8 C(E5P32MD/E5P33MD) BDP3010/F8 / F8 C(E5P32MD/E5P33MD) Q2608 PNP TRANSISTOR 2SA1980MG-AT NQSG2SA1980M R2042 CHIP RES. 1/10W J 10K OHM RRXAJR5Z0103 Q2609 NPN TRANSISTOR SMD 2SC5343SFG NQ1G2SC5343S R2043 CHIP RES. 1/10W J 10K OHM RRXAJR5Z0103 Q2619 NPN TRANSISTOR SMD 2SC5343SFG...
  • Page 61 BDP3010/F8 / F8 C(E5P32MD/E5P33MD) BDP3010/F8 / F8 C(E5P32MD/E5P33MD) R2607 CHIP RES. 1/10W J 4.7K OHM RRXAJR5Z0472 R6006 WIRE CP STP-S-0.60 XZ40F0REN002 R2608 CHIP RES. 1/10W J 4.7K OHM RRXAJR5Z0472 R6007 CHIP RES. 1/10W J 68K OHM RRXAJB5Z0683 R2609 CHIP RES. 1/10W J 4.7K OHM...
  • Page 62 Misuse of any trademarks or any other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights to the fullest extent of the law. BDP3010/F8 / BDP3010/F8 C E5P32/33MD 2009-09-17...
  • Page 63 SUPPLEMENT SERVICE MANUAL This service manual shows only the differences between the model BDP3010/F7 and the original model BDP3010/F7 C. All other information is described in the service manual of the original model BDP3010/F7 C. BLU-RAY DISC PLAYER BDP3010/F7...
  • Page 64 Different parts from the original model BDP3010/F7 C Ref. No. Description Part No. MECHANICAL PARTS Not used Not used BAR CODE LABEL E5P30UD ---------- MODEL NO LABEL E5P30UD ---------- ELECTRICAL PARTS BD MAIN CBA & BD MECHANISM ASSEMBLY N77P0CUN © 2009 Funai Electric Co., Ltd. All rights reserved.
