  • Page 1 9.7” LED Monitor Manual inM497-1...

  • Page 2: Introduction And Package Contents

    Introduction and Package Contents Introduction Congratulations on your purchase. You can expect only the sharpest and most brilliant color images from this monitor. Featuring easy to use OSD controls and built in speakers, you will find this monitor both easy to use and a pleasure to view. Package Contents •...

  • Page 3: Specifications

    Specifications Model inM497-1 General Diagonal size 9.7" Panel type TFT LCD Aspect ratio Number of pixels 1024 x 768 Pixel pitch 0.192 x 0.192 mm Color depth 262K Colors Backlight Optical (typ.) Brightness 400 cd/m2 Contrast ratio 1000:1 Response time...
  • Page 4 VGA Timing Item Resolution H Freq.(kHz) V Freq.(Hz) Note 640x400@70 31.460 70.080 640x480@60 31.469 59.940 640x480@72 37.861 72.809 640x480@75 37.500 75.000 720x400@70 31.460 70.080 800x600@56 35.156 56.250 800x600@60 37.879 60.317 800x600@72 48.077 72.188 800x600@75 46.875 75.000 1024x768@60 48.363 60.004 1024x768@70 56.476 70.069 Note:...

  • Page 5: Monitor And Osd Control

    Monitor and OSD Control Monitor and OSD Control The LED color monitor has a simple control layout for controlling the monitor and OSD (On Screen Display) functions. The table below summarizes the control keys and their related functions. 6-Key feature Keys Function Description To turn the power ON or OFF.
  • Page 6 Select Use the keys to advance to the proper selection and press keys button to confirm the setting. － OR ＋ Note: The message will be displayed on the screen if there’s no VGA signal detected in VGA mode, and the power will be off automatically after 10 seconds.

  • Page 7: Osd Control Function List

    OSD Control Function List PICTURE Mode 1.Picture Mode Press - OR + to select the picture mode “User, Normal, Vivid, User, Movie” 2. Color Temp. Press - OR + to adjust the color tones. “ User, Cool , Warm , Normal “ 3.

  • Page 8: Option Mode

    OPTION Mode Press - OR +( Left，Right),Select(Up，Down) to select language. 1. Language 2.Key Lock Press - OR + to adjust Key Lock. “ Off , On”.( Key unlocking method, pressing the Select button for 5 to 10 seconds after seeing flashing lights completed.) 3.OSD_Reset Press - OR + to adjust OSD_Reset.
  • Page 9 USB Mode (Button operation) 1. Access to multimedia, Press – (left) or + (right) and Menu key (confirm) to choose – photo, music , movie and text function. To press menu key to execute USB data “ FAT32” Going back to upper level , Press the – (left) or + (right) to move to Return , and then press menu key.
  • Page 10 3. Under auto display photos function, to press menu to show the operation menu. To press “ Power “ key to release the Auto display photos function USB multimedia player to meet the following format (MEPG、JPEG、PNG、FLV、DAT、AVI、MKV、MP3、RMVB、MP4、BMP、VOB)

  • Page 11: Accessory Option / Carry Bag And Battery

    Accessory Option / Carry Bag and Battery Charging the Battery Pack 1. Plug charging adaptor into the battery pack then plug the adaptor into a 110 Volt AC socket. 2. Flip the switch on the battery to the on position a.
  • Page 12 Dimensions...
  • Page 13 Caring for Your LED Monitor Caring for your LED Monitor The LED color monitor is a sensitive piece of electronic equipment. Proper care can prevent accidentally damaging the LED panel or the monitor itself. By following these guidelines you can ensure many years of trouble free use. 4.

  • Page 14: Frequently Asked Questions

    Frequently Asked Questions Power button does not respond • Check the power cord to ensure that it is securely plugged into the monitor base and also into the electrical outlet. • Ensure there is electrical power coming from the AC outlet. Use another device to check for power.

  • Page 15: Regulations And Maintenance

    Regulations and Maintenance FCC compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 16 ＊ Plugs Do not remove any of the prongs of the monitor’s three-pronged power plug. Disconnect the power plug from the AC outlet under following conditions: ◎ If you will not use it for an indefinite period time. ◎ When the power cord or plug is damaged or frayed. ◎...
