Orion OLW-4651 User Manual

Hybrid video system

Advertisement

A revolutionary MLCD
Hybrid Video System
A revolutionary MLCD
Hybrid Video System
ORION CO.,LTD.
www.oriondisplay.net
Address: 217, 1gongdan-ro, Gumi-si, Gyeongsangbuk-do, Korea
Tel : +82-2-6678-8533,
Fax: +82-2-6678-8599
User's Manual
OLW-4651 | OLW-5550 | OLWU-5520 | OLWU-5550
Thank you for purchasing our MLCD.
Please read through this user's manual for safety before installing this product.
This product is manufactured for Multi LCD model only.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OLW-4651 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Orion OLW-4651

  • Page 1 Tel : +82-2-6678-8533, Fax: +82-2-6678-8599 User’s Manual OLW-4651 | OLW-5550 | OLWU-5520 | OLWU-5550 Thank you for purchasing our MLCD. Please read through this user's manual for safety before installing this product. This product is manufactured for Multi LCD model only.
  • Page 2: Important Safety Instructions

    Features of MLCD Hybrid Video System ▶ Enjoy a wide flat screen with high brightness and high quality. ▶Easy to install and move due to its thin design ▶ Enjoy your favorite programs with various split-screen features simultaneously presenting Notice to users several programs.
  • Page 3: Table Of Contents

    5.15. Option Control ................................51 4. Use only a properly grounded plug and receptacle 5.16. ORION Homepage log on and Version Information ....................52 5. "Warning" CAUTION – These servicing instructions are for use by qualified service personnel only. 6. MSCS Protocol To reduce the risk of electric shock, do not perform any servicing other than that contained in the ................................
  • Page 4 - When you design the exterior design for MLCD system, consider easier disassembly for possible service occasion in the future. - The sliding Universal Unit of ORION is recommended for easier service. - If service people can step into the backside of MLCD system, it can greatly reduce time and effort for service.
  • Page 5 Hybrid Video System ORION ※ Please keep following instruction ※Handle with Caution. for panel protection without - Shock/Impact on the set's sides will result in exception. internal circuit damages. Warning Warning - The edge/bottom of the panel are fragile. - This product can be damaged even with minor Use shock-absorbing pads or rugs for laying down impact for its nature.
  • Page 6: Application Information

    Hybrid Video System ORION ※How to carry MLCD ※Application information It always needs two persons to carry or install MLCD. If static images are displayed on the screen for a long time, it causes burn-in When you carry MLCD with up straight manner, please hold handles on the back and image.
  • Page 7: Safety Precautions

    Hybrid Video System ORION 1. Safety Precautions • If it operates abnormally, stop using it • Do not pull out or hang down the • Do not place any liquid-containing • Do not put any foreign material into • Do not lean against the product or •...
  • Page 8: Guidance For Users

    Hybrid Video System ORION 2. Guidance for Users 2.1. LCD Panel 2.2. Receiver Module ¡ ¡ Upper¡Deck¡ LVDS OUT ①. LVDS OUT : Output port for transferring LVDS signal to LCD Panel ¡ ¡ Lower¡Deck RECEIVER MODULE BLU1 BLU2 VIDEO COMM ①.
  • Page 9: Power Module

    Hybrid Video System ORION 2.3. Power Module 2.4. Image Processor Module ¡ ¡ Front¡ ¡ ¡ Front¡ POWER MODULE PWR 1 PWR 2 PWR 3 OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 PWR 4 IN : DVI 1 IN : DVI 1...
  • Page 10: How To Install

    Hybrid Video System ORION 3. How to Install MAIN¡FRAME¡Stand¡Unit¡(Option) MAIN¡FRAME¡Wall¡Mounting¡Unit¡(Option) • Please do not install our product at following locations to protect the product • Please check the stability of wall. and prevent possible malfunction. If the wall is not strong enough, reinforce the wall before installation.
  • Page 11: How To Connect Cables

    Hybrid Video System ORION 4. How to Connect Cables • Do not connect/disconnect cables while MLCD or other external equipments are turned on. • First turn off the power all the attached equipment and make connections. ID : 2 ID : 1 4.1.
  • Page 12: Multi Image Processor Connection (For Two Or More 2X2 Mlcd Formation)

    Hybrid Video System ORION 4.2. Multi Image Processor Connection (for two or more 2X2 MLCD formation) • This instruction is for multi Image processor connection (More than 2 Image processors) • Configure the ID in the front side of the Image Processor to connect more than 2 Image processors.
  • Page 13: Setting And Operation Of Mscs Software

    Hybrid Video System ORION 5. Setting and operation of MSCS software 5.1. MSCS Installation 5.2. Start MSCS • Insert the Installation CD. • MSCS is an application program needed to control MLCD. • You can see following installation start screen.
  • Page 14: Control Signal Connections

    Hybrid Video System ORION 5.3. Control signal connections 5.3.2. Setting of LAN Port 1)¡In¡case¡of¡connecting¡to¡a¡LAN¡Hub 5.3.1. Setting of COM Port • This function is used to control the MLCD via LAN PORT. • Com Port connects or disconnects the communication between PC and MLCD.
  • Page 15 Hybrid Video System ORION 2)¡In¡case¡of¡connecting¡directly¡to¡user's¡computer 5) Click “SET TCP/IP Info.” to save the IP address.. • Cross-LAN cable is required to connect. ■ Check¡the¡network¡informations ¡ 1) Execute the LAN Configurator from installation CD. 2) Select Com Port and select "OPEN".
  • Page 16 Hybrid Video System ORION 3)¡Network¡IP¡setting¡for¡MSCS¡ 4) Click "GET TCP/IP Info." and check the network informations. 1) Execute the MSCS. 2) Select "Menu->Communication -> Setup" or "Ctrl+U" to start setup. 3) Select "Socket" radio button. 4) Type in IP Address of MLCD.
  • Page 17: New Design/Last Design" Setting

    Hybrid Video System ORION 5.4. "New design/Last design" setting 5.5. Selecting the command transmission method • You can see following pop-up window for "New design/Last design" when you click "Connect" or press "Ctrl+C" using keyboard after select communication type. • ONE LCD : Transmit Protocol Command to one MLCD.
  • Page 18: Image Processor Configuration

    Hybrid Video System ORION 5.6. Image Processor Configuration 5.7. Multi Screen Configuration 1) Click ADD IMAGE Processor button according to the number of installed Image Processor. 1) Screen Configuration Dialog will pop up, when you Click Image Processor ID Node in the Tree The input channel of Image Processor Module will be displayed at the View window.
  • Page 19 Hybrid Video System ORION 6) Add Image Processor : Click Add Image Processor button, each time one set of Image 9) Select 2x2 LCD set formation in Screen Configuration Dialog and click +button to increase Processor Module is increased. the number 1 to 2, and click button, 4x2 LCD screen formation will be created at Screen Configuration.
  • Page 20: Power On/Off

    Hybrid Video System ORION 10) Remove All IMAGE Processor : If there are any changes in Image Processor Modules or you want 5.9. Power On/Off to re-configure Image Processor Module, initialize Tree View window with Remove All IMAGE Processor button.
  • Page 21: Input Channel Change

    Hybrid Video System ORION 5.8. Input Channel Change 5.8.2. Mouse (left button use) ¡ e.g.) select DVI 3 5.8.1. Play button ¡ e.g.) select DVI 2 1) Select the input channel source of your choice at the Input Channel in Tree View window.
  • Page 22: Mouse Drag & Drop

    Hybrid Video System ORION 5.8.3. Mouse Drag & Drop 5.10. Loop Out (Daisy-Chain Out) Channel Configuration • Select the input channel source of your choice at the Input Channel in Tree View window. • Configure the channel for Loop Out (Daisy-Chain Out) ¡...
  • Page 23: Slide Show

    Hybrid Video System ORION 5.11. Slide Show 1) Create the screen format of your choice. • Display the screens formats saved by users sequentially.. • Select Menu -> Control -> Slide Control or press 'Ctrl+S' keys in the keyboard to start slide show.
  • Page 24 Hybrid Video System ORION 3) Configure various screen format in the same manner. 4) Click Start button after screen configuration. Screen formats are displayed according to the configured time and sequence. • The screen formats of Slide Show are displayed only for scheduled time.
  • Page 25: Picture Control

    Hybrid Video System ORION 5.12. Picture Control 6) Click "Stop" button to end "Slide Control" • Register values related to display of MLCD can be changed. • To use Picture Control, go to MSCS Menu -> Control -> Picture Control or press "Ctrl+P" using Keyboard.
  • Page 26: Timer Control

    Hybrid Video System ORION 5.13. Timer Control 5.14. Equalizer Control • Users can set the time for turn on or turn off. • You can control the Equalizer for more stable image quality according to the length of the image signal cable.
  • Page 27: Option Control

    Hybrid Video System ORION 5.15. Option Control ¡ Image De-Emphasis Control(IP Board in Image Processor Module) compensates output signal loss and Image Receiver Equalization Control(Image Receiver Board) compensates input signal loss. • There are various optional functions for convenient use.
  • Page 28: Orion Homepage Log On And Version Information

    ORION 6. MSCS Protocol 5.16. ORION Homepage log on and Version Information • In order to move to Orion website, go to "Help" of menu bar ->"OrionDisplay HomePage". - PWR : Power Supply Board - IP : Image Processor Board...
  • Page 29 Hybrid Video System ORION - Send To MLCD - Receive Data - CMD : 0x41 Data ID(1Byte) LENGTH Check sum • ID Range (0x11~0x94): Upper Byte is Image Processor Module Set ID(1~9) and Lower Byte is the ID of IP Board(1~4.) In case of 4 LCD...
  • Page 30 Hybrid Video System ORION 5. Graphic User Mode Control • ID Range (0x11~0x94): Upper Byte is Image Processor Module Set ID(1~9) and Lower Byte is the ID of IP Board(1~4.) In case of 4 LCD sets, IDs will be 0x11, 0x12, 0x13, and 0x14.
  • Page 31 Hybrid Video System ORION • ID Range (0x11~0x94): Upper Byte is Image Processor Module Set ID(1~9) and Lower Byte is the ID of IP Board(1~4.) In case of 4 LCD - Send To MLCD sets, IDs will be 0x11, 0x12, 0x13, and 0x14.
  • Page 32 Hybrid Video System ORION 11. Dimming Control - Receive Data Data - The command for controlling the backlight of LCD ID(1Byte) LENGTH Check sum A. General Command Master Control Image Processor IP ID Module ID Data Value 0X02 0x88 0x0C...
  • Page 33 Hybrid Video System ORION 15. Global Offset - Receive Data Data - The images on the seam area between the screens can be displayed on the screen or omitted from the screen. It can be selected to improve the continuity of the images.
  • Page 34 Hybrid Video System ORION Data - Receive Data ID(1Byte) LENGTH Check sum Data Image Processor IR ID Module ID LENGTH ID(1Byte) Check sum Value 0X02 0x87 0X01 Variable Variable Variable 0x03 Control Image Processor IP ID Module ID - Send To MLCD...
  • Page 35 Hybrid Video System ORION • ID Range (0x11~0x94): Upper Byte is Image Processor Module Set ID(1~9) and Lower Byte is the ID of IP Board(1~4.) In case of 4 LCD - Control (27 Bytes) sets, IDs will be 0x11, 0x12, 0x13, and 0x14.
  • Page 36 Hybrid Video System ORION 20. DE-Emphasis Control Data Length Explanation 1 byte - The command for compensating output signal loss according to the cable length Fan 1 Status 1 byte 0x31 : Good, 0x30 : Error - CMD : 0x51...
  • Page 37 Hybrid Video System ORION 21. DE-Emphasis Get Current Status 22. Equalizer Control - The command for collecting the current configuration information of DE-Emphasis for compensating the output - The command for compensating the input signal loss from the cable length.
  • Page 38 Hybrid Video System ORION 23. Equalizer Get Current Status Data Length Explanation White Balance-Gain R 1 byte Range: 0(0x00)~255(0xFF) - The command for collecting information of the current Equalizer configuration. Equalizer is adjusted to compensate the input signal loss according to the cable length.
  • Page 39: Attachment : Ascii To Hex Conversion Table

    Hybrid Video System ORION 7. Before calling for service - Receive Data Data ID(1Byte) LENGTH Check sum Picture Control Image Processor IP ID • Before calling for any repair, check the following and then refer to a near A/S center.
  • Page 40: Dvi Resolution

    Hybrid Video System ORION 8. DVI Resolution 9. Specification MODEL NAME OLW-4651 OLW-5550 OLWU-5520 OLWU-5550 Horizontal (Pixels) Vertical (Lines) Pixel V-Freq H-Freq Pol. Standard Diagonal 46" 55" 55" 55" Resolution Clock Addr. Sync. Back Addr. Sync. Back (Hz) (KHz) (H/V)
  • Page 41 Hybrid Video System ORION Image Processor Module Power Module OLW-4651 / OLW-5550 443.4mm(±0.2) 80.1mm(±1.0) 443.4mm(±0.2) 1.023.98mm / 1,215.63mm(±1.0) 600mm(±1.0) 44mm(±0.2) 88mm(±0.2) 400mm 578.57mm/ (±1.0) 686.43mm (±1.0) Weights 22Kg(±0.5Kg) OLWU-5520 / OLWU-5550 OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 PWR 1...
  • Page 42 ORION MEMO - 80 -...
