Summary of Contents for Murphy PowerView PV1000
- Page 1 PowerView™ Model PV1000 Hardware Installation Manual 00-02-0599 07-19-07 Section 78...
- Page 2 The latest version of this manual can be found at www.fwmurphy.com. Warranty A limited warranty on materials and workmanship for one year is given with this FW Murphy product. A copy of the warranty may be viewed or printed by going to www.fwmurphy.com/support/warranty.htm Please read the following information before installing.
-
Page 3: Table Of Contents
Table of Contents Product Information........................ 1 Inspecting Package Contents..................1 Hardware Installation......................2 Dash-Mounted Installation....................2 Gimbal Mount Installation.....................3 Wiring Instructions ......................... 4 Single Engine .......................4 Dual Engine Static Addressing..................5 NMEA Wiring........................6 PVA Gages ........................7 Pin Specifications for Deutsch DT04-6P Style Connections.........8 Wiring Schematic ......................9 Specifications........................ - Page 4 (THIS PAGE INTENTIONALLY LEFT BLANK)
-
Page 5: Product Information
Product Information The PowerView™ display is designed for instrumentation on electronically controlled engines communicating using the SAE J1939 Controller Area Network (CAN), NMEA 2000 (GPS features) or a proprietary blend of protocols. The PowerView display is a multifunction tool that enables operators to view many different engine, equipment, or transmission parameters and service codes, and can support many devices simultaneously. -
Page 6: Hardware Installation
If you must use the paper template from the manual and you downloaded this document from the FW Murphy website, be aware that the pdf file may not automatically print to scale. When submitting the file for print, you will need to select “None”... -
Page 7: Gimbal Mount Installation
Gimbal Mount Installation Tools Needed • Flathead or Phillips Screwdriver (depending upon screws used for mounting) • Drill with 9/64” size bit • Hole saw • Three (3) 6-32 stainless panhead screws (self tapping or machine screws) (length = panel thickness + 0.125”) Mounting the Unit 1. -
Page 8: Wiring Instructions
Wiring Instructions The following illustrations are examples of various typical quick-connect options for 1 or 2 engine setups and gages. Wiring harnesses are sold separately. Single Engine Software Configuration for Single Engine Setup To set the software configuration for single engine, on the System Settings screen, under Wiring Configuration, select Engine(s) –... -
Page 9: Dual Engine Static Addressing
Dual Engine Static Addressing NOTE: Port A and B have different connector keys to ensure proper connection. All cables are black with the exception of cables for Port B, which are yellow. Software Configuration for Dual Engine Static Addressing To set the software configuration for dual engine static addressing, on the System Settings screen, under Wiring Configuration, select Engine(s) –... -
Page 10: Nmea Wiring
NMEA Wiring NOTE: The NMEA wire harness contains blocking pins that only allow the cable to be connected to Plug D. Software Configuration for NMEA Setup If only NMEA devices such as GPS are connected to Plug D, and engines are connected to Plug A or B, then use the appropriate single or dual engine configuration settings. -
Page 11: Pva Gages
PVA Gages NOTE: Port B and C connectors are keyed differently than Port A and D connectors to ensure proper connection. Section 78 00-02-0599 07-19-07 - 7 -... -
Page 12: Pin Specifications For Deutsch Dt04-6P Style Connections
Pin Specifications for Deutsch DT04-6P Style Connections Section 78 00-02-0599 07-19-07 - 8 -... -
Page 13: Wiring Schematic
Wiring Schematic Section 78 00-02-0599 07-19-07 - 9 -... -
Page 14: Specifications
Specifications Electrical Display 6.4” Color transmissive TFT LCD Resolution VGA, 640 x 480 pixels Orientation Landscape Backlighting CCFL, 350 cd/m² (50,000 h lifetime) not replaceable Sharp ARM9 LH7A404, 200 MHz Processor Philips ARM7 LPC2194 70 MHz Flash Memory 16 Mbytes 32 Mbytes SDRAM EEPROM 32 Kbytes... - Page 15 Environmental Operating Temperature -40º C to +85º C Storage Temperature -40º C to +85º C Protection IP68 Emissions IEC 60945, 95/54/EC Immunity SAE J1113, ISO 11452 Section 78 00-02-0599 07-19-07 - 11 -...
- Page 17 Industries, Inc. This document, including textual matter and illustrations, is copyright protected by Murphy Industries, Inc., with all rights reserved. (c) 2006 Murphy Industries, Inc. Other third party product or trade names referenced herein are the property of their respective owners and are used for identification purposes only.
