- Page 1 Amigo DMG SpA Via Quarto Negroni, 10 00040 CECCHINA (ROMA) • ITALIA Emergency Telephone Tel. +39 06930251 • Fax +39 0693025240 info@dmg.it • www.dmg.it U.S. version Installation manual 93010123_E_amigo-usa-EN_090318_v1.4.cdr...
- Page 2 FCC NOTICE FOR PART 15 AMIGO can be wired to the phone line in a way that allows it to take the line with priority for all outgoing and This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not incoming calls, thereby excluding any other device from the phone line upon pressure of the ON/OFF button.
- Page 3 1.2 Flat plate and Gilda plate 200 mm 2.2) Phone Line Connection Connect the two telephone line wires (Line In) to terminals 7 and 8 of the AMIGO (see figure A) and then use the same terminals to connect the following phone device in the loop.
- Page 4 Amigo - Amigo - Emergency Telephone Emergency Telephone 1.2) Flat plate and Gilda plate 200 mm Installation instructions The Emergency Telephone can be inserted in the following plates: 1.1) Gilda plate 100 mm NOT supplied Insertion to pressure Insertion to pressure all dimensions in millimeters (inches) 110°...
