Range H 400
Connection diagram
Ph
N
Electrical rating data
Réf.
Voltage
Freq.
(V)
(Hz)
HX 701
12/60
50/60
12/60
DC
HX 704
110/240
50/60
110/125
DC
HX 705
380/440
50/60
Shunt trip
GB
HX 701, HX 704, HX 705
Uitschakelspoel door emissie
NL
HX 701, HX 704, HX 705
Bobina por emissão de corrente
P
HX 701, HX 704, HX 705
Arbeidsstrømsutløser
N
HX 701, HX 704, HX 705
Πηνίο εργασίας
GR
HX 701, HX 704, HX 705
(TM)
(LS, LSI)
1
3
5
2
4
6
Minimum
Maximum
Consum.
operating
operating
max.
voltage
voltage
(VA)
(V)
(V)
0,75 Un
1,1 Un
1280
0,75 Un
1,1 Un
550
0,75 Un
1,1 un
136
1
User instructions
Gebruiksaanwijzing
Instruções de instalação
Bruksanvisning
Oδηγίες χρήσεως
4 mm
6H 5435.b
Advertisement
Related Manuals for hager HX 701
Summary of Contents for hager HX 701
- Page 1 Shunt trip User instructions HX 701, HX 704, HX 705 Uitschakelspoel door emissie Gebruiksaanwijzing HX 701, HX 704, HX 705 Bobina por emissão de corrente Instruções de instalação HX 701, HX 704, HX 705 Arbeidsstrømsutløser Bruksanvisning HX 701, HX 704, HX 705 Πηνίο...
