TECHNICAL SPECIFICATIONS

GENERAL
Mains voltage -/00/14 : 230 V
-/01/11/16 : 120/230 V
-/05/10 : 240 V
Mains frequency -/00/05/10/14 : 50 Hz
-/01/11/16 : 50 / 60 Hz
Battery
remote : 3 V (R03 x 2)
Power consumption
standby : 2.3 W
Dimension (W x H x D)
Weight
AMPLIFIER
Output power
battery : 2 x 6 W
Speaker impedance
Frequency response
TUNER - FM SECTION
Tuning range
IF frequency
Sensitivity
Selectivity
IF rejection
Image rejection

SERVICE TOOLS

Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5 (disc without errors ) +
Test disc 5A (disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without "pause") .....4822 397 30155
Universal test cassette Fe SBC 420 ........................................................4822 397 30071

AVAILABLE ESD PROTECTION EQUIPMENT

anti-static table mat large 1200x650x1.25mm
small 600x650x1.25mm
anti-static wristband
connection box (3 press stud connections, 1MΩ )
extendible cable (2m, 2MΩ , to connect wristband to connection box)
connecting cable (3m, 2MΩ , to connect table mat to connection box) 4822 320 11306
earth cable (1MΩ , to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat)
wristband tester
-/17 : 120 V
-/17 : 60 Hz
mains : 12 V (R20 x 8)
max : < 35 W
: 540 x 177 x 276 mm
: 5.5 kg
mains : 2 x 6 W
: 2 x 8 Ohm
: 2 x
6 Ohm
: 70 Hz - 10 kHz (-3dB)
: 87.5 - 108 MHz
-/14 : 65.81 - 74 MHz
: 10.7 MHz ± 0.2 MHz
: 14 dB at 26dB S/N
: 55 dB at ±300kHz
: 65 dB
: 26 dB
2-1
TUNER - AM SECTION
Tuning range
IF frequency
Sensitivity
Selectivity
IF rejection ratio
Image rejection ratio
AUDIO CASSETTE RECORDER
Number of tracks
Tape speed
Wow & flutter
Fast wind/rewind C60
Frequency response
S/N ratio
COMPACT DISC
Frequency response
S/N ratio
Channel difference
Channel crosstalk
Laser wavelength
Laser light power
4822 466 10953
4822 466 10958
4822 395 10223
4822 320 11307
4822 320 11305
4822 310 10671
4822 344 13999
MW : 531 - 1602 kHz
-/17 : 530 - 1700 kHz
LW : 153 - 279 kHz
: 468 kHz ± 3 kHz
MW : 1500 µV/m at 26dB S/N
LW : 5500 µV/m at 26dB S/N
MW : 20 dB
LW : 29 dB
MW : 60 dB
LW : 60 dB
MW : 32 dB
LW : 38 dB
: 1 stereo
: 4.76 cm/sec ± 3%
: < 0.48 % JIS UWTD
: < 110 sec.
P/B : 125 - 8000 Hz
: > 38 dB
: 100 Hz - 10 kHz
: 60 dB
1 kHz : 2 dB
1 kHz : 40 dB
: 780 ± 20nm
: < 0.3 mW
PCS 107 272
