Page 1: Table Of Contents
AD25 GB Issue 04 Advance Humidity Pump EX Upgrade Kit for: Ova-Easy 190 / 380 / 580 Advance Ova-Easy Advance Hatcher TLC-40 / TLC-50 Advance Vetario S40M / S50M / T40M / T50M User Instructions Contents Section Subject Page Introduction...
Page 2: Introduction
AD25 GB Issue 04 Introduction These instructions detail the installation and operation of your new Brinsea Advance Humidity Pump. Please read them carefully before setting up your machine to achieve best results and keep these instructions safe for future reference. Used in conjunction with the Ova-Easy and TLC Advance and the Vetario SM and TM products, the Advance Humidity Pump offers convenient and refined control of humidity.
Page 3: Unpacking
Identify each part and check that they are all present and undamaged. If there are any parts damaged or missing please contact your dealer or Brinsea Products (at the address at the end of the document).
Page 4 Open the door and pull enough tube through so that its end may be pushed into the mesh of the evaporating block. As water is pumped out of the tube it will soak into the block and be evaporated by warm air flowing over the block. Ova-Easy 190 / 380 / 580 Water Evaporation...
Page 5: Evaporation Block Installation - Tlc Brooder / Vetario Sm
AD25 GB Issue 04 Evaporation Block Installation – TLC Brooder and Vetario SM / TM Intensive Care Units Place the pump module on a flat surface within 0.5m of the brooder / intensive care unit. Plug the connector on the pump signal lead into the control socket on the control panel. Keep any excess lead tied in a neat coil with the wrap supplied.
Page 6: Pump Installation (All Models)
AD25 GB Issue 04 Fit the short, rigid plastic pipe into the end of the silicone tube by 12mm (1/2”). Insert the end of the silicone tube with the rigid pipe through the Water Fill Hole on the top of the brooder / intensive care unit and push the rigid pipe into the centre of the evaporating block mesh so that it holds the water tube in position.
Page 7: Operation
AD25 GB Issue 04 Operation The scope of these instructions is limited solely to the humidity control system. Please read the user instructions supplied with the incubator, brooder or intensive care unit itself for full details of all aspects of operation. Fill the water tank to no higher than the bottom of the yellow moulding with clean water and fit the rubber bung in the filler hole.
Page 8: Guidelines For Egg Incubation Humidity Levels
To determine the correct humidity level for any given species either consult available literature (a range of bird keeping and breeding books is available from Brinsea Products at the address below) or experiment with different humidity levels and record which proved most successful or weigh eggs during incubation.
Page 9: Routine Maintenance
AD25 GB Issue 04 Routine Maintenance Changing the pump tube:- The peristaltic pump will need to have its tube replaced about every 3 months. Cut a length of the thick silicone tube to about 160mm. Remove the connectors and pull off the old tube. Replace with the new tube, avoiding twists.
Page 10: Service And Calibration
PRODUCTS USES SOPHISTICATED EQUIPMENT TRACEABLE TO INTERNATIONAL REFERENCE STANDARDS. Refer to the incubator, brooder or intensive care unit instructions for details on calibration technique. 11.6 Spare evaporation blocks and silicone tube are available from Brinsea Products Ltd at the address below. 12 Specification Sensor: Sensor accuracy +/- 3%.
