  • Page 2: Table Of Contents

    150M Wireless N ADSL2+ Router TABLE OF CONTENTS CHAPTER 1 PRODUCT OVERVIEW ..............- 4 - 1.1 P ................... - 5 - RODUCT EATURES 1.2 P ................... - 6 - ACKAGE ONTENTS CHAPTER 2 HARDWARE DESCRIPTION............- 7 - 2.1 P ....................
  • Page 3 150M Wireless N ADSL2+ Router 4.2.9 Time Restriction .................. - 68 - 4.2.10 Quality of Service ................- 70 - 4.2.11 Routing ....................- 72 - 4.2.12 DNS ....................- 75 - 4.2.13 DSL ....................- 77 - 4.2.14 UPnP ....................- 78 - 4.2.15 Interface Grouping ................
  • Page 4 150M Wireless N ADSL2+ Router 1. S ............- 113 - ETTING THE OF YOUR MANUALLY 2. PC ....................... - 114 - DIAL APPENDIX 2 ...................... - 119 - 1. T ..................- 119 - ROUBLESHOOTING 2. V ................- 120 - ERIFYING THE ONNECTION 3.

  • Page 5: Chapter 1 Product Overview

    150M Wireless N ADSL2+ Router Chapter 1 Product Overview Note: This user guide applies to W150D products. W150D is equipped with 1 antenna and the maximum wireless rate it can reach is 150Mbps. Thanks for purchasing this W150D ADSL2/2+ router! It is an easy-to install gateway device which provides easy-to-operate configuration interface to free you from complicated configurations.

  • Page 6: Product Features

    150M Wireless N ADSL2+ Router In a word, with fast wireless speed and large coverage, W150D is the best choice for families, student dorms and small-sized enterprises, etc to access Internet wirelessly. 1.1 Product Features  Complies with IEEE802.11b/g/n, IEEE802.3, IEEE802.3u, ADSL, ADSL2, ADSL2+ standards etc ...

  • Page 7: Package Contents

     One RJ45 network Cable  Two RJ11 Telephone Lines  One Quick Installation Guide  One CD-ROM If any of the above listed items is missing or damaged, please contact your PTCL reseller for immediate replacement. - 6 -...

  • Page 8: Chapter 2 Hardware Description

    2.1.1 Front Panel W150D’s Front Panel There are 9 LED indicators on the front panel of W150D. You can judge whether the device is in correct working condition by checking the status of the indicators. The meanings of the indicators are described...
  • Page 9 150M Wireless N ADSL2+ Router Green Flashing System functions correctly Packets being Flashing transferred WLAN Green Wireless is disabled Slow ADSL Link has not been Flashing established Fast ADSL Link being ADSL Green Flashing established ADSL Link has already Always On been established Unconnected Packets...

  • Page 10: Back Panel

    150M Wireless N ADSL2+ Router 2.1.2 Back Panel W150D’s Back Panel ON/OFF: Power Switch. Press it in to turn on the power and press it out to turn off the power. WPS/RESET：Hold and press it for 1 second to connect WPS, and 7 seconds to bring all settings back to factory defaults.
  • Page 11 150M Wireless N ADSL2+ Router using DSL uplink access mode (through telephone line).  Follow the diagram below to connect your network devices when using Ethernet uplink access mode (through network cable). - 10 -...

  • Page 12: Chapter 3 Fast Configuration

    150M Wireless N ADSL2+ Router Chapter 3 Fast configuration Since we are using computer to access Internet, we need to first configure the computer and then log on to router’s management interface (WEB UI) to configure the router through the configured computer.
  • Page 13 150M Wireless N ADSL2+ Router Click ―Change adapter settings‖ on the left side of the window. Right click ―Local Area Connection‖ and select ―Properties‖. Select‖ Internet Protocol Version 4(TCP/IPv4)‖and then click ―Properties‖. - 12 -...
  • Page 14 150M Wireless N ADSL2+ Router Select ―Obtain an IP address automatically‖ and ―Obtain DNS server address automatically‖. Click ―OK‖ to save the configurations. - 13 -...

  • Page 15: Logging On To Your Router Through Web Browser

    150M Wireless N ADSL2+ Router Note: Certainly you can set your IP manually, for detailed ： information please refer to appendix 1 3.2 Logging on to your router through Web browser Before entering the web browser, you need to verify the connectivity between the router and your computer.
  • Page 16 150M Wireless N ADSL2+ Router Then, input ―cmd‖ in the search programs and file texts box and press ―enter‖. Finally, Open the dos window and enter ―ping 192.168.1.1‖, and press Enter. If the screen displays the following results, it indicates your computer has already been connected to the router.
  • Page 17 150M Wireless N ADSL2+ Router Now the direct link between your computer and the router has been successfully established, which means you can log on to the router’s web-based utility. Open the IE Browser as shown below. Input http://192.168.1.1 in the address field and press ―Enter‖. - 16 -...

  • Page 18: Fast Internet Access

    150M Wireless N ADSL2+ Router Enter the router’s login screen and login password dialog will pop up. The default password is admin, as shown below： Input ―admin‖ in the Password field on the appearing page and click ―OK‖. 3.3 Fast Internet Access In previous section, we have explained how to log on to the router and in the following;...
  • Page 19 150M Wireless N ADSL2+ Router There are two Connection modes available. However, Wizard only provide DSL Uplink mode. The Ethernet Uplink mode can be configured in ―Advanced Settings‖. DSL Uplink: Select this mode, if you are using a telephone line to directly connect to router’s DSL port and then connect the router to your PC (Internet---telephone line—router---network cable---PC).
  • Page 20 150M Wireless N ADSL2+ Router For Internet access via DSL uplink mode (through telephone line), there are 3 options available under ―Network‖: 1. VPI/VCI Settings, 2. PPPOE User name, 3. PPPOE Password. VPI/VCI Settings: This option is mainly for distinguishing various areas and operators that have different VPI/VCI values.
  • Page 21 150M Wireless N ADSL2+ Router local area. PPPOE User name: the user name provided by your ISP; used together with password to authenticate the user. PPPOE Password: the password provided by your ISP; used together with user name to authenticate the user. For example: User A obtains a user name and a password, which are respectively 123456 and 123456, from ISP for ADSL broadband, so he/she needs to input the parameters as below:...
  • Page 22 150M Wireless N ADSL2+ Router is 12345678, you can check the button to show its character value. For example: if you want to set the password as 88888888, follow the configurations as shown in the figure below: And then click ―OK‖ to save the settings. Congratulations! You can access Internet now when the following screen appears as below (the Status displays ―Connected‖.) Launch a web browser, enter www.msn.com in the address field and...
  • Page 23 150M Wireless N ADSL2+ Router Now, try to use a wireless network adapter to search ―PTCL-BB‖: First, click (network adapter connection icon) to search wireless signals as shown in the figure below: - 22 -...
  • Page 24 150M Wireless N ADSL2+ Router Then click ―PTCL-BB‖ select ―Connect‖ to go to the dialogue box below: Enter the key: 88888888 and click ―OK‖; system will automatically connects with your wireless network in a while. The product includes wireless feature. If you have a wireless adapter...
  • Page 25 150M Wireless N ADSL2+ Router and wish to access the Internet via the adapter, you need to set the wireless parameters. You can refer to ―Easy-to-install-----Wireless network configuration‖ in previous section of this user guide. Advanced settings provide you more powerful functions such as filter, QoS and port range forwarding.

  • Page 26: Chapter 4 Advanced Settings

    150M Wireless N ADSL2+ Router Chapter 4 Advanced Settings Enter the setup wizard screen below and then click ―Advanced Settings‖ on the right top corner as shown in the figure below: After you enter the advanced settings screen, you can set the advanced settings for the router to satisfy your requirements.

  • Page 27: Device Information

    150M Wireless N ADSL2+ Router 4.1 Device Information There are five submenus: Summary, WAN, Statistics, Route and ARP. Summary: It displays system information，current status of WAN connection and Wireless as shown in the figure below: - 26 -...
  • Page 28 150M Wireless N ADSL2+ Router WAN: Click this menu to display the WAN information of this routing modem: Interface, Description, Type, Igmp, NAT, Firewall, Status, IPv4 Address and vlanID as shown in the figure below: Statistics: It gathers the received and transmitted packets on LAN/WAN ports.
  • Page 29 150M Wireless N ADSL2+ Router the device’s LAN ports as shown in the figure below: Note: eth0, eth1 and eth2 are respectively port1, 2 and 3 of the device; and wl0 is a wireless port. Statistics—WAN: It displays the received and transmitted packets of the device’s WAN port as shown in the figure below: Statistics-xDSL: It displays statistic information of ADSL connection including mode, traffic type, status and other ADSL parameters as...

  • Page 30: Advanced Setup

    150M Wireless N ADSL2+ Router shown in the below figure: Route: displays routing table of the device as shown in the figure below: ARP: displays the device’s LAN ports, IP and MAC addresses of the PCs that are wirelessly connected as shown in the figure below: 4.2 Advanced Setup Advanced Setup: Consists of 14 submenus including Connection - 29 -...

  • Page 31: Connection Mode

    150M Wireless N ADSL2+ Router Mode / WAN Service / LAN / DHCP Setting / NAT / Security / Time Restriction / Quality of Service / Routing / DNS / DSL / UpnP / Interface Grouping and Multicast as shown in the figure below: 4.2.1 Connection mode Connection Mode This router supports two connection modes: DSL mode and Ethernet...
  • Page 32 150M Wireless N ADSL2+ Router Setup‖---―Connection Mode‖. Select a proper connection mode and then click the ―Apply‖ button. 1. In DSL mode, you are required to configure parameters for ATM interface. To enter the ATM Interface page, click ―Advanced Setup‖---―Connection Mode‖...
  • Page 33 150M Wireless N ADSL2+ Router On this page, you can configure VPI and VCI values (consult your local ISP if you are not clear). For other options, keep the defaults and click the ―Apply/Save‖ button. 2. In Ethernet modes, you are required to configure parameters for Ethernet interface.

  • Page 34: Wan Service

    150M Wireless N ADSL2+ Router 4.2.2 WAN service 1. WAN Configuration in DSL Mode PPP over Ethernet (PPPoE) Click ―Advanced Setup‖—―Connection mode‖ (Select DSL mode and click ―Apply‖) ---―WAN Service‖---―ATM Interface‖ (refer to 4.3 for configuring the ATM interface) ---―Connection Setting‖ to enter WAN service setup interface (page1).
  • Page 35 150M Wireless N ADSL2+ Router Select PPP over Ethernet (PPPoE), modify the service description if necessary and then click ―Next‖ on page 2 to enter the page below (page 3): Page 3  PPP User Name: User name for PPPoE dialup. It is provided by your ISP.
  • Page 36 150M Wireless N ADSL2+ Router  PPP IP extension: The IP addresses of all packets including management packets that egress WAN port will be converted to the WAN port’s IP address once this feature is enabled.  Enable PPP Debug Mode: This feature can be enabled only when supported by your ISP.
  • Page 37 150M Wireless N ADSL2+ Router the ―Next‖ button on page 4 to enter the following page (page 5): page 5 This page allows you to configure the DNS server’s IP address for the WAN port. We recommend you to keep the default values if you are not clear about it and click the ―Next‖...
  • Page 38 150M Wireless N ADSL2+ Router Page 6 This page displays the configuration information. After confirmation, please click ―Apply/Save‖ to save it. You can access Internet once PPPoE dialup succeeds. IP over Ethernet When your ISP provides you an IP address or tells you that you only need to configure your PC to obtain an IP address automatically to access Internet, you need to select IP over Ethernet （...
  • Page 39 150M Wireless N ADSL2+ Router Modify the service description if necessary and then click the ―Next‖ button:  Obtain an IP address automatically: WAN port will automatically obtain an IP address for accessing Internet from the ISP, if this feature is selected. ...
  • Page 40 150M Wireless N ADSL2+ Router  WAN Subnet Mask: the subnet mask address provided by your ISP for accessing Internet.  WAN gateway IP Address: the gateway IP address provided by your ISP for accessing Internet. Enter the IP/ subnet mask/gateway IP address provided by your ISP or select ―Obtain an IP address automatically‖...
  • Page 41 150M Wireless N ADSL2+ Router Page 2 We recommend you to keep the default settings unchanged and click the ―Next‖ button (on page 2) to enter the screen (page 3) below: Page 3 This page allows you to configure the gateway address for WAN connection.
  • Page 42 150M Wireless N ADSL2+ Router Page 4 This page allows you to configure the DNS server’s IP address for the WAN port. We recommend you to keep the default values if you are not clear about it and click the ―Next‖ button (on page 4) to enter the following page (page 5): - 41 -...
  • Page 43 150M Wireless N ADSL2+ Router Page 5 This page displays the configuration information. After confirmation, please click ―Apply/Save‖ to save it. You can access Internet once the configured connection succeeds. Bridging If you want to use your PC or other devices to execute dialup or you don't want to share your broadband service with other users, you can first configure your router’s WAN service type as bridging and then use your PC or other devices for dialup connection.
  • Page 44 150M Wireless N ADSL2+ Router Modify the service description if necessary and then click ―Next‖. This page displays the configuration information. After confirmation, please click ―Apply/Save‖ to save it. - 43 -...
  • Page 45 150M Wireless N ADSL2+ Router After successful configurations, use your PC or other devices to dialup and then you can access Internet. Note: When you need to configure several WAN connections (multiple PVCs), first configure the needed number of ATM interfaces and then follow the above corresponding configuration procedures.
  • Page 46 150M Wireless N ADSL2+ Router Page 1 Page 2 Select PPP over Ethernet (PPPoE) on page 2, modify the service description if necessary and then click ―Next‖ to enter page 3: - 45 -...
  • Page 47 150M Wireless N ADSL2+ Router Page 3  PPP User Name: User name for PPPoE dialup. It is provided by your ISP.  PPP Password: The password provided by your ISP for PPPoE dialup.  PPPoE Service Name: it is provided by your ISP. Do not fill it in if you don’t have it;...
  • Page 48 150M Wireless N ADSL2+ Router ISP limits network use time. This feature can help you to save the Internet fee.  PPP IP extension: The IP addresses of all packets including management packets that egress WAN port will be converted to the WAN port’s IP address once this feature is enabled.
  • Page 49 150M Wireless N ADSL2+ Router the ―Next‖ button to enter the following page: This page allows you to configure the DNS server’s IP address for the WAN port. We recommend you to keep the default values if you are not clear about it and click the ―Next‖...
  • Page 50 150M Wireless N ADSL2+ Router You can access Internet once PPPoE dialup succeeds. IP over Ethernet When your ISP provides you an IP address or tells you that you only need to configure your PC to obtain an IP address automatically to access Internet, you need to select IP over Ethernet （...
  • Page 51 150M Wireless N ADSL2+ Router  Obtain an IP address automatically: WAN port will automatically obtain an IP address for accessing Internet from the ISP, if this feature is selected.  Use the following Static IP address: select this feature if your ISP provides you an IP address.
  • Page 52 150M Wireless N ADSL2+ Router We recommend you to keep the default settings unchanged and click the ―Next‖ button: - 51 -...
  • Page 53 150M Wireless N ADSL2+ Router This page allows you to configure the gateway address for WAN connection. We recommend you to keep the default values and click the ―Next‖ button: - 52 -...

  • Page 54: Lan

    150M Wireless N ADSL2+ Router This page allows you to configure the DNS server’s IP address for the WAN port. We recommend you to keep the default values if you are not clear about it and click the ―Next‖ button: This page displays the configuration information.

  • Page 55: Dhcp Setting

    150M Wireless N ADSL2+ Router requirement of the practical network environment. To enter the screen below, click ―Advanced Setup‖--―LAN‖.  IP Address: It is the Router’s LAN IP address. The default IP address is 192.168.1.1. Subnet Mask: It is the Router’s LAN subnet mask. You can ...
  • Page 56 150M Wireless N ADSL2+ Router gateway and DNS server, etc for the computers that connect to the router’s LAN ports and are configured to obtain an IP address automatically. Therefore it reduces the inconvenience and trouble in manually configuring IP address and other network parameters for multiple computers in LAN.

  • Page 57: Nat

    150M Wireless N ADSL2+ Router TCP/IP protocol of the computers in LAN to “Obtain an IP address automatically”. DHCP client This page displays DHCP client’s information such as host name, MAC address, IP address, and lease time.  Hostname: The name of a PC or a network device that has successfully obtained an IP address from the DHCP server.
  • Page 58 150M Wireless N ADSL2+ Router To enter virtual server interface, click ―NAT‖-> ―Virtual Server‖. And then click the ―Add‖ button to add rules for accessing the server.  Use Interface: It indicates which WAN connection the configured rules are to be applied to. When there is only one configured WAN connection available, system will select it automatically.
  • Page 59 150M Wireless N ADSL2+ Router  Service Name: There are two options available: (1) Select a Service: allows you to select an existing service from the drop-down list box. (2) Custom Service: allows you to define a service yourself.  Server IP Address: The IP address of the server created on LAN side.
  • Page 60 150M Wireless N ADSL2+ Router parameters that are configured on the page): 2. Configuring Web server The screen appears as below after the above configuration is finished: - 59 -...

  • Page 61: Port Triggering

    150M Wireless N ADSL2+ Router Supposing that the IP address of PPP0 is 183.37.227.201, then the Internet user only needs to enter ftp ： //183.37.227.201 or http ： //183.37.227.201 in Web browser address field to respectively access your FTP or Web server. 4.2.6 Port Triggering Some application programs or network business (such as network game, video conference, etc) can not work with simple NAT router due...
  • Page 62 150M Wireless N ADSL2+ Router  Use Interface: It indicates which WAN connection the configured rules are to be applied to. When there is only one configured WAN connection available, system will select it automatically.  Application Name: There are two options available: (1) Select an application: allows you to select an existing application from the drop-down list box.
  • Page 63 150M Wireless N ADSL2+ Router automatically enabled by the built-in firewall when connections initiated by application programs succeed. For example: You have created a server on router’s LAN side that can automatically download material from Internet (via port: 9090) and share its data with other users.

  • Page 64: Dmz Host

    150M Wireless N ADSL2+ Router 4.2.7 DMZ Host Once a PC on a LAN is set as a DMZ host, it can implement network communication with Internet without limit.  DMZ Host IP Address: the IP address of a PC to be set as a DMZ host.

  • Page 65: Security

    150M Wireless N ADSL2+ Router Supposing that the router’s WAN IP address is 183.37.227.201, then the Internet user only needs to enter http：//183.37.227.201 in Web browser address field to access your Web server. 4.2.8 Security IP Filter IP filter function can block LAN PCs from communicating with Internet PCs by preventing specific IP addresses from accessing external network through router via specific a port number or range.
  • Page 66 150M Wireless N ADSL2+ Router below to add filtering rules. Filter Name: Enter the defined filtering name. IP Version: Only Ipv4 is provided. Protocol: TCP/UDP; TCP; UDP; ICMP available for your option. Source IP address [/prefix length]: Enter the LAN IP address to be filtered.
  • Page 67 150M Wireless N ADSL2+ Router the filtering function can also be implemented. For example: If you want to filter the PC at the IP address of 192.168.1.100 and make it unable to access Internet. Then follow the instructions below: First, click ―Advanced Setup‖ → ―Security‖ → ―IP Filtering‖ to enter the IP filtering setup page and then click the ―Add‖...
  • Page 68 150M Wireless N ADSL2+ Router  The ports that BT ―seed‖ server frequently uses are in the range of 6900-8100 such as 6969，8000 and 7373. So we can block this port range by creating proper rules to stop BT software from connecting the server.

  • Page 69: Time Restriction

    150M Wireless N ADSL2+ Router needed parameters: URL Address: Enter the domain name that rejects LAN PCs access. Port Number: The port used by Web server, 80 by default. Then click the ―Apply/Save‖ button to save your settings. And all LAN PCs can not access www.sina.com.cn.
  • Page 70 150M Wireless N ADSL2+ Router For example: If you want the PC at the MAC address of aa:bb:cc:dd:ee:ff to access Internet on Saturday and Sunday only, then follow the instructions below: Click ―Advanced Setup‖―Security‖  ―Time Restriction‖ to enter the screen above and then click the ―Add‖...

  • Page 71: Quality Of Service

    150M Wireless N ADSL2+ Router automatically added by system.  Other MAC Address: The MAC address whose Internet access time you want to restrict. Enter it manually.  Start Blocking Time (hh:mm) / Blocking Time (hh:mm): The time range during which Internet access is blocked.
  • Page 72 150M Wireless N ADSL2+ Router Click ―Advanced Setup‖-> ―Quality of Service‖-> ―Queue config‖ to display the configured QoS rule. Click ―Add‖ to enter the following screen to add rules. Name: The name of the configured rule. Enable: Enable/Disable the rule. - 71 -...

  • Page 73: Routing

    150M Wireless N ADSL2+ Router Interface: The interface that needs to configure priority. Precedence: Set a priority for the selected interface. Click ―Save/Apply‖ to save the settings. 4.2.11 Routing Default Gateway Gateway is the path for sending packets when your computer is communicating with computers on other networks.
  • Page 74 150M Wireless N ADSL2+ Router Select the WAN connection that you want to set as the gateway and click ―Apply/Save‖ to save the settings. The settings will be effective after the system reboot. Static Route Static Route is a special route. When you use proper static routing in networks, you can reduce routing selection problems and the forwarding rate of the data packets.
  • Page 75 150M Wireless N ADSL2+ Router Click ―Apply/Save‖ to display the current configured static route information.  IP version: It is used to indicate that the IP belongs to IPv4.  Destination IP address/prefix length: to identify the destination IP address or network that the data is sending to. Prefix length together with the destination IP address are used to identify the destination network.

  • Page 76: Dns

    150M Wireless N ADSL2+ Router  Gateway IP address: the IP address of the router or host the data packets are sending to.  Metric: the number of the routers that the data packets go through (optional).  Apply /Save：Complete the settings. Note: ...
  • Page 77 150M Wireless N ADSL2+ Router After entering the DNS server IP address, click ―Apply/Save‖ to save the settings. Note:  After saving the settings, you need to reboot the router to bring the new configuration into effect.  Please keep the default settings if there’s no special requirement for incorrect DNS settings will cause the LAN computer to be unable to access the Internet via the domain name.

  • Page 78: Dsl

    150M Wireless N ADSL2+ Router Dynamic DNS Provider: Select your DDNS provider. Hostname: The domain name registered at the corresponding DDNS website. Interface: WAN connection interface Username: Enter the username that you use to register from the DDNS provider Password: Enter the password that you use to register from the DDNS provider Click ―Apply/Save‖...

  • Page 79: Upnp

    150M Wireless N ADSL2+ Router Click the checkbox to enable corresponding modulation modes, and then click ―Apply/Save‖ to complete the settings. Note: If you are not familiar with the ADSL modulation modes, please use the default settings. 4.2.14 UPnP With UPnP (Universal Plug and Play) function, the host in LAN can request the Router to carry specific port forwarding, thus the external host can access the internal host for resources.

  • Page 80: Interface Grouping

    150M Wireless N ADSL2+ Router Select ―Enable UPnP‖ and then click ―Apply/Save‖ to save the settings. Note: 1. Because the security of current UPnP version has not been guaranteed, please close it when you don’t need it. 2. Only the application programs that support UPnP protocol can use this function.
  • Page 81 150M Wireless N ADSL2+ Router  Group Name：The name of the configuration rule.  WAN Interface used in the grouping: WAN connection that needs to be grouped.  Available LAN Interfaces: Interfaces that can be grouped.  Grouped LAN Interfaces: LAN interface that needs to connect with specified WAN interface Example: Your ADSL line supports two groups of PVC;...
  • Page 82 150M Wireless N ADSL2+ Router below, and click ―Add‖ to configure the IPTV grouping parameters. Click ―Save/Apply‖ to save the settings. Note: After completing the settings, reboot the router to bring the router - 81 -...

  • Page 83: Multicast

    150M Wireless N ADSL2+ Router settings into effect. After setting the interface grouping, the gateway IP address the default grouping uses is 192.168.1.1, and then the second grouping uses 192.168.2.1 as the gateway IP address, and the others follow by analogy. 4.2.16 Multicast IGMP Configuration Click ―Advanced Setup‖->...

  • Page 84: Wireless Setting

    150M Wireless N ADSL2+ Router 4.3 Wireless Setting Wireless function includes ―Basic‖, ―Security‖, ―MAC Filter‖, ―Wireless Bridge‖ and ―Station Info‖. 4.3.1 Basic Setting  Enable Wireless: check/uncheck to enable/disable the wireless function. Wireless Mode:  b/g/n Mixed Mode: By default, system is in this mode. So your network adapter can connect to this router’s wireless network no - 83 -...
  • Page 85 150M Wireless N ADSL2+ Router matter which standard it complies with: 802.11b, 802.11g or 802.11n. (Different wireless network standards have different maximum transmission rates ： 802.11b mode is at 11Mbps ， 802.11g mode at 54 Mbps and 802.11n mode at 150Mbps. ...
  • Page 86 150M Wireless N ADSL2+ Router there is only one AP and all clients share the same BSSID which is usually the MAC address of the AP.  Max Clients: The max number of wireless clients that are allowed to be connected to the wireless network, 8 by default. You can modify it manually(The Max number is 8).

  • Page 87: Security Setting

    150M Wireless N ADSL2+ Router 4.3.2 Security Setting  WPS Setup: Wi-Fi protected setting (WPS) can create encrypted connection between wireless network clients and the router simply and quickly. Without selecting an encryption mode and configuring a key, you only need to enter the correct PIN code or select the ―Push Button‖(press the WPS button on the router’s back panel) to easily configure WPS.

  • Page 88: Mac Filter

    150M Wireless N ADSL2+ Router is successfully connected. PIN: To use PIN, you must know wireless client’s PIN code and  input it in its text box, then save this configuraton.Meanwhile, use the same PIN code in the client for connection. Enable WPS: check/uncheck to enable/disable the WPS function.
  • Page 89 150M Wireless N ADSL2+ Router “Disabled”: Select it to disable MAC filter function. “Allow”: only allows clients in the MAC address list to access your wireless network. “Deny”: only prohibits clients in the MAC address list from accessing your wireless network. Add: to add a MAC address, click the ―Add‖...
  • Page 90 150M Wireless N ADSL2+ Router And then click the ―Apply/Save‖ button on the above screen to save the parameter. Select ―Allow‖ on the page below: Example 2: If you want to prohibit the PC with MAC address of FF:EE:DD:CC:BB:AA only from accessing your wireless network, then follow the instructions below: Enter the Wireless--MAC filter page and click the ―Add‖...
  • Page 91 150M Wireless N ADSL2+ Router enter page below enter address FF:EE:DD:CC:BB:AA in the text box as shown in the below figure: And then click the ―Apply/Save‖ button on the above screen to save the paramter. Select ―Deny‖ on the page below: - 90 -...

  • Page 92: Wireless Bridge

    In the above figure, 2 W150Ds are used to enlarge wireless signal coverage. W150D-2 is configured as a wireless access point to establish a wireless bridge with W150D-1. In the meantime, the AP function reserved in W150D-2 enables PC3 and PC4 to communicate with W150D-2 and access Internet through wireless network adapters.
  • Page 93 150M Wireless N ADSL2+ Router In the above figure, 2 W150Ds are used to enlarge wireless signal coverage. W150D-2 is configured as a wireless bridge to establish a wireless bridge with W150D-1. W150D-2, here, does not have the AP function, thus, PC3 and PC4 can communicate with W150D-2 and access Internet only through wired network adapters instead of wireless ones.

  • Page 94: Station Info

    150M Wireless N ADSL2+ Router You only need to check the wireless network that you want to bridge with and click the ―Apply/Save‖ button. And system will automatically establish wireless bridge with the remote device for you. Disabled: To disable wireless bridge function, select this option. Note: To use the wireless bridge function, both devices must support the function.

  • Page 95: Diagnostics

    150M Wireless N ADSL2+ Router 4.4 Diagnostics Through the Diagnostics function, you can check connection status of the router’s interfaces. When a connection is successfully established, its status displays a ―PASS‖, otherwise it displays a ―FAIL‖ click ". To enter the page below, click the ―Diagnostics‖ tab on the left navigation menu column: - 94 -...
  • Page 96 150M Wireless N ADSL2+ Router If you are not clear about the test result, please click ―Help‖ for more details. - 95 -...

  • Page 97: Management

    150M Wireless N ADSL2+ Router 4.5 Management Management settings include: system log, TR-069 client, Internet time, access control, backup, update, restore default，update software and reboot, as shown in the picture below. 4.5.1 Settings  Backup With backup settings, you can back up your router’s configuration. The steps are as follows: 1.
  • Page 98 150M Wireless N ADSL2+ Router 2. Click the ―Backup settings‖ button, and click ―Save‖ on the appearing ―File Download‖ dialog to export the router’s configuration file.  Update This function enables you to import the previous backup file with ease. The steps are as follows: 1.
  • Page 99 150M Wireless N ADSL2+ Router 2. Click ―Browse‖ to select the file you want to import. 3. Click ―Update settings‖ to import the configuration and the device will reboot. - 98 -...
  • Page 100 150M Wireless N ADSL2+ Router  Restore Default If you have made some illegal operation on the device, you will be unable to access the Internet. This feature enables you to restore the device to factory default settings. Click ―Restore Default‖ to display the ―Tools -- Restore Default Settings‖...

  • Page 101: System Log

    150M Wireless N ADSL2+ Router 4.5.2 System log System log records the running status of W150D, such as ADSL dial-up procedure and data packets records and so on. To view the log, please follow the steps below. 1. Click ―System Log‖ to enter the ―System Log‖ screen and click the radio button before ―Enable‖...

  • Page 102: Client

    150M Wireless N ADSL2+ Router 4.5.3 TR-069 client TR-069 client is used to implement remote centralized management over the W150D from the Internet (Note: to use this function, there must be a remote centralized manager), the configuration steps are as follows: 1.
  • Page 103 150M Wireless N ADSL2+ Router 2. Click ―Enable‖ to open the function. The default is disabled. - 102 -...
  • Page 104 150M Wireless N ADSL2+ Router 3. Enter the Inform Interval which is 300, ACS URL (the domain name of the Auto-Configure Server), ACS User name, ACS Password and WAN Interface used by TR-069 client as the picture below. 4. Disable ―Display SOAP messages on serial console‖, and uncheck ―Connection Request Authentication‖, then click‖...

  • Page 105: Internet Time

    150M Wireless N ADSL2+ Router 4.5.4 Internet Time Internet time synchronization is used to update the router’s system time so that the router’s system time accords with the Internet time. Please select ―Automatically synchronize with Internet time servers‖ and click apply/save. - 104 -...

  • Page 106: Access Control

    150M Wireless N ADSL2+ Router Note: NTP time server is used to update the time. Select ―Time zone offset‖ as the time zone where you are. 4.5.5 Access Control  Passwords This screen allows you to change the device’s login password which is admin by default.
  • Page 107 150M Wireless N ADSL2+ Router 2. Enter the router’s current login password in the old password textbox. 3. Enter the password you wish to set in the new password and confirm password textboxes. - 106 -...
  • Page 108 150M Wireless N ADSL2+ Router 4. After clicking Apply/Save, the login dialog will pop up. 5. Enter the new password you have set to re-enter the router’s setup wizard screen. - 107 -...
  • Page 109 150M Wireless N ADSL2+ Router  Service Five services are provided in the control list as below: FTP, HTTP, ICMP, SNMP, TELNET. You can enable or disable them on LAN or WAN by check the buttons. - 108 -...

  • Page 110: Update Software

    150M Wireless N ADSL2+ Router 4.5.6 Update Software Update Software enables you to upgrade the device to improve its system stability. The upgrade steps are as follows: 1. Click ―Update Software‖ to display the ―Tools -- Update Software‖ screen. - 109 -...

  • Page 111: Reboot

    150M Wireless N ADSL2+ Router 2. Click the ―Browse‖ button to select the upgrade file and then click ―Update Software‖. 3. After clicking the “Update Software”, it comes to the upgrade screen. The progress takes about 2 minutes. 4.5.7 Reboot To reboot the router, click ―Management‖----―Reboot‖...

  • Page 112: Exit

    150M Wireless N ADSL2+ Router 4.6 Exit Select the Exit menu and click Ok on the appearing dialog to log out from the router’s web-based utility. 4.7 Back to Wizard Click Back to Wizard menu, you will come back to the router’s setup wizard screen as shown in the screen below: - 111 -...
  • Page 113 150M Wireless N ADSL2+ Router - 112 -...

  • Page 114: Setting The Ip Of Your Pc Manually

    150M Wireless N ADSL2+ Router Appendix 1 1. Setting the IP of your PC manually Choose ―Use the following IP address‖, and enter the IP address: 192.168.1.xxx. (xxx ranges 2~254), Subnet mask : 255.255.255.0, Gateway: 192.168.1.1, DNS Server: You can enter your local DNS server address (consult your local ISP) or set the Router as DNS proxy server.

  • Page 115: Pc Dial-Up

    150M Wireless N ADSL2+ Router 2. PC dial-up When working in bridging mode, W150D connects with internet via dial-up software (the third party software). With multiple built-in VPI/VCI, there is no need for any configuration and only an installed dial-up program will enable access to internet.
  • Page 116 150M Wireless N ADSL2+ Router Enter Control Panel page and click ―Network and Sharing Center‖as below: Enter ―Network and Sharing Center‖ and select ―Set up a new connection or network‖ as below: - 115 -...
  • Page 117 150M Wireless N ADSL2+ Router Choose ―Connect to the Internet‖ and click ―Next‖ on the page below: Select ―Dialup‖ on the appearing page below: Enter User name and password provided by your ISP on the page below: - 116 -...
  • Page 118 150M Wireless N ADSL2+ Router And then click ―Connect‖ If you get the screen below in a while, then you can access Internet. - 117 -...
  • Page 119 150M Wireless N ADSL2+ Router - 118 -...

  • Page 120: Troubleshooting

    150M Wireless N ADSL2+ Router Appendix 2 1. Troubleshooting Trouble Case Troubleshooting ● Check if the power adapter is connected properly. Power LED Off ● Check if the power adapter is matched. ● Check if the ADSL cable connection is OK. ●...

  • Page 121: Verifying The Connection

    150M Wireless N ADSL2+ Router 2. Verifying the Connection First, click the start menu on the left bottom corner of your computer desktop. Then, input ―cmd‖ in the search programs and file texts box and press ―enter’. Finally, Open the dos window and enter ―ping 192.168.1.1‖, and press Enter.
  • Page 122 150M Wireless N ADSL2+ Router Now the direct link between your computer and the router has been successfully established, which means you can log on to the router’s web-based utility. If the picture shows as below, it indicates the connection hasn’t been established.

  • Page 123: Faq

    Q: How to judge whether ADSL connection is OK? A: After the hardware is connected correctly, when the connection is OK, the ―ADSL-LINK‖ indicator of W150D will be always on; otherwise, it will be flashing. Flashing indicates the connection is troubled or wrong.
  • Page 124 A: Contact the technical engineer for support or after-sales service engineer. Note: Please download the upgrade packets from the PTCL website. Q: How to restore my device to factory default value? A: There is a reset button on the Router. Follow the steps below to restore the device: 1) Keep the device in running status.
  • Page 125 150M Wireless N ADSL2+ Router A: 1) The walls in the house are main obstacles. Because wireless LAN adopts wireless microwave frequency range, the signals received by wireless receiving devices behind the obstacles will be rather weak. 2) Physical obstacles not only hold up the wireless signals but also absorb the electromagnetic power.
  • Page 126 150M Wireless N ADSL2+ Router 2) Modify channels to reduce wireless disturbance. Note: When you set your wireless transmitting channel, keep above 5 channels far away from other wireless signal channels. 3) Keep the wireless Router far away from household appliances to reduce the disturbance of the signals.

  • Page 127: Vpi/Vci List

    150M Wireless N ADSL2+ Router 4. VPI/VCI List The VPI/VCI list is collected by our company for the convenience of customers. If you can not successfully dial-up, please ask your ISP for help. Encapsulation Australia - Telstra PPPoA LLC Argentina - Telecom PPPoE LLC Argentina - Telefonica PPPoE LLC...
  • Page 128 150M Wireless N ADSL2+ Router Iceland - Islandssimi PPPoA VC-MUX Iceland - Siminn PPPoA VC-MUX Israel PPPoA VC-MUX Italy PPPoA VC-MUX Jamaica (1) PPPoA VC-MUX Jamaica (2) PPPoA VC-MUX 1483 Bridged Jamaica (3) 1483 Bridged Jamaica (4) Kazakhstan PPPoA VC-MUX Mexico PPPoE LLC Netherlands - BBNED...
  • Page 129 150M Wireless N ADSL2+ Router Spain - Albura, Tiscali PPPoA VC-MUX Spain - Colt Telecom, Ola PPPoA VC-MUX Internet Spain - EresMas, Retevision PPPoA VC-MUX Spain - Telefonica (1) PPPoE LLC Spain - Telefonica (2), Terra 1483 Routed IP LLC Spain - Wanadoo (1) PPPoA VC-MUX Spain - Wanadoo (2)
  • Page 130 150M Wireless N ADSL2+ Router 1483 Bridged United States - CenturyTel (2) United States - Coqui.net PPPoA LLC United States - Covad PPPoE LLC United States - Earthlink (1) PPPoE LLC United States - Earthlink (2) PPPoE LLC United States - Earthlink (3) PPPoALLC 1483 Bridged...
  • Page 131 150M Wireless N ADSL2+ Router Communications(1) Snap United States SureWest PPPoE LLC Communications(2) United States SureWest PPPoA LLC Communications(3) United States - Toast.Net PPPoE LLC United States - US West PPPoA VC-MUX United States - Verizon (1) PPPoE LLC 1483 Bridged United States - Verizon (2) United Kingdom (1)

  • Page 132: Appendix 3: Regulatory Information

    150M Wireless N ADSL2+ Router Appendix 3: Regulatory Information Eu Declaration or Declaration of Conformity this Wireless Broadband Router is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
  • Page 133 150M Wireless N ADSL2+ Router expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). ―The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.‖...
