- Page 1 DOL 53X Broiler Production Computer User Manual For other language variants of this document we refer to http://docs.skov.com/1018 http://docs.skov.com/1019or your local dealer. 2016.11.11 • 611621 Software version 4.2...
- Page 3 It was released in 2016. Product and Documentation Changes SKOV A/S reserves the right to change this manual and the product described herein without further notice. In case of doubt, please contact SKOV A/S. Date of change appears from the front and the back page.
-
Page 4: Table Of Contents
Silo ..........................31 2.7.1 Empty Silo Sensor ..........................32 2.7.2 Gradual Transition ..........................32 Light Control ....................... 33 2.8.1 Light Dimmer ............................35 24-hour Clock ......................36 2.10 Feed Weigher ......................37 2.11 User-defined Inputs ....................38 DOL 53X Broiler... - Page 5 Stopping the Alarm Signal ..................46 Alarm Log ........................47 Alarm Test........................47 Alarms for Production....................50 4.4.1 Feed Alarms ............................50 4.4.2 Water Alarms ............................53 4.4.3 Light Alarms ............................54 4.4.4 Catching ..............................54 MAINTENANCE GUIDE ..................... 55 DOL 53X Broiler...
-
Page 6: Product Description
Feed control SKOV's house computer can ensure the precise dosing of feed. The feed is weighed out and supplied in pan or feed chain lines. Feed can be used from up to five silos and the feed can be mixed prior to feeding. Feed and water consumption is precisely registered. -
Page 7: Guidelines
If a function is not used, e.g. Extra sensor, it is not shown on the computer's user menus. The manual can therefore contain sections that are not relevant to the specific set-up of your computer. See also Technical Manual or, if necessary, contact SKOV A/S service or your dealer. This manual's User Guide consists of a general introduction, which describes briefly how to operate the house computer. -
Page 8: User's Guide
Hard alarms are marked in red. Soft alarms are marked in yellow. Deactivated alarms are grey. The alarm relay is only trigged by hard alarms. Soft alarms generate a pop-up in the display. See also section 4. DOL 53X Broiler... -
Page 9: Selection Of Language
Step 2. Add more pages (optional) Press on to add more pages to the front display (max. 5 in total). The same function can also be selected to displays on several pages, if this is required. DOL 53X Broiler... -
Page 10: Changing The Settings
A blue mark on the bar displays the change. Press to implement the change. Press to undo. Press to enter a value instead. Press to implement the change. Press to undo. Yes/Approve No/Undo DOL 53X Broiler... -
Page 11: Password
In the menu enter a new four-digit Management/ Change password password twice to change an existing password. SKOV A/S recommends that you change the passwords of the factory setting and subsequently change the password on a regular basis. DOL 53X Broiler... -
Page 12: Production
Manual registration of weight Water Water meter Water program Control according to light program Light Light dimmer Light program Main light Slave light Light sensor Boost function Inspection light Light dimmer controlled by light sensor 24-hour clock 24-hour clock DOL 53X Broiler... -
Page 13: 2.1 Production Menues
Feed consumption Water Silo Main light Light control Slave light Inspection light 24 hour click Feed weigher User defined inputs Interval timers User-offsets Table 1: Overview of the main menues in Production (depending on the current set-up). DOL 53X Broiler... -
Page 14: Animals
, DOL 53X displays a number of Sexed animals females and males, respectively. 2.2.1 Add/ Remove Animals On the basis of the numbers entered, DOL 53X calculates the total numbers of animals for the morning and evening and for the total batch. DOL 53X Broiler... - Page 15 If, in the course of a batch, animals are added or removed from the house, this must be registered in the menus Add/ Remove animals Culled animals It is important that the figure is correct as this is essential for the calculation of key figures. DOL 53X Broiler...
-
Page 16: Bird Weigher
Manual weighing Manual weight Entering of the average of your manual weighings. The value is used as the basis for DOL 53X's calculations. DOL 53X Broiler... -
Page 17: Correction Factor
(in percent). Example 1: Calculation of a Correction factor from the factory pre-set value Slaughter weight: 2190 g Final weight DOL 53X: 2110 g Calculation: 2190/ 2110 × 100% = 103.8% ≈ 104% Correction factor DOL 53X Broiler... -
Page 18: Period Without Weighing
User Manual SKOV A/S recommends that the Correction factor be adjusted for the current animals. This can be done by setting the Correction factor at 100 % and making frequent manual weighings during the first 1-2 batches. Correlate the weighing results with the weight reference curve and adjust the Correction factor. -
Page 19: Feed Control
Total no. of chain starts yesterday No. of chain runs today No. of chain runs today calculated No. of chain runs offset Chain runtime Table 4: Overview of the complete Feed control menu at service user level. DOL 53X Broiler... -
Page 20: Feed Programs
User Manual DOL 53X Broiler operates with two kinds of feed control: pan feeding chain feeding 2.4.1 Feed Programs The time control of feeding is regulated using the feed programs. The feeding follows a pre-determined program, which determines at what time of day and for how long feed is to be administered. It is possible to create up to eight different programs. -
Page 21: Pan Feeding
Feed program indicate in the menu. Feed program The feed program is set as described above in section 2.4.1. Active program no. Reading of the feed program which DOL 53X is using on the current day (max. 8). DOL 53X Broiler... - Page 22 (periods). If a period is changed, DOL 53X automatically adapts the subsequent values. Therefore changes should be made so that they follow the order of the periods. DOL 53X Broiler...
- Page 23 (3) No refeeding. Feeding is stopped by the feed program. The feeding amount is as required. (4) Feeding stops before the feeding period ends. The animals have not eaten for a set period of time ) and they have received the amount of feed required. Check consumption when birds full DOL 53X Broiler...
-
Page 24: Chain Feeding
• Set the feeding periods in the curve. See section 2.4.1. menu is not visible if pan feeding is controlled Feed program according to the light program. Chain runs Set the following for each program: • Day number • Number of daily runs DOL 53X Broiler... - Page 25 The number of chain runs for which there is room in the periods. today calculated No. of chain runs Offset in relation to the number of feedings set in the program. ofset Chain runtime Setting the runtime for one chain rotation. It is important to set this parameter correctly. DOL 53X Broiler...
-
Page 26: Feed Mixture (Drum Weigher And Dol 9940)
However, DOL 53X will always calculate the correct mixture proportion. Catching. Displaying the type of feed selected for the transition to Catching. See also Feed mixture uses the DOL 53X user manual climate, the section on Catching. DOL 53X Broiler... -
Page 27: Feed Consumption
The consumption levels are calculated separately for all feed types. Feed consumption for the current 24 hours and total feed consumption can be displayed. In the submenus, DOL 53X also displays calculations of feed consumption levels per animal and of the water/feed consumption ratio. DOL 53X Broiler... -
Page 28: Manual Distribution Of Feed Before Batch Start (Broiler)
(and included in, e.g., calculations of FCR and PEF). 1. Wait until the first filling has been entirely completed. 2. Take the feed from the last hopper with the cross auger sensor. DOL 53X Broiler... -
Page 29: Water
DOL 53X makes up water consumption in litres for a total overview. In order to render sudden changes visible the water consumption is also made up in percent. Under normal conditions, such percentages will increase by a couple of percent per day as the birds grow older. DOL 53X Broiler... -
Page 30: Water Control
The desired amount of water on the day (as indicated in the refe- rence curve) can be divided between the number of starts (periods). If a period changes, DOL 53X automatically adjusts the subsequent values. Make the changes therefore so they follow the periods' sequence. DOL 53X Broiler... -
Page 31: Silo
Silo delivery log for each silo. For the same type of feed in several silos, it is possible to set the silo to supply feed. Select silo X The change occurs immediately after the setting has been changed. DOL 53X Broiler... -
Page 32: Empty Silo Sensor
Feeding from Silo 2 Feed A: grow feed Silo 1 is now empty When the content in the silo falls to a set quantity, the gradual transition to a silo with the same type of feed will start. DOL 53X Broiler... -
Page 33: Light Control
DOL 53X automatically regulates the light in the house based on the values which you indicate in the menu. Light program Set the program as described below. Reading of whether the main light is ON or OFF. Light status DOL 53X Broiler... - Page 34 Slave light Start-offset - 00:15 Stop-offset + 00:15 Slave light turns the light on and off, offset in relation to the main light. The offset can be set with a start and stop offset for each slave light. DOL 53X Broiler...
-
Page 35: Light Dimmer
Set the duration of the individual periods as well as the value of the light intensity when the period expires. Production/ Light control/ Catching. Display of the status of the Catching light. See also the DOL 53X user Catching light manual climate, the section on Catching. DOL 53X Broiler... -
Page 36: 24-Hour Clock
If an ON-time runs past midnight on a day when the timer is not active, the function will remain ON until the time has elapsed. Monday Tuesday Wednesday 00:00 24:00 00:00 24:00 00:00 24:00 Start time ON-time Start time DOL 53X Broiler... -
Page 37: Feed Weigher
DOL 53X indicates the current status of the weigher. This can be used in connection with calibration. DOL 53X stops the feed weigher for the catching function. See also the DOL 53X user manual climate, the section on Catching. DOL 53X Broiler... -
Page 38: User-Defined Inputs
24-hour clock) is set up. For example, if you choose that the timer follows the main light, the interval timer will run when the main light program is ON. Set an ON and OFF time for the timer. DOL 53X Broiler... -
Page 39: User Offsets
User Manual 2.13 User Offsets Main menu Production User offsets Offset feed reference Offset water reference Light intensity offset Table 13: Overview of the menu for the user offsets Displaying user offsets relative to the standard curve values. DOL 53X Broiler... -
Page 40: Management
Manual bird weigher Standard deviation Bird weigher Uniformity Average Growth Light sensor Today Feed/Bird Water/Bird Water/Feed Water today Feed A-E Total Feed/Bird Feed A-E Feed eaten by dead Water total Animals Mortality Dead animals Culled animals Moved animals DOL 53X Broiler... - Page 41 Slave light Consumption Energy meter 1-2 Energy this batch Energy consumption Energy total Actual power consumption Change password Change password Daily Change password Advanced Change password Service Table 14: Overview of the menu items in the Management menu DOL 53X Broiler...
-
Page 42: House Data
The house name is transferred through the network and the house should therefore be identifiable based on its name. Set up a plan for naming all computers connected to the network. DOL 53X Broiler... -
Page 43: Key Values
Animal's weight (ref. behaviour) 3.4.1 Setting of Curves For each curve, set 1) a day number for each of the eight curve points. 2) the required value of the function of each of the eight curve points. DOL 53X Broiler... -
Page 44: Catching
Selection of the last type of feed to be used before the feeding system is stopped. Type of feed when feed mix is stopped Selection of whether activation of Catching will change the light control. Active Selection of the desired light level for when Catching is activated. Intensity DOL 53X Broiler... - Page 45 Stop feed mixture feeding (non-wheat) Catching key active (animals eat until (animals get the system is only one type of empty) food) Catching automatically ends if not Date/time stopped The sequence when stopping the feed system during Catching. DOL 53X Broiler...
-
Page 46: Alarms
The signal continues after the alarm event has stopped. The signal stops after the alarm event has stopped. Stopping the Alarm Signal The alarm window in the display disappears and the alarm signal stops when you acknowledge the alarm by pressing the adjustment knob. DOL 53X Broiler... -
Page 47: Alarm Log
A few of the alarms are always connected, e.g. . You can connect and disconnect the Power failure others and for some you can set the alarm limits. It is always the user’s responsibility to ensure that the alarm settings are correct. DOL 53X Broiler... - Page 48 Too much feed after stop Too much feed after stop alarm Max. feed consumption after stop Chain or pan feeding with water meter Water/Feed ratio Water/Feed ratio alarm Begin to check at day number Time threshold for alarm DOL 53X Broiler...
- Page 49 Light alarm Light sensors deviate limit ± Light sensors deviate alarm delay Main light Main light alarm Light alarm limit Light alarm delay Main light sensors deviate Slave lights 1 Slave light 1 alarm Light alarm limit ± DOL 53X Broiler...
-
Page 50: Alarms For Production
The feed weigher cannot carry out a stable weighing process. This may be caused by vibrations. Reference voltage DOL 53X has registered that the reference signal from the drum scale is less than 9.0 V for a given period of time. DOL 53X Broiler... - Page 51 As a main rule, the alarm limit should be set to 10 kg ( Feed consumption in given check interval For chain feeding, monitoring time may not exceed the time for a chain rotation. DOL 53X Broiler...
- Page 52 Silo is empty alarm The empty silo sensor registers that there is no more feed in the silo and it is not possible to change to another silo, possibly due to low silo content. DOL 53X Broiler...
-
Page 53: Water Alarms
Water meter leakage DOL 53X cannot turn off water when water consumption is too high. Water meter relay For water meters where a relay has been selected, a soft or a hard alarm will interrupt the addition of water. DOL 53X Broiler... -
Page 54: Light Alarms
DOL 53X generates the light alarm if the light intensity deviates ( Light alarm Slave light +/-10 lux) from the required level. limit ± 4.4.4 Catching Catching Catching key error Alarm that the catching is not completed within the set period. DOL 53X Broiler... -
Page 55: Maintenance Guide
See the picture. It will be possible for a customer to deliver SKOV A/S products to local collection sites/recycling stations according to local instructions. The recycling station will then send the products to an approved plant for recycling and reuse. - Page 56 2006/42/EC (Directive on Machinery) Standards: EN 61000-6-2:2005 + AC:2005 EN 61000-6-4:2007 + A1:2011 We declare as manufacturer that the products meet the requirements of the listed directives and standards. Location: Hedelund 4, DK-7870 Roslev Date: 2016.07.05 Jesper Mogensen DOL 53X Broiler...
- Page 57 DOL 53X Broiler...
- Page 58 DOL 53X Broiler...
- Page 60 SKOV A/S • Hedelund 4 • Glyngøre • DK-7870 Roslev Tel. +45 72 17 55 55 • Fax +45 72 17 59 59 • www.skov.com • E-mail: skov@skov.dk...
