1.Projector Overview~1
1
2
4 4
1
5
6
1
8
9
10
Kind reminder:
Please ensure that you are using the correct cable for the VGA/AV port!
(For more details please inquire with your distributor) .
3
1. Projection lens
2. Front IR remote
controlling sensor
3. Ventilation holes
4. Power on/off
5. USB 3.0 ports
7
1
6. TF card reader
7. 3.5mm earphone ring
8. Adapter connection port
9. U disk/mouse port
10. HDMI input port
11. Computer/video port
12. Switch botton
11
12
1.Projector Overview~2
1
1
3
4
1. Height bracket
2. Air intake holes
4. Battery ventilation holes 5. Ventilation holes
Kind reminder:
It's strictly prohibited to block the air intake window,
which may cause over heating and damage the projector.
2
5
6
3. Screw Mount (M5)
6. Focusing knob
Advertisement
Table of Contents
Related Manuals for ICODIS CB400
Summary of Contents for ICODIS CB400
- Page 1 1.Projector Overview~1 1.Projector Overview~2 1. Projection lens 2. Front IR remote controlling sensor 3. Ventilation holes 4. Power on/off 5. USB 3.0 ports 6. TF card reader 7. 3.5mm earphone ring 8. Adapter connection port 9. U disk/mouse port 10. HDMI input port 11.
-
Page 2: Specifications
3.Remote Control 2. Specifications Display chip: 0.3'' DMD RGB-LED Lens: High light transmittance coating glasses Optical Brightness uniformity: 98% Brightness:3000 lumens(international standard 500 Ansi Lumens) parameters Contrast ratio:1000:1 NTSC: ≥120% Resolution: 1 280*800 3D display: Yes 1.Power Projection size:20-200 inch Throw ratio: 1.47:1 2.Arrow keys Keystone: Electronical adjusting 50... -
Page 3: Power On/Off
4.Power ON/OFF 5.How to Focus? 1.ON: Plug the DC terminal of the power adaptor to DC-IN terminal of projector, adjust the Adjust the focus button up or down lightly until the image is clear. 5.How to Focus? master switch on the right to “ON”, while the red light indicator light is on, press the power key. 2.OFF: Press the power key while the projector is working normally, if the indicator Adjust the focus button up or down light turns from green to red, the projector is off. - Page 4 6.How to use the USB2.0/3.0 interface? 7.How to connect WiFi? WiFi connection steps: Connect your mouse and keyboard via the USB 2.0/3.0 ports. Read your audio, video, Please press the main interface on the remote controller until the main screen appears, and photos directly through USB.
-
Page 5: Surfing The Net
8.How to connect Blutooth? 9. Surfing the Net When connecting a Bluetooth device for the first time (such as Bluetooth Speaker/ Head- Please press the main interface on the remote controller until the main screen appears, set), you will need to match said device with your projector. press “Home”... -
Page 6: File Management
11.Local Play 10.File Management Put the USB stick with audio, video, or photo into the USB2.0 or USB3.0 interface, press Please press the main interface on the remote control until the main screen appears, the main interface on the remote control until the main screen appears. select “Multi- Media”... - Page 7 12.APK Install Instructions 13.Wireless Display for Android IMPORTANT : Android devices require Android OS 4.4 or later and the wireless screen Please press the main interface on the remote control, whent he main screen appears, mirroring capability to connect wirelessly with the projector. select the “Apps Center ”, find the “...
- Page 8 14.Wireless Display for iOS 14.Wireless Display for iOS~2 1. Connect the projector to a wireless network(the same network as your mobile device). 2. Open the Happy Cast app on projector’s home screen. 3. Connect the iOS device to the same wireless network as your projector 4.
-
Page 9: How To Charge
16.How to Charge 15.3D Function 1. 3D video play: 1. To charge when the projector is off: when the projector is connected via the DC-In When playing video; compatible DLP 3D formats of videos will be automatically recogni- power adapter, put the main power switch in the “OFF” position, your device should zed, the projector will automatically switch to 3D mode;... - Page 10 Instruc tion Manual may cause electric shock and fire. It is better to unplug the power cord after powering off. CB400 CLEANING Unplug the power cable first. Clean the shell regularly with a damp cloth, neutral detergent can be used.
