Active Vision ACC-P106N-2VSW-W User Manual

Weatherproof ir ip camera
Hide thumbs Also See for ACC-P106N-2VSW-W:
Table of Contents

Advertisement

Quick Links

Download this manual

User Manual

WEATHERPROOF IR
IP CAMERA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACC-P106N-2VSW-W and is the answer not in the manual?

Questions and answers

Related Manuals for Active Vision ACC-P106N-2VSW-W

Summary of Contents for Active Vision ACC-P106N-2VSW-W

  • Page 1: User Manual

    User Manual WEATHERPROOF IR IP CAMERA...
  • Page 2 WARINGS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK).

  • Page 3: Table Of Contents

    CONTENT Preface Product Specifications Product Installation Monitor Setting Hardware Installation IP Assignment Install ActiveX control Live Video IP Camera Configuration System Network A/V Setting Event List Network Configuration I/O Configuration VIII Factory Default Package contents Appendix I Appendix II V1.0_121126...

  • Page 4: I Preface

    Preface This IP Camera is a Full HD 1080P waterproof IR IP camera. It has the web server built in. User can view real-time video via IE browser. IP Camera supports simultaneously H.264, Motion JPEG & MPEG4 video compression and dual streaming which provides smooth and high video quality.
  • Page 5 Power over Ethernet Operating Temperature -10°C ~ 45°C φ83mm * H180mm Dimensions Weight 1000g IR LEDs (Optional) LEDs 35 units IR distance (meter) Network Ethernet 10/ 100 Base-T Network Protocol HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE 802.1X, RTSP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, 3GPP, SAMBA, Bonjour System 1920x1080@30fps, 1280x720@30fps, ,640x480@30fps,...

  • Page 6: Product Installation

    Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or above, Chrome, Safari, Firefox Mobile Support iOS 4.3 or above, Android 1.6 or above. Hardware Suggested Intel Dual Core 2.53G,RAM: 1024MB, Graphic card: 128MB Product Installation Monitor Setting 1. Right-Click on the desktop. Select “Properties” 2.

  • Page 7: Hardware Installation

    B. Hardware Installation 1. Connect power adaptor first. 2. Connect IP Camera to PC or network 3. Set up the network configurations according to the network environment. For further explanation, please refer to chapter VI: “Network Configuration for IP Camera”. 4.
  • Page 8 the camera locations and enables easier application of uninterruptible power supplies (UPS) to ensure 24 hours a day, 7 days a week operation.

  • Page 9: Ip Assignment

    C. IP Assignment 1. Use the software, “IP Installer” to assign the IP address of IP Camera. The software is in the attached CD. 2. There are two languages for the IP installer a. IPInstallerCht.exe: Chinese version b. IPInstallerEng.exe: English version 3.
  • Page 10 7. IP Installer will search all IP Cameras connected on LAN. The user can click “Search Device” to search again. 8. Click one of the IP Camera listed on the left side. The network configuration of this IP camera will show on the right side. You may change the “name” of the IP Camera to your preference (ex: Office, warehouse).

  • Page 11: Install Activex Control

    10. A quick way to access remote monitoring is to left-click the mouse twice on a selected IP Camera listed on “Device list” of IP Installer. An IE browser will be opened. 11. Then, please key in the default “user name: admin” and “password: admin”. D.
  • Page 12 When popup the following dialogue box, click “Yes”.

  • Page 13: Live Video

    IV Live Video Start an IE browser, type the IP address of the IP camera in the address field. It will show the following dialogue box. Key-in the user name and password. The default user name and password are “admin” and “admin”. When the IP Camera is connected successfully, it shows the following program interface.
  • Page 14 : Video Snapshot 3. Show system time, video resolution, and video refreshing rate 4. Adjust image, 1/2x, 1x, 2x (If ”Video Setting” the streaming 2 setting is 5. Select video streaming source closed, this option will not appear here.) 6. Show how many people connect to this IP camera. 7.

  • Page 15: Vip Camera Configuration

    V. IP Camera Configuration Click to get into the administration page as below. Click to back to the live video...

  • Page 16: System

    A. System 1. System Information a. Server Information: Set up the camera name, select language, and set up the camera time. Server Name: This is the Camera name. This name will show on the IP Installer. (ii) LED Indicator: The LED in the front of camera flickers when processing data.
  • Page 17 c. Server time setting: Select options to set up time - “NTP”, “Synchronize with PC’s time”, “Manual”, “The date and time remain the same” 2. User Management IP CAMERA supports three different users, administrator, general user, and anonymous user.
  • Page 18 a. Anonymous User Login: Yes: Allow anonymous login No: Need user name & password to access this IP camera b. Add user: Type the user name and password, then click “Add/Set”. c. Click “edit” or “delete” in the user list to modify them. The system will ask you to key in the password in the pop-up window before you edit the user information.
  • Page 19 a. To update the firmware online, click “Browse…” to select the firmware. Then click “Upgrade” to proceed. b. Reboot system: re-start the IP camera c. Factory default: delete all the settings in this IP camera. d. Setting Management: User may download the current setting to PC, or upgrade from previous saved setting.

  • Page 20: Network

    B. Network 1. IP Setting IP Camera supports DHCP and static IP. a. IP Assignment DHCP: Using DHCP, IP CAMERA will get all the network parameters automatically. (ii) Static IP: Please type in IP address, subnet mask, gateway, and DNS manually.
  • Page 21 c. Port assignment: Web Page Port: setup web page connecting port and video transmitting port (Default: 80) (ii) HTTP Port: setup HTTPS connecting port (Default:443) d. UPnP (Universal Plug and play): This IP camera supports UPnP. If this service is enabled on your computer, the camera will automatically be detected and a new icon will be added to “My Network Places.”...
  • Page 22 e. RTSP setting RTSP Server: enable or disable (ii) RTSP Port: setup port for RTSP transmitting (Default: 554) (iii) RTSP Start and End Port: in RTSP mode, you may use TCP and UDP for connecting. TCP connection uses RTSP Port (554). UDP connection uses RTSP Start and End Port.
  • Page 23 i. LLTD If your PC supports LLTD, enable this function then you can check the connection status, properties, and device position (like IP address) of this IP Camera in the network map.
  • Page 24 2. Advanced a. Https (Hypertext Transfer Protocol Secure): Https can help protect streaming data transmission over the internal on the higher security level. Https setting: Before setting new request, please remove old secure identification at Http connection type. Created Request: To remove secure identification in created request mode.
  • Page 25 (iii) Installed Certificate: remove Certificate in .Installed Certificate mode. There will be a warning message to check again. (iv) There are two ways to set Certificate- Install Signed Certificate and Create Self-Signed Certificate. b. SNMP(Simple Network Management Protocol) Enable SNMPv1 or SNMPv2 and write the name of Write Community and Read Community.
  • Page 26 Please set what event need to detect. c. Access List:”Enable IP address filter” can set IP address which can allow or deny to this camera. There are two options, single and range, for user to set the IP address. d. QoS (Quality of Server / DSCP (Differentiated Services Code Point) : DSCP specifies a simple mechanism for classifying and managing network traffic and provide QoS on IP networks.
  • Page 27 point encryption over the local LAN segment. Please check what version of the authenticator and authentication server support. This camera supports EAP-TLS method. Please enter ID, password issued by the CA, then upload related certificates. 3. PPPoE & DDNS a. PPPoE: Select “Enabled” to use PPPoE. Key-in Username and password for the ADSL connection.
  • Page 28 b. DDNS: It supports DDNS (Dynamic DNS) service. Enable this service (ii) Key-in the DDNS server name, user name, and password. (iii) Set up the IP Schedule update refreshing rate. (iv) Click “Apply” (v) If setting up IP schedule update too frequently, the IP may be blocked. In general, schedule update every day (1440 minutes) is recommended (vi) DDNS Status •...
  • Page 29 configuration first. b. FTP: To send out the video via mail of ftp, please set up the configuration first. c. Samba: Select this option to send the media files via a network neighborhood when an event is triggered...

  • Page 30: A/V Setting

    C. A/V Setting 1. Image Setting For the security purpose, there are three areas can be setup for privacy mask. Click Area button first and pull an area on the above image. Finally, click save button to reserve the setting. Please refer to the details below for Image setting: a.
  • Page 31 choose "Light Sensor Mode", the image will be turned to black and white at night in order to keep clear. To set light sensor mode, appoint a lux standard of switching D/N here. Current lux value is provided for reference. Under "Times Mode"...
  • Page 32 b. Advanced Mode of Streaming 1 and Streaming 2: Resolution There are 5 resolutions can be chosen: 1920x1080, 1280x720, ,640x480, 320x240, 176x144 (ii) Bitrate Control Mode There are CBR (Constant Bit Rate) and VBR (Variable Bit Rate) to be chosen. (iii) Video Quantitative The quality adjustment of VBR, you can choose 1~10 compression rate (iv) Video Bitrate...
  • Page 33 c. 3GPP Streaming mode: 3GPP mode has 640x480, 320x240, 176x144 resolutions, 3~15FPS frame rate levels, H.264 / MPEG4 format Enable or Disable 3GPP Streaming (ii) 3GPP Path: 3GPP output connecting route 3. Audio: IP Camera supports -way audio. User can send audio from IP Camera Built-in mic to remote PC;...

  • Page 34: Event List

    D. Event List IP Camera provides multiple event settings. 1. Event Setting a. Motion Detection IP CAMERA allows 3 areas motion detection. When motion is triggered, it can send video to some specific email address, transmit the video to remote ftp server or Samba. To set up the motion area, click “Area Setting”. Using mouse to drag and draw the area.
  • Page 35 2. Schedule a. Schedule: After complete the schedule setup, the camera data will be recorded according to the schedule setup. b. Snapshot: After enabling the snapshot function, user can select the storage position of snapshot file, the interval time of snapshot and the reserved file name of snapshot.
  • Page 36 4. Log List Sort by System Logs, Motion Detection Logs and I/O Logs. In addition, System Logs and I/O Logs won’t lose data due to power failure 5. Micro SD card Choose “The 1st day” means the recoding file will be kept one day. Example: It is five o’clock now.

  • Page 37: Network Configuration

    VI Network Configuration • Configuration 1: a. Internet Access: ADSL or Cable Modem b. IP address: One real IP or one dynamic IP c. Only IP Camera connects to the internet d. For fixed real IP, set up the IP into IP Camera. For dynamic IP, start PPPoE. •...

  • Page 38: I/O Configuration

    a. Internet Access: ADSL or Cable Modem b. IP address: one real IP or one dynamic IP c. IP Camera and PC connect to the internet d. Device needed: IP sharing e. Use virtual IP, set up port forwarding in IP sharing. VII I/O Configuration 1.
  • Page 39 2. I/O Setup a. Click “I/O Setting” from the system setup page via IE, and check “Out1” to enable I/O signal. b. Click ON/OFF from the setup main page via IE to control relay out signal.

  • Page 40: Factory Default

    VIII Factory Default If you forget your password, please follow the steps to revert back to default value. • Remove the power and Ethernet cable from your camera • Put one side of electric wire in to “Default”, and the other side of electric wire in to “GND”, as the picture below.

  • Page 41: X Appendix I

    IX. Appendix I (I) The following is the Micro SD Card recommended: Transcend SDHC class4 16GB SDHC class4 32GB SDHC class4 16GB SDHC class4 32GB SDHC class6 4GB SDHC class6 8GB SDHC class6 16GB SDHC class6 4GB SDHC class6 8GB SDHC class6 16GB SDHC class10 4GB SDHC class10 8GB...

  • Page 42: Appendix

    X. Appendix II (II) 2M 1080P IP Cameras – Video Setting – Streaming 1 & Streaming 2 setting table, NVR@ Normal Mode Co-working with NVR, the listed video setting in Streaming 1 & 2 appendix table: ITEM Streaming 1 Streaming 2 Test Result Setting Setting...
  • Page 43 Video Frame Rate(fps) Video Bit rate 10Mbps 1Mbps Resolution 1920x1080 320x240 Profile Baseline Baseline Pass Bit rate Control Mode Video Frame Rate(fps) Video Bit rate 10Mbps 1Mbps Resolution 1920x1080 176x144 Profile Baseline Baseline Pass Bit rate Control Mode Video Frame Rate(fps) Video Bit rate 10Mbps 1Mbps...
