Summary of Contents for PROEL ACEX2
- Page 1 OWNER’S MANUAL STEREO COMPRESSOR ACEX2...
-
Page 2: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS CAUTION: To reduce the risk of electric shock do not remove cover (or back panel). No user serviceable parts inside. Refer servicing to qualified personnel only. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. -
Page 3: Detailed Safety Instructions
Sentences preceded by symbol contain important safety instruction. Please read it carefully. DETAILED SAFETY INSTRUCTIONS. Water and moisture: This apparatus should not be used near water (i.e. bathtub, kitchen sink, swimming pools, etc.) Ventilation: This apparatus should be placed in position that doesn’t interfere with correct ventilation. This unit, for example, should not be placed on a bed, sofa cover o similar surfaces that could cover ventilation openings, or placed in a built-in installation, such a bookcase or a cabinet that could block air flow trough ventilation openings. - Page 4 Objects or liquid entry inside the unit: Be careful that no objects fall or liquid is spilled inside the unit through ventilation openings. Safe power line use: • Keep firmly the plug and the wall outlet while disconnecting the unit from AC power. •...
- Page 5 Don’t place this unit in a bookshelf o in other places with small room. • PROEL S.P.A. is not responsible for any damage that occurs due to a wrong unit installation. Thank you for choosing one of Proel products, and for your confidence towards our brand, synonymous of professionalism, accuracy, high quality and reliability.
- Page 6 Front panel description fig. 1 1. Gate/expander section THRESHOLD level. 2. Gate/expander section CLOSE LED. 3. EFFECT switch for compressor section activation. 4. Compressor section THRESHOLD level. 5. Compressor section RATIO control. 6. Compressor section ATTACK time manual control. 7. Compressor section RELEASE time manual control. 8.
- Page 7 Installation 1. Input/output connections. This unit has two independent input/output channels (CH1 and CH2). Each channel is supplied with a balanced XLR and a balanced 6.3mm (1/4”) TRS jack. The TRS jacks can be used in an unbalanced way by just connecting tip and sleeve (TS connection) only.
- Page 8 Tip to receive external equipment signal, Ring to send unit output signal, Sleeve for both signals grounding. To do this kind of connection you need a “Y” cable that splits the ACEX2 TRS connector into two TS connectors. 3. Power supply connections •...
- Page 9 over the threshold. Try to set THRESHOLD and RATIO with AUTO ATTACK RELEASE times, searching for the best values, a good starting point for paging is with threshold around –20dB with a ratio around 2:1, then do some tests to find the better settings for your application.
- Page 10 Technical specifications Model ACEX2 Input connectors Active balanced XLR and 6,3 mm (1/4”) TRS jack Input impedance 60-kOhm balanced Max input level +21dBu balanced and unbalanced Output connectors Active balanced XLR and 6,3 mm (1/4”) TRS jack Output impedance 40-Ohm balanced...
- Page 11 This unit complies with CE Directive 73/23/CEE (Low Voltage) and following modifications 93/68/CEE, by European Specifications: EN 60065:1998 Disclaimer Proel SpA pursue a policy of continuous research and development. Proel SpA reserve the right to modify product circuitry and appearance at any moment, without prior notice..
- Page 12 PROEL S.p.A. (World Headquarters - Factory) Via alla Ruenia 37/43 64027 Sant’Omero (Te) – Italy Tel: +39 0861 81241 Fax: +39 0861 887862 E-mail: info@proelgroup.com installation.proelgroup.com...
