- Page 1 100VA eLimiter+ Installation & Operation Manual Part # 0120028-J0 Effective: 06/2015 Your Power Solutions Partner member of The Group ™...
- Page 3 Canada and USA: 1-888-462-7487 International: +1-604-436-5547 Copyright Copyright © 2015 Alpha Technologies Ltd. All rights reserved. Alpha is a registered trademark of Alpha Technolo- gies. No part of this documentation shall be reproduced, stored in a retrieval system, translated, transcribed, or transmit- ted in any form or by any means manual, electric, electronic, electromechanical, chemical, optical, or otherwise without prior explicit written permission from Alpha Technologies.
-
Page 5: Table Of Contents
Table of Contents 1. Safety �����������������������������������������������������������������������������������������������������������������������������������6 1.1 Safety Symbols .......................... 6 1.2 General Warning and Cautions ....................6 1.3 Mechanical Safety ........................6 1.4 Electrical Safety ......................... 7 2. Product Overview........................8 2.1 Introduction ..........................8 2.2 Features and Benefits ........................ 8 2.3 Product Part Numbers ....................... 9 3. ... - Page 6 6.9 Summary of Controller Software ....................33 6.10 LPS Channel Grouping ......................35 6.11 LPS Channel Custom Text ..................... 36 6.12 LPS Alarms ..........................37 7. Maintenance and Troubleshooting ..................42 7.1 Fan Tray Replacement ......................42 7.2 Fan Filter Maintenance ......................43 7.3 Troubleshooting Converter Status LEDs ..................
- Page 7 Figure 14 — CAN and fan connections on the shelf interface panel ..........24 Figure 15 — CAN Bus cabling ......................24 Figure 17 — Fan tray connections ....................25 Figure 18 — Terminal block and connector pinouts ................ 25 Figure 19 —...
-
Page 8: Safety
Keep it in a safe place. Review the drawings and il- lustrations contained in this manual before proceeding. If there are any questions regarding the safe installation or operation of this product, contact Alpha Technologies or the nearest Alpha representative. 1�1 Safety Symbols To reduce the risk of injury or death, and to ensure the continued safe operation of this product, the following symbols have been placed throughout this manual. -
Page 9: Electrical Safety
1�4 Electrical Safety WARNING! The DC input to the modules (and the converter system) – though not dangerous in volt- age – has a high short circuit current capacity that may cause severe burns and electri- cal arcing. The DC output is a potentially dangerous voltage. Do not touch the output connections when under power. -
Page 10: Product Overview
2� Product Overview 2�1 Introduction The 100VA eLimiter+ is a unique remote powering solution that meets the NEC requirements for remote power- ing of electrical devices such as iDAS (indoor distributed antenna systems), remote radios, security cameras, different sensors, access controllers and alarms. The unit can be used to distribute -48Vdc to remote equipment without the use of conduits and complies with the NEC requirement for Class 2 power limited circuits. -
Page 11: Product Part Numbers
2�3 Product Part Numbers Product Part number eLimiter+ shelf 0300156-001 eLimiter+ modules 0120028-001 CXCI+ controller 7400232-001 Fan tray 0300055-002 Air baffle 0300055-003 Fan tray replacement 0300055-004 Blanks, (2 blank modules per package) 0380070-001 0120028-J0 Rev F... -
Page 12: Product Specifications
3� Product Specifications Electrical -40 to -60Vdc Input voltage: Recommended breaker: 70A per feed 19" shelf: Recommended cable size: Minimum #6 AWG (16mm) copper rated for 110˚C Output voltage: -57Vdc Power: 98W nominal per output, ± 2W tolerance (4 outputs per module) Efficiency: >92% Regulation: <2% no load to full load <1% line Output Noise: Wide band: <50mVRMS (10kHz to 10MHz) <100mV pk-pk (10kHz to 100MHz) <60dBa @ 1m (3ft), 55˚C... - Page 13 Performance/ Features Communication Ports: CAN: Smart peripherals Ethernet: 10/100 Base-T for TCIP/SNMP features Alarm Relays: Shelf: 1x Form C Major 1x Form C Minor Fan Tray: 1x Form C fan tray alarm Alarm indicating LEDs: Module: One tri color LED per converter—see Table A page 12 Shelf: System OK (green) Minor alarm (yellow)
-
Page 14: Features
4� Features 4�1 Converter Modules A module contains four isolated DC to DC converters with a common control and supervisory circuit. An internal microcontroller monitors both the inputs and outputs of the converters, turns the converters on and off, and generates a converter fail alarm if required. -
Page 15: Cxci+ Controller
• Output short circuit ≤1V • Input voltage out of range • Heatsink / ambient temperature out of range (Over Temperature Protection) 4�2 CXCI+ Controller The CXCI+ controller is mounted in the converter system shelf and brings advanced monitoring technology to the Cordex series of converters. -
Page 16: Shelf Connections And Indicators
4�3 Shelf Connections and Indicators Connections to alarms as well as load connections are conveniently located on the side of each shelf. Major alarm relay Minor alarm relay Shelf ID rotary switch Fan power connector CAN connectors Figure 3 — Shelf connections 4�3�1 Alarm Relays (Form C Contacts) The converter shelf has an interface panel with terminal blocks for Major and Minor alarm outputs (Form C contacts), which are controlled by the CXCI+. -
Page 17: Shelf Accessories
4�4 Shelf Accessories 4�4�1 Fan Tray and Baffle Tray The optional fan tray and baffle tray are each 1RU high (Figure 5). They are typically mounted together directly below the shelf assembly. See Figure 6 on page 18. Fan status Air baffle Figure 5 —... -
Page 18: Site Evaluation And Pre-Installation
If the original container is unavailable, make sure that the product is packed with at least three inches of shock-absorbing material to prevent shipping damage. Alpha Technologies is not responsible for damage caused by improper packaging of returned products. 5�4 Check for Damage Before unpacking the product, note any damage to the shipping container. -
Page 19: System Installation
6� System Installation This chapter is provided for qualified personnel to install the system and provides cabling details and notes on cable sizing for DC applications. 6�1 General Instructions Connections to the converter system must comply with all the local codes and ordinances. 6�2 Safety Precautions WARNING! The DC input to the modules (and the converter system) –... -
Page 20: Figure 6 - Multi-Shelf System Mounting
6�4�2 Thermal Management with Fan Tray If operating more than 1 continuous shelf a fan tray is required. One fan tray can be used for up to three shelves. Three contiguous shelves require a fan tray and two baffles to meet the specified cooling requirements. Install the fan tray directly below the three converter shelves and a baffle tray below the fan tray. -
Page 21: Figure 7 - Thermal Management Without A Fan Tray
6�4�3 Thermal Management without Fan Tray When installing the eLimiter+ without a fan tray, 3RU space is required for thermal management. Each shelf requires a 1RU air space, 1 baffle tray and then an additional 1RU air space, see Figure 7. Install the first converter shelf and then leave 1 RU of air space directly above the converter shelf. -
Page 22: Input And Output Wiring
6�5 Input and Output Wiring This power system is suitable for installation as part of a Common Bonding Network (CBN) and is intended to be used in a DC-I configuration (isolated from frame ground). This system is intended to be used with a -48Vdc rectifier/ battery system at the input, and surge protectors and line terminators at the output. -
Page 23: Figure 10 - Dc Input Connections (19")
6�5�2 Connecting the DC Input NOTE: Connect the eLimiter+ to a Safety Extra Low Voltage (SELV) <60VDC input power circuit. Connections are provided for either front or rear access (Figure 10). Side-front Side-rear Figure 10 — DC input connections (19") WARNING! Ensure input feeder breakers are off before connecting inputs. -
Page 24: Figure 11 - Formex Separators Between The Inputs
6�5�3 Accessing the Front Input Terminals To use the front inputs: 1. Remove the center screw on the side cover. 2. Pull the side cover about 1/8 inch towards the front and then move it to the side. 3. Pull the front cover froward to gain access to the input terminals and straighten the underlying black separators that were folded under the side cover. -
Page 25: Figure 12 - Cut Lines For Cable Input
4. Trim the side cover between the slots as required for the cables to fit through. See Figure 12 and Figure 13. CAUTION! The cut out guidelines illustrated in Figures 12 and 13 are for reference purposes only, the actual trimming should be performed in a manner to assure minimal clearance around the incoming cables relative to their specific size. -
Page 26: Figure 16 - Can Out Terminator
6�5�4 Making CAN Bus Connections Each module communicates with the CXCI+ using CAN pro- tocol. The modules report alarms, converter output voltages, ambient temperature and the location of the module within a cabinet. Major alarm Minor alarm relay relay Fan power connector CAN connectors Figure 14 —... -
Page 27: Figure 17 - Fan Tray Connections
6�5�5 Connecting Power to the Fan Tray Power to the fans is provided by the converter shelf immediately above it. Plug the cable from the fan tray into the receptacle labeled FAN PWR in the converter shelf above it. Fan tray power cable Figure 17 —... -
Page 28: Figure 20 - Inserting The Channel Designation Card
Figure 20 — Inserting the channel designation card UNLESS OTHERWISE SPECIFIED THESE DESIGNS AND SPECIFICATIONS ARE DIM ARE IN MM CONFIDENTIAL, REMAIN THE PROPERTY OF ALPHA TECHNOLOGIES LTD., AND SHALL NOT BE COPIED OR USED WITHOUT ITS WRITTEN CONSENT X.XX 0.25 ANGULAR:... -
Page 29: Wiring The Alarm Relays
6�6 Wiring the Alarm Relays 6�6�1 Converter Shelf Two Form C relay contacts are available for Major and Minor alarms. Major Minor Alarm Alarm Connect the relays (located on the side of the controller-side of the shelf) to the local alarm-sending unit using wire gauges from #28 to #16 AWG (0.08 to 1.31 mm ). -
Page 30: Figure 23 - Group Reset Switches
6�6�3 Group Reset Configuration The group reset configuration is used to synchronize the start up or reset of multiple modules (more than 4 outputs). Group reset is used in case of fault conditions so that all outputs recover at the same time. Up to 9 modules can be configured in a daisy chain wiring scheme. -
Page 31: Installing The Controller And Converters
6�7 Installing the Controller and Converters The CXCI+ controller and converters ship as separate items and are installed after mounting the eLimiter+ shelf. 6�7�1 Installing the CXCI+ Controller STEP 1: STEP 2: Loosen the thumbscrew and Slide the locking tab to the left. remove the blank panel. -
Page 32: Figure 26 - Installing Converters
6�7�2 Installing the Converters 1. Populate the shelf sequentially starting from the slot closest to the controller or controller blanking plate. 2. Slide the module into the slot with the handle in a closed position. Some additional pressure may be required to engage the card edge connector at the rear of the shelf. -
Page 33: Figure 27 - Securing The Wires
6�7�3 Installing the Back Cover and Securing the Wires Once the recommended load wiring connections are complete secure the wires with cable ties, as in Figure 27 and then install the back cover as seen in Figure 28. Figure 27 — Securing the wires Figure 28 —... -
Page 34: System Startup
6�8 System Startup To ensure proper operation, perform the following startup and test procedure after completing the system installation wiring. 6�8�1 Procedure To meet GR-1089-CORE requirement, the Ethernet cable shall be a maximum of 6 meters in length. Start with DC input breakers off. Install the CXCI+ into the left most position. -
Page 35: Summary Of Controller Software
6�9 Summary of Controller Software NOTE: Refer to the CXCI+ user guide for controller functionality. Menu item Line Powering System > View Live Status displays a graphical view of all acquired devices: • Shelf ID • Slot ID • Per-channel information (output voltage and output current) A tabular view can be accessed by clicking the Switch to Table View link. -
Page 36: Figure 31 - Channel Information For Position 6
Clicking a row displays a pop-up window with information specific to that LPS (eLimiter+) module and its channels. Figure 31 — Channel information for position 6 The icon in the Startup/ Shutdown row indicates whether the LPS channel is powered ON (green) or OFF (black). Clicking a green icon for a particular channel commands the module to turn the output of that channel OFF. -
Page 37: Lps Channel Grouping
Therefore, the remote Shutdown should never be relied upon for powering off the de- vice for safety purposes - for example, during maintenance activities. Due to power line fluctuations, module swapping, or up-stream maintenance work, it is possible that the equipment could re-start without warning after a remote shutdown is used.”... -
Page 38: Lps Channel Custom Text
6�11 LPS Channel Custom Text The CXC provides the user two custom text fields per LPS channel. These can be used to store information such as customer name or address where the channel output is directed, or any other information the user would like to associate with the channel. -
Page 39: Lps Alarms
6�12 LPS Alarms The LPS and channel alarms are indicated on the Line Powering System > View Live Status interface with a red border Figure 34. Figure 34 — LPS alarm highlighting LPS alarms report in Alarms > View Live Status (Figure 35), Alarms > Configure Alarms (Figure 36), and Event Log interfaces. -
Page 40: Figure 36 - Configuring Lps Alarms
Figure 36 — Configuring LPS alarms 6�12�1 Configuring a Fan Tray Alarm When the fan tray is installed and connected to the CAN bus, it shows up as a signal in the Signals > View Live Status screen as shown in Figure 37 The signal is named Fan Fail so an alarm can be generated if any of the six fans fail. -
Page 41: Figure 38 - Configuring A Custom Alarm
1. Select the menu item Alarms > Configure Alarms (Figure 36). 2. From the Alarm Configuration drop-down menu, select Custom Alarms� 3. Select the Enable check box of an unused custom alarm (Custom 1 is shown in Figure 38). 4. From the Priority drop down menu, set the alarm Priority to Major. Figure 38 —... -
Page 42: Figure 41 - Manage Editable Text Files
Change the name of Custom 1 to Fan Fail: 1. Click Logs & Files > Manage Editable Text Files as shown in Figure 41. Figure 41 — Manage Editable Text Files 2. Click in the text box for Custom 1 and change the name to Fan Fail (Figure 42). Figure 42 —... - Page 43 6�12�2 Controller Reset Soft Reset A soft reset enables the Controller to finish saving files to flash memory before a power down or restart. When pressed momentarily, the unit beeps twice then resets. The front-panel LEDs illuminate temporarily, but will extinguish after the system has finished its 15-second self-test.
-
Page 44: Maintenance And Troubleshooting
7� Maintenance and Troubleshooting Although very little maintenance is required with Alpha systems, routine checks and adjustments are recommended to ensure optimum system performance. Only qualified service personnel should do the repairs. WARNING! Use extreme care when working inside the unit while the system is energized. Do not make contact with live components or parts. -
Page 45: Fan Filter Maintenance
7�2 Fan Filter Maintenance Regular intervals for fan filter maintenance should be set for every 90 days for the filter to be cleaned or replaced. To replace the fan filter use fan filter kit P/N 0380256-xxx. The following are manufacturers cleaning instructions. Method 1 &... -
Page 46: Troubleshooting Converter Status Leds
7�3 Troubleshooting Converter Status LEDs 7�3�1 Card Alarms (All 4 LEDs) LED State Individual Converter status Action Green Normal None Remote shutdown enabled on Can be reset by toggling module/card Startup / Blinking Green whole module Shutdown button through the CXCI+ controller. Shelf is not compatible with the Ensure that the shelf is correct. -
Page 47: Troubleshooting The Fan Tray Status Led
7�4 Troubleshooting the Fan Tray Status LED LED State Module Status Action Green Normal None Ambient Temperature < 20 C None Blinking Green Yellow Recoverable: Resets automatically when ambient temperature • Ambient temperature high reduces to approximately 85°C or below. Recoverable: Fan operation is disabled if input voltage is not within the Blinking Yellow • Input Voltage out of range (High/ range of 40-60Vdc. -
Page 48: Replacing The Controller
7�5 Service Kits Blanking plate kit (quantity 2) 0380070-001 Alarm relay replacement kit 0380148-001 (includes PCB and bracket) Fan input power cable 8700590-001 Can Bus terminator 5450228-001 Fan tray replacement assembly (19") 0300055-004 Fan filter kit 0380256-001 DC input cover kit 0380249-001 Alarm relay cables (6ft) 8700649-001... -
Page 49: Replacing An Alarm Relay
7�8 Replacing an Alarm Relay The following two procedures cover how to replace an alarm relay for shelves with or without the CXCI+ controller. 7�8�1 Alarm Relay Replacement for a Shelf With or Without a CXCI+ Controller The system is operational even without the controller during the alarm relay interface board change. 1. - Page 50 4. Remove the two screws and then slowly slide the entire interface bracket out for about 2 inches. At this distance, the ribbon cable (not shown) should still maintain some slack. Outlined is part of the fan tray power cable (for reference ) it may or may not to be connected depending on the required system setup .
-
Page 51: Warranty And Service Information
8� Warranty and Service Information Alpha Technologies Ltd warrants all equipment manufactured by it to be free from defects in parts and labor, for a period of two years from the date of shipment from the factory. The warranty provides for repairing, replacing or issuing credit (at Alpha’s discretion) for any equipment manufac- tured by it and returned by the customer to the factory or other authorized location during the warranty period. -
Page 52: Acronyms And Definitions
9� Acronyms and Definitions Alternating current ANSI American National Standards Institute American Wire Gauge British thermal unit Controller area network Canadian Electrical Code Canadian Standards Association Cordex™ series; e.g., CXC for Cordex System Controller Direct current Electromagnetic compatibility Electromagnetic interference Electromagnetic Compatibility and Radio Spectrum Matters Electrostatic Discharge Federal Communications Commission (for the USA) Ground fault interrupt Internet Protocol... -
Page 53: 10� Certification
10� Certification About CSA and NRTL CSA (Canadian Standards Association also known as CSA International) was established in 1919 as an independent testing laboratory in Canada. CSA received its recognition as an NRTL (Nationally Recognized Testing Laboratory) in 1992 from OSHA (Occupational Safety and Health Administration) in the United States of America (Docket No. - Page 60 Canada and USA: 1-888-462-7487 International: +1-604-436-5547 Visit us at www.alpha.ca Due to continuing product development, Alpha Technologies reserves the right to change specifications without notice. Copyright © 2015 Alpha Technologies. All Rights Reserved. Alpha® is a registered trademark of Alpha Technologies.
