  • Page 1 ERVICE ANUAL & PARTS LIST REF. NO. S/M-980 JAN. 2007 MODULE NO. QW-4762 QW-4778 G-1800D G-011D INDEX (WITHOUT PRICE)

  • Page 2: Table Of Contents

    CONTENTS Page 1. SPECIFICATIONS: MODULE QW-4762/4778 ........... 1 2. OPERATION CHART: MODULE QW-4762/4778 ........2 3. DRAWINGS: MODULE QW-4762/4778 3-1. LCD DIAGRAM .................... 10 3-2. CHECKING TERMINALS AND COMPONENTS ......... 12 4. EXPLODED VIEW: MODULE QW-4762/4778 .......... 13 5. PARTS LIST: MODULE QW-4762/4778 ........... 14 6.

  • Page 3: Specifications: Module Qw-4762/4778

    1. SPECIFICATIONS: MODULE QW-4762/4778 Item Detail Battery CR1220 Battery life QW-4762: Approx. 3 years QW-4778: Approx. 3 years QW-4762: 0.7690 µA maximum Current consumption QW-4778: 0.4970 µA maximum Alarm system Piezo plate on Cover/Back ±15 sec./month Accuracy Accuracy setting system Trimmer capacitor Accuracy checking See page 18...

  • Page 4: Operation Chart: Module Qw-4762/4778

    2. OPERATION CHART: MODULE QW-4762/4778 MODULE QW-4762 * The operation chart will be added in the next revision. — 2 —...
  • Page 5 — 3 —...
  • Page 6 — 4 —...
  • Page 7 — 5 —...
  • Page 8 MODULE QW-4778 * The operation chart will be added in the next revision. — 6 —...
  • Page 9 — 7 —...
  • Page 10 — 8 —...
  • Page 11 — 9 —...

  • Page 12: Drawings: Module Qw-4762/4778

    3. DRAWINGS: MODULE QW-4762/4778 3-1. LCD DIAGRAM MODULE QW-4762 DST0 AUTO EL COM. COM. SEG. SEG. x12y1 x12y5 x12y4 x12y3 x12y2 x11y1 x11y5 x11y4 x11y3 x11y2 x10y5 x10y4 x10y3 x10y2 x10y1 x9y1 x9y5 x9y4 x9y3 x9y2 x8y5 x8y4 x8y3 x8y2 x8y1 x7y1 x7y5...
  • Page 13 MODULE QW-4778 AUTO EL pm 0 DST 0 COM. LC 1 LC 2 LC 3 LC 4 LC 5 COM. LC 1 LC 2 LC 3 LC 4 LC 5 SEG. SEG. x15y5 x15y4 x15y3 x15y2 x15y1 x14y5 x14y4 x14y3 x14y2 x14y1 x13y5...

  • Page 14: Checking Terminals And Components

    3-2. CHECKING TERMINALS AND COMPONENTS Short pad for switching modules Short pad for switching modules KI3-KI3/KI5: Open (No Soldering) KC2-KI2: Open (No Soldering) KI5-KI3/KI5: Short (Soldering) KC3-KI2: Open (No Soldering) GND-OVD: Short (Soldering) KC4-KI2: Open (No Soldering) GND-KI7: Open (No Soldering) KI4-KI1/KI4: Open (No Soldering) K13/K15 VOSC...

  • Page 15: Exploded View: Module Qw-4762/4778

    4. EXPLODED VIEW: MODULE QW-4762/4778 7 (10201541 ) 12 (10137169) 11 (10137168) 7 (10201541 ) 9 (10260667) QW4762: 4a (10250499) 4b (10250965) QW4778: 4 (10253673) QW4762: 3a (10250500) 2 (76410299) 3b (10250966) PCB Ass'y QW4778: 3 (10253674) 8 (10243739) 14 (10209124) 19 (72240652) 16 (72300665) 20 (10109742)

  • Page 16: Parts List: Module Qw-4762/4778

    5. PARTS LIST: MODULE QW-4762/4778 MODULE QW-4762 QW-4762AT 1 QW-4762AT-91 2 QW-4762AT-92 Note: 1. Prices and specifications are subject to change without prior notice. 2. Spare parts are classified as follows according to their importance in after-sales service. A Rank ----------------------------------------- Important C Rank ----------------------------------------- Not Important 3.
  • Page 17 Q'TY Item Code No. Parts Name Specification 10137169 PLATE/TERMINAL 2787-2 RJQ515399-001V02 10201055 SCREW/1300-1 Q436969-1V03 10209124 SCREW 4323 RJQ526942-001V01 10243741 SHEET/INSULATION RJQ533683-001V01 72300665 SPRING/COIL 1349-1 Q450872-1 10201015 SPRING/COIL 2958 RJQ525615-001V01 10224334 SPRING/COIL 4359-1 RJQ529996-001V01 72240652 WASHER Q421691-1 10109742 WHEEL/HOUR Q372649-1 For the prices and minimum order/supply quantities of the above parts, refer to the Parts Price List P.P.L.-638. Notes: Q - Used quantity R - Rank...
  • Page 18 MODULE QW-4778 QW-4778AT 1 QW-4778AT-01TK Note: 1. Prices and specifications are subject to change without prior notice. 2. Spare parts are classified as follows according to their importance in after-sales service. A Rank ----------------------------------------- Important C Rank ----------------------------------------- Not Important 3.
  • Page 19 Item Code No. Parts Name Specification Q'TY 72300665 SPRING/COIL 1349-1 Q450872-1 10201015 SPRING/COIL 2958 RJQ525615-001V01 10224334 SPRING/COIL 4359-1 RJQ529996-001V01 72240652 WASHER Q421691-1 10109742 WHEEL/HOUR Q372649-1 For the prices and minimum order/supply quantities of the above parts, refer to the Parts Price List P.P.L.-638. Notes: Q - Used quantity R - Rank...

  • Page 20: Precautions For Repair: Module Qw-4762/4778

    6. PRECAUTIONS FOR REPAIR: MODULE QW-4762/4778 6-1. AC (ALL CLEAR) AND REMOVING OF MODULE 1. Perform AC (ALL CLEAR) when inserting a new battery, or else the memories and/ or counters may give erratic displays. Touch the AC contact and the main plate with the metallic tweezers. The contact should be made for about two seconds.
