2.3 Operating Notes:

Do NOT
Shut off the
power
supply

2.4 Notes on Moving and Repairing the Unit:

Caution
Suitably
qualified
engineer
Do NOT
Transporting
the Unit

2.5 Operation Notes:

Siting the
Unit
Shut off the
power
You MUST

2.6 General Requirements:

IMPORTANT: PLEASE READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING
THE ESP Ecocent ("DHW ASHP" or "unit"). INCORRECT INSTALLATION WILL INVALIDATE ANY
GUARANTEE.
PLEASE NOTE THAT THERE ARE ESSENTIALLY 2 UNITS COMBINED INTO ONE IN THE ESP
ECOCENT AND YOU MUST BE SURE TO UNDERSTAND BOTH ELEMENTS - THE INDIRECT HOT
WATER CYLINDER AND THE AIR SOURCE HEAT PUMP. PLEASE ALSO NOTE THE ECOCENT
CAN BE INSTALLED IN EITHER A VENTED OR UNVENTED SYSTEM.

3.0 Component Checklist:

Before commencing installation of the unit, check that all the components for your unit are contained in the
package. The following components are supplied as standard with any unit being installed in a
"mains pressure" configuration:
• Factory fitted immersion heater (s) and thermal controls.
• Cold Water Combination Valve (comprises Pressure Reducing Valve, Strainer, and Check Valve).
• Expansion Core Unit (comprises Check Valve and Expansion Valve).
• Temperature/Pressure Relief Valve (set at 90 - 95°C/1 Mpa (7bar).
• Tundish (included in Cold Water Combination Valve pack).
2of 36
Do not push anything into the fan blades when running and
make sure that children cannot access the unit or play close
to the unit.
If there is an unusual sound or smell coming from the unit,
immediately shut off the power supply and call your
installation engineer.
This unit has a high centre of gravity. This unit must be
strapped to prevent it falling over when in transit.
When moving the unit or carrying out repair work please be
sure to use only a suitably qualified engineer.
Do NOT try to install, move or repair the unit yourself – it is
NOT worthwhile running the risk of injury.
The unit must be transported in the vertical position. It can
be tilted up to 60° from the horizontal axis.
The unit must only be installed indoors – the unit is neither
designed for, nor suitable for, installation outside. The Unit
needs to be sited where the ambient temperature never
goes below 5 degrees. If the unit is to be left unused for any
significant period of time during which the ambient
temperature could cause the unit or pipe work from the unit
to freeze, it should be drained down.
When cleaning the unit, shut off the power supply.
You must use a suitable power supply that is appropriately
fused.
ESP400-10-200L and 300L
