MK Diamond Products MK-1280 Owner's Manual

Brick/paver saw
Hide thumbs Also See for MK-1280:
Table of Contents

Advertisement

Quick Links

Download this manual
www.mkdiamond.com
MK-1280 ELECTRIC SAW
BRICK/PAVER SAW
OWNERS MANUAL &

PARTS LIST

Electric Baldor Part # 167492
Revision 103
03.2017
Manual Part No. 168786
Caution: Read all safety and operating instructions
before using this equipment. This owners manual
MUST accompany the equipment at all times.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK-1280 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MK Diamond Products MK-1280

Summary of Contents for MK Diamond Products MK-1280

  • Page 1: Parts List

    MK-1280 ELECTRIC SAW BRICK/PAVER SAW OWNERS MANUAL & PARTS LIST Electric Baldor Part # 167492 Revision 103 03.2017 Manual Part No. 168786 Caution: Read all safety and operating instructions before using this equipment. This owners manual MUST accompany the equipment at all times.
  • Page 2 MK-1280 ELECTRIC SAW INTRODUCTION We at MK Diamond want to congratulate you on selecting the MK-1280 Electric Saw. We are certain that you will be pleased with your purchase. MK Diamond takes pride in producing the finest prod- ucts in the industry.

  • Page 3: Table Of Contents

    MK-1280 ELECTRIC SAW TABLE OF CONTENT SAFETY Page Safety Message/Alert Symbols, Warnings Hazard Symbols General, Maintenance, Saw Safety California Proposition 65 Message Electrical Requirements and Ground Instructions 8-10 Product Specifications Safety Labels Safety Labels & Location PRODUCT SPECIFICATIONS Unpacking Contents...
  • Page 4 MK-1280 ELECTRIC SAW SAFETY Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life.
  • Page 5 MK-1280 ELECTRIC SAW SAFETY MAKE THE WORKSHOP KID PROOF Make the workshops kid proof by using padlocks, master switches or by removing starter keys. DO NOT FORCE THE TOOL A power tool will do a job better and safer operating at the rate for which it was designed.

  • Page 6: Safety

    MK-1280 ELECTRIC SAW SAFETY HAZARD SYMBOLS ELECTRICAL SHOCK NEVER touch electrical wires or components while the engine is running. They can be sources of electrical shock which could cause severe injury or burns. ROTATING PARTS Keep hands, feet, hair, and clothing away from all moving parts to prevent injury.

  • Page 7: California Proposition 65 Message

    MK-1280 ELECTRIC SAW SAFETY USE RECOMMENDED ACCESSORIES Consult the owner’s manual for recommended accessories. Using improper accessories may increase the risk of personal or by-stander injury. NEVER STAND ON THE TOOL Serious injury could occur if a power tool is tipped, or if a cutting tool is unintentionally contacted.

  • Page 8: Electrical Requirements And Ground Instructions

    ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS In order to prevent potential electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! WARNING In case of a malfunction or breakdown, grounding provides a path of least resistance for electric cur- rent to reduce the risk of electric shock.
  • Page 9 WARNING To avoid the possibility of the appliance plug or receptacle getting wet, position the machine to one side of a wall mounted receptacle. This will prevent water from dripping onto the receptacle or plug. A “drip loop,” shown in the picture below, should be arranged by the user to properly position the power cord relative to the power source.
  • Page 10 MK-1280 ELECTRIC SAW SAFETY WARNING To reduce the risk of electrocution, keep all connections dry and off the ground. Do not touch the plug with wet hands. WARNING Use of under sized extension cords result in low voltage to the motor that can result in motor burnout and premature failure.

  • Page 11: Product Specifications

    GENERAL DESCRIPTION The MK-1280 Electric Saw is engineered as portable brick saw powered by a Baldor 2 Hp motor. The saw is capable of cutting masonry up to five (5.75) inches (127 mm) in height, and twenty-eight (28) inches (711 mm) in length in a single pass.
  • Page 12 MK-1280 ELECTRIC SAW SAFETY OPERATION & SAFETY DECALS The MK-1280 Saw is equipped with a number of safety decals provided for operator safety and main- tenance information. Should any of these decals become unreadable, replacements can be obtained by calling (800) 262-1575.
  • Page 13 MK-1280 ELECTRIC SAW SAFETY SAFETY DECAL LOCATIONS Fig. 4 MK-1280 Safety Decal Locations Decal Location Description Motor - Front Warning - Silica Frame Service or Warranty Information Belt Guard/Blade Guard Caution - Guards in Place Motor -Front Warning - Read Manual...

  • Page 14: Unpacking

    This owners manual turned to the dealer where it was purchased. This warranty DOES NOT cover normal wear or damage resulting from operator abuse. In no event shall MK Diamond Products, MUST accompany the equipment at all times.

  • Page 15: Transport

    Remove the Movable Cutting Table when transporting the MK-1280 Electric Saw. NOTE: The MK-1280 Electric Saw is designed with handles on the front & rear of the saw for ease of transport. To transport –...

  • Page 16: Assembly

    MK-1280 ELECTRIC SAW ASSEMBLY MOVABLE CUTTING TABLE INSTALLATION Fig. A Fig. B Fig. C While holding the front, position Seat movable Cutting Table Verify movable Cutting Table movable Cutting Table roller roller wheels on saw Guide Rails is seated correctly by moving...

  • Page 17: Diamond Blade Installation

    MK-1280 ELECTRIC SAW ASSEMBLY DIAMOND BLADE INSTALLATION NOTE: When installing the diamond blade retaining-bolt, ensure the threads of the bolt are aligned with the threads of the blade shaft so as not to “cross-thread” the bolt. Fig. A Fig. B Fig.

  • Page 18: Pre-Start Inspection

    Verify Movable Cutting Table Verify Blade correct for mate- excessive grooves moves freely and inspect rial being cut engine Fig. D Inspect MK-1280 Electric Saw for general damage, loose con- nections and hardware WET CUTTING Fig. A Fig. B Attach Hose...

  • Page 19: Cutting

    MK-1280 ELECTRIC SAW STARTUP DRY CUTTING Fig. A Attach Vacuum Hose to Vacuum Port CUTTING CAUTION DO NOT FORCE TOOL, it will do the job better and safer at the rate for which it was designed. NOTE: Skip step C, if cutting dry.

  • Page 20: Cleanup

    Roller Wheels engine) with soap and clean clean water water INITIAL MAINTENANCE Perform the following after initial purchase and operation of the MK-1280 Electric Saw. Fig. A Check and adjust V-belt tension following first 48 hours of opera- tion. See Micro V-belt Inspection MONTHLY MAINTENANCE The following should be performed monthly.

  • Page 21: Maintenance

    MK-1280 ELECTRIC SAW MAINTENANCE BLADE DRESSING Like most cutting instruments, a diamond blade performs best when it is dressed. Over time and use, diamonds on the outer edge will become smoothed or “glazed” over. This will reduce grinding efficiency and may cause the blade to “wander” or bend giving the illusion of an alignment problem.
  • Page 22 MK-1280 ELECTRIC SAW MAINTENANCE PROTECTIVE WOODEN STRIP REPLACEMENT The protective wooden strip is to protect the Movable Cutting Table from damage during operation. Over time, the wooden strip will become grooved from use. A grooved wooden strip will not support masonry during cutting causing the blade to “break through”...
  • Page 23 MK-1280 ELECTRIC SAW MAINTENANCE BELT INSPECTION, ADJUSTMENT AND REPLACEMENT 1. When a new belt is installed, it should be inspected and re-tensioned after the NOTE: first forty-eight (48) hours of operation. MICRO-V BELT Fig. A Fig. B Fig. C Remove Outer Belt Guard...

  • Page 24: Troubleshooting

    MK-1280 ELECTRIC SAW TROUBLESHOOTING Turn the ON/OFF switch to the OFF position and place the Fuel Valve in the WARNING CLOSED position before performing the following. BLADE WILL NOT CUT PROPERLY Fig. A Fig. B Fig. C Check for Smoothness or...

  • Page 25: Troubleshooting

    MK-1280 ELECTRIC SAW TROUBLESHOOTING & CART ASSEMBLY BLADE STOPS TURNING Fig. A Fig. B Verify the motor is running, if Check Micro-V Belts (See Micro-V not restart (See Setup, Start- Belt Inspection, Adjustment and up, Adjustment, Operation Replacement) and Shutdown)
  • Page 26 MK-1280 ELECTRIC SAW CART ASSEMBLY HANDLE ASSEMBLY Fig. A Fig. B Place handle in the middle of tow Place washer and Nylok nut on bracket. Slide one washer on to end of bolt and tighten bolt and slide through hole LOCK ASSEMBLY Fig.
  • Page 27 MK-1280 ELECTRIC SAW CART ASSEMBLY SETTING BRAKE Fig. A To set brake press “on” the lever on back casters The wheels and casters each have a zerk fitting that needs to be lubricated every 6 NOTES: months or as needed.
  • Page 28 NOTES...
  • Page 29 NOTES...
  • Page 30 MK-1280 ELECTRIC SAW EXPLODED VIEW FIGURE 1 - MK-1280 PAVER SAW - P/N 167492...
  • Page 31 PULLEY, 10J28 X 5/8 BORE 160949 FITTING, 1/2 NPT COUPLER 164208 MASONRY LABEL SHEET (NOT SHOWN) 166011 FRAME, MAIN MK-1280 166555 BACKSPLASH, MK-1280 166576 ASSY, TABLE, MK-1280 166577 ASSY, BLADE GUARD, 16”, MK-1280 166581 GUIDE, TENSION 167750 BRACKET, BELT GUARD 167763 CAP, VACUUM 167777...
  • Page 32 MK-1280 ELECTRIC SAW EXPLODED VIEW FIGURE 2 - MK-1280 PAVER SAW - P/N 166561...
  • Page 33 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 2 - MK-1280 PAVER SAW - P/N 166561 ITEM DESCRIPTION PART# OWNERS MANUAL, MK-1280 168786 ASSY, ARBOR, ELEC 1280 168712 GUARD, BELT, INNER 168713 MOUNT, MOTOR, ELEC 1280 168714 MTR, 2HP 115/230V 60 HZ...
  • Page 34 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 3 - ASSY, TABLE - P/N 166577 ITEM DESCRIPTION PART# WHEEL, CONVEYOR CART 133090 SCREW, HEX HD, 1/4 - 20 X 3/4 152370 NUT, HEX W/WSHR, 1/4 - 20 153941 NUT, HEX, TW, 5/16 - 18...
  • Page 35 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 4 - ASSY, ARBOR - P/N 166579 ITEM DESCRIPTION PART# KEY, 3/16 SQ X 1 - 1/8 150344 BEARING, ARBOR HOUSING 154594 CASTING, 2000/5000 ARBPR - COMP 154637 SCREW, 5/16 - 18 X 3/8 SOCKET HEAD SET...
  • Page 36 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 5 - ASSY, 16” BLADE GUARD - P/N 166581 ITEM DESCRIPTION PART# ELBOW, 1/4 MNPT STREET 154615 FITTING, 1/4 MNPT X 3/8 BARB 154659 SCREW, HEX HEAD 3/8 - 16 X 1 - 1/2 LG.

  • Page 37: Assy, Cart

    MK-1280 ELECTRIC SAW PARTS LIST FIGURE 6 - ASSY, CART - P/N 167437 ITEM DESCRIPTION PART# NUT, 3/8 - 16 HEX 101188 WASHER, FLAT, USS, 3/8 101360 WASHER, 3/8 SPLIT LOCK 150925 NUT, 3/8 - 16 NYLOK HEX 152505 SCREW, 3/8 - 16 X 2-1/4 HEX HEAD...

  • Page 38: Ordering Information

    ORDERING & RETURN INSTRUCTIONS ORDERING INFORMATION You may order MK Diamond products through your local MK Diamond distributor or, you may order direct from MK Diamond. When ordering direct from MK Diamond, please have the following information ready before calling: •...
  • Page 39 © COPYRIGHT 2017, MK DIAMOND PRODUCTS, INC. ALL RIGHTS RESERVED. The MK Diamond logo is a registered trademark of MK Diamond Products, Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their re- spective owners and used with permission.
  • Page 40 MK-1280 ELECTRIC SAW SERIES OWNERS MANUAL & PART LIST MK Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 845-5830 Phone: (310) 539-5221 Fax: (310) 539-5158 www.mkdiamond.com...
