Document Ref:
0420805
Date:
October 2003
This confidential document was prepared by the staff of Valeport Limited, the Company, and is the property of the
Company, which also owns the copyright therein. All rights conferred by the law of the copyright and by virtue of
international copyright conventions are reserved to the Company. This document must not be copied, reprinted or
reproduced in any material form, either wholly or in part, and the contents of this document, and any method or technique
available therefrom, must not be disclosed to any other person whatsoever without the prior written consent of the
Company.
Valeport Limited,
St. Peter's Quay,
Totnes,
Devon, TQ9 5EW,
UK
As part of our policy of continuous development, we reserve the right to alter, without prior notice, all specifications,
designs, prices and conditions of supply for all our equipment.
Copyright ©2003
MIDAS Surveyor Operating Manual
VALEPORT LIMITED
M
Surveyor
IDAS
Operation Manual
Tel:
Fax:
e-mail:
Web:
Page 1
© Valeport Limited 2003
+44 (0)1803 869292
+44 (0)1803 869293
sales@valeport.co.uk
www.valeport.co.uk
0420805d.doc
