Kurz B-Series Operation Manual

B-series flow meter

Hide thumbs Also See for B-Series:

Operation manual (165 pages)

Table Of Contents

Table of Contents

Quick Links

Complex Technology Made Simple

B-Series Flow Meter

Operations Guide

368042A

Technical Reference

Kurz Instruments, Inc.

2411 Garden Road

Monterey, CA 93940

800-424-7356 / 831-646-5911

www.kurzinstruments.com

Table of Contents

Need help?

Do you have a question about the B-Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Kurz B-Series

Page 1 Technical Reference Complex Technology Made Simple B-Series Flow Meter Operations Guide Kurz Instruments, Inc. 2411 Garden Road Monterey, CA 93940 800-424-7356 / 831-646-5911 www.kurzinstruments.com 368042A...
Page 2 Kurz Instruments, Inc., reserves the right to make engineering changes, product improvements, and product design changes without reservation and without notification to its users. Consult your Kurz Instruments, Inc. representative or a factory applications engineer for information regarding current specifications. Kurz Instruments, Inc. assumes no liability for damages or injuries (consequential or otherwise) caused by the improper use and/or improper installation of this product or where this product is used in any application other than what it was designed for and intended. Kurz Instruments, Inc. expressly denies any responsibility if this product has been modified without Kurz Instruments, Inc. written approval or if this product has been subjected to unusual physical or electrical stress, or if the original identification marks have been removed or altered. Equipment sold by Kurz Instruments, Inc. is not intended for use in connection with any nuclear facility or activity unless specifically sold for such applications and specific conditions for such usage are detailed. If the equipment is used in a nuclear facility or activity without supporting quotation, Kurz Instruments, Inc. disclaims all liability for any damage, injury, or contamination, and the buyer shall indemnify and hold Kurz Instruments, Inc., its officers, agents, employees, successors, assigns, and customers, whether direct or indirect, harmless from and against any and all losses, damages, or expenses of whatever form and nature (including attorneys fees and other costs of defending any action) which they, or any of them, may sustain or incur, whether as a result of breach of contract, warranty, tort (including negligence), strict liability or other theories of law, by reason of such use. The Kurz logo is a trademark of Kurz Instrument, Inc., registered in the U.S. and other countries. Use of the Kurz logo for commercial purposes without the prior written consent of Kurz Instruments, Inc. may constitute trademark infringement in violation of federal and state laws. MetalClad, Series MFTB, Series 454FTB, Series 504FTB, Series 534FTB, and KBar‐2000B are trademarks of Kurz Instruments, Inc. Other company and product names mentioned herein are trademarks of their respective owners. Mention of third‐ party products is for informational purposes only and constitutes neither an endorsement nor a recommendation. Kurz Instruments, Inc., assumes no responsibility with regard to the performance or use of these products. Kurz Instruments Inc. Kurz Technical Support 2411 Garden Road Customer Service Monterey, CA 93940 800‐424‐7356 (toll free) 831‐646‐5911 (main) www.kurzinstruments.com 831‐646‐8901 (fax) service@kurzinstruments.com B‐Series Flow Meter Operations Guide...
Page 3: Table Of Contents
Boot Mode ...................... 1‐5 Run Mode ....................... 1‐7 Static Variables ..................1‐7 Scrolled Variables ..................1‐8 Display Mode ....................1‐9 Program Mode ....................1‐11 Log Mode ......................1‐20 Event Log ....................1‐20 Min/Max Log ................... 1‐20 Trend Log ....................1‐21 Config Log ....................1‐21 Run Data Log .................... 1‐21 Extended Utilities Mode ................. 1‐22 Quick Reference Card ..................1‐24 Kurz B‐Series Operations Guide...
Page 4 Setting Up Drift Check ................2‐28 Specifying Drift Check Triggers ............... 2‐29 Specified‐Time Interval Drift Check ..........2‐29 External Digital Input ............... 2‐30 Extended Utilities Mode Options ............. 2‐30 Modbus Protocol Write Coil Command ........... 2‐32 Modbus Status Registers ..............2‐32 HART Interface ..................2‐33 Configuring the Built‐In Flow Controller ............2‐33 Setting Up the Flow Controller ............... 2‐34 Setting Up a PID ..................2‐34 Accessing the PID Data Menu ..............2‐35 Setting Up the PID 4‐20 mA Control Output ........... 2‐37 Setting Up the External Input for PID Remote Reference ....... 2‐38 iv Kurz B‐Series Operations Guide...
Page 5 Determining the PID Control Mode ............2‐40 PID Control in Automatic Mode ............2‐40 PID Control in Manual Mode ............2‐40 Viewing the PID External Input Current ..........2‐41 Manually Tuning A PID Loop ..............2‐42 Changing the WGF Vapor Correction Factor ..........2‐44 Setting Flow Meter Modbus Connectivity ............. 2‐45 Cleaning A Sensor ..................2‐47 Using the Integrated Purge Controller ........... 2‐47 Wiring for the Purge Controller .............. 2‐48 Assigning a Relay to the Purge Function ..........2‐48 Changing the Purge Controller Configuration ........2‐49 Operating and Monitoring Purge Cleaning Using Modbus ....2‐51 Operating and Monitoring Purge Cleaning Using HART ......2‐51 Automatically Triggering Drift Check and Purge ........2‐52 Kurz B‐Series Operations Guide ...
Page 6 vi Kurz B‐Series Operations Guide...
Page 7: List Of Tables
Log Mode .................. 1‐20 Table 1‐5. Extended Utility Mode .............. 1‐22 Chapter 2 B‐Series Flow Meter Menu Applications Table 2‐1. 4‐20 mA Output Functions ............2‐15 Table 2‐2. Temporary 4‐20 mA Process Measurement Override ....2‐15 Table 2‐3. Relay Functions ................. 2‐18 Table 2‐4. Extended Utility Mode (Drift Options) ........2‐30 Table 2‐5. Summary of flow controller capabilities ........2‐33 Table 2‐6. Modbus Communication Parameters ........2‐45 Kurz B‐Series Operations Guide ...
Page 8: List Of Figures
B‐Series Flow Meter Modes & Menus Figure 1‐1. Flow meter user interface ............1‐2 Figure 1‐2. Flow meter display screen ............1‐4 Figure 1‐3. Menu suboption indicator ............1‐4 Figure 1‐4. User interface quick reference card .......... 1‐24 Chapter 2 B‐Series Flow Meter Menu Applications Figure 2‐1. 4‐20 mA operation with the NE‐43 alarm ......... 2‐17 Figure 2‐2. Examples of system responses ..........2‐43 Figure 2‐3. Masked purge blast ..............2‐48 Figure 2‐4. Hart Sensor Purge Setup menu ..........2‐52 Kurz B‐Series Operations Guide viii...
Page 9: Preface
Preface Kurz B‐Series Operations Guide...
Page 10: Before You Begin
Before You Begin The device warranty is void if the device is not installed in accordance with the Important specified installation requirements. Read and thoroughly understand the installation requirements before attempting to install the device. If you have any questions, contact your Kurz customer service representative before attempting installation. Using this Manual Kurz Instruments, Inc., documentation includes manuals, product literature, Adobe Acrobat PDF files, and application online Help files. The Kurz Instruments CD contains all the available documentation files. To read PDF files, download the free Adobe Acrobat Reader from www.adobe.com. The Kurz Instruments Web site provides additional information: World Wide Web: www.kurzinstruments.com • Email: service@kurzinstruments.com • Documentation links to the most current manuals and literature • You can access device support in the following ways: Main: 831‐646‐5911 • Phone: 800‐424‐7356 • Fax: 831‐646‐8901 • Manual Conventions The following table lists conventions used in the Kurz Instruments, Inc., documentation, and gives an example of how each convention is applied. Table 1. Conventions used in this manual Convention For Example Text type, click, or select (for example, ...
Page 11: System Requirements
System Requirements The B‐Series use the XMODEM communication protocol via USB port, or the MODBUS protocol via RS‐485 port or MODBUS TCP/IP. The Kurz USB device driver or FTDI USB device driver must be installed before attempting to connect a computer with a B‐Series device via a USB cable. The B‐Series devices require: A two‐wire shielded cable for Modbus RTU. • For the XMODEM protocol, a USB Type A‐to‐mini B cable. • The Kurz USB device driver or FTDI USB device driver must be installed Note before attempting to connect a computer with a B‐Series device via a USB cable. For the Modbus TCP/IP protocol, an Ethernet cable to a Modbus TCP/IP to RS‐485 gateway. • Software Requirements KzComm is supported on Windows XP, Windows Vista, Windows 7, and Windows 8. All platforms require up‐to‐date service packs. On Windows Vista, downloading the Trend Log has infrequently caused Note the operating system to freeze (no screen activity). Restart the computer as described in your computer hardware manual. Basic computer knowledge is necessary for copying and moving files, navigating file structures, identifying file types, and installing applications. You will need a decompression utility to extract files from compressed file packages. The Kurz USB device driver or FTDI USB device driver must be installed before attempting to connect a computer with a B‐Series device via a USB cable. Both drivers are available during the KzComm installation, on the Kurz customer CD in the USB Device Driver folder, and on the Kurz website (kurzinstruments.com). The FTDI USB driver is a 64‐bit virtual COM port (VCP) driver available from the FTDI Chip website (ftdichip.com). Kurz B‐Series Operations Guide...
Page 12 Kurz B‐Series Operations Guide...
Page 13: B-Series Flow Meter Modes & Menus
Chapter 1 B-Series Flow Meter Modes & Menus Overview This section describes the user interface for the B‐Series flow meter and provides the menu structure for each mode: Boot‐Up mode • Run Mode • Display mode • Program mode • Log mode • Extended Utilities mode • This chapter is intended for users accessing the flow meter menus using the local keypad and display. However, the menus and commands remain the same even if you are using KzComm or a terminal emulator with a blind device. Refer to the KzComm User’s Guide for information about KzComm. Kurz B‐Series Operations Guide 1–1...
Page 14: Flow Meter User Interface
J K L M N O P Q R S T U V W X Y Z Figure 1‐1. Flow meter user interface There are six operating modes for the meter: Boot‐up mode • Occurs during a power cycle when the meter performs self‐tests for diagnostics. Run mode • An installed meter is normally in Run mode to show the flow and temperature of the processed gas. Display mode • A view‐only of the meter’s configuration parameters. Program mode • Allows you to make configuration and parameter changes to the meter. Log mode • Allows you to send reports to the meter’s serial port. Extended Utilities mode • Allows access to advanced meter functions. 1–2 Kurz B‐Series Operations Guide...
Page 15: Meter Keypad
The D key accesses Display mode for a view‐only of the meter’s configuration parameters. • It can also be used as a backspace key. The L key accesses Log mode and sends reports to the meter’s serial or USB port. • The E key accesses Extended Utilities mode for the advanced features of the meter. This is a • password protected mode. The E key is also used as an Enter key and to accept and save changes after entering data. The H key is the Home key used for backing out of any menu. Press H to back up one level • or press it twice to return to Run mode. The C key is used to clear a data entry field. • The alphanumeric keys include numbers 0 through 9, with keys 2 through 9 also being used for letters A to Z. For data fields that accept alphabetic data, continue pressing the alphanumeric key to cycle through the letters. For example, if you wanted to enter the letter “R,” you would press the 7 key, press again for “P,” press again for “Q,” and press again for “R.” Press the E key to save the selection and move to the next field. The symbol keys are: The up ( ) and down ( ) arrow keys are used to scroll through a menu. The scroll option • is available when the symbol ^ appears. — The bar key ( ) is used for entering negative values. •  The dot key ( ) is used for entering decimal places. • The arrow key ( ) overlaying the D key becomes a backspace key after you enter a mode • and is used for deleting characters to the left. Kurz B‐Series Operations Guide 1–3...
Page 16: Flow Meter Display Screen
Flow Meter Display Screen Each user configurable mode provides menu options based on the access code you enter. For example, one code might only allow access to basic meter settings while another code allows access to all meter settings. Full meter access provides the option of scrolling through the list of available menu options or entering the number of a specific menu item. Menu Scroll allows you to go through all menu options for that mode. • Quick Jump allows you to enter a menu number within the specified mode. • M E N U S C R O L L Q U I C K J U M P Figure 1‐2. Flow meter display screen When menu suboptions are available, up and down symbols appear at the end of the second line. Figure 1‐3. Menu suboption indicator 1–4 Kurz B‐Series Operations Guide...
Page 17: Boot Mode
Table 1‐1. Nominal Boot‐Up Times Settling Time Cold Sensor Hot Sensor (1% Reading, Modbus, 4‐20 mA, or Display) (Power Off) (Power Cycled) 1600 SFPM, velocity, filter TC = 0.5 seconds 15 seconds 17 seconds 1600 SFPM, temperature, filter TC = 0.5 seconds 10 seconds 13 seconds Zero flow, velocity, filter TC = 0.5 seconds 15 seconds 60 seconds Zero flow, temperature, filter TC = 0.5 seconds 10 seconds 55 seconds The B‐Series flow meter can boot‐up and start responding to Modbus communications or updating the 4‐20 mA output and display within one second of restarting/powering up. However, the boot sequence has to complete to guarantee the integrity of the data, and it is generally recommended to wait an additional 20 seconds before issuing any commands. A near zero flow rate can cause a boot delay up to 2 minutes, during which time the velocity sensor must cool off so its resistance value can be checked to ensure there are no sensor faults. A high process velocity during boot‐up reduces the delay because the hot sensor can cool down faster. When the meter is turned on from a power‐off state, the NE‐43 alarm low (3.6 mA or less) is set until the sensor boot process starts. The flow and temperature will then increase to their proper values depending on the process velocity meter filter settings. Firmware version 1.10 and later hold the NE‐43 alarm until boot‐up and Note sensor stabilization complete. Kurz B‐Series Operations Guide 1–5...
Page 18 B‐Series Flow Meter Modes & Menus When you boot‐up (power on) the flow meter, the display progresses through a series of initialization indicators: KURZ INSTRUMENTS DISP DRIVER V4.X CHECKING TYPE OF CONNECTED SENSOR WAIT PERFORMING SENSOR LEAK TEST KURZ INSTRUMENTS SERIES MFT-B FIRMWARE VERSION MFT-B VER 2.XX If the device supports Hart communication, an H appears before the Note firmware version number. Once boot testing completes, the flow meter automatically goes into Run mode. An error message indicates the unit has failed boot‐up testing due to a sensor mismatch, wiring, or other problem. The device will cycle through boot testing again until the issue is resolved. • Downloading the Min/Max, Event, and Trend logs is not possible until Note boot testing completes successfully. You can force a boot exit by pressing the C key. •...
Page 19: Run Mode
FLOW 0.0000 SCFM FLTOT 183545.0 Line 2 is totalized flow Flow and velocity • Line 1 is flow FLOW 0.0000 SCFM VEL 0.00000 SFPM Line 2 is velocity Tag name and flow • Line 1 is tag name TAG NATURAL GAS1 FLOW 0.0000 SCFM Line 2 is flow Flow and temperature • Line 1 is flow FLOW 0.0000 SCFM TEMP 82.52 DEGF Line 2 is temperature Kurz B‐Series Operations Guide 1–7...
Page 20: Scrolled Variables
• VELOCITY 0.00000 SFPM Totalized flow • TOTAL FLOW 183545.0 SCF Tag name • TAG NAME NATURAL GAS1 The scroll combinations are: Scroll all • Flow only • Flow and totalized flow • Flow and velocity • Tag name and flow • Tag name, flow, and velocity • Flow, totalized flow, and velocity • Flow and temperature • Flow, temperature, and velocity • 1–8 Kurz B‐Series Operations Guide...
Page 21: Display Mode
ASSIGN DOUT Relay output setup ALARM SETUP Alarm setup NE‐43 ALRM NE‐43 alarm setup PULSE OUT Pulse output setup PURGE TIMR Sensor purge setup CALIB DATA Flow calibration parameters setup CALIB AOUT Calibrate outputs VRMS DATA Variable flow correction data REMOTE CF Remote correction factor data CAL CURVE Gas calibration curve selection DATA LOG Data logging setup MODBUS COM Modbus communication setup EXT AINPUT External input setup PID SETUP PID data setup PID CONTRL Manual PID adjustment DRIFT CHCK Drift check setup CHANGE PW Change user password GET EEPROM Update from EEPROM BOOTUP DLY Set bootup output delay Kurz B‐Series Operations Guide 1–9...
Page 22 SENS CONFG Factory sensor setup INCAL CONF Calibration coefficients PROD CONFG Manufacturing data setup SAV 2 EEPR Save to EEPROM BRIDGE PID Bridge PID coefficients AUTO SAVE AutoSave status CURSR HOME Terminal home status SETFACTORY Extended factory meter setup AO CALCOEF Set analog output cal coefficient EXT INP mA External input current FLOW DATA Flow data TEMP DATA Temperature data INPUT VOLT Input voltage () SENSOR OUT Sensor output () SENSOR CTL Sensor control ELEC TEMP Electronics temperature SENS LEAKG Sensor leakage EVENT CODE Meter event code FW VERSION Firmware version 1–10 Kurz B‐Series Operations Guide...
Page 23: Program Mode
Run mode display setup — The default password for advanced meter setup is 654321. Advanced settings • (see“Program Mode — Advanced Access” on page 2‐7) are for options 2 through 26, which include an option for changing the default passwords. Before making any configuration changes in Program mode, it is important to remember: Any configuration changes followed by the message “New value accepted” are • automatically saved to EEPROM. There are no prompts to confirm changes. To back out of a series of menus, continue to press H for each level (manual exit). • If there is no menu activity for 3 minutes, the display automatically exits to Run mode. • The configuration is retained through flow meter reboots and power cycles. • You should not make any changes to the meter configuration without a Important complete understanding of the flow meter parameters. Changing a setting incorrectly can cause the flow meter to malfunction. To enter Program mode: Press P. 1> Enter the advanced meter setup password. 2> Press E. 3> You can scroll through the menu or quick jump to any of the options shown in Table 1‐3. 4> Not all parameters may appear based on your meter configuration. Note  Functions with ( ) support Hart. Within a menu, press E to scroll through the menu options unless the up/down arrows appear. Kurz B‐Series Operations Guide 1–11...
Page 24 ROUND Jump option within Inside Diameter Basic Meter Setup. RECTANGLE Duct Width All Basic Meter Duct Height Setup parameters CUSTOM are available as Flow area individual options, Flow Area (calculated from Duct Profile, but can which you can override with manual entry) () access using Quick Probe Depth (for Insertion meters only) Jump. Analog Out 1 FLOW RATE The purpose for VELOCITY each parameter in TEMPERATURE (optional) Basic Meter Setup is PID (optional) described with its AO1at 4mA () option number. AO1 at 20mA () Analog Out 2 (optional) FLOW RATE VELOCITY TEMPERATURE PID AO2 at 4mA AO2 at 20mA 1–12 Kurz B‐Series Operations Guide...
Page 25 Value in flow rate units on the output. FLOW CF/TC Flow Correction Factor and Time Constant () Applies a correction Sensor Blockage CF (for Insertion meters only) to an existing flow. Field Calib CF Flow TC Sec RESET TOTAL Flow Totalizer Reset Setup () An accumulation of Totalizer Reset the flow going past MAN RESET the sensor. The Auto Reset Flow Total Reset allows to NO preset a value for AUTO RESET returning to zero. Total Reset Cnt Reset Flow Total NO AOUT 1 Analog Output #1 Setup The 4‐20mA output Analog Out 1 range to the control FLOW RATE room. VELOCITY TEMPERATURE PID AO1at 4mA () AO1 at 20mA () Kurz B‐Series Operations Guide 1–13...
Page 26 FLOW+VEL FLOW+TEMP+VEL TAG+FLOW STATIC Static Vars FLOW ONLY TAG+FLOW FLOW+TOT FLOW+TEMP FLOW+VEL ASSIGN DOUT Relay Output Setup Opens or closes a Select Relay # contact on a preset Assign Relay To setting. ALARM OUTPUT See Setup Alarm TOT PULSE OUT See Setup Pulse Output PURGE OUTPUT (optional) See Setup Sensor Purge ALARM SETUP Alarm Setup Triggers an alarm for Select Alarm # an event. This is Value x used in conjunction Set Alarm x with the Relay Output Setup. Alarm x Trigger VELOCITY FLOW RATE TEMPERATURE GLOBAL EVENT 1–14 Kurz B‐Series Operations Guide...
Page 27 LO Alarm Setpt HI SETPOINT HI Alarm Setpt LO AND HI SP LO Alarm Setpt HI Alarm Setpt Continue with Relay Setup If YES, Alarm x assigned to DO n Relay n State NORMALLY OPN NORMALLY CLS NE‐43 ALRM NE‐43 Alarm Setup NE‐43 Alarm Type LOW OUTPUT HIGH OUTPUT PULSE OUT Pulse Output Setup Used in conjunction Pulse Output with the Relay Output Setup. If ON, Pulse Output assigned to DO n Flow Volume per Pulse Pulse Width PURGE TIMR Sensor Purge Setup () Used to send Purge Timer compressed air to OFF clean the sensor. If ON, Purge Output assigned to DO n This option requires Purge Time msec the Purge System. Hold Time msec Purge Intv min Kurz B‐Series Operations Guide 1–15...
Page 28 B‐Series Flow Meter Modes & Menus Table 1‐3. Program Mode (continued) Option Function Parameters / Description Purpose CALIB DATA Flow Calibration Parameters Setup This should only be Sensor SN changed with Cal Flow Unit approval from Kurz. SCFM SCMH SFPM SMPS Used for calibrating Factory STP Ref the sensor data. User Ref Temp () Standard reference User Ref Press () temperature is 25 C or 77 F. Standard reference pressure is 14.7 PSI. Cal Curve Type (optional) This is velocity VELOCITY MAP temperature MULTIPLE CAL mapping. VM Reference INTERNAL EXTERNAL Gas Mol Wt ...
Page 29 Option Function Parameters / Description Purpose AO2 Calib Coeff (optional) (con’t) A02 Slope A02 Offset Chk NE‐43 Alarms If YES Low Alarm Check High Alarm Check Enter output mA mA and equivalent VRMS DATA Variable Flow Correction Data () This should only be Enter # of Flow Data Sets n changed with Enter Flow Data Set # x approval from Kurz. Ref Value Rx (Vrms‐x) Test Data Dx (VdsAve‐x) REMOTE CF Remote Correction Factor Data This allows you to Remote CF correct the meter OFF reading in reference Enter # of Remote CF Data Points n to other data Enter ExtInput.RemCF‐D1 Enter ExtInput.RemCF‐X1 Enter ExtInput.RemCF‐Dn Enter ExtInput.RemCF‐Xn CAL CURVE Gas Calibration Curve Selection (optional) Curve Sel Mode MANUAL SELECT EXT INPUT LEV...
Page 30 Register Order BYTE #12 34 BYTE #34 12 EXT AINPUT External Input Setup Ext Input Usage CAL DATA SW PID EXT. REF (optional) VM REFERENCE REMOTE CF PURGE COMMAND (optional) VM REFERENCE Scale Unit Inp Val At 4mA Inp Val At 20mA Filter TC PID SETUP PID Data Setup (optional) PID State OFF PID Operation MANUAL AUTOMATIC PID Control To VELOCITY FLOW RATE PID Setpt Ref INTERNAL EXTERNAL PID Setpoint Prop Gain (KP) Integral TC Derivative TC PID Low Limit PID High Limit PID CONTRL Manual PID Adjustment (optional) Manual PID Adjust 1–18 Kurz B‐Series Operations Guide...
Page 31 DRIFT CHCK Drift Check Setup () Auto Drift Check OFF If ON, Drift Chk Intrvl % FS at Zero Duration at Zero % FS at Mid Duration at Mid % FS at Span Duration at Span CHANGE PW Change User Password Allows you to Basic Setup Code change the basic Adv Setup Code and advanced passcodes (6 digits). GET EEPROM Update From EEPROM Load From EEPROM NO BOOTUP DLY Bootup Output Delay Setup Bootup Out Delay seconds WGF PARAMS WGF Parameters Setup Calculates the vapor WFG Tmax (estimated saturation temperature) pressure correction DegF DegC for the dry flow rate. WGF Press (line pressure) kPA Kurz B‐Series Operations Guide 1–19...
Page 32: Log Mode
Description EVENT Event log MIN/MAX Min/max data TREND Trend log CONFIG System configuration RUN DATA Snapshot of flow meter data Log files are comma‐delimited files that can be opened using any Note spreadsheet application or basic word processing application (such as WordPad). Event Log The Event log contains up to 260 of the most recent events determined and reported by the flow meter. The output provides the runtime and an event code. Refer to B‐Series Troubleshooting for error codes and a brief description of behavior and possible causes. In the table, x’s represent leading zeros that do not appear, and the plus signs (+) represent any digits after the number that clarify the event. Min/Max Log The Min/Max log is used to determine the range of the flow rate, temperature, and electronics temperature for the process being measured by the Kurz flow meter. The output file contains up to 20 records for each of the following events: Minimum and maximum flow rate • Minimum and maximum process temperature • Minimum and maximum electronics temperature • 1–20 Kurz B‐Series Operations Guide...
Page 33: Trend Log
Config Log The Config log provides the following information: Firmware version • Runtime duration • Meter number • Analog output meter number • Alarm output status (enabled or disabled) • Pulse output status (enabled or disabled) • Data log status (enabled or disabled) • Modbus status (enabled or disabled) • PID status (enabled or disabled) • Multiple calibration curves status (enabled or disabled) • Remote correction factor status (enabled or disabled) • System unit language • Run Data Log The Run Data log provides the following information: Device tag name • Length of meter activity in seconds • PPM flow rate • Temperature in degrees Farenheit • Kurz B‐Series Operations Guide 1–21...
Page 34: Extended Utilities Mode
The E key is also used as an Enter key and to accept and save changes after entering data. To enter Extended Utilities mode: Press E. 1> Enter your password. 2> Press E. 3> You can scroll through the menu or quick jump to any of the options shown in Table 1‐5. 4>  Functions with ( ) support Hart. Note Table 1‐5. Extended Utility Mode Option # Function Description / Parameters ZERO DRIFT Drift Check at Zero () If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. MIDSP DRIFT Drift Check at Mid‐span () If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. FULLSP DRFT Drift Check at Full‐span () If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. CYCLE DRIFT Drift Check Cycle (all tests) () If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. 1–22 Kurz B‐Series Operations Guide...
Page 35 DEL EVENTS Reset Event Log Memory DEL MIN/MAX Reset Min/Max Records RESET RUNTM Reset Runtime Counter RP CIRCUIT RP Circuit Test RTC CIRC RTC Circuit Test IN CAL LO Input Cal Low Test IN CAL HI Input Cal High Test END IN CAL End Input Cal Test VLEAK HI VLeak Cal High VLEAK LO VLeak Cal Low VOLTG DRV Voltage Drive Test VOLTG RAMP Voltage Ramp Test BRIDGE PID Bridge PID Coefficients EVENT TEST Event Code Bit Test INPUT VOLT Display Input Voltages SENSOR OUT Display Sensor Output SENSOR CTL Display Sensor Control ELEC TEMP Display Electrical Temperature SENS LEAKG Sensor Leakage Kurz B‐Series Operations Guide 1–23...
Page 36: Quick Reference Card
B‐Series Flow Meter Modes & Menus Quick Reference Card You should have received a Quick Reference Card similar to the one shown in Figure 1‐4. In the event the card is missing or you need extra cards, print the following Quick Reference Card. fold here Kurz Instruments, Inc. www.kurzinstruments.com B–Series v2.0 800‐424‐7356 Quick Reference Card Home Key Function Option # Back out of menu system Program Mode (Quick Jump) Clears input in Program mode Basic Meter Setup...
Page 37: B-Series Flow Meter Menu Applications
Chapter 2 B-Series Flow Meter Menu Applications Overview This section provides the steps for frequently requested topics and menu processes. It includes: Display Mode — Wet and Dry Flow Rates • Program Mode — Basic Access • Program Mode — Advanced Access • Enabling Data Logging • Setting Up Analog Output Channels • Setting Relay Assignments • Setting the Pulse Mode Totalizer Output • Using the Built‐In Zero‐Mid‐Span Drift Check Calibration • Configuring the Built‐In Flow Controller • Changing the WGF Vapor Correction Factor • Setting Flow Meter Modbus Connectivity • Cleaning A Sensor • Kurz B‐Series Operations Guide 2–1...
Page 38: Display Mode - Wet And Dry Flow Rates
4> PROCESS PRESSURE >14.7000000 PSI This is the pressure in the line where the flow is being measured. Press E. 5> VEL RATIO OF GAS >1.50000000 This is the estimated velocity of the flow where the it is being measured. This value is derived from the velocity ratio of gas‐to‐air or steam‐to‐air. See “Changing the WGF Vapor Correction Factor” on page 2‐44 to change these values. To access the wet and dry flow rates information in Display mode: Press D. 1> Press 2 to invoke the Quick Jump option. 2> Press 42 for the Flow Data menu, and then press E. 3> Press P until the Dry/Wet option appears. 4> DRY/WET uuuu dd.d ww.w where: uuuu are the flow rate units dd.d is the dry flow rate ww.w is the wet flow rate The flow rate can also be monitored through Modbus using function04, input register 0x43. 2–2 Kurz B‐Series Operations Guide...
Page 39: Program Mode - Basic Access
Important complete understanding of the flow meter parameters. Changing a setting incorrectly can cause the flow meter to malfunction. A flow meter used in a critical process or feedback control should be taken offline before • making configuration changes in Program mode. The Basic Setup menu option temporarily suspends flow meter output at the last value before the menu option was invoked. ! WARNING ! OUTPUT WILL STOP If this prompt does not appear, the meter continues to operate normally. Press only P to continue to the next prompt without making changes. • To back out of a menu, press H to force an exit. • Any changes accompanied by the following message are automatically saved to EEPROM: • NEW VALUE ACCEPTED There are no prompts to confirm that you want to make a change. If there is no menu activity for 3 minutes, the display automatically exits to Run mode. • The configuration is retained through flow meter reboots and power cycles. • The output automatically restarts when you exit the Basic Setup menu option. • OUTPUT UPDATE IS RESUMED ..If a parameter change affects the output, the output will restart as the Note new parameter is accepted or the output update is resumed. Kurz B‐Series Operations Guide 2–3...
Page 40 (either insertion or inline). METER TYPE IS INSERTION FLOW Press E. 3> TAG NAME >FLOW METER The tag name is the flow meter name. The name can indicate the location, process, or company naming convention. Press E to continue to the next option without making changes. 4> If you want to change the flow meter name, press C to clear the tag name field. Use the alphanumeric keys to enter letters and numbers. Press E to advance to the next character position. Press E to accept the new name and continue to the next option. FLOW UNITS >SCMH The flow units determine the units that appear for velocity and temperature. The flow rate options are NCMH, NLPM, SCFH, SCFM, SCMH, and SLMP. The mass rate options are KGH, KGM, PPH, and PPM. Use the arrow keys to select the flow units, and then press E. 5> DUCT PROFILE >ROUND The duct profile options are round, rectangle, and custom. Use the arrow keys to select the duct profile, and then press E. 6> Depending on the duct profile selection, the duct width, inside diameter, or flow area prompt appears. 2–4 Kurz B‐Series Operations Guide...
Page 41 FLOW AREA >10.525 SQFT Use the number and decimal keys to enter the profile measurements. Press E. 7> FLOW AREA >10.525 SQFT The Flow Area is calculated from the height and width of a rectangular profile or the inside diameter of a circular profile. Note: If you selected a custom duct profile, the Flow Area option will not appear twice. Use the number and decimal keys to enter the flow area measurements. Press E. 8> For insertion flow meters, the Probe Depth option appears. PROBE DEPTH >18.230 Use the number and decimal keys to enter the probe depth. Press E. 9> ANALOG OUT >FLOW RATE The Analog Output options include flow rate, velocity, temperature, and PID. The availability of options is based on other settings. Use the arrow keys to select an Analog Output option, and then press E. 10> AO1 at 4mA >0.0000000 SCFM Kurz B‐Series Operations Guide 2–5...
Page 42 RUN MODE DISPLAY >STATIC The Run Mode options are static variables and scrolled variables. Refer to “Run Mode”on page 1‐7 for a description of static and scrolled modes. Use the arrow keys to select the Run Mode Display, and then press E. 13> Depending on the run mode selection, the static variable or scrolled variables prompt appears. STATIC VARS >FLOW+TEMP SCROLLED VARS >SCROLL ALL Refer to “Run Mode” on page 1‐7 for a description and examples of static and scrolled variables. Use the arrow keys to select the variable, and then press E. 14> SCROLL INTERVAL >2 The Scrolled Variable option also allows you to determine the length of time (between 2 and 8 seconds) that information appears on the display before changing to the next value. Use the number keys to to choose between 2 and 8 seconds, and then press E. 15> 2–6 Kurz B‐Series Operations Guide...
Page 43: Program Mode - Advanced Access
Important complete understanding of the flow meter parameters. Changing a setting incorrectly can cause the flow meter to malfunction. A flow meter used in a critical process or feedback control should be taken offline before • making configuration changes in Program mode. Advanced setup temporarily suspends flow meter output at the last value before Program mode was invoked. ! WARNING ! OUTPUT WILL STOP If this prompt does not appear, the meter continues to operate normally. Press only P to continue to the next prompt without making changes. • To back out of a menu, press H (possibly multiple times) to force an exit. • Any changes accompanied by the following message are automatically saved to EEPROM: • NEW VALUE ACCEPTED There are no prompts to confirm that you want to make a change. If there is no menu activity for 3 minutes, the display automatically exits to Run mode. • The configuration is retained through flow meter reboots and power cycles. • The output automatically restarts when you exit the Basic Setup menu option. • OUTPUT UPDATE IS RESUMED ..If a parameter change affects the output, the output will restart as the Note new parameter is accepted or the output update is resumed. Kurz B‐Series Operations Guide 2–7...
Page 44: Enabling Data Logging
Enabling Data Logging Data logging typically occurs for: Field calibration process • Troubleshooting a process flow • Troubleshooting meter readings • To access the Data Logging menu in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 18 for the Data Logging menu, and then press E. 4> The menu prompts you for enabling the data log. ENABLE DATA LOG >OFF Use the arrow keys to select ON, and then press E. 5> The LOG INTERVAL prompt defines the frequency (in seconds) of data logged to the USB port. The interval can be between 1 second and 32,768 seconds (approximately 9.1 hours). LOG INTERVAL SEC >300 Enter the LOG INTERVAL value using the number keys, and then press E. 6> 2–8 Kurz B‐Series Operations Guide...
Page 45: Totalizing Volume Or Mass Flow
Determining Accuracy Limits Data for the flow totalizer is retained in less than eight digits. Round‐off errors cause mistracking to occur when the data has been accumulating for extended periods (more than two years). To maintain mistracking below one percent, select an automatic roll‐over value that occurs within two years as a point for resetting the flow totalizer. This value is independent of the flow rate. See “Resetting the Flow Totalizer Value” on page 2‐10 for additional information. For example, a typical flow rate of 100 SCFM that occurs for 10 hours per day results in a total flow per day of 100 x 10 x 60 = 60,000 CF. In one year this accumulates 60,000 x 365 = 21,900,000 or 21.9 MCF per year. Configuring the flow totalizer to automatically reset at 10 MCF would force it to reset about every 6 months. Viewing the Totalized Flow To access the Flow Totalizer in Display mode: Press D. 1> Press 2 to invoke the Quick Jump option. 2> Press 42 for the Flow Data menu, and then press E. 3> Press P repeatedly until similar information appears: 4> The example uses standard cubic feet (SCF), although metric or mass can Note appear based on the meter configuration. SCF =183747.5 ET 2036.256 MIN Press H twice to return to Run mode. 5> Kurz B‐Series Operations Guide 2–9...
Page 46: Resetting The Flow Totalizer Value
Press 2 to invoke the Quick Jump option. 3> Press 4 for the Flow Totalizer Reset Setup menu, and then press E. 4> The menu prompts you for a manual or automatic reset. Use the arrow keys to select either MANUAL RESET or AUTOMATIC RESET, and then press E. 5> For MANUAL RESET: TOTALIZER RESET >MAN RESET ^v Selecting MANUAL RESET will then prompt you to confirm resetting the totalizer. a> RESET FLOW TOTAL >YES ^v Use the arrow keys to select YES, and then press E. b> Press P to exit the prompt without changes. The following information appears: RESETTING FLOW TOTALIZER... TOTALIZER IS RESET... Press E, C, or P to return to the Program mode option menu. c> 2–10 Kurz B‐Series Operations Guide...
Page 47 B‐Series Flow Meter Menu Applications For AUTOMATIC RESET: TOTALIZER RESET >AUTO RESET ^v Selecting AUTOMATIC RESET will then prompt you for a reset count. a> The reset count defines the maximum limit of the flow totalizer before it automatically resets to zero. TOTAL RESET CNT >1.000E+20 SCF Enter the maximum limit using the number and decimal keys, and then press E. b> A prompt appears to confirm resetting the totalizer. RESET FLOW TOTAL >YES ^v Use the arrow keys to select YES, and then press E. c> Press P to exit the prompt without changes. The following information appears: RESETTING FLOW TOTALIZER... TOTALIZER IS RESET... Press E, C, or P to return to the Program mode option menu. d> Kurz B‐Series Operations Guide 2–11...
Page 48: Setting Up Alarms
B‐Series Flow Meter Menu Applications Setting Up Alarms A Kurz thermal flow meter can be factory configured with up to two alarms. The alarms can be monitored on the display, via ASCII or Modbus commands, or through the HART interface. Additionally, the alarms can be setup to send a control signal (energize a relay output) when an alarm event occurs. Alarm Setup It is recommended that you start with the Relay Output Setup (option 8) Note to avoid assigning conflicting relays. See “Setting Up the Relay Output for an Alarm Function” on page 2‐14 for information. As the relays are solid state optically isolated, SSRs (SPST), their Note unpowered state is an open circuit and must be considered for fail‐safe alarm logic configurations. To access the Alarm Setup menu in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 9 for the Alarm Setup menu, and then press E. 4> The following information appears if the meter was not purchased with the alarm option: ALARM FUNCTION IS NOT INSTALLED If you would like the Alarm function available, contact your Kurz representative. ...
Page 49 If you select FLOW RATE, VELOCITY, or TEMPERATURE, the menu system prompts for the condition that activates the alarm. The condition can be LOW SETPOINT / HIGH SETPOINT / LO AND HI SP. ALARM 1 TRIP >LOW SETPOINT Use the arrow keys to scroll through the list, and then press E. 8> Depending on the activation condition you selected, you could be prompted for the LOW and/or HIGH set points. The following examples show the prompting for the FLOW RATE low and high alarm set points. LO ALARM SETPT >0.0000000 SFPM HI ALARM SETPT >10000.0000 SFPM Use the numeric and decimal keys to enter the set point value, and then press E. 9> If the alarm condition energizes a relay output, the following example shows setting up the relay output assigned to the alarm. CONTINUE WITH RELAY SETUP >YES Press H to exit if the alarm will not energize a relay. Otherwise, use the arrows keys to 10> select YES or NO, and then press E. Kurz B‐Series Operations Guide 2–13...
Page 50: Setting Up The Relay Output For An Alarm Function
Before setting up the relay for the alarm, the system checks if the relay is assigned to another active function. If the relay is being used, the following prompt appears (where x is either 1 or 2): DOx IS USED CHANGE IT >NO This prompt indicates that the relay is assigned to either the TOTALIZER PULSE OUTPUT or the PURGE OUTPUT function. If you do not want to make any changes, press E to accept the setting, H to back out of the prompt, or P to go to the main menu. Use the arrow keys to change the selection to YES to proceed with the relay reassignment. 5> If the relay is currently assigned, a prompt similar to the following example appears: ALARM x AT DO y REASSIGN >NO Use the arrow keys to change the selection to YES, and then press E. 6> If the relay is reassigned, the other alarm will still be active but it will no Note longer energize the reassigned relay. A confirmation of the relay selection and alarm number assignment appears, similar to the following example: ALARM #1 ASSIGNED TO DO1 Press P or C to advance to the next setup screen. 7> After the relay selection is confirmed, a prompt for the normal (unalarmed) state of the relay appears. 2–14 Kurz B‐Series Operations Guide...
Page 51: Setting Up Analog Output Channels
8> If the meter is configured for multiple alarms, the alarm setup can be repeated for the other alarms. Setting Up Analog Output Channels The flow meter supports up to two analog output (AO) channels. Each analog output channel (AO1 and AO2) can report flow rate, temperature, velocity, or be assigned to a PID flow controller. Both channels are active during the zero‐mid‐span drift check. HART versions of the sensor control board only have one AO channel. Note Table 2‐1. 4‐20 mA Output Functions Analog Output Functions Description Flow rate Temperature Process measurement. Velocity PID flow controller Control valve position, damper position, or motor controller speed. The drift check and NE‐43 alarms are temporary overrides to the analog output signals. Table 2‐2. Temporary 4‐20 mA Process Measurement Override Drift Check NE‐43 Alarms Trigger Internal timer Error event bits Trigger DI2 input Kurz B‐Series Operations Guide 2–15...
Page 52: Analog Output Setup Menu
4> The following example uses the Analog Out 1 option with the flow rate feature. ANALOG OUT 1 > FLOW RATE ^v Use the arrow keys to scroll through the list, then press E. 5> The prompt appears for assigning the minimum flow rate at 4 mA. This is the value of the controlled variable (flow rate or velocity) when the valve or damper is fully closed or the fan is OFF; this value is usually zero. AO1 at 4mA >0.00000000 SCFM Use the numeric and decimal keys to enter the minimum flow rate, and then press E. 6> The prompt appears for assigning the maximum flow rate at 20 mA. This is the value of the controlled variable (flow rate or velocity) when the valve or damper is completely open or the fan is at full speed (controlled device). AO1 at 20mA >12000.0000 SCFM Use the numeric and decimal keys to enter the maximum flow rate, and then press E. 7> The prompt returns to the Program mode main menu. Repeat these steps if the meter has a second analog output channel. 2–16 Kurz B‐Series Operations Guide...
Page 53: Pid Flow Control
(low value kick-out) (high value kick-out) Normal Operation 3.6 3.8 20.5 21 Figure 2‐1. 4‐20 mA operation with the NE‐43 alarm The following flow meter error events cause a NE‐43 alarm: Unable to write configuration file to EEPROM • Abnormal sensor node voltages • Sensor type does not match configuration • Sensor over‐voltage crowbar engaged • Sensor control drive stopped responding • ADC failed to convert measurement • High sensor or wire leakage • Rps sensor lead open circuit • Wire loop resistance above high limit • Rtc resistance below low limit and above high limit • Rp resistance below low limit and above high limit • Kurz B‐Series Operations Guide 2–17...
Page 54: Setting Relay Assignments
Setting Relay Assignments The B‐Series has two solid state relays rated for +/‐30 VDC or 24 VAC up to 0.5 A RMS load; however, not all versions of the sensor control board support the relays. The relay functions are configurable, but each relay can only be assigned one function at a time. Table 2‐3 shows the functions that can be assigned to each relay. Table 2‐3. Relay Functions Relay # (DO#) Alarms Pulse Totalizer Purge Valve The sensor purge cleaning function can only use Relay #2 (or DO2). Note To access the Relay Outputs Setup menu in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 8 for the Relay Outputs Setup menu, and then press E. 4> The menu prompts you for a relay number. SELECT RELAY # > 1 Press either 1 or 2, and then press E. 5> 2–18 Kurz B‐Series Operations Guide...
Page 55: Assigning An Alarm To A Relay
If the relay is being used by another active function the following prompt appears: RELAY IS USED CHANGE IT>NO The relay can be reassigned to the new function by changing the response to YES by using 7> the arrow keys, and then pressing E. The meter will reassign the relay to the new function. The previously assigned function is now unassigned and turned off, when applicable. An example of when the function is turned off is if Relay #2 is assigned to the — PURGE OUT function and then reassigned to the TOTALIZER PULSE OUTPUT and the PURGE TIMER is ON. The meter will turn OFF the PURGE TIMER when the relay is reassigned. An example of when the function is not turned off is when a relay is assigned to the — ALARM OUTPUT function and then reassigned to another function, the alarm is not turned OFF. Only the actuation of the relay due to the triggered alarm is disabled, and the alarm will remain ON and continue to trigger as configured. If the flow meter is configured with more than 1 relay output, the meter will repeat the sequence of prompts to configure the other relay output. Press H to exit the Setup Relay Outputs menu. 8> Assigning an Alarm to a Relay After a relay is configured to actuate an alarm, the menu advances to the Setup Alarms menu. A flow meter can have up to two alarms. You are prompted to select an alarm number. SELECT ALARM # >1 Kurz B‐Series Operations Guide 2–19...
Page 56 Press P or C to advance to the next prompt. 3> If the relay is currently assigned to the other alarm the following prompt appears. ALARM 2 AT DO 1 REASSIGN>NO The relay can be reassigned to the new function by changing the response to YES by using 4> the arrow keys, and then pressing E. If you reassign the relay, the other alarm is active but it will not activate any relay. After confirming the relay selection, the meter prompts for the normal (unalarmed) state of the relay. RELAY 1 STATE >NORMALLY OPN NORMALLY OPN is used if the contact is closed when the alarm is triggered. NORMALLY CLS is used if the contact is opened when the alarm is triggered. Use the arrow keys for your selection, and then press E. 5> You are prompted to select a trigger event that will activate the alarm. ALARM 1 TRIGGER >FLOW RATE The available events are FLOW RATE, VELOCITY, TEMPERATURE, and GLOBAL EVENT. Selecting FLOW RATE, VELOCITY, or TEMPERATURE prompts you for a trip condition — to activate the alarm. The trip condition can be LOW SETPOINT, HIGH SETPOINT, or LO AND HI SP. Select GLOBAL EVENT if the alarm will be triggered by any flow meter event. — 2–20 Kurz B‐Series Operations Guide...
Page 57: Assigning A Pulse To A Relay
SFPM Enter the set point value using the number and decimal keys, and then press E. 7> Press P if you want to skip entering a value. The Setup Relay Outputs menu appears. Assigning a Pulse to a Relay When a relay is configured to the Pulsed Output of Totalized Flow from the Setup Relay Outputs Menu (option 8), the meter advances to the Setup Pulsed Output menu. The meter was not purchased with this option if the following prompt appears. PULSE OUTPUT IS NOT INSTALLED You can perform a hardware check to see if this feature is available for your meter. Press E to continue. 1> You are prompted to set the Totalizer Pulse Output function ON or OFF. PULSE OUTPUT >ON Use the arrow keys to select ON, and then press E. 2> A prompt confirming the relay assignment appears. PULSE OUTPUT #1 ASSIGNED TO DO1 Press E or P to continue. 3> Kurz B‐Series Operations Guide 2–21...
Page 58: Assigning A Purge To A Relay
PULSE WIDTH >50 MSEC Enter the number of milliseconds using the number keys, and then press E. 5> Press P if you want to skip entering a value. The Setup Relay Outputs menu appears. Assigning a Purge to a Relay When a relay is configured to the Purge Output from the Setup Relay Outputs menu (option 8), the meter advances to the Setup Sensor Purge menu. A prompt appears for the state of the PURGE TIMER. PURGE TIMER >ON Use the arrow keys to select ON, and then press E. 1> A confirmation prompt for the relay assignment appears. PURGE OUTPUT ASSIGNED to DO2 Press E or P to continue. 2> A prompt for the PURGE TIME appears. The PURGE TIME is the length of time the purge solenoid is held open. PURGE TIME MSEC >500 2–22 Kurz B‐Series Operations Guide...
Page 59 A cleaned sensor changes the flow readings following a purge regardless Note of the specified hold time. Additionally, the rate at which the shift occurs is filtered by the meter time constant setting. The HOLD TIME applies to the update of the flow rate, velocity, and temperature values with respect to the 4‐20mA output, Modbus output, and display. The HOLD TIME is the total time for the entire purge cycle. For example, a HOLD TIME of 2000 milliseconds with a PURGE TIME of 500 milliseconds means that the Purge Relay will be pulsed for 500 milliseconds, followed by an additional 1500 milliseconds of idle time to allow for sensor recovery. The HOLD TIME value must be greater than or equal to the PURGE TIME Note value. HOLD TIME MSEC >2000 Use the numeric keys and type in the number of milliseconds for the desired HOLD TIME, 4> and then press E. The PURGE INTERVAL prompt appears. The PURGE INTERVAL is used to set the frequency (in minutes) of the purge cycle when it is triggered by the internal timer. For example, a PURGE INTERVAL of 60 minutes will trigger one purge per hour. If the internal timer and the external purge contact closure are used to start the purge, set the internal timer PURGE INTERVAL to a value higher than is specified by the external closure. This will prevent the internal timer from purging too soon after the last externally commanded purge. PURGE INTV MIN > 60 The PURGE INTERVAL can be from 1 to 1440 minutes. Use the numeric keypad and type the number of minutes for the desired PURGE INTERVAL, 5> and then press E. Press P if you want to skip entering a value. The Setup Relay Outputs menu appears. Kurz B‐Series Operations Guide 2–23...
Page 60: Pulse Mode Totalizer Output
Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 8 for the Relay Outputs Setup menu, and then press E. 4> The menu prompts you for a relay number. SELECT RELAY # > 1 Press either 1 or 2, and then press E. 5> The meter prompts you for a function to assign to the selected relay number. Relay #1 can be assigned to the ALARM OUTPUT and TOT PULSE OUT functions. Relay #2 can be assigned to the ALARM OUTPUT, TOT PULSE OUT, PURGE OUTPUT functions. ASSIGN RELAY TO >TOT PULSE OUT ^v Use the arrow keys to select totalizer pulse output, and then press E. 6> Once a function is configured for the selected relay number, the meter will advance to the setup menu for that function. The relay is being used by another active function if the following prompt appears: RELAY IS USED CHANGE IT>NO 2–24 Kurz B‐Series Operations Guide...
Page 61: Accessing The Totalizer Pulse Setup Menu
Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 11 for the Pulse Output Setup menu, and then press E. 4> The meter was not purchased with this option if the following prompt appears. PULSE OUTPUT IS NOT INSTALLED You can perform a hardware check to see if this feature is available for your meter. Press E to continue. 1> You are prompted to set the Totalizer Pulse Output function ON or OFF. PULSE OUTPUT >ON Use the arrow keys to select ON, and then press E. 2> If the relay is being used, the following prompt appears (where x is either 1 or 2): DO1 IS USED CHANGE IT>NO This prompt indicates that the relay is assigned to another function. If you do not want to make any changes, press E to accept the setting, H to back out of the prompt, or P to go to the main menu. The relay can be reassigned to the new function by changing the response to YES by using 3> the arrow keys, and then pressing E. Kurz B‐Series Operations Guide 2–25...
Page 62 If the relay is assigned to another function, you should go through the Note Relay Assignment menu so that a previous configuration is not inadvertently changed. See “Setting Relay Assignments” on page 2‐18 for additional information. When the pulse output is turned on, a prompt appears confirming the relay assignment. PULSE OUTPUT #1 ASSIGNED TO DO1 Press E or P to continue. 4> A prompt for the Totalized Flow Per Pulse appears. This value defines the accumulated flow per pulse, which is the units of volume or mass per pulse based on the system units. (In this example, each pulse represents 100,000 standard cubic feet.) SCF PER PULSE >100000.000 Enter the value using the number and decimal keys, and then press E. 5> A prompt for the Pulse Width appears. This is the length of time to close the assigned relay after reaching the accumulated volume or mass. The value of the pulse width can be between 50 to 2000 milliseconds. PULSE WIDTH >50 MSEC Enter the number of milliseconds using the number keys, and then press E. 6> Press P if you want to skip entering a value. Repeat the setup if there is a second pulse output. 2–26 Kurz B‐Series Operations Guide...
Page 63: Built-In Zero-Mid-Span Drift Check Calibration
Digital Input” on page 2‐30). The meter also retains the recorded values from the previous test, which can be accessed through the meter’s onboard menu system or through Modbus registers. The independent calibration is factory calibrated to better than 0.13% FS and can be used at any time to verify the proper calibration of the flow meter. When the drift check is in‐progress, the 4‐20 mA output represents the Important percentage of full scale for which the drift check was configured, not the process flow reading or temperature. The amplitudes, duration, and trigger conditions are configured for the drift check feature. The configurable parameters are as follows: Auto drift check ON or OFF of the internal timer only. • No effect on Modbus or DI triggers. Interval time xx hours (internal timer trigger only) • Zero drift check value % full scale (4‐20 mA output current) • Zero drift check duration xx seconds • Mid‐span drift check value % full scale (4‐20 mA output current) • Mid‐span drift check duration xx seconds • Span drift check value % full scale (4‐20 mA output current) • Span drift check duration xx seconds • Kurz B‐Series Operations Guide 2–27...
Page 64: Setting Up Drift Check
Press 23 for the Drift Check Setup menu, and then press E. 4> A prompt appears for setting automatic drift ON or OFF. AUTO DRIFT CHECK >ON ^v Press the arrow keys to select ON or OFF, and then press E. 5> When AUTO DRIFT CHECK is ON, the prompt appears for the Drift Check Interval. This parameter defines the periodic interval (in hours) that the drift check sequence will be initiated by the internal timer. The interval can be between 1 to 18000 hours. The factory default is 16 hours. DRIFT CHK INTRVL >16 HOUR Use the numeric keys to enter a time value, and then press E. 6> Press P to skip to the prompt without making changes. A series of prompts appear for each drift check test level (zero‐mid‐span) regarding the amplitude of the output signal and its duration. The amplitude is given as a % of the FS of the independent voltage source (3.3V). In the following example, 10.0% means that 0.33V (10% of 3.3V) will be applied to the 4‐20 mA output for the drift check at zero. % FS AT ZERO >10.000 Use the numeric and decimal keys to enter the value, and then press E. 7> The prompt appears for specifying the duration. The duration is the time the 4‐20 mA output is at the zero value before switching to the mid and span drift check prompts. 2–28 Kurz B‐Series Operations Guide...
Page 65: Specifying Drift Check Triggers
Use the numeric and decimal keys to enter the % AT FS values, and then press E. 9> Use the numeric to enter the time value, and then press E. 10> Press P to skip to the prompt without making changes. After completing all prompts, the main Program mode option entry prompt appears. Press 11> H to return to Run mode. The zero‐mid‐span drift check and sensor purge features can be Note configured to automatically trigger on a user‐configured interval. If both features are ON and scheduled to run at the same time, the features will run consecutively, not concurrently. Specifying Drift Check Triggers There are four ways to initiate the zero‐mid‐span drift check. A specified time interval • An external digital input • A menu option in Extended Utilities mode • A Modbus command • The duration of the individual zero, mid, or span checks are controlled by user‐specified duration values. Specified-Time Interval Drift Check The zero‐mid‐span check can be triggered by the drift check interval time. To configure this option, turn ON the Auto Drift Check. When it is triggered, it will perform the zero, mid, and span sequence. Change the value of the drift check interval to change the frequency that the drift check starts. See step 6 under “Setting Up Drift Check” for information about setting up drift check. Kurz B‐Series Operations Guide 2–29...
Page 66: External Digital Input
The Extended Utilities mode allows zero, mid, span, and all drift checks to be initiated using the flow meter user interface or from a remote terminal. You can also view the results from the last drift check test, which does not require that the Auto Drift Check be turned ON. To access the drift options from the Extended Utility mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> The following table list the drift menu options. Use the number keys to make your 4> selection, and then press E. Table 2‐4. Extended Utility Mode (Drift Options) Option # Function Description ZERO DRIFT Drift Check at Zero (H) If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. MIDSP DRIFT Drift Check at Mid‐span (H) If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. FULLSP DRFT Drift Check at Full‐span (H) If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. CYCLE DRIFT Drift Check Cycle (all tests) (H) Consecutively performs the zero, mid, and span drift checks. If YES, runs test and provides updated % Diff, VIN, and VOUT data. If NO, shows current % Diff, VIN, and VOUT data. 2–30 Kurz B‐Series Operations Guide...
Page 67 The prompt appears to confirm starting the drift check test. ZERO DRIFT CHECK START TEST> YES Press the arrow keys to select YES, and then press E. 2> The display indicates that the test is running. ZERO DRIFT CHECK IS RUNNING... When the test completes, the display shows the percent difference between the voltage input and voltage output for the zero drift check. ZERO DRIFT CHECK %DIFF = 1.091 After 3 seconds, the display shows the voltage input and output values used in the zero drift check. Vin = 0.33000 V Vout= 0.33360 V If you select NO when prompted to start the drift check, the percent Note difference between voltage input/output and the voltage input/output values for the last drift check appear. Press E or C to return to the Extended Utilities mode option prompt. 3> Kurz B‐Series Operations Guide 2–31...
Page 68: Modbus Protocol Write Coil Command
Modbus coil #2 Triggers span drift check • Modbus coil #3 Triggers cycle all drift check (zero‐mid‐span sequence) • Modbus coil #4 Aborts any of the above states • Modbus Status Registers Status registers are provided via Modbus (function code 01) to indicate whether zero, mid, and span checks are busy or idle. Status register 0 Status register for zero drift check, 0=idle or 1= busy • Status register 1 Status register for mid drift check, 0=idle or 1=busy • Status register 2 Status register for span drift check, 0=idle or 1=busy • Status register 3 Status register for cycle all check (zero‐mid‐span sequence) • 0=idle or 1=busy While performing a cycle check, both the register 3 and the corresponding zero, mid, or span register are set to the current status (busy). When the cycle completes, the status returns to idle. The status register bits are also used to report the diagnostic errors on the flow meter (function code 02). This permits fast status polling along with the principle variable polling. A drift check triggered through Modbus is a bit or coil write command with status. The amplitude values (% 4‐20 mA scale) and the duration (seconds) for each drift check are available as read and write registers. The results from a previous drift check (using volts measured from the 3.3 V programmable reference, not 4‐20 mA range) and percentage change are also available as read registers. 2–32 Kurz B‐Series Operations Guide...
Page 69: Hart Interface
Emerson 475 handheld communicator. Configuring the Built-In Flow Controller The B‐Series uses a manually configured, built‐in flow controller based on a simple local flow control PID loop. This section describes setting up the flow control functions and information about feedback control systems. Table 2‐5. Summary of flow controller capabilities Capability Description Control output 4‐20 mA positional signal. Fixed output position control for testing in program mode (% of AO range). Set point register Fix flow, menu programmed. Modbus write register. Analog input set point 4‐20 mA input, engineering units scaled. Reference meter Meter 1, flow rate. Manual gain setting. Normalized coefficients: P: gain I: time constant D: time constant Kurz B‐Series Operations Guide 2–33...
Page 70: Setting Up The Flow Controller
RPM. To use the B‐Series as an automatic flow controller, connect one of its 4‐20 mA outputs to the control valve, damper, or motor controller. It will regulate the flow based on a fixed flow set point value or an analog input for the set point. The following example has the B‐Series flow meter actuating a valve based on an external set point of the flow rate. The second 4‐20 mA output channel is sending the flow rate signal elsewhere, although temperature can be specified instead of flow rate. PID control of the process is manually configured. The control output can be controlled manually from the display to verify the range operation of the control loop or to manually set the output (control valve) at a fixed position. Setting Up a PID To setup a PID: Mechanically mount all components, test for leaks, and check flow control actuator motion 1> or motor controller action. Electrically connect all components. Wire‐in one of the 4‐20 mA outputs. The default 2> output of the FT device is for loop powered 4‐20 mA. Refer to the device wiring diagram if you need it to be self‐powered. Configure the 4‐20 mA output scale for the control device using velocity or flow rate units 3> to determine the process flow units at the 4 mA output position and the 20 mA output position. Configure the set point source for the: 4> External analog input by configuring the 4‐20 mA scale using appropriate — engineering units. Internal set point using a flow rate or velocity value that will maintain the PID — control variable (flow rate or velocity) at a fixed value. This set point can be changed at the meter keypad or using a Modbus command. Tune the control loop for stable operation over the specified flow range. 5> 2–34 Kurz B‐Series Operations Guide...
Page 71: Accessing The Pid Data Menu
PID FUNCTION IS NOT INSTALLED You can perform a hardware check to see if this feature is available for your meter. If the feature was included, a prompt appears to turn the PID function ON or OFF. PID STATE >ON Press the arrow keys to change the response to YES, and then press E. 5> A prompt appears to make the PID mode of operation AUTOMATIC or MANUAL. AUTOMATIC is used for constant flow control that adjusts based on an external or — internal set point. MANUAL is used for manual flow control using the PID Manual Control menu to set — the PID control to a fixed position. PID OPERATION >MANUAL Press the arrow keys to select the mode of operation, and then press E. 6> A prompt appears for the FLOW RATE or VELOCITY control variable. FLOW RATE is for volumetric and mass flow. — VELOCITY is for flow velocity. — PID CONTROL TO >FLOW RATE Press the arrow keys to select the control variable, and then press E. 7> A prompt appears for the internal or external PID set point reference. Kurz B‐Series Operations Guide 2–35...
Page 72 PID SETPT REF >INTERNAL Press the arrow keys to select the PID set point reference, and then press E. 8> If you choose EXTERNAL, the external analog input channel must be assigned to the PID EXT. REF variable in option 20, External Input Setup, of Program mode. If you choose INTERNAL, a prompt appears for the set point value. The PID SETPOINT uses the units specified in the PID CONTROL TO variable. PID SETPOINT >1234.5600 SCFM Use the numeric and decimal keys to enter the PID set point value, and then press E. 9> The set point value can also be specified using Modbus command 0x06, register 44. Prompts appear for the PID tuning parameters: Proportional gain — Integral time constant — Derivative time constant — The integral gain is the proportional gain divided by the integral time constant. The derivative gain is the proportional gain multiplied by the derivative time constant. Linking the integral time constant with the proportional gain and linking the derivative time constant with the proportional gain makes it easier to manually tune the system. PP GAIN (KP) >0.300 INTEGRAL TC >1.000 DERIVATIVE TC >0.300 2–36 Kurz B‐Series Operations Guide...
Page 73: Setting Up The Pid 4-20 Ma Control Output
PID HIGH LIMIT >5000.00 SCFM Use the numeric and decimal keys to enter the PID high limit, and then press E. 12> Press E or P to exit the PID Data Setup menu and return to the main Program mode 13> prompt. Setting Up the PID 4-20 mA Control Output The PID control output is a 4‐20 mA positional signal. It uses either one of the 4‐20 mA analog outputs. An analog output (AO1 or AO2) must be configured to the PID output. To set the analog output in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 5 for the Analog Output #1 Setup menu or 6 for the Analog Output #2 Setup menu, 4> and then press E. The following examples use Analog Output #2 as the PID output. A prompt appears for selecting a function to assign to the analog output. Kurz B‐Series Operations Guide 2–37...
Page 74: Setting Up The External Input For Pid Remote Reference
AO1 at 20mA >12345.678 SCFM Use the numeric and decimal keys to enter the PID high limit, and then press E. 7> Press E or P to exit the Analog Output Setup menu and return to the main Program mode 8> prompt. Setting Up the External Input for PID Remote Reference The PID is controlled from a set point reference that is defined as Internal or External. When the set point reference is Internal, the set point value you specify via the keypad or Modbus is stored in the flow meter. When the PID is controlled from an analog input (4‐20 mA) signal, the PID set point reference is an External configuration. To access the External Input Setup option in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 20 for the External Input Setup menu, and then press E. 4> The following information appears if the feature was not purchased or was not available with the flow meter: 2–38 Kurz B‐Series Operations Guide...
Page 75 Press P to skip to the prompt without making changes. You need to specify the 4‐20 mA range of the external analog input by setting the 4 mA and 20 mA values. The 4 mA value prompt sets the minimum value for the PID set point in flow rate or velocity units (determined when the PID was set up). The example uses the PID controlled variable as the flow rate. INP VAL AT 4mA >0.000000 SCFM Use the numeric and decimal keys to enter the minimum PID set point, and then press E. 6> Press P to skip to the prompt without making changes. The 20 mA value prompt sets the maximum value for the PID set point in flow rate or velocity units (determined when the PID was set up). INP VAL AT 20mA >0.000000 SCFM Use the numeric and decimal keys to enter the maximum PID set point, and then press E. 7> Press P to skip to the prompt without making changes. The prompt appears for the External Input digital filter time constant. FILTER TC >0.500 Use the numeric and decimal keys to enter the value, and then press E. 8> The default is 0.5 seconds. Press E or P to exit the External Input Setup menu and return to the main Program mode 9> prompt. Kurz B‐Series Operations Guide 2–39...
Page 76: Determining The Pid Control Mode
“Accessing the PID Data Menu” (option 21). The PID is under manual control if PID operation is in Manual mode and the PID state is ON. Under manual control, you adjust the PID output or 4‐20 mA position signals. To access the Manual PID Control menu in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 22 for the Manual PID Control menu, and then press E. 4> The following information appears if the feature was not purchased or was not available with the flow meter: PID FUNCTION IS NOT INSTALLED You can perform a hardware check to see if this feature is available for your meter. If the feature is installed, a prompt appears indicating the PID active state ON or OFF. PID STATE IS OFF NOT ACTIVE To change the active state of PID from OFF to ON, go to the PID Data menu (option 21). If Automatic mode is enabled, the following prompt appears. PID IS AUTOMATIC SET MANUAL MODE 2–40 Kurz B‐Series Operations Guide...
Page 77: Viewing The Pid External Input Current
0 percent is the minimum PID limit equivalent to the minimum output current is — reached. Viewing the PID External Input Current The External input current level is available in Display mode. To view the External input current in Display mode: Press D. 1> Press 2 to invoke the Quick Jump option. 2> Press 41 to view the External input current, and then press E. 3> The following information appears. IN= XX.XXX AT YYYY.YY SCFM where: XX.XXX value is the 4‐20mA signal (current) read from the analog input. YYYY.YY value is the equivalent PID reference (flow rate or velocity) at the XX.XXX current level. The mapping of input current to flow rate or velocity is configured in the Set External Input Data menu. Press H to exit the External input current and return to the main Display mode option entry 4> prompt. Press H again to return to Run mode. Kurz B‐Series Operations Guide 2–41...
Page 78: Manually Tuning A Pid Loop
B‐Series Flow Meter Menu Applications Manually Tuning A PID Loop To manually tune a PID loop: Place the unit in manual control mode or open loop control. 1> Increase or decrease the 4‐20 mA output from 5 to 10 percent, and note the flow response 2> change. Then the Proportion Gain starting point is: 2 x output change (engineering units/flow response change) (this is a unit less number) Note the system response time change (from 0 to 63 percent). Set the Integral response time to this number. 3> Set the derivative time constant to 1/6 of the integral time. 4> Place the flow meter in a closed loop or automatic operation. Make a small change to the 5> set point and observe the reaction. 2–42 Kurz B‐Series Operations Guide...
Page 79: Figure 2-2. Examples Of System Responses
Time Over Damped Response Reduce the proportional gain and increase the integral time constant by the same percentage (such as 25 percent). Time Over Damped Response System tuned corre.ctly. Note the parameters. Time Figure 2‐2. Examples of system responses Kurz B‐Series Operations Guide 2–43...
Page 80: Changing The Wgf Vapor Correction Factor
Changing the WGF Vapor Correction Factor To access the WGF Parameters menu in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 27 for the WGF Parameters menu, and then press E. 4> PROCESS TMAX >0.00000000 DEGF This is the estimated maximum saturation temperature in the pipe. For a digester application, this will match the digester temperature (a typical digester operates at 100°F). If this value is set too high, it will overcorrect the wet‐to‐dry flow rate. The unit of measurement is either DegC or DegF. If the measure is zero (0), the dry flow rate value is assigned. Press E. 5> PROCESS PRESSURE >14.7000000 PSI This is the pressure in the line where the flow is being measured. The unit of measurement is either kPA or PSI. If the measure is zero (0), the dry flow rate value is assigned. Press E or P to exit the WGF Parameters menu. 6> The WGF vapor correction factor is also accessible through Modbus using function 03, holding registers 0x3b for WGF pressure and 0x3D for WGF Tmax. If you change WGF parameters via Modbus, you must also save the changes to EEPROM so the changes are saved if the flow meter is power cycled. 2–44 Kurz B‐Series Operations Guide...
Page 81: Setting Flow Meter Modbus Connectivity
Flow control — None Flow control — None Default address — 1 Default address — 1 To access the Modbus Communications menu in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 19 for the Modbus Communication Setup menu, and then press E. 4> The menu prompts you for the flow meter device address. DEV MODBUS ADDR >1 The address can be in the from 1 to 247. The default address is 1. Press the numeric keys to enter the device address, and press then E. 5> The menu prompts you for the Modbus mode. MODBUS MODE >MODBUS ASCII ^v The Modbus mode defines whether the master/slave device will communicate using the Modbus ASCII or Modbus RTU protocol. Modbus RTU is the default. The B‐Series Modbus setup for ASCII transmission framing is not Note supported by KzComm. If KzComm is to be used over Modbus, RTU transmission framing must be used. Kurz B‐Series Operations Guide 2–45...
Page 82 MODBUS BAUD RATE >9600 BPS ^v Slower rates (9600) are commonly used for longer distances between the device and the computer, while faster rates (57600) are for much shorter distances. The rates are 9600, 14400, 19200, 38400, and 57600. The default is 9600 BPS. Use the arrow keys to select a data speed, and then press E. 7> The menu prompts you for the byte order of the Modbus registers. REGISTER ORDER >BYTE #12 34 ^v This parameter ensures the Modbus Master correctly interprets the floating point data from the Modbus registers. There two options indicate the order of the Modbus registers when two registers are used for a device parameter. BYTE #1 2 3 4 (the default) means that the low order byte is sent first, followed by — the high order byte. BYTE # 3 4 1 2 means that the high order byte is sent first, followed by the low — order byte. Use the arrow keys to select a byte order, and then press E. 8> Press E or P to exit the Modbus Communication Setup menu. 9> If an issue occurs with reading floating point numbers, try changing the Note Register Order parameter. 2–46 Kurz B‐Series Operations Guide...
Page 83: Cleaning A Sensor
Using the Integrated Purge Controller The B‐Series is available for single‐point or multi‐point applications with a purge version that incorporates a purge control timer and data‐hold function built into the flow transmitter. The cleaning sequence can be initiated from: Internal flow meter timer • External contact closure • Write Coil command via Modbus • HART command • The Purge version of the flow meter provides an automated cleaning method to remove as much dirt buildup as possible using high velocity gas on the velocity sensor. This purge method is very effective at increasing the intervals between manual cleaning. In many cases it has altogether eliminated the need for manual cleaning, significantly reducing the cost of ownership. The purge gas can be at ambient temperature or heated to the process temperature. The advantage of using heated purge gas is that it does not condense any of the process gas onto the sensor, which could cement the dirt onto the sensor instead of blowing it off. Data is held during the Purge cycle. Implementing the internal timer with the cleaning control makes it easier to be independent of the process operation. The only verification for an active Purge cycle is querying a status register through Modbus (register 1XXXX ‐ coil status #8). The meter’s process variables (flow, velocity, and temperature) are held at their values prior to the start of the Purge cycle. Going from a dirty sensor to a clean sensor will show a spike in the flow rate and velocity after the Purge cycle completes. For applications that need tight control of the operation, the external contact closure offers the best results. Kurz B‐Series Operations Guide 2–47...
Page 84: Wiring For The Purge Controller
Wiring for the Purge Controller The purge controller setup requires connecting a 24 VDC 12 W maximum solenoid to the DO2 or solid state relay channel #2. Pin # TB6‐1 is +24 VDC and TB6‐2 is the GND connection. See the field wiring diagram for an example of the solenoid wiring. The recommended wiring gage is 18 AWG (1.02 mm), although the gage and length are not critical for this connection. This wiring information only applies to the Purge version of Note model 454PFTB‐16. To activate the purge with an external contact closure, the contact closure is on pins TB6‐8 or digital input 1 (DI1) and GND, TB6‐5. The width of the activation pulse must be at least 25 ms long, and the purge will start on the leading edge (or falling from logic high to low). Assigning a Relay to the Purge Function To use the sensor purge cleaning feature of the meter, relay #2 must be assigned to PURGE OUTPUT. To set the purge relay assignment in Program mode: Press P. 1> Enter your advanced access password, and then press E. 2> Press 2 to invoke the Quick Jump option. 3> Press 8 for the Relay Output Setup menu, and then press E. 4> 2–48 Kurz B‐Series Operations Guide...
Page 85: Changing The Purge Controller Configuration
Use the arrow keys to change the selection to PURGE OUTPUT, and then press E. 6> Relay #2 is now assigned to the purge output function unless the following prompt indicates that Relay #2 is used by another function: RELAY IS USED CHANGE IT>NO Press the arrow keys to change the response to YES, and then press E. 7> The meter will reassign Relay #2 to the PURGE OUT function. The previously assigned function is now unassigned and turned off, when applicable. The user interface advances to the Setup Sensor Purge function (menu option 12). Changing the Purge Controller Configuration The first parameter in the Setup Sensor Purge menu turns the Purge Timer ON or OFF. When set to ON, the sensor purge cleaning sequence is initiated by an internal timer in the flow meter. The PURGE TIMER does not need to be ON for the purge to be initiated Note via Modbus, HART, or the external contact closure. PURGE TIMER >ON ^v Press the arrows keys to set the parameter to ON, and then press E. 1> If Relay #2 is used by another function, the following prompt appears: DO2 IS USED CHANGE IT>NO Press the arrow keys to change the response to YES, and then press E. 2> Kurz B‐Series Operations Guide 2–49...
Page 86 After the PURGE TIMER is turned on, the menu confirms the relay assignment with the following prompt: PURGE OUTPUT ASSIGNED to DO2 Press E or P to continue. 3> The PURGE TIME prompt appears. This is the length of time the purge solenoid is held open. PURGE TIME MSEC >500 Use the numeric keys and type in the number of milliseconds to hold the purge solenoid 4> open during the purge, and then press E. (A short blast generally works best.) The HOLD TIME prompt appears. The HOLD TIME allows the sensor to recover from the purge by masking off the large flow spike following the purge. It can be a function of the purge gas temperature compared with the temperature of the process gas being measured. A longer HOLD TIME may be needed if there is a large temperature difference between these two variables. Following a purge, lower flow rates typically need more recovery time than higher flow rates. A cleaned sensor changes the flow readings following a purge regardless Note of the specified hold time. Additionally, the rate at which the shift occurs is filtered by the meter time constant setting. The HOLD TIME applies to the update of the flow rate, velocity, and temperature values with respect to the 4‐20mA output, Modbus output, and display. The HOLD TIME is the total time for the entire purge cycle. For example, a HOLD TIME of 2000 milliseconds with a PURGE TIME of 500 milliseconds means that the Purge Relay will be pulsed for 500 milliseconds, followed by an additional 1500 milliseconds of idle time to allow for sensor recovery. The HOLD TIME value must be greater than or equal to the PURGE TIME Note value. 2–50 Kurz B‐Series Operations Guide...
Page 87: Operating And Monitoring Purge Cleaning Using Modbus
> 60 The PURGE INTERVAL can be from 1 and 1440 minutes. Use the numeric keypad and type the number of minutes for the desired PURGE INTERVAL, 6> and then press E. Operating and Monitoring Purge Cleaning Using Modbus The purge sequence can be triggered by writing a 1 to the Modbus coil #8 (Register 0X). This operation does not require the purge timer to be ON; however, Relay #2 must be assigned to the PURGE OUT function. Once started, the Modbus purge operation ignores Program mode purge commands. The Modbus purge trigger is independent of the internal timer. For example, if the Program mode purge interval is configured for 60 minutes, any Modbus purge commands are performed without affecting the internal timer purge sequence. The status of the purge via Modbus is provided at coil status #8, (Register 1X). A value of 1 indicates it is in the middle of a purge cycle, and a 0 indicates the cycle is idle. An in‐process purge sequence initiated through HART takes precedence Note over a purge sequence initiated through Modbus and causes the purge sequence initiated through Modbus to be ignored. Operating and Monitoring Purge Cleaning Using HART The parameters for setting up the purge sequence can be changed through the HART interface. Device‐specific commands 137, 138, and 139 are used for the B‐Series purge cleaning through the HART Master. The B‐Series Field Device Specification describes the format of these commands. For HART Masters using the B‐Series Device Descriptor (DD) files, the Purge Setup menu and purge method are available, as shown in Figure 2‐4. Refer to the HART Interface Guide for information about the B‐Series DD menu organization. Kurz B‐Series Operations Guide 2–51...
Page 88: Automatically Triggering Drift Check And Purge
B‐Series Flow Meter Menu Applications Figure 2‐4. Hart Sensor Purge Setup menu If the Purge Timer has been turned ON, the purge cycle initiated through the HART interface will not affect the purge sequence controlled by the internal timer. An in‐process purge sequence initiated through Modbus takes Note precedence over a purge sequence initiated through HART and causes the purge sequence initiated through HART to be ignored. Automatically Triggering Drift Check and Purge The Sensor Purge and the Drift Check zero, mid, and span parameters are two flow meter functions that can be configured to automatically trigger on a user configured interval. If both timers for these functions are turned ON and scheduled to initiate at the same time, the meter will run the activities consecutively (not concurrently). 2–52 Kurz B‐Series Operations Guide...
Page 89 2–2 access code 1–11 dot key 1–3 Boot mode 1–5 Display mode 1–9 downloading display screen 1–4 config log 1–21 keypad 1–3 event log 1–20 keypad symbols 1–3 min/max log 1–20 Log mode 1–20 run data log 1–21 Kurz B‐Series Operations Guide Index–1...
Page 90 1–22 access code 1–22 keypad decimal places 1–3 external input setup menu 1–18 , description 1–2 1–3 negative values, entering 1–3 Kurz USB driver xi files KzComm config log, downloading 1–21 software requirements xi event log, downloading 1–20 USB driver requirements xi min/max log, downloading 1–20 ...
Page 91 1–13 , 1–2 1–7 gas calibration curve selection 1–17 input cal high test 1–23 input cal low test 1–23 manual PID adjustment 1–18 NE‐43 alarm setup menu 1–15 modbus communications setup 1–18 NE‐43 alarm setup 1–15 negative key 1–3 PID data setup 1–18 pulse mode totalizer 2–24 pulse output 2–25 Kurz B‐Series Operations Guide Index–3...
Page 92 2–44 relay outputs menu 2–24 time, boot‐up 1–5 remote correction data factor menu 1–17 , timeout 2–3 2–7 reports, running 1–20 totalized flow resetting 2–10 requirements viewing 2–9 B‐Series xi software xi trend log 1–21 USB driver xi Index–4 Kurz B‐Series Operations Guide...
Page 93 2–9 VLeak ca high menu 1–23 VLeak ca low menu 1–23 voltage drive test menu 1–23 input menu 1–23 ramp test menu 1–23 , wet flow rate 2–2 2–44 , dry flow rate 2–2 2–44 , wet flow rate 2–2 2–44 wireless configuration, modbus TCP/IP 2–45 wiring verification 1–5 Kurz B‐Series Operations Guide Index–5...
Page 94 Index–6 Kurz B‐Series Operations Guide...
