Ipod Speaker, art.no. 38-2647/38-2648
model FG-M512E-B/FG-M512C-B
Please read the entire instruction manual before using and
save it for future use.
We apologise for any text or photo errors and any changes
of technical data.
If you have any questions concerning technical problems
please contact our Customer Service Department (see ad-
dress on reverse.)

Getting Started

Inserting batteries

1. Turn the on/off switch on the top of the speaker to "OFF"
before inserting or changing batteries.
2. Open the two battery covers on the back and insert 4
x LR03/AAA-batteries. Make sure to align the batteries
according to the marking in the battery compartment.
3. Close the battery covers.

Using the AC/DC adaptor

1. Turn the on/off switch on the top of the speaker to "OFF"
before connecting or disconnecting the adaptor.
2. Plug the AC/DC adaptor into the "DC IN" socket on the
back of the speaker and then into a wall socket.

Using the table stand

To extend – Depress the catch and fold out
the table stand until a "click" is heard.
To retract – Depress both of the hinge
catches as shown in the diagram whilst
folding up the table stand.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service. Internet: www.clasohlson.co.uk
ENGLISH

Use

Playing music

1. Lift the transparent cover.
2. Place the iPod in the holder by pushing
it straight down with the front facing
you.
Make sure that the speaker connection
on the bottom of the holder is correctly
connected to the speaker connection
on your iPod.
3. Close the cover and turn the on/off
switch to "ON". The indicator on the
front of the speaker will light.
4. Turn on your iPod and start playing it, adjust the volume
on your iPod.
5. You can connect earphones to the earphone socket on
the top of the speaker if you wish to listen discretely. The
speakers will then become silent.

Care and Maintenance

Use a soft damp cloth to wipe the product. Do not use deter-
gents or solvents.

Troubleshooting Guide

No sound
-
Check that the batteries are inserted correctly or that the
adaptor is connected (the indicator lamp will light if the
speaker is on).
-
Make sure that the speaker is turned on and that the
iPod is sitting in the holder correctly.
-
Adjust the volume on your iPod.

Disposal

Follow local ordinances when disposing of this product. If
you are unsure about how to dispose of this product contact
your municipality.

Specifications

Power:
5 V DC, 1 A
Battery type:
4x LR03/AAA
Impedance:
4 Ohm
Output:
4 W max
Frequency range: 150 Hz ~ 20 kHz
Earphone socket: 3.5 mm stereo
Size:
110 x 128 x 17 mm (WxHxD)
Weight:
ca 127 grams (excl.adaptor)
