GAS DRYER INSTALLATION INSTRUCTIONS
CANADIAN ELECTRIC DRYER INSTRUCTIONS
INSTRUCTIONS POUR L'INSTALLATION
DE LA SÉCHEUSE À GAZ (É.-U. ET CANADA)
ÉLECTRIQUE (CANADA UNIQUEMENT)

Table of Contents

DRYER SAFETY .......................................................................... 2
INSTALLATION REQUIREMENTS .............................................. 4
Tools and Parts ...................................................................... 4
LOCATION REQUIREMENTS ..................................................... 5
GAS DRYER POWER HOOKUP ................................................. 7
INSTALL LEVELING LEGS .......................................................... 9
MAKE GAS CONNECTION ....................................................... 10
VENTING .................................................................................... 10
Venting Requirements ......................................................... 10
Plan Vent System ................................................................. 11
Install Vent System .............................................................. 12
CONNECT VENT ....................................................................... 14
LEVEL DRYER ........................................................................... 15
COMPLETE INSTALLATION CHECKLIST ............................... 15
DOOR REVERSAL (OPTIONAL) ............................................... 16
INSTALLATION NOTES
__________________________________
Date of purchase:
________________________________
Date of installation:
_________________________________________
Installer:
____________________________________
Model number:
____________________________________
Serial number:
W10868945A
W10868946A-SP
Para una version de estas instrucciones en español, visite www.Whirlpool.com
Table des matières
SÉCURITÉ DE LA SÉCHEUSE ................................................. 26
EXIGENCES D'INSTALLATION................................................. 28
Outillage et pièces ............................................................ 28
EXIGENCES D'EMPLACEMENT .............................................. 29
SÉCHEUSE ÉLECTRIQUE RACCORDEMENT À
L'ALIMENTATION ÉLECTRIQUE - CANADA SEULEMENT ... 31
RACCORDEMENT D'UNE SÉCHEUSE À GAZ ....................... 31
INSTALLATION DES PIEDS DE NIVELLEMENT...................... 33
RACCORDEMENT AU GAZ ...................................................... 34
ÉVACUATION ............................................................................ 34
Exigences concernant l'évacuation ................................ 34
Planification du système d'évacuation ........................... 35
Installation du système d'évacuation .............................. 37
RACCORDEMENT DU TUYAU D'ALIMENTATION
(MODÈLE À VAPEUR UNIQUEMENT) ..................................... 37
RACCORDEMENT DU CONDUIT D'ÉVACUATION ................ 39
RÉGLAGE DE L'APLOMB DE LA SÉCHEUSE......................... 39
ACHEVER L'INSTALLATION LISTE DE VÉRIFICATION .......... 40
INVERSION DE LA PORTE (FACULTATIF) ............................... 40
NOTES CONCERNANT L'INSTALLATION
_____________________________________
Date d'achat:
_________________________________
Date d'installation:
______________________________________
Installateur:
________________________________
Numéro de modéle:
__________________________________
Numéro de série:
