  • Page 1 Manual LED Easy Move Micro Beam RGBW...

  • Page 2: Table Of Contents

    Table of contents Safety instructions ..........................3 1.1. FOR SAFE AND EFFICIENT OPERATION ................3 Designated use ..........................4 2.1. Overhead installation ....................... 5 Introduction ............................7 3.1. Product overview ........................7 Connections ............................. 8 4.1. Electrical connections ......................8 4.2.

  • Page 3: Safety Instructions

    1. Safety instructions • This device is suitable for indoor use (not outdoors) only. device is suitable for indoor use (not outdoors) only. • All modifications to the device will void the warranty. All modifications to the device will void the warranty. •...

  • Page 4: Designated Use

    2. Designated use This device was developed for professional use on stages, in discos, theatres etc. The device is only approved for a connection up to 230V 50/60 Hz AC voltage and only for indoor use. Regular breaks during operation increase the lifetime of your device. Avoid convulsions or any form of forceful impact during the installation or the start-up of the device.

  • Page 5: Overhead Installation

    2.1. Overhead installation Overhead installation Danger of life! Danger of life! You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and EN60598-2-17 17 Installations are to carry out by skilled personnel only.
  • Page 6 The maximum drop exceed must not exceed 20cm. A safety rope once exposed to failing load or damaged may not be used furthermore. Adjust the desired inclination angle via the mounting bracket and tighten the screw. 6 / 16...

  • Page 7: Introduction

    3. Introduction Thank you for buying the LED Easy Move Micro Beam. . It is a powerful device. For a successful installation and operation, please read this manual carefully. 3.1. Product overview 1. Display 6. Power in P-Con 2. Menu 7.

  • Page 8: Connections

    4. Connections 4.1. Electrical connections If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the mains with the enclosed power cable and plug. The earth has to be connected. Cable (EU) Cable (US) International Brown Black...

  • Page 9: Control

    5. Control Press MENU to reach the first menu and use UP/DOWN to get to submenu. To open submenu you have to press ENTER, here you can also reach other menu items with UP/DOWN buttons, confirm with ENTER. Press MENU to store your settings. 5.1.
  • Page 10 Manual assignment of the DMX channel for the Stro 00-08 strobe. Manual assignment of the DMX channel for the Lumi 01-13 dimmer. Manual assignment of the DMX channel for color Colo 01-13 macros. Manual assignment of the DMX channel for Autu 00-08 automatic mode.

  • Page 11: Dmx Chart

    6. DMX chart 6.1. DMX mode Standard (13 channels) Channel Value from Value to Function Pan fine Tilt Tilt fine Speed Pan/Tilt fast-slow No function Highest speed Dimmer red Dimmer green Dimmer blue Dimmer white Strobe No function Strobe Dimmer Color macros No function Green...

  • Page 12: Dmx Mode Basic (11 Channels)

    6.2. DMX mode Basic (11 channels) Channel Value from Value to Function Tilt Speed Pan / Tilt fast-slow No function Highest speed Dimmer red Dimmer green Dimmer blue Dimmer white Strobe No function Strobe Dimmer Color macros No function Green Blue White Red / blue...

  • Page 13: Technical Data

    7. Technical data Power supply Voltage AC 100-240 V; 50/60 Hz Power consumption max. 35 W Light source LM type 4in1 Osram LED Color spectrum RGBW Power 15 W Number / Power 1 x 15 W Connections Strom in P-Con Strom out P-Con XLR in/out...
  • Page 14 14 / 16...
  • Page 15 15 / 16...
  • Page 16 Importer: B & K Braun GmbH Industriestraße 2 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 16 / 16...
