Summary of Contents for Cuckoo CRP-JH10 Fuzzy Series
Page 1
Operating nstructions CRP-JH10 Fuzzy Series 1.8L(2~10Persons) / 1.8L(2~10 NO.1 CUCKOO CUCKOO IH PRESSURE JAR COOKER Thank you very much for purchasing “CUCKOO” 저희 쿠쿠 IH 압력밥솥을 애용해 주셔서 IH PRESSURE JAR COOKER 대단히 감사 드립니다. 이 사용설명서는 잘 보관하여 주십시오.
현재시각의 설정 / 야간음성 볼륨 설정 기능 How to cook …………………………………………………… 17 ……………………………………… 41 취사 전 준비사항 My mode (CUCKOO Customized taste function) …………… 18 ……………………… 42 취사는 이렇게 하십시오 How to use “GABA Rice (BROWN Rice)”…………………… 19 …………………………………… 43 쿠쿠...
IMPORTANT SAFEGUARDS 1. Read all instructions before using this appliance. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against fire, electric shock and / or injury to persons do not immerse cord, plugs, or Pressure Cooker Body in water or any other liquid.
If the plug does not properly fit in the outlet, turn the plug over. If it still does not fit, contact a qualified electrician. Please, keep this safety feature. SPECIFICATIONS / 제품규격 / 产品规格 CRP-JH10 Fuzzy Series Model Name(모델명) Power Supply(전원) AC120V, 60Hz Power Consumption(소비전력)
SAFETY PRECAUTIONS Read the following product safety guide carefully to prevent any accidents and/or serious danger. ● ‘Warning’ and ‘Caution’ are different as follows. ● •This sign is intended to remind and alert that something may cause This means that the action it describes Warning problems under the certain situation.
Page 6
SAFETY PRECAUTIONS Caution Do not Do not use it on a rice chest or a shelf. After you finish cooking, do not try to open the cooker •Do not place the power cord between furniture. It can by force until the steam is completely exhausted. cause an electric shock resulting in fire.
Page 7
안전상의 경고 ‘안전상의 경고’ 는 제품을 안전하고 올바르게 사용하여 사고나 위험을 미리 막기 위한 것이므로 반드시 지켜 주십시오. ● ‘안전상의 경고’ 는 ‘경고’ 와 ‘주의’ 의 두가지로 구분되어 있으며 ‘경고’ 와 ‘주의’ 의 의미는 다음과 같습니다. ● •이 기호는 특정조건하에서 위험을 끼칠 우려가 있는 사항에 피하지...
Page 8
안전상의 경고 주의 (금지 ) 쌀통 및 다용도 선반 등에 제품을 놓고 사용하지 마십시오. 사용하지 않을 때는 전원플러그를 콘센트에서 뽑아 주십시오. •전원코드가 틈새에 눌러져 화재 및 감전의 원인이 됩니다. •절연 성능 저하로 인해 감전, 누전, 화재의 원인이 될 수 있습니다. 수시로...
NAME OF EACH PART Name of each part Accessories Pressure Weight Soft Steam Cap Always keep it horizontal.It stabilizes steam inside of the oven. Pressure weight is twisted, it release steam. Automatic Steam Exhaust Outlet (Solenoid valve) When finished cooking or during warming, steam is automatically released.
HOW TO CLEAN - To prevent foul odor clean the lid assy after the rice cooker has cooled and the rice cooker is unplugged. - Clean the body of rice cooker and the cover with a dry towel. Do not use benzene or thinner to clean the rice cooker.
HOW TO CLEAN How to clean the pressure weight nozzle. If the valve of the pressure part is clogged, puncture it with the cleaning pin •The valve hole of the pressure weight allows steam to release. Check regularly to ensure that it not blocked. If the valve hole of the pressure weight is blocked, the hot steam and hot content within the cooker can cause serious injury.
FUNCTION OPERATING PART/ HOW TO SET OR CANCEL VOICE GUIDE FUNCTION FUNCTION OPERATING PART Display :SLIDE TOUCH HIGH HEAT Button Ri g ht sel e cti o n button This function is used for to activate Left selection button the High heat cooking mode of the SLIDE Touch cooking functions such as GLUTIN.
HOW TO SET CURRENT TIME/ NIGHT VOICE VOLUME REDUCTION How to set current time ex)8:25am now Press ‘MODE’ button 2 times. <Standby mode> ▶ ‘MODE’ button needs to be pressed for over 1 second at the first time. ▶ A voice comes up saying “Setting mode for current time. Touch and slide to set current time then press SET button.”...
BEFORE COOKING RICE Use a dry cloth to clean inner pot. ▶ Use a soft scrubber to wash the inner pot. ▶ Do not use rough or metallic scrubber. Otherwise, coating will pilled off. ▶ Do not put anything that are metallic and sharp into the inner pot while cleaning.(Fork, spoon, chopsticks, knife, and etc.) Use measuring cup to measure desirable cooking amount.
Then press the ‘COOK/TURBO’ button, and ·Each time ‘MENU/SELECTION’ button is pressed, the selection sound “GLUTIONUS RICE, Cuckoo starts cooking switchs in the sequential order, LOW PRESS GLUTIN. → SUPER GRAIN → GABA RICE → NU RUNG JI → GLUTIN.RICE → HIGH HEAT GLUTIN.RICE → MIXED RICE → HIGH at a pressure of 2 atmosphere.”...
HOW TO USE “GABA RICE (BROWN RICE)” What is Germinated Brown rice? Brown rice has richer nutrients than polished rice. However, brown rice is rather tough and hard to be digested. By germination, the enzymes in the brown rice are activated, generating nutrients, and are easier to digest. Using “GABA”...
HOW TO COOK SUPER GRAINS What are supergrains? Supergrains have a better nutritional balance than that of rice, and contain an abundance of various vitamins, minerals, antioxidants, and dietary fiber. It is a good alternative to rice, and is an excellent nutritional source for supplementing nutrition. Characteristics of Supergrains Kamut (for antioxidant effects): Kamut contains selenium, which removes active oxygen from your body.
HOW TO COOK LOW/HIGH PRESS STEAM HOW TO COOK LOW/HIGH PRESS STEAM Coupling Handle toward “ ” (Lock), and press the Select button to select low-pressure steaming or high-pressure steaming. The SET button blinks, and the Cancel button and the Cook/Turbo ▶...
” (Lock). Press the Pressure Check button or the Cook/Turbo button, and pressure check begins. The Voice Guide will say, “CUCKOO begins pressure check.” ▶ ▶ If you press the Cook/Turbo button without turning the Cover Coupling Handle toward “...
HOW TO USE PRESET / PRESET REHEATING FUNCTION How to preset timer for cooking For example, if it is nine o’clock in the evening and you want to have warm breakfast at seven forty the next morning. ❶ Make sure that the current time is correct. ▶...
HOW TO USE PRESET / PRESET REHEATING FUNCTION Precautions for PRESET / PRESET REHEATING Cooking Precautions for Preset Cooking ▶ If the rice is old and dry, the result may not be good. ▶ If the rice is not well cooked, add more water by about half-scale. ▶...
Page 25
TO KEEP COOKED RICE WARM AND TASTY Having a Meal ▶ If you want to have warm rice, press the ‘WARM/REHEAT’ button. Then ‘Reheat’ function will be started and you can eat fresh rice in 9 minutes. ▶ To use reheating in standby status after power is applied, turn lid combining hand grip to Locked location, press ‘WARM/REHEAT’...
Page 26
TO KEEP COOKED RICE WARM AND TASTY How to Operate My Mode Function. Use it while opening the lid when there is too much water or rice becomes too soft. ❷-1 Press the right select button. ❸If you set your desired temperature and press the SET button, the set ❶...
FOR THE BEST TASTE OF RICE Cook tasty rice with Cuckoo pressure rice cooker For the best taste of rice, check the following points carefully. When measuring the rice, use the measuring cup. (The amount When measuring the rice, Use the measuring cup. (The amount of the rice may vary depending on the quality of the rice.) Place...
2), set the mode to Step 1. If you want the mode to start when it's brighter than the current level, set the mode to Step 3. (The power saving mode of CUCKOO is set to Step 2 at the factory.) ...
HOW TO USE POWER SAVE SCREEN LIGHT / LOCK BUTTON / REMAINING COOKING TIME DISPLAY MODE Display POWER SAVE SCREEN LIGHT Mode This mode adjusts the brightness of the display during cooking, warming or reservation cooking. ▶ How to set and unset the mode (This mode is selected ‘On’...
Page 30
CHECK BEFORE ASKING FOR SERVICE ▼ If there is a problem with your cooker, check the following details before requesting service to your dealer. Sometimes the cooker may not operate as desired if used incorrectly. Case Check points Do the following •Did you turn the “lid”...
Page 31
CHECK BEFORE ASKING FOR SERVICE ▼ If there is a problem with your cooker, check the following details before requesting service to your dealer. Sometimes the cooker may not operate as desired if used incorrectly. Case Check points Do the following When the button cannot •Please insert inner pot.
CHECK BEFORE ASKING FOR SERVICE ▼ If there is a problem with your cooker, check the following details before requesting service to your dealer. Sometimes the cooker may not operate as desired if used incorrectly. Case Check points Do the following •...
Recipe ※ After cooking reter to page 12 of the notes upon the inner pot washing. ※ Please refer to our website (www.cuckoo.co.kr) for more information. Recipe Ingredients Directions Rice 6 cups Glutin. * The “cup” in ingredients means a measuring cup 1.
Page 34
Hard-boi l e d Cuttl e fi s h Japchas Steamed Corn Butter chocol a te cake 35min 25min 20min 15min 40min 40min 20min 15min Steak Steamed Dumpl i n g Fresh Cream Cake Tteokbokki ※ Please refer to our website (www.cuckoo.co.kr) for more information.
Page 35
취사는 이렇게 하십시오 각 부분의 이름 각 부 명칭(외부) 부속품 안내 압력추 소프트스팀캡 취사나 요리 전 압력추를 수평으로 맞추어 주십시오. 내부의 압력이 일정하도록 조절하며, 젖히면 수동으로 증기배출이 됩니다. 자동 증기 배출구 취사나 요리가 끝나거나 보온시 자동으로 증기를 배출시켜 줍니다. 필요할 경우 취소 버튼을 눌러 증기를...
Page 36
제품 손질 방법 / 뚜껑 결합 손잡이의 사용법에 관하여 - 청소를 잘하지 않으면 보온 중 냄새가 나는 원인이 됩니다. 특히 뚜껑부는 자주 청소해 주십시오. (전원플러그를 빼고 본체의 열이 식고 난 후 손질하십시오.) - 본체·뚜껑은 물기를 제거한 행주로 닦아 주십시오. 벤젠, 신나 등은 사용하지 마십시오. - 분리형...
Page 37
제품 손질 방법 압력 노즐막힘 손질 방법 압력추 소프트 스팀캡 이물질 등으로 압력추 증기 배출구가 막혀 있으면 제 기능을 발휘하지 못하므로 취사나 요리 완료 후 떼어낸 다음 사용 전·후에는 아래의 압력추/증기배출구 청소방법을 참조하여 압력추를 주방용 중성세제 및 스폰지로 자주 분리한 다음 청소용 핀으로 구멍을 뚫은 후 사용해 주십시오. 세척해...
Page 38
기능 조작부의 이름과 역할 / 음성 안내기능의 설정과 해제 기능 조작부의 이름과 역할 기능표시부 :SLIDE TOUCH : 우측 선택 버튼 고화력 버튼 : 좌측 선택 버튼 백미, 잡곡, 현미 메뉴의 고화력 : 슬라이드부 취사를 할 경우 사용 ▶ 41쪽 참조 메뉴를...
Page 39
현재시간의 설정 / 야간 음성볼륨 설정 현재시각은 이렇게 맞추십시오. 현재시각을 맞추려면 다음 사항을 꼭 알아두십시오. 예) 현재 시각이 오전 8시 25분일 경우 <대기상태> 전원플러그를 꽂은 후 설정 버튼을 2회 누릅니다. ▶ 설정 버튼을 초기에 누를 시 0.3초 이상 눌러야 진입 가능합니다. ▶“현재...
Page 40
취사 전 준비사항 내솥을 깨끗이 씻은 후 물기를 닦습니다. ▶ 내솥을 씻을 때는 부드러운 행주를 사용하여 주십시오. ▶ 강한 수세미를 사용하면 내솥 안쪽 표면이 벗겨지는 경우가 있습니다. 계량컵을 사용하여 쌀을 인분수 만큼 별도의 용기에 담습니다. ▶ 쌀을 계량컵의 윗면 기준하여 평평하게 맞추면 1인분에 해당됩니다. (예...
Page 41
취사는 이렇게 하십시오 선택 버튼을 눌러 원하시는 메뉴를 선택합니다. 취사/쾌속 버튼을 눌러 취사를 시작합니다. ·분리형 커버가 장착되어 있는지 확인하여 주십시오. ·취사를 하기전에 반드시 뚜껑 결합 손잡이를“ ” (잠김)방향으로 ·취사 전 압력추를 수평으로 맞추어 주십시오. 돌리고 취사/쾌속 버튼을 누르면“백미, 쿠쿠가 2기압으로 맛있는 ·선택...
Page 42
쿠쿠 맞춤 밥맛 / 쿠쿠 맞춤 취사 기능 쿠쿠 맞춤밥맛이란 세계 최초로 쿠쿠만의 가변밥맛 기술을 개발하여 밥의 부드러운 정도와 차지고 구수한 정도를 자신의 기호에 맞게 선택하여 취사하는 기능으로 소비자가 원하는 밥맛으로 취사할 수 있는 쿠쿠만의 특허 기술입니다. 쿠쿠 맞춤밥맛기능 부드러운밥 단계 증가시 : 밥맛이 부드러워집니다. (부드러움 4단계 선택가능) 구수한밥...
Page 43
현미발아는 이렇게 하십시오 발아현미란 현미는 백미에 비해 영양가가 높은 식품이지만 먹었을 때 거칠고 딱딱하며, 소화하기 힘들다는 단점이 있으나 아주 조금만 발아 시켜도 잠자고 있던 효소가 활성화되어 영양성분이 보다 풍부하게 되고 소화 흡수가 훨씬 수월한 형태로 변화됩니다. 현미발아 메뉴의 조작방법 발아를 더욱 촉진 시키기 위해 현미를 미리 16시간 이내로 침수하여 예비발아를 해주십시오. 예비발아방법...
Page 44
슈퍼곡물은 이렇게 하십시오 슈퍼곡물이란 슈퍼곡물은 쌀보다 영양 밸런스가 좋고 각종 비타민과 미네랄, 항산화 성분, 식이섬유가 풍부하여 쌀 대체식으로 이용하기에 좋으며 부족한 영양 보충을 할 수 있는 훌륭한 영양원입니다. 슈퍼곡물의 특징 ❶ 카무트 : 항산화 효과 – 카무트에 함유되어 있는 셀레늄이 몸속에 활성 산소를 제거합니다. ❷...
Page 45
저압찜/고압찜은 이렇게 하십시오 저압찜/고압찜 사용 및 예약방법 뚜껑 결합 손잡이를“ ” (잠김) 방향으로 돌리고, 선택 버튼을 눌러 저압찜 또는 고압찜을 선택합니다. ▶ 확인 버튼이 점멸하고, 취소, 취사/쾌속 버튼이 켜집니다. ▶ 저압찜 또는 고압찜 메뉴가 선택되었을때는 표시부에 시간이 표시됩니다. ( “ 저압찜 확인 버튼을 눌러주세요.”또는“고압찜 확인 버튼을 눌러주세요.” 하는...
Page 46
압력체크는 이렇게 하십시오 압력체크 사용방법 밥솥 내부의 압력을 체크하여 압력 누설이 발생하는지 또는 증기 배출 장치의 이상여부를 점검할 수 있는 기능입니다. 대기상태 에서 압력체크 버튼을 눌러 주십시오. <대기상태> (38쪽 참조) ▶ “압력체크 기능입니다. 백미 물눈금 2까지 물을 넣고 취사나 압력체크 버튼을 눌러주세요.”하는...
예약 취사 / 예약 재가열은 이렇게 하십시오 예약 취사하는 방법 현재 시각이 오후 9시이고 다음날 오전 7시 40분에 식사를 하고 싶을 경우 ❶ 현재 시각이 맞는지 확인합니다. ▶ 현재 시각을 맞추는 방법은 39쪽을 참조하십시오. ❷ 뚜껑 결합 손잡이를“ ”(잠김) 방향으로 돌려 잠김표시가 나타나면 예약/자동세척...
Page 48
예약 취사 / 예약 재가열은 이렇게 하십시오 예약 취사 / 예약 재가열시 유의사항 예약 취사시 유의 사항 ▶ 쌀이 개봉된 지 오래되어 매우 말라버린 경우에는 층밥이 되는 수도 있습니다. ▶ 예약취사 설정시간 또는 주변 환경조건에 따라서 밥이 되거나 질어질 수 있으므로 내솥표시의 물(水)눈금 기준에서 가감하여...
밥을 맛있게 보온하려면 식사하실 때 ▶ 보온 중 식사를 하실 때 따끈따끈한 밥을 원하시면, 보온/재가열 버튼을 누르면 보온재가열이 시작되고 9분 후 밥을 드시면 금방 지은 밥처럼 따끈따끈한 밥을 드실 수 있습니다. ▶ 전원을 인가 후 대기상태에서 재가열을 사용하실 경우에는 뚜껑 결합 손잡이를 “ ”(잠김)위치로 돌린후 보온/재가열 버튼을...
Page 50
밥을 맛있게 보온하려면 맞춤보온 기능 조정방법 보온 시 뚜껑을 열 때 물이 많이 흐를 경우나 밥 가장자리에 밥 퍼짐 현상이 생길 경우에 사용합니다. ❷-1 우측 선택 버튼을 누릅니다.(높임) ❶ 대기상태에서 설정 버튼을 5회 누르면 맞춤 ❸ 원하는 값을 설정한 후 확인 버튼을 보온...
Page 51
맛있는 밥을 드시려면 취사할 때 주의 사항 맛있는 압력밥솥 밥을 드시려면 다음 사항을 꼭 알아 두십시오. 쌀의 양과 물의 양이 맞지 않으면 밥이 퍼석하거나 쌀은 반드시 계량컵을 사용하여 정확히 계량합니다. 설익거나 질게 될 수가 있습니다. (시중에 유통되고 있는 쌀통은 제품에 따라 쌀의 양이 다소 차이 가...
Page 52
절전기능 / 에너지아이 기능은 이렇게 하십시오 대기모드 절전기능이란 전원코드를 뽑지 않으면 동작하지 않는 대기상태라 할지라도 약간의 전력이 소모됩니다. 이를 대기전력이라고 하는데 이를 절감하기 위해 밥솥내부의 전기회로를 외부 전원으로부터 차단시켜 전력 소모를 최소화 하는 기술입니다. 수동 사용방법 ▶ 절전 시작방법 대기...
화면조명 절전기능 / 버튼 잠금기능 / 취사 잔여시간 표시기능은 이렇게 하십시오 화면조명 절전기능 대기, 취사, 보온, 예약 취사 중 화면의 밝기를 적절히 조절하는 기능입니다. (화면조명 절전기능 On상태에서 버튼 조명이 꺼지면 화면이 어두워집니다.) ▶ 기능 설정 및 해제 방법 ※제품출고시 설정된 값은 On 입니다. ...
고장신고 전에 확인하십시오 ▼ 제품에 이상이 생겼을 경우에는 서비스센터로 문의하시기 전에 아래 사항을 확인해 주십시오. 증 상 확인사항 조치사항 뚜껑 결합 손잡이가 “ ” (열림) •취사 또는 요리중에 뚜껑 결합 손잡이를 돌리지 •취사 또는 요리중에는 뚜껑이 열리지 않습니다. 방향으로 움직이지 않을 때 않았습니까? 뚜껑을...
Page 55
고장신고 전에 확인하십시오 ▼ 제품에 이상이 생겼을 경우에는 서비스센터로 문의하시기 전에 아래 사항을 확인해 주십시오. 증 상 확인사항 조치사항 밥이 심하게 눌을 때 •온도감지기, 내솥 외면에 밥알이 심하게 눌어 •온도감지기, 내솥외면의 이물질을 제거해 주십시오. 붙어 있거나 이불질이 있지는 않습니까? (36쪽 참조) •...
Page 56
고장신고 전에 확인하십시오 ▼ 제품에 이상이 생겼을 경우에는 서비스센터로 문의하시기 전에 아래 사항을 확인해 주십시오. 증 상 확인사항 조치사항 콩(잡곡/현미)이 설익을 때 •콩(잡곡/현미)이 너무 마르지 않았습니까? •콩(잡곡/현미)을 불리거나 삶아서 잡곡메뉴에서 취사를 하십시오. 잡곡의 종류에 따라 설익을 수도 있습니다. 밥이 너무 질거나 된밥일 때 •메뉴...
요리안내 ※ 상세 요리 재료 손질법은 쿠쿠홈페이지(www.cuckoo.co.kr)을 참조하세요. ※ 취사 후 내솥 세척시 36쪽의 유의사항을 참조하여 주십시오. 카테고리 요리명 요 리 재 료 요 리 방 법 1. 깨끗이 씻은 쌀을 내솥에 넣고 백미 또는 백미저압 물눈금 6까지 물을 부어 주십시오.
Page 58
두 부 찜 25분 15분 새우케찹볶음 15분 15분 약 밥 40분 30분 밥 피 자 20분 20분 잡 채 20분 20분 버터초콜릿케익 45분 45분 만 두 찜 20분 15분 떡 볶 이 20분 15분 → 상세 요리 손질법은 쿠쿠홈페이지(www.cuckoo.co.kr)를 참조하세요.
CUCKOO ELECTRIC RICE COOKER/WARMER LIMITED WARRANTY KEY Company, P&K USA TRADING CORP and Cuckoo Trading Canada will repair at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase. This warranty is good only to the original purchaser of the product during the warranty period.
