digiDL Con guration - Status Window

Status Item
Ignition
Authentication
Download
Upload
Task
Maintenance
VU CAN
Connectivity
Network Index
Download Button
VU Error Instruction
VU Error Code
Data Log
Please note: A status of zero generally means that this particular status is happy.
DigiDL Installation Guide
DigiDL Con guration Windows® Software
WIFI GPRS Description
Indicates whether CAN-Bus C, required for remote
download, is available
Indicates a valid Authentication with a Company Card or
the progress of the Authentication.
Shows whether a download is in progress
Shows whether an upload is in progress
Indicates when a task is requested from digicentral and
shows the type returned.
Indicates when the digiDL is maintaining its own les
and memory
Indicates activity over CAN-Bus C
Indicates activity over WIFI or GPRS
Currently chosen WIFI network index
Only relevant if the optional remote button is connected
and is used for Driver Card download requests
The most recent request made by digiDL resulting in an
error. Codes from Annex 1B.
Last error code from Vehicle Unit. Codes as de ned in
Annex 1B.
Default is OFF. Can be turned on remotely for debugging
by manufacturer.
Page - 20
