Philips FW-V720 Service Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. Stereo System
  5. FW-V720
  6. Service manual
Philips FW-V720 Service Manual

Philips FW-V720 Service Manual

Mini system
Hide thumbs Also See for FW-V720:
Table of Contents

Advertisement

Quick Links

See also: User Manual
www.freeservicemanuals.info
Mini System
Service
Service
Service
Service Manual
©
Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by BB 0119 Service Audio

TABLE OF CONTENTS

Location of pc boards & Version variations ................ 1-2
Technical Specifications ............................................. 1-3
Measurement Setup .................................................... 1-4
Service Aids, Safety Instruction, etc. .......................... 1-5
Instruction for use ....................................................... 2-1
Disassembly Instructions & Service positions ........... 3-1
Service Test Programs ............................................... 3-4
Set Block Diagram ...................................................... 4-1
Set Wiring Diagram ..................................................... 4-2
Front Control Board ....................................................... 5
Front Display Board ....................................................... 6
ECO6 Tuner Board : Systems Non-Cenelec .............. 7A
VCD-MPEG-01B Module ............................................... 8
ETF7 ND Tape Module .................................................. 9
3Cdc-Lc-Vcd Module ............................................... 10
Power 2001 Module (30-70W Version) ....................... 11
Center/Surround & Matrix Surround Socket Board ... 11A
Af9 Board .................................................................... 12
Vcd Gnd Isolator Board ............................................ 13
Set Mechanical Exploded View & parts list ................. 14
Printed in The Netherlands
Subject to modification
Published in Heiloo, Holland.
FW-V720/
Page
CLASS 1
GB
1/3/16
21M
COMPACT
DIGITAL AUDIO
3139 785 22840

Advertisement

Table of Contents
loading

Related Manuals for Philips FW-V720

Summary of Contents for Philips FW-V720

  • Page 1 LASER PRODUCT © Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2 SOCKET BOARD VIDEO OUT CINCH BOARD HEADPHONE BOARD KARAOKE BOARD POWER BOARD VERSION VARIATIONS: Type /Versions: FW-V720 /21M Features & Board in used: Aux in /CDR in Line Out Surround Out Subwoofer Out Digital Out Video Out Matrix Surround CD Text...
  • Page 3 www.freeservicemanuals.info 1/3/16 SPECIFICATIONS GENERAL: CASSETTE RECORDER: Mains voltage : 110-127V / 220-240V Switchable Number of track : 2 x 2 stereo : 4.76 cm/sec ± 2% Mains frequency : 50/60Hz Tape speed Power consumption : 15W at Standby Wow and flutter : <...

  • Page 4: Measurement Setup

    www.freeservicemanuals.info 1/3/16 MEASUREMENT SETUP Tuner FM Bandpass LF Voltmeter 250Hz-15kHz e.g. PM2534 e.g. 7122 707 48001 RF Generator e.g. PM5326 S/N and distortion meter e.g. Sound Technology ST1700B Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz). Tuner AM (MW,LW) Bandpass LF Voltmeter...
  • Page 5 www.freeservicemanuals.info 1/3/16 SERVICE AIDS Service Tools: ESD Equipment: Universal Torx driver holder ........4822 395 91019 Anti-static table mat - large 1200x650x1.25mm ... 4822 466 10953 Torx bit T10 150mm ..........4822 395 50456 Anti-static table mat - small 600x650x1.25mm ..4822 466 10958 Torx driver set T6 - T20 .........

  • Page 6: Laser Product

    www.freeservicemanuals.info 1/3/16 WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen susceptible to electrostatic discharges (ESD). (ESD). Careless handling during repair can reduce life Onzorgvuldig behandelen tijdens reparatie kan drastically.
  • Page 7 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 8 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 9 www.freeservicemanuals.info 1/3/16 E n g l i s h Published in Heiloo, Holland.
  • Page 10 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 11 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 12 www.freeservicemanuals.info 1/3/16 E n g l i s h Published in Heiloo, Holland.
  • Page 13 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 14 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 15 www.freeservicemanuals.info 1/3/16 English Published in Heiloo, Holland.
  • Page 16 www.freeservicemanuals.info 1/3/16 2-10 English Published in Heiloo, Holland.
  • Page 17 www.freeservicemanuals.info 1/3/16 2-11 English Published in Heiloo, Holland.
  • Page 18 www.freeservicemanuals.info 1/3/16 2-12 E n g l i s h Published in Heiloo, Holland.
  • Page 19 www.freeservicemanuals.info 1/3/16 2-13 Published in Heiloo, Holland.
  • Page 20 www.freeservicemanuals.info 1/3/16 2-14 English Published in Heiloo, Holland.
  • Page 21 www.freeservicemanuals.info 1/3/16 DISMANTLING INSTRUCTIONS Dismantling of the CDC Module and Front Panel Dismantling of the Cassette Cover 4) Remove the Cover Tray VCD (pos 106) as indicated. 2. Twist screw driver 3. Lift up and out Remove Cover Tray VCD 1.
  • Page 22 www.freeservicemanuals.info 1/3/16 Dismantling of the Front Display Board and Front Control Board Dismantling of Rear Portion 1) Remove 1 screw C as indicated to loosen the VCD GND 1) Remove 1 screw J and uncatch M1 as indicated to loosen Isolator Board.
  • Page 23 www.freeservicemanuals.info 1/3/16 Repair Hints 3) During repair it is possible to disconnect the Tuner Board Service pos C Picture 3 (pos 1103) and CDC & MPEG Module (pos 1105) unless the fault is suspected to be in that area. This will not affect the performance of the rest of the set.
  • Page 24 Disconnect LEAVE SERVICE 9kHz and 10kHz for the Oversea (/21) version. TESTPROGRAM mains cord b) This Tuner information is also applicable for /12 and /28 versions. Figure 2 Mini 2001 FW-V720 Service Test Program (dd wk0119) Published in Heiloo, Holland.
  • Page 25 www.freeservicemanuals.info 1/3/16 SET BLOCK DIAGRAM 75 ohm COAX1 (FROM CDC) Vpp 0.5V NOTE : MAIN SIGNAL PATH MEASUREMENTS ARE IN AUX MODE : LEVELS AT MAX VOL AUX 500mV XX mV YY dBA S/N AT 500mW CDR 1V ZZ dB HEADROOM (1% THD) WRT TO LEVEL AT MAX VOL +12V_A +9V1...
  • Page 26 www.freeservicemanuals.info 1/3/16 SET WIRING DIAGRAM FRONT FRONT FRONT CONTROL/KEYS VU Meter * For POWER 2001 Module (30-70W Version) only CDC KEYS ( 1107 ) ( 1107 ) MOTOR ( 1107 ) LS SL/SR 1600 (12p) 1603 (10p) 1300 1315 1403 1401 1405 1321 ( Only for FW-C720 ) 1330...
  • Page 27 www.freeservicemanuals.info 1/3/16 REMARKS : FRONT CONTROL BOARD TABLE OF CONTENTS Front Control Board - Component & Chip layout .... 5-2 Front Control Board - Circuit diagram ......5-3 IR-Eye Part - Layout & Circuit diagram ......5-3 Key-CDC Part - Layout & Circuit diagram ....... 5-4 VU Meter Part - Layout &...
  • Page 28 www.freeservicemanuals.info 1/3/16 FRONT CONTROL BOARD - COMPONENT LAYOUT This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list. 3139 113 3446 pt2 dd wk0116 FRONT CONTROL BOARD - CHIP LAYOUT This assembly drawing shows a summary of all possible versions.
  • Page 29 www.freeservicemanuals.info 1/3/16 FRONT CONTROL BOARD - CIRCUIT DIAGRAM IR-EYE BOARD - COMPONENT LAYOUT IR-EYE BOARD - CHIP LAYOUT 1600 F1 1653 C3 1660 D5 1667 C4 1674 D5 2605 B4 2622 F6 3606 A2 3613 C3 3620 C7 3632 D3 3639 D6 3648 G3 3655 H6...
  • Page 30 www.freeservicemanuals.info 1/3/16 KEY-CDC BOARD - COMPONENT LAYOUT KEY-CDC BOARD - CIRCUIT DIAGRAM 1800 A3 1802 B2 1804 B1 2800 B1 3801 A1 3803 A1 3805 A2 3807 A2 6803 A1 1801 B2 1803 B2 1805 B1 3800 A1 3802 A2 3804 A1 3806 A2 6802 A1...
  • Page 31 www.freeservicemanuals.info 1/3/16 KARAOKE BOARD - COMPONENT LAYOUT KARAOKE BOARD - CHIP LAYOUT ELECTRICAL PARTS LIST - FRONT CONTROL BOARD MISCELLANEOUS 1602 4822 265 11535 Flex Connector 8P 2707 4822 126 14305 100nF 10% 16V 1603 4822 265 11208 Flex Connector 10P 2708 4822 124 21732 10µF 20% 25V...
  • Page 32 www.freeservicemanuals.info 1/3/16 ELECTRICAL PARTS LIST - FRONT CONTROL BOARD RESISTORS 3705 4822 051 30272 2k7 5% 0,062W 4715 4822 051 30008 0R Jumper 0603 3706 4822 116 52191 33R 5% 0,5W 4721 4822 051 30008 0R Jumper 0603 3707 2120 366 90291 POTM CAR LOG 20k 4723 4822 051 30008...
  • Page 33 www.freeservicemanuals.info 1/3/16 FTD DISPLAY PIN CONNECTIONS FRONT DISPLAY BOARD (1G) (1G) (1G) (1G) TABLE OF CONTENTS FTD pin connection ............6-1 Front Display Board - Chip layout ........6-2 Front Display Board - Component layout ......6-3 Front Display Board - Circuit diagram ......6-4 Headphone Part - Layout &...
  • Page 34 www.freeservicemanuals.info 1/3/16 FRONT DISPLAY BOARD - CHIP LAYOUT This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list. 3139 113 3447 pt2 dd wk0119 Published in Heiloo, Holland.
  • Page 35 www.freeservicemanuals.info 1/3/16 FRONT DISPLAY BOARD - COMPONENT LAYOUT This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list. 3139 113 3447 pt2 dd wk0119 Published in Heiloo, Holland.
  • Page 36 1N4148 Cdc2 FW-C780/33 I2C_DATA 3564 220R 2549 10p FW-C780/30 Cdc3 I2C_CLK 3565 3559 220R FW-C780/22 6413 +5V6 2588 220R 7400 FW-V720/21M 3558 220R 2550 TMP88CU74YF 1N4003 220n +5V6_Con 3557 220R DBB_ShStr 3465 470R 3556 220R +12V_D 470R IS_ShData 3466 VAREF...
  • Page 37 www.freeservicemanuals.info 1/3/16 HEADPHONE BOARD - COMPONENT HEADPHONE BOARD - CHIP LAYOUT ELECTRICAL PARTS LIST - FRONT DISPLAY BOARD LAYOUT 2510 4822 126 14305 100nF 10% 16V 2572 3198 028 44790 47µF 20% 35V 2519 5322 126 11583 10nF 10% 50V 2573 3198 028 44790 47µF 20% 35V...
  • Page 38 www.freeservicemanuals.info 1/3/16 ELECTRICAL PARTS LIST - FRONT DISPLAY BOARD ELECTRICAL PARTS LIST - FRONT DISPLAY BOARD RESISTORS 3433 4822 051 30471 470R 5% 0,062W 3511 4822 051 30272 2k7 5% 0,062W 3578 4822 051 30103 10k 5% 0,062W 5405 4822 157 62552 Coil 2,2µH 5% 3434 4822 051 30102...
  • Page 39 www.freeservicemanuals.info 1/3/16 7A-1 7A-1 BLOCK DIAGRAM TUNER BOARD ECO 6 Systems Vcc1 buffer ampl. Stab Stab Discriminator FM-RF FM-IF 1 FM-IF 2 (MPX) Vcc2 1101 Loop (1102) LF filter 10,7 MHz 10,7 MHz 10,7 MHz 1120 left left right Stereo right Decoder Mixer...
  • Page 40 www.freeservicemanuals.info 1/3/16 7A-2 7A-2 1101 A1 1102 B1 1103 F2 1120 E14 1130 A2 TUNER BOARD ECO6 1131 B2 / SYSTEMS NON CENELEC 1132 G13 2101 B3 VERSION PROGRAMMING COMPONENTS 2102 B1 1101 2103 C7 2105 AM-IF1 2104 B3 1130 2105 A2 5111 450kHz...
  • Page 41 www.freeservicemanuals.info 1/3/16 7A-3 7A-3 1101 A6 1120 A4 1132 A5 2128 C4 2138 C2 3142 D2 5110 B3 5114 A2 5123 D5 7112 C1 9104 B5 9107 D4 TUNER ADJUSTMENT TABLE ( ECO6 FM/MW- and FM/MW/LW - versions with AM-frame aerial ) 1102 B6 1130 B5 2106 C5...
  • Page 42 www.freeservicemanuals.info 1/3/16 7A-4 7A-4 Electrical Partslist ECO6 SYSTEMS NON CENELEC MISCELLANEOUS RESISTORS ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– 1101 2422 015 19376 SOCKET 2P CLICKFIT 3143 © 4822 051 20223 22kΩ 0,1W USA only RDS only 1102 4822 267 10283 SOCKET COAX, IEC 75Ω 3144 ©...
  • Page 43 www.freeservicemanuals.info 1/3/16 EXPLODED VIEW OF MODULE 3CDC-LC-VCD Module D3 x 16 VCD - MPEG-01B MODULE This chapter shows the MPEG-01B Board, for 3CDC-LC-VCD mechanism & electronics please refer to Chapter 10 Flex Cable 22pin TABLE OF CONTENTS (3139 110 35290) Plate Insulation CDC-LC Exploded View of Module ..........
  • Page 44 www.freeservicemanuals.info 1/3/16 NOTES: Brief Introduction on the MPEG 1. When VCD source is selected the MPEG_RESET line will go positive triggering the following: DRST pulse to reset 8-bit microcontroller IC 7212 P83C528EBB RSTOUT# pulse to reset IC 7201 ESS3880 IC7212 sends CD10_RST to reset Signal Processor IC 7802 on the in the VCD electronics. 2.
  • Page 45 www.freeservicemanuals.info 1/3/16 MPEG-01B BLOCK DIAGRAM P83C528EBB INTERNAL BLOCK To Front Microprocessor via Servo Board Conn. MPEG-01B 1601 - DSA_ACK P2-0 P0-0 - DSA_DAT - DSA_STB P2-1 P0-1 P2-2 P0-2 P2-3 P0-3 DRAM MSM514265C P2-4 P0-4 P2-5 P0-5 +3.5V From MIC_IN P2-6 P0-6 Karaoke...
  • Page 46 www.freeservicemanuals.info 1/3/16 ES3880 VIDEO CD PROCESSOR CHIP VISBA VIDEO PC PROCESSOR CHIP PIN DESCRIPTION Name Number Definition 1, 31, 51 Voltage supply for 3.3 V. RAS# DRAM row address strobe (active low). LA12 AUX4 DWE# DRAM write enable (active low). LA13 AUX3 DA[8:0]...
  • Page 47 www.freeservicemanuals.info 1/3/16 ES3883 VIDEO CD COMPANION CHIP Name Number I/O Definition Transmit audio data input. TBCK Transmit audio bit clock. Dual-purpose pin RWS is the receive audio frame sync. 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 DSC_D7 MIC2 SEL_PLL1...
  • Page 48 www.freeservicemanuals.info 1/3/16 MPEG-01B BOARD LAYOUT Published in Heiloo, Holland.
  • Page 49 www.freeservicemanuals.info 1/3/16 ES3880 CIRCUIT 1601 D1 2210 F9 2258 F9 2271 E1 2276 C2 2280 C9 3204 C3 3207 C4 3210 E3 3214 B9 3270 B2 3273 B8 3276 B2 5212 A3 7202 A6 7205-B E1 7205-E D2 2201 E9 2223 A3 2268 D1 2272 F1...
  • Page 50 www.freeservicemanuals.info 1/3/16 ES3883 CIRCUIT 2231 B6 2253 A1 2259 E7 3236 A4 3239 E1 1602 C9 2213 D1 2216 D2 2219 C9 2225 B8 2228 A7 2263 C7 2284 A4 3219 E2 3224 B4 3227 F8 3231 E8 3242 A4 3245 C8 3248 B7 3287 E4...
  • Page 51 www.freeservicemanuals.info 1/3/16 AUDIO CIRCUIT 2202 F3 2203 F3 2204 F3 2209 F1 2212 F2 2251 2221 F6 2237 E1 2238 F7 3266 2240 E1 2242 C3 2243 F5 2244 E2 2245 D1 4u7 2260 AGND 3265 2246 C1 2.4V AOL- 2252 10u 2249 F2 3285...
  • Page 52 www.freeservicemanuals.info 1/3/16 8-10 8-10 ELECTRICAL PARTS LIST - MPEG-01B BOARD ELECTRICAL PARTS LIST - MPEG-01B BOARD MISCELLANEOUS 5209 4822 526 10704 FE Bead 100MHz 1601 2422 025 16837 Flex Socket 22pin Hort. 2266 3198 016 31020 1nF 5% 25V 3245 4822 051 30102 1k 5% 0,062W 5210 4822 526 10704 FE Bead 100MHz...
  • Page 53 www.freeservicemanuals.info 1/3/16 Tapedeck wiring (Double deck) TO ETF BOARD CONNECTOR 1770 (ND) 14P CONNECTOR 1740 (DB) 14P CRO2* CRO2* * Not for Ferro version ETF7 TAPE MODULE (Non-Dolby Version) MODE TAPE DECK MOTOR Mechanism B Mechanism A TO ETF BOARD TO ETF BOARD CONNECTOR 1730 (3P) CONNECTOR 1710 (ND) 5P...
  • Page 54 www.freeservicemanuals.info 1/3/16 BLOCK DIAGRAM Line-In ATTEN 7710 7720 PB Out 9792 # Playback SOURCE SEL PRE-AMPLIFIER ATTEN Head AN7318S HEF4952BT For Dolby version only ALCEN 1A0 1A1 1A2 PB In PB Out 7630 Rec current REC Out DOLBY B NR Rec/Pb 7740 Rec In...
  • Page 55 www.freeservicemanuals.info 1/3/16 Brief introduction General Playback Mode 13. Motor Speed (For FR versions only) Signal from the playback head Deck A or Deck B is selected and fed through by the Mode Selector IC7710 (HEF4952BT). During High speed dubbing, a feedback signal from the uP through pin 03 of the IC7610 (HEF4094BT) will trigger the transistors 7622 (BC847B) and 7616 (BC857B) to cause a change in the voltage level between High and Low, thus changing The signal is amplified by amplifier IC7720 (AN7323S) before feeding to the IC7740 (HEF4952BT) and out to the AF Board the speed of the motor.
  • Page 56 www.freeservicemanuals.info 1/3/16 CONNECTORS ASSIGNMENTS: CONNECTOR 1701 INTERCONNECTION TO AF BOARD CONNECTOR 1740 DECK A & B CONTROL INTERFACE (For Dolby B NR version only) REC REW Record tab protection status switch (reverse) [open=on: close=off] REC-L Record input left REC-R Record input right CrO2 B Chrome tape detection switch deck B [open=Cr: close=Fe]...
  • Page 57 www.freeservicemanuals.info 1/3/16 TAPE MECHANISM ELECTRONICS TAPE ADJUSTMENT & CHECK TABLE TEST ADJUST RECORDER MEASURE READ ON CASSETTE MODE with B Photo Sensor 1. B Rec Switch (REV) Rec-R ADJUST MOTOR SPEED 2. B CrO2 Switch CrO2* PLAY B 3620 3150Hz – 0.5% SBC420 frequency NORMAL SPEED...
  • Page 58 www.freeservicemanuals.info 1/3/16 COMPONENT LAYOUT CHIP LAYOUT Some location on this board is prepared for both 0603 & 0805 SMDs footprint, 3139 113 3409 pt2 dd wk0042 in such locations 0603 SMDs may be substituted. 3139 113 3409 pt2 dd wk0042 Published in Heiloo, Holland.
  • Page 59 www.freeservicemanuals.info 1/3/16 ANALOG CIRCUIT 1701 F9 2705 A2 2712 B6 2719 C5 2726 D4 2735 B3 2745 F5 2765 B4 2785 F1 3705 A4 3712 B4 3719 C6 3726 D5 3733 A2 3744 F8 3753 F5 3760 A7 3767 A7 3774 E3 3781 D2 4794 C6...
  • Page 60 www.freeservicemanuals.info 1/3/16 SERVO CONTROL CIRCUIT 1702 A7 1760 B8 2622 D2 2625 E4 3601 B2 3604 C2 3607 C6 3610 D6 3613 B2 3618 A4 3622 A4 3625 B3 3630 A6 3676 C5 3680 C5 3687 D2 4785 D2 6612 B6 7612 A6 7616 A4 7620 B6...
  • Page 61 www.freeservicemanuals.info 1/3/16 TAPE MECHANISM - MOTOR EXPLODED VIEW TAPE MODULE EXPLODED VIEW 4822 361 11055 Motor Assembly 1 3139 118 77130 Autoreverse Mech. CWE44FR01 Screw M2,6 x 5 1 3139 118 77140 Non-Autoreverse Mech. CWE44FF02 Chrome/Ferro Screw M2 x 5 1 3139 118 77950 Non-Autoreverse Mech.
  • Page 62 www.freeservicemanuals.info 1/3/16 9-10 9-10 TAPE MECHANISM A - PLAY MECHANICAL PARTS - PLAY MECHANISM 9965 000 02313 Play Head (Non-Autoreverse deck) 9965 000 02321 Play Head (Autoreverse deck) 4822 402 10972 Pinch Arm Assembly R 9965 000 02314 Coil Assembly 9965 000 06443 Cam Gear 4822 528 11209...
  • Page 63 www.freeservicemanuals.info 1/3/16 9-11 9-11 TAPE MECHANISM B - RECORD/PLAYBACK (Non-Autoreverse version) MECHANICAL PARTS - REC/PB MECHANISM 9965 000 02313 Play Head 9965 000 02600 Head, Erase 4822 402 10972 Pinch Arm Assembly R 9965 000 02314 Coil Assembly 9965 000 06443 Cam Gear 4822 528 11209 Flywheel Assembly RV...
  • Page 64 www.freeservicemanuals.info 1/3/16 9-12 9-12 TAPE MECHANISM B - RECORD/PLAYBACK (Autoreverse version) MECHANICAL PARTS - REC/PB MECHANISM 4822 402 10972 Pinch Arm Assembly R 9965 000 02314 Coil Assembly 9965 000 06443 Cam Gear 4822 528 11209 Flywheel Assembly RV 9965 000 02322 Belt AF 44-2 9965 000 02317...
  • Page 65 www.freeservicemanuals.info 1/3/16 9-13 9-13 ELECTRICAL PARTS LIST - ETF7 NON-DOLBY BOARD ELECTRICAL PARTS LIST - ETF7 NON-DOLBY BOARD MISCELLANEOUS 2738 482212614585 100nF 10% 50V 3685 482211652234 100k 5% 0,5W 3745 482205120332 3k3 5% 0,1W Autoreverse 1701 482226710953 Flex Socket 7pin Vert. 2741 482212611585 22nF +80/-20% 25V 3686 482211710837...
  • Page 66 www.freeservicemanuals.info 1/3/16 9-14 9-14 ELECTRICAL PARTS LIST - ETF7 NON-DOLBY BOARD RESISTORS 4706 482205120008 0R Jumper 0805 6612 482213031878 1N4003G 4707 482205120008 0R Jumper 0805 6614 482213030621 1N4148 Autoreverse 4708 482205120008 0R Jumper 0805 6770 482213030621 1N4148 4709 482205120008 0R Jumper 0805 6771 482213030621 1N4148 4710 482205120008...
  • Page 67 www.freeservicemanuals.info 1/3/16 10-1 3CDC-LC-VCD (3 Disc Carousel Changer) Layout stage .1 TABLE OF CONTENTS Servicing Hints ..............10-2 Wiring ................10-4 Blockdiagram ..............10-5 Component Layout Main Board ........10-6 Circuit Diagram part1 ............10-7 Component Layout Main Board ........10-8 Circuit Diagram part2 ............10-9 Circuit Diagram part3 ............10-10 Exploded View ..............10-10 Partslist ................10-12 Published in Heiloo, Holland.
  • Page 68 www.freeservicemanuals.info 1/3/16 10-2 WARNING CHARGED CAPACITORS ON THE SERVO BOARD MAY DAMAGE THE CD DRIVE ELECTRONICS WHEN CONNECTING A NEW CDM MECHANISM. THAT´S WHY, BESIDES THE SAFETY MEASURES LIKE • SWITCH OFF POWER SUPPLY • ESD PROTECTION ADDITIONAL ACTIONS MUST BE TAKEN BY THE REPAIR TECHNICIAN. The following steps have to be done when replacing the CD mechanism: 1.
  • Page 69 www.freeservicemanuals.info 1/3/16 10-3 Service Position Published in Heiloo, Holland.
  • Page 70 www.freeservicemanuals.info 1/3/16 10-4 Wiring Published in Heiloo, Holland.
  • Page 71 www.freeservicemanuals.info 1/3/16 10-5 10-5 BLOCK DIAGRAM 3CDC-LC VCD Version CD MECHANISM MAINBOARD VAM2201 DISC 7816 1805 M63000 7803 7802 EXCK DQSY DQSY TURNTABLE SBSO FOCB+ MOTOR CD Text FOCUS SRDT SBSY SCOR SRDT MOTOR SFSY WFCK µP_CLK FOCB- SCLK CL11 CD Text LC89170M 1802...
  • Page 72 www.freeservicemanuals.info 1/3/16 10-6 10-6 Mapping Copperside Componentside 2800 F4 3729 F2 3845 D2 4827 E4 7823 F2 0801 E2 2801 D4 3730 C3 3846 E2 4828 C3 0802 C3 2802 E4 3CDC-LC (Herman) Copperside view 3731 C2 3847 E1 4829 G4 1800 F4 3CDC-LC (Herman) Components seen from Copperside 2803 D4...
  • Page 73 www.freeservicemanuals.info 1/3/16 10-7 10-7 1800 2803 2808 2815 2830 2839 2848 2885 3703 3721 3727 3801 3807 3821 3833 3838 3844 3850 3863 3876 7801 7823 1801 2804 2809 2817 2831 2840 2852 2886 3704 3722 3728 3802 3808 3822 3834 3839 3845...
  • Page 74 www.freeservicemanuals.info 1/3/16 10-8 10-8 Mapping Copperside Componentside 2800 F4 3729 F2 3845 D2 4827 E4 7823 F2 0801 E2 2801 D4 3730 C3 3846 E2 4828 C3 0802 C3 2802 E4 3CDC-LC (Herman) Copperside view 3731 C2 3847 E1 4829 G4 1800 F4 3CDC-LC (Herman) Components seen from Copperside 2803 D4...
  • Page 75 www.freeservicemanuals.info 1/3/16 10-9 10-9 1802 2816 2823 2833 2843 2870 3701 3711 3717 3732 3759 3777 3810 3816 3823 3828 3855 3861 3878 6807 1805 2818 2824 2834 2845 2871 3705 3712 3718 3733 3767 3804 3812 3817 3825 3832 3858 3862 3881...
  • Page 76 www.freeservicemanuals.info 1/3/16 10-10 10-10 1875 1876 1880 1883 2873 2881 3713 3736 3745 3752 Drawer bottom view 1875 1876 1881 1883 2875 2883 3714 3737 3747 3753 1875 1877 1882 2860 2877 2888 3715 3738 3748 3754 1876 1878 1882 2872 2878 2889...
  • Page 77 www.freeservicemanuals.info 1/3/16 10-11 10-11 EXPLODED VIEW (3CDC-LC M ODULE MECHANICAL PARTS Drawer → Chapter 10-10 ––––––––––––––––––––––––––––––––––––––––––––––––––––– 3103 304 69310 DRAWER BLACK 3103 304 69320 CAROUSEL BLACK 3103 304 07120 PULLEY DRAWER BLACK 45 5x 3103 304 06850 ECCENTRIC GEAR WHEEL 3103 304 07110 NAIL FIXATION BLACK 3103 304 66850 DRIVING BELT CAROUSEL 4822 532 12365 BUSH DRAWER (height=5,5mm,d=9,4mm)
  • Page 78 www.freeservicemanuals.info 1/3/16 10-12 10-12 ELECTRICAL PARTSLIST 3CDC-LC MODULE ELECTRICAL PARTSLIST 3CDC-LC MODULE –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– MISCELLANEOUS CAPACITORS RESISTORS RESISTORS ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– 9305 022 30103 CD Drive VAM2201/03 2884 © 5322 126 11578 3814 © 4822 051 20471 470Ω 0,1W 4733 ©...
  • Page 79 www.freeservicemanuals.info 1/3/16 10-13 ELECTRICAL PARTSLIST 3CDC-LC MODULE –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– RESISTORS ––––––––––––––––––––––––––––––––––––––––––––––––––––– 4876 © 4822 051 20008 CHIP JUMPER 0805 4877 © 4822 051 30008 CHIP JUMPER 0603 4879 © 4822 051 20008 CHIP JUMPER 0805 4884 © 4822 051 20008 CHIP JUMPER 0805 4885 ©...
  • Page 80 www.freeservicemanuals.info 1/3/16 10-14 Technical remarks Published in Heiloo, Holland.
  • Page 81 www.freeservicemanuals.info 1/3/16 11-1 11-1 Circuit details: Amplifier: Attention: In the POWER 2001 module the power amplifier IC AN7591 is used as a bridge-amplifier. Any connection from output to ground will destroy the outpout stages! • Via the AMP_ON control line, connected to pins 6 (Stby), the power amplifiers are switched on/off by the µP. High level (approx.
  • Page 82 www.freeservicemanuals.info 1/3/16 11-2 11-2 Circuit details continued: Generation of +C1 Full wave rectifying with 2 diodes of bridge rectifier 6202, using 50% secondary winding of mains transformer (pin 13-15/13-11). See picture 2 below. • Low power standby feature An additional small standby transformer, reduces power consumption in standby-mode. In case power is switched on, the control line ECO is low →...

  • Page 83: Mains Board

    www.freeservicemanuals.info 1/3/16 11-3 11-3 Block Diagram MAINS BOARD P2001 BOARD 1200 5001 is used for monitoring the transformer temparature Mains socket 1204 6201 1207 Stand by Relais 7301,7302 6200 1210 1205 LEFT, RIGHT Power amplifier from Source Selector on Audio Frequency Board is used for filament of display...
  • Page 84 www.freeservicemanuals.info 1/3/16 11-4 11-4 1200 B5 6210 C5 1201 B4 6211 B5 Mains Board Copperside view 1202 C1 6212 C5 1203 A5 6213 B5 1205 B3 6214 B5 1206 C1 6215 D5 1207 C3 6216 C5 1208 D1 6217 C5 B C E 1209 C5 6218 C5...
  • Page 85 www.freeservicemanuals.info 1/3/16 11-5 11-5 1200 A6 1207 B6 1222 A2 2204 D7 2210 E7 2216 A7 3204 E7 3211 E6 6201 B8 6208 D4 6214 E3 6221 C8 9208 B2 9215 F6 1201 A9 1208 B4 1223 B2 2205 D8 2211 E3 2217 A8 3205 E4...
  • Page 86 www.freeservicemanuals.info 1/3/16 11-6 11-6 0300 B3 1307 B5 1316 C1 2306 A4 2313 B4 2320 A5 2327 B3 2334 C3 2341 B1 3303 C4 3310 A5 3317 C3 3324 A3 3331 C1 3340 C5 3347 A3 3354 A4 3361 A1 3368 A4 3375 C1 3382 C2...
  • Page 87 www.freeservicemanuals.info 1/3/16 11-7 11-7 6307 6314 6321 6328 7302 7309 7316 7323 7331 9308 0300 1307-a F14 1315 2305 2312 2319 2326 2333 2340 3303 3310 3317 3324 3331 3340 3347 3354 3361 3368 3375 3382 6300 1300 1307-b E14 1316 2306 2313...
  • Page 88 www.freeservicemanuals.info 1/3/16 11-8 11-8 ELECTRICAL PARTSLIST POWER2001 MODULE ELECTRICAL PARTSLIST POWER2001 MODULE –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– MISCELLANEOUS CAPACITORS RESISTORS DIODES ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––––––––––––––––––– 1200 2422 086 10963 FUSE RAD 5A 250V IEC 2326 4822 124 22652 2,2µF 3343 4822 116 52285 470kΩ...
  • Page 89 www.freeservicemanuals.info 1/3/16 11A-1 11A-1 REMARKS : CENTER/SURROUND & MATRIX SURROUND SOCKET BOARD TABLE OF CONTENTS Circuit diagram ............11A-2 Component layout ............11A-2 Variant table ..............11A-2 Electrical parts list ............11A-2 Published in Heiloo, Holland.
  • Page 90 1311-A 3315 VARIANT TABLE 470R FW-P750/22 FW-C720/21 FW-P750/34 EH-B EH-B EH-B # 3316 FW-V720/21M FW-P750/37 470R 1311 3317 1312 # : Provision 470R 1313 Note : Some values may varies, see respective parts # 3318 list and variant table for correct value.
  • Page 91 www.freeservicemanuals.info 1/3/16 12-1 12-1 BRIEF INTRODUCTION OF THE AF9 BOARD The AF9 Board consists of the following features : a. TDA7468D IC TDA7468D IC (7501) which includes functions such as source selection, loudness control, dynamic bass control, treble control, volume control and muting function. Sound features such as ALC, DBB, DSC and IS are controllable via I C Bus from the microprocessor.
  • Page 92 www.freeservicemanuals.info 1/3/16 12-2 12-2 AF9 BOARD - COMPONENT LAYOUT This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list. 3139 113 3435 pt3 dd wk0112 Published in Heiloo, Holland.
  • Page 93 www.freeservicemanuals.info 1/3/16 12-3 12-3 AF9 BOARD - CHIP LAYOUT This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list. 3139 113 3435 pt3 dd wk0112 Published in Heiloo, Holland.
  • Page 94 www.freeservicemanuals.info 1/3/16 12-4 12-4 AF9 BOARD - CIRCUIT DIAGRAM (PART 1) 1102 L10 1531 D1 2205 D6 2504 F3 2516 G8 2535 C4 2549 D11 2558 H13 2568 H10 2589 B10 2604 F16 2621 B16 2654 B21 2681 H7 2771 K20 2924 G5 3408 K14 3503 E3...
  • Page 95 www.freeservicemanuals.info 1/3/16 12-5 12-5 AF9 BOARD - CIRCUIT DIAGRAM (PART 2) 1100 F6 1201 C1 1202 E1 1203 C1 3412 1204 E1 FE-BT-VK-N 1205 C1 4909 1521 1206 C1 FE-BT-VK-N 1401 A9 4910 4911 1403 1401 1405 D_Text GND_D 4.5V 1402 D9 3802 1403 A9...
  • Page 96 www.freeservicemanuals.info 1/3/16 12-6 12-6 VIDEO OUT CINCH BOARD - VIDEO OUT CINCH BOARD - ELECTRICAL PARTS LIST - AF9 BOARD COMPONENT LAYOUT CHIP LAYOUT MISCELLANEOUS 1201 4822 267 10738 Flex Connector 13P 2547 5322 126 11579 3,3nF 10% 63V 1401 4822 265 11553 Flex Connector 19P 2548...
  • Page 97 www.freeservicemanuals.info 1/3/16 12-7 ELECTRICAL PARTS LIST - AF9 BOARD RESISTORS 3201 4822 117 12968 820R 5% 0,62W 3621 4822 051 30103 10k 5% 0,062W 3202 4822 051 30151 150R 5% 0,062W 3622 4822 051 30103 10k 5% 0,062W 3205 4822 116 52289 5k6 5% 0,5W 3623 4822 051 30102...
  • Page 98 www.freeservicemanuals.info 1/3/16 12-8 ELECTRICAL PARTS LIST - AF9 BOARD RESISTORS 4122 4822 051 30008 0R Jumper 0603 7601 4822 209 31378 NJM4556AM 4124 4822 051 30008 0R Jumper 0603 7603 4822 130 42804 BC817-25 4125 4822 051 30008 0R Jumper 0603 7604 4822 130 42804 BC817-25...
  • Page 99 www.freeservicemanuals.info 1/3/16 13-1 13-1 VCD GND ISOLATOR BOARD - COMPONENT LAYOUT This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list. VCD GND ISOLATOR BOARD 3139 113 3468 pt1 dd wk0119 TABLE OF CONTENTS VCD GND ISOLATOR BOARD - CHIP LAYOUT Component &...
  • Page 100 www.freeservicemanuals.info 1/3/16 13-2 13-2 VCD GND ISOLATOR BOARD - CIRCUIT DIAGRAM 48 B9 2710 B2 2713 B3 2716 B4 2720 B5 2724 C8 3717 C2 3721 B3 3724 C4 3728 B5 3731 A6 3734 A7 4700 D8 7710-A B6 1705 A1 2711 B2 2714 B4 2717 B5...
  • Page 101 www.freeservicemanuals.info 1/3/16 14-1 14-1 SET MECHANICAL EXPLODED VIEW Exploded_View_3139 119 34230 dd wk0113 Published in Heiloo, Holland.
  • Page 102 0204 4822 402 11246 Bracket Right 9965 000 08842 Tweeter 2" 6R 5W D3 x 12 0107 4822 454 13408 Badge Philips 0205 4822 402 11245 Bracket Left 9965 000 08797 Woox 6,5" D3 x 12 9965 000 08798 Piezo Assembly...

This manual is also suitable for:

Fw-v721m

Table of Contents
