- Page 1 FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/ PARA USO EN AUTOMÓVILES/SOLO PER L’UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE AUTO/ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/DO UŻYCIA TYLKO W SAMOCHODZIE ADVANCED NAVI STATION INE-W990HDMI QUICK REFERENCE GUIDE Kurzanleitung GUIDE DE RÉFÉRENCE RAPIDE GUÍA DE REFERENCIA RÁPIDA...
-
Page 3: Table Of Contents
For details on all functions, refer to the Owner’s Manual stored in the supplied CD-ROM. (As it is data CD, the CD cannot be used for playing back music and images on the player.) If required, an ALPINE dealer will readily provide you with a print out of the Owner’s Manual contained in the CD-ROM. -
Page 4: Warning
Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR Center for repairing. -
Page 5: Getting Started
Owner’s manual Touch operation, Location of Controls, Turning Power On or Off Getting Started Touch operation You can operate the system by using the touch panel on the screen. Common onscreen buttons Returns to the previous screen. Depending on the function, this button may cancel the operations performed on the screen. - Page 6 Turning Power On or Off Turn the ignition key to the ACC or ON position. The system is turned on. Press and hold the MUTE button for at least 3 seconds to turn the power off.
-
Page 7: Radio Operation
Owner’s manual Radio Radio Operation Decreases frequency RDS information display Increases frequency Preset button Displays the preset stations with a Switches band short touch. Touch for at least 2 seconds to memorise the current station as a preset station. Changes operation button Changes tuning mode Changes text information Seek mode indicator... -
Page 8: Dvd Operation
Owner’s manual DVD Operation When you touch the DVD playback screen, the DVD operation screen is displayed. The following is an example of the DVD-VIDEO operation screen. Finds the beginning of the Finds the beginning of current chapter/Finds a next chapter/Fast-forwards previous chapter within when touched for at least one second after playback... -
Page 9: Ipod/Iphone Operation (Optional)
Owner’s manual iPod/iPhone (Optional) iPod/iPhone Operation (Optional) A separately sold USB iPod/iPhone AV cable (KCU-461iV) or a separately sold Lightning to USB cable (KCU-471i) is required depending on the type of iPod/iPhone. Audio mode Artwork display iPod/iPhone information display Finds the beginning of the Finds the beginning of the current file/Finds a previous next file/Fast-forwards... -
Page 10: Usb Memory Operation (Optional)
Owner’s manual USB Memory (Optional) USB Memory Operation (Optional) You can play back music files (MP3/WMA/AAC) and video files (DivX® ) stored in a USB memory device on the internal player of this system. Refer to the “MP3/WMA/AAC Operation” (page 5) for information on music. Video mode DivX®... -
Page 11: Hands-Free Phone Control
Owner’s manual BLUETOOTH Setting, BLUETOOTH Operation Hands-Free Phone Control Hands-free calls are possible when using an HFP (Hands-Free Profile) compatible mobile phone with the INE- W990BT. How to connect to a BLUETOOTH When the device registration is complete, a compatible device (Pairing) message appears and the device returns to normal mode. -
Page 12: Map Functions
Map Functions Below is an overview of different buttons and icons on the map display. For more detailed information about this screen, please see the Owner’s Manual. Next Street Name Next Manoeuvre Arrow Access the customizable Quick Menu Distance to next Manoeuvre Traffic Information Trip Information Displaying Audio/Visual... -
Page 13: Go To A Destination
Go to a Destination The following example briefly describes how to input a destination. Touch [Go to] from Navigation Menu. • You can touch [Results] to display the candidate list. Select a destination input method. ([Find Address] is selected.) Type in the city name or postcode until displayed in the selection list. - Page 14 Type in the street name until displayed in the selection list. Select the matching entry. • You can touch [Results] to display the candidate list. Enter a house number. Touch [Done] to access the confirmation screen. Touch [Select] to initialize route calculation and start navigation.
-
Page 15: Installation
(on the sun visor, etc.). unit and/or the vehicle. When in doubt, consult your When you speak into the microphone, you should Alpine dealer. not have to change your driving posture. This may cause a distraction, taking your attention away Install at an angle between horizontal from safely driving your vehicle. - Page 16 Remove the mounting sleeve from the When your vehicle has the Bracket, mount main unit. the long hex bolt onto the rear panel of the INE-W990BT and put the Rubber Cap on This unit the hex bolt. If your vehicle does not have the Mounting Support, reinforce the head unit with the metal mounting strap (not Bracket keys...
- Page 17 Connection Diagram of SPST Switch (sold separately) (If the ACC power supply is not available) FUSE (5A) SPST SW (Optional) (Red) (Optional) INE-W990BT BATTERY (Yellow) FUSE (20A) (Optional) Battery • If your vehicle has no ACC power supply, add an SPST (Single-Pole, Single-Throw) switch (sold separately) and fuse (sold separately).
-
Page 18: Connections
Owner’s manual Connections Connections Connections 1/2 GPS Antenna (Included) Antenna ISO Antenna Plug iPod/iPhone iPod/iPhone with a with a Lightning 30-pin connector connector (Sold separately) (Sold separately) Connection kit iPod VIDEO AV extension cable KCU-461iV KCU-461iV (Sold separately) (Sold separately) USB extension cable (Included) Lightning to USB Cable KCU-471i (Sold separately) - Page 19 Connections 2/2 Connect this to the optional Vehicle Display Interface box Microphone (Included) To steering remote control interface box CAMERA To Camera with RCA Output terminal (Yellow) REMOTE OUT To remote input lead (Brown) AUX OUTPUT To Rear Monitor Input terminal (Yellow) Rear Left Amplifier...
-
Page 20: Specifications
Owner’s manual Specifications Specifications MONITOR SECTION PICKUP Screen Size 6.1” Wave length DVD: 666 nm LCD Type Transparent type TN LCD CD: 785 nm Operation System TFT active matrix Laser power CLASS II Number of Picture Elements 1,152,000 pcs. GPS SECTION (800 ×... - Page 21 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under licence. Other trademarks and trade names are those of their respective owners.
- Page 24 Phone 1-800-ALPINE-1 (1-800-257-4631) 95 945 Roissy CDG cedex 1-888-NAV-HELP (1-888-628-4357) FRANCE Phone : + 33(0)1 48 63 89 89 ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ITALIA S.p.A. 161-165 Princes Highway, Hallam Victoria 3803, Australia Viale Cristoforo Colombo, 8 Phone 03-8787-1200...
