General Slicing MM-5 Operator's Manual page 9

REPLACEMENT PARTS PRICE LIST MODEL:
MM-5
KEY
NAME: DESCRIPTION
NO. PART NO.
1 366193 COVER:JUICE EXTR OUTLET, BROWN...1
353548 COVER:JUICE EXTR OUTLET, BLACK....1
2 366246 COVER:LIQUIDIZER OUTLET, BROWN...1
353744 COVER:LIQUIDIZER OUTLET, BLACK.....1
3 371227 SCREW:PN HD M3.5 X 25 .......................3
4 353768 SPIGOT .....................................................1
5 353770 SPIGOT SEAT PLATE ..............................1
6 601244 COVER:TOP, SILVER...............................1
7 428549 BODY UPPER TRIM:BROWN...................1
353756 BODY UPPER TRIM:BLACK..................1
8 353718 WASHER:SMALL PULLEY........................1
9 353627 SCREW:PN HD M5 X 20 ..........................3
10 353811 BUSHING:MOTOR MTG. ADJUSTMENT..3
11 353823 MOTOR MOUNTING RING........................1
12 353586 GEARBOX DOWEL TUBE ........................2
13 615465 BODY:SILVER............................................1 100.00
14 05-MM- CORDSET .................................................1
15 457370 BODY COVER ASSY ................................1
2235
16 353835 QUADRANT BRACKET..............................1
17 198508 CIRCLIP (HINGE PIN)................................1
18 353691 HINGE PIN ................................................1
19 353720 COUNTER BALANCE SPRING..................1
20 353847 QUADRANT................................................1
21 177554 CATCH SPRING.........................................1
22 198493 CIRCLIP (CATCH PIN)...............................1
23 353794 CATCH PIN ...............................................1
24 366208 CATCH PIN BUTTON ASSY:BROWN ......1
353562 CATCH PIN BUTTON ASSY:BLACK ........1
25 357271 CORD CLAMP ASSY ................................1
25A 353536 CLAMP UPPER ASSY...............................1
_________________________________________________________________________________________________________________________________________________________12.22.97
General Slicing/Red Goat Disposers
MAIN BODY ASSEMBLY
QTY.
LIST
PER
PRICE
MACH.
EACH
4.00
4.00
13.00
13.00
1.00
4.00
9.00
116.00
6.00
6.00
1.00
1.00
1.00
3.00
2.00
6.00
22.00
2.00
1.00
3.00
9.00
6.00
1.00
1.00
6.00
2.00
2.00
6.00
4.00
** Refer to current equipment Price List for pricing of these items.
• 1152 Park Ave • P.O. Box 428 • Murfreesboro, Tennessee 37133-0428 • (615) 893-4820
KEY
NO. PART NO.
NAME: DESCRIPTION
25B 343983 CLAMP .................................................... 1
25C 353665 SCREW:PN HD M3 X 25 ......................... 2
26 353483 PEDESTAL WHITE ................................. 1
609882 PEDESTAL, SILVER ............................... 1
26A 613704 FOOT (S/N 051193 FWD) ....................... 5
26B 365541 PIN:FOOT................................................ 1
27 343270 5 QT BOWL:SS ....................................... 1
28 417239 BOWL MTG PAD:5 QT BOWL ................ 1
29 353639 SCREW:PN HD M4 X 20 ......................... 1
30 353574 TERMINAL COVER................................. 1
31 357312 SCREW:PN REC HD............................... 1
32 239168 TERMINAL BLOCK 2-WAY ..................... 1
33 366260 KNOB ATTACHMENT ............................. 1
34 353615 SCREW:PN REC HD............................... 2
35 366234 COVER:GEARBOX LOWER, BROWN ... 1
353732 COVER:GEARBOX LOWER, BLACK ..... 1
36 201393 SCREW:PHP HD TYPE Y NO. 8 X 13 .... 2
37 353598 FELT PAD:GEARBOX............................. 1
38 353225 GEARBOX ASSY .................................... 1
38A 616603 PLANET HUB ASSY................................ 1
38B 353237 GEARBOX SERVICE ASSY .................... 1
38C 616598 LG PULLEY (S/N 051193 FWD).............. 1
39 428575 WASHER:M6 STEEL ZINC PLATED ...... 2
40 353641 BOLT:HXHD M6 x 40 .............................. 2
41 197944 TIMING BELT .......................................... 1
42 28961/BN1 COVER:SLOW SPEED OUTLET, BROWN 1
353500 COVER:SLOW SPEED OUTLET, BLACK 1
375948 SPATULA ................................................ 1
Effective: October 1,1997
QTY.
LIST
PRICE
PER
EACH
MACH.
2.00
2.00
122.00
122.00
(S/N 051895 FWD)
1.00
1.00
**
3.00
1.00
2.00
1.00
3.00
1.00
1.00
12.00
12.00
1.00
2.00
233.00
52.00
111.00
20. 00
1.00
1.00
12. 00
18.00
18.00
**
