Electrical Requirements; Operation - General Slicing MM-5 Operator's Manual

Plug the mixer into a properly grounded three-prong outlet. DO NOT use
an extension cord.
Use a 115 Volt, A.C., 60 Hz power source, as indicated on the Data Plate
on the back of the unit. To operate the unit on other voltages, the mixer
must be returned to the factory for modification.
All electrical connections must be made in compliance with all applicable
local electrical codes, as well as the latest edition of the National Electrical
Code (NFPA 70)
Raise the Head
1. Press the push button release catch.
2. Placing one hand under the front, raise the head until it locks in the
open position.
NOTE: The head should be in the locked position when fitting the bowl or
implements onto the unit.
Bowl Installation
1. Fit the plastic bowl mounting pad with the ribs downward into the bowl
recess.
2. Place the bowl in the recess, engaging the lugs in the slots into the
base of the bowl.
3. Press down on the bowl rim and turn in a clockwise direction to lock.
Implement Installation
Select Implement as per Mixing Guide on Page 7.
1. Gently slide the implement into the accessory socket, rotating it
slowly clockwise until a stop is reached.
2. Press firmly upwards until the implement locks into position.

ELECTRICAL REQUIREMENTS

5

OPERATION

04.02.96
