USER MANUAL
Home Automation Gateway
HA102

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HA102 and is the answer not in the manual?

Questions and answers

Summary of Contents for Schwaiger HA102

  • Page 1 USER MANUAL Home Automation Gateway HA102...
  • Page 3: Table Of Contents

    DEVICE DESCRIPTION ........... 5 INSTALLATION OF THE SCHWAIGER GATEWAY ......6 WIFI CONFIGURATION OF THE GATEWAY ....................7...
  • Page 4: Important Safety Information

    Power Source according to IEC 60950-1. 1. IMPORTANT SAFETY INFORMATION Before using Schwaiger Home Automation Gateway, please read the following information to avoid any potential dangers: Read the instructions carefully and follow the precautions in this manual. All mains connec-...
  • Page 5: Device Description

    By supporting the most popular wireless communication protocols today (Zigbee, Z-Wave, IP), Schwaiger gateway communicates with connected devices and enables users to monitor and con- trol their home. FRONT...
  • Page 6: Installation Of The Schwaiger Gateway

    3. INSTALLATION OF THE SCHWAIGER GATEWAY In order to install your Schwaiger gateway, please follow next steps: Plug in the Home Automation Gateway to the AC power supply Connect the Gateway to the home network router by using Ethernet ( Illustration 2) or WiFi...
  • Page 7: Wifi Configuration Of The Gateway

    3.1 WIFI CONFIGURATION OF THE GATEWAY In case you would like to connect the gateway device to the home network router by using WiFi connection, please follow next steps: After powering up, the gateway enters AP (Access Point) mode if Ethernet cable is not con- nected.
  • Page 8: Configuring Schwaiger Home Automation System

    Schwaiger cloud Illustration 6: Our System Schwaiger client application is intuitive and easy to use. Its comfortable graphical user interface will smoothly guide users through the process of configuration of their space. The app can be used both in-home or remotely – it is smart enough to connect to the gateway directly if possible, to ensure the best user experience.
  • Page 9: Install Schwaiger Client Application

    4.1 INSTALL SCHWAIGER CLIENT APPLICATION In order to start configuring Schwaiger home automation system, the user needs to install Schwaiger client application. By using client application, users can control their household devices and manage their accounts as well as the list of their gateways and configuration options.
  • Page 10: Create User Account By Using Web Application

    4.2.2 Create user account by using web application Please follow next steps in order to create new account: Visit https://home4you.schwaiger.de Tap the “Don’t have an account” button on the login dialog (see Illustration 11). Enter your personal and login information on the login dialog (see Illustration 12).
  • Page 11: Add The Gateway By Using Client Application

    Please follow next steps in order to add the gateway to the user account: Make sure that your smart phone/tablet and the gateway are active within the same network Open the Schwaiger application and log into the user account Select Home Setup option from the main menu (Illustration 13) On the Home Setup screen tap the “Add gateway”...
  • Page 12: Home Setup

    4.4 HOME SETUP The user can setup its smart home by using Schwaiger client application. To setup the home, please follow next steps: Make sure that your smart phone/tablet and the gateway are active within the same network...
  • Page 13: Device Management

    All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. HA102 gateway is also compliant with ZigBee Home Automation (ZHA) 1.2 and is guaranteed to function with any ZHA 1.2-compliant devices...
  • Page 14 network first. If this is the case, please proceed to step 4. In case of Z-Wave devices, device removal from previous network can be done by following next steps: a. Tap the button in the upper right corner and select “Exclude Device” option (see Illustration 19).
  • Page 15: Z-Wave-Specific Information Related To Device Inclusion

    5.1.1.1 Z-Wave-specific information related to device inclusion If another Z-Wave controller is added to HA102 gateway, it will initiate network information replica- tion from the HA102 gateway to the included controller. HA102 gateway ignores any basic command class commands from devices.
  • Page 16: Update Device Name And Location

    5.1.3 Update device name and location To update device name and location, please follow next steps: Tap on the device name and hold it until the “Edit” option appears Tap on the “Edit” button In the new dialog, change the device name and choose the device location from the drop down list (Illustration 25) Tap the button OK Illustration 25...
  • Page 17: Ha102 As A Part Of Other Z-Wave Controller's Network

    6. HA102 AS A PART OF OTHER Z-WAVE CONTROLLER’S NETWORK In order to add HA102 gateway into other controller’ s Z-Wave network, please follow next steps: Start learn mode by pressing back button 12 times. After entering learn mode, LED will blink blue 2 times per second.
  • Page 18: Advanced Device Configuration

    Illustration 28 8. SCENE MANAGEMENT One of the main features of Schwaiger client application is scene. Scene is specific event or set of actions created by end user. Scenes can be triggered by one or more events/devices, which are called triggers. The scene can also be set to send an email notification to the user’ s email address or push notification to the user’...
  • Page 19 Illustration 29 In case you would like to create device trigger (or triggers), please follow next steps: a. In the device trigger dialog, choose the device you want to add as a trigger b. In the drop down list, choose functionality and its value c.
  • Page 20 Illustration32 For selected action set you will be able to add following actions by pressing “Add” button in the upper right corner (Illustration 34): a. Control device by location b. Control device by type c. Send email notification d. Send push notification e.
  • Page 21: Run The Scene

    NOTE: In case you are using your smartphone for defining action sets and delay time, you need to open slider control as described in Illustrations 37, 38 and 39. Illustration 37 Illustration 38 Illustration 39 Once you have set action sets/delay time you will be able to test defined scene: a.
  • Page 22: Disable The Scene

    From the drop down menu select option Delete Confirm deletion 8.5 DISABLE THE SCENE Please follow next steps in order to disable the scene: Select Scenes option in the application’ s main menu Choose the scene you want to disable and tap the toggle switch button in the upper left corner 9.
  • Page 23: Buttons/Functions

    Dimensions W x H x D: 108 x 26 x 108 mm 12. DECLARATIONS OF CONFORMITY Hereby, Schwaiger GmbH declares that HA Gateway device is in compliance with the essential requirements and other relevant provisions of following European directives: •...
  • Page 24 Dear customer Should you require any technical support and not be able to get it at your specialist dealer’ s , please contact our technical support team. Schwaiger GmbH Würzburger Straße 17 90579 Langenzenn Hotline: +49 (0) 9101 702-199 www.schwaiger.de...
