TracVision M3DX Special Instructions Manual

Conversion system/receiver
Hide thumbs Also See for M3DX:

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
IMPORTANT! Special Instructions for the
TracVision M3DX Conversion System
You have purchased a special TracVision
that can be configured for either circular or linear satellite signals.
These instructions explain how to configure the system for your
desired satellite(s). For example, if you travel from the U.S. to Mexico,
refer to these instructions to convert the system from a circular
configuration to a linear configuration.
IMPORTANT!
To configure the system for circular signals, you will need to wire
the system differently from the wiring diagrams shown in the
Installation Guide and User's Guide. Your conversion system comes
with a linear interface box, which gives you the flexibility to
simply add a destacker for circular use. Be sure to read these
special instructions for complete details.
Tools Required
•
#2 Phillips-head screwdriver
•
7/16" open-end wrench

Table of Contents

Overview of Circular and Linear Configurations..........................................2
Configuring for Circular Signals, Out of the Box .........................................3
Converting from Circular to Linear..............................................................4
Converting from Linear to Circular............................................................10
Modified Wiring Diagrams for Circular Signals .........................................15
Wiring Diagram for Linear Signals ............................................................16
54-0390 Rev. B
TracVision M3DX Conversion System Instructions
(01-0279-05)
®
M3DX conversion system
•
Cutting pliers
•
Flashlight
1
