WIRING THE RECEIVER TO THE EQUIPMENT
THERMOSTAT TERMINALS (HEAT PUMP)
SYSTEM Heat Pump 1
C 24 Volt (Common)
R
24 Volt (hot)
E/W1
Emergency 1st stage
W2
Auxiliary / Emergency 2nd Stage
Heat and Cool mode 1st stage (compressor)
Y1
No output
Y2
G
Blower/Fan Energized on call for Heat and Cool
O Energized in Cool Mode
B Energized in Heat Mode
UZC-4
Heat Pump 3H/2C
O Reversing Valve
Figure 2
BmPlus 3000
Heat Pump 2H/1C
B Reversing Valve
Figure 3
NCM-300
Gas/Elec. 1H/1C
Figure 4
Warning: There should be at least 1 hardwired system thermostat in the home or building to ensure the
ability to control the HVAC equipment in the event of a drained battery or loss of communication.
