2
Thank you for purchasing the FrSky 2.4GHz RF radio control system. In order to fully enjoy benefits of this
system, please, carefully read the instruction manual and set up the devices as described below.
1.
Brief Introduction
FrSky V8 2.4GHz radio control system is a new generation of radio control product developed by FrSky RC
Technology Co., Ltd. that incorporates the most advanced 2.4GHz digital communication technology. Thanks to
the high precision, minimum latency and interference resistant, the system makes the simultaneous use of multiple
devices without the risk of interference. Combining our software with FHSS we have developed a system
presenting the highest performance available.
We are glad to introduce the FrSky 2.4GHz Radio System.
ACCST
(Advanced Continuous Channel Shifting Technology) is our advanced technology. The
system shifts the frequency hundreds of times per second. It means there are no signal conflicts and interruptions.
2.
Main features
◆ ◆ ◆ ◆ Advanced Continuous Channel Shifting Technology ( ACCST SYSTEM)
◆ ◆ ◆ ◆ Universal transmitter and receiver for all 4ch-8ch controllers.
◆ ◆ ◆ ◆ Quick and precise channels.
◆ ◆ ◆ ◆ Error-free Digital link.
◆ ◆ ◆ ◆ Low power consumption.
◆ ◆ ◆ ◆ Supports the multiple controls by a single controller.
◆ ◆ ◆ ◆ Extended operating range (1.2km).
3. FrSky V8 2.4GHz radio control system
If you are into FUTABA OR JR and want to update your radio system to the 2.4GHz technology, the FrSky V8
system is the right choice.
3.1 FrSky V8 2.4GHz radio control system consists of
1× transmitter module （Model: V8FT or V8JT）
1× receiver module（Model: V8FR）
1× transmitter antenna (Model: V8JTA)
3.2 Transmitter Module is compatible with the following transmitters:
Futaba module: Futaba: 3PM, 3PK, 7U, 8U, 8J, 9C , 9Z and FN series.
Hitec: Optic 6, Eclipse 7.
WFLY: WFT09, WFT 08.
JR module:
JR:347/388/783/U8/PCM10/PCM10S/PCM10SX/ PCM10IIS/8103/J9303/MX-22/MX-24S/PX/9XII
FrSky V8 2.4GHz Radio Control System
Instruction Manual for V8 series
- 1 -
： ： ： ：
ACCST
2.4GHz
Advertisement
Related Manuals for HobbyKing FrSky V8
Summary of Contents for HobbyKing FrSky V8
- Page 1 ◆ ◆ ◆ ◆ Extended operating range (1.2km). 3. FrSky V8 2.4GHz radio control system If you are into FUTABA OR JR and want to update your radio system to the 2.4GHz technology, the FrSky V8 system is the right choice.
- Page 2 3.3 Receiver specifications: Operating Voltage Range: 4.8V-6V Operating Current: 30mA Specified Range: 1.2km Resolution: 10bit Latency: 22ms Number of Channels: 8CH Dimensions: 60×37×21 mm 3.4 Transmitter module specifications: Operating Voltage Range: 6.0V-13.0V Operating Current: 50mA Output Power: 18.5mW Resolution: 10bit Dimensions: 63.9X48.5X36.5mm (V8JT);...
- Page 3 4.3 Receiver and Transmitter Setup Instructions Follow the steps below to properly set up your system. Turn your FUTABA OR JR transmitter on and switch it to PPM mode, power off the TX. Turn the transmitter on while holding the programming button. Release it a few seconds later. The RED LED on the transmitter module will flash indicating the transmitter is ready to bind the receivers.
- Page 4 4.5 Safety range indicator When the model controlled by V8 2.4GHz radio control system is close to the maximum distance of control, the response of the model will slow down. It is the safety feature designed by FrSky. It means, the user should fly the model closer to the transmitter as soon, as the reactions are getting slower.
