Code U431 & CG836:- Bolero Round Stacking Table
Pack Contents:-
1.
2.
3.
4.
Assembly Instructions:-
1.
Place 2 leg tubes together and line up the holes on the two adjacent upstanding legs
2.
Push a hex socket bolt (4) through the lined up holes and fasten with a locking nut (3), use the Allen
key and suitable spanner to tighten
3.
Repeat steps 1 and 2 for the other five fixing points on the legs
4.
Place the table top face down on a level floor (use protection to prevent the surface from being
scratched).
5.
Pass the screw (5) through the plastic fitting (6) (with the curved side of the fitting wrapped around
the table leg)
6.
With the holes in the upturned legs lined up with the underside of the table top, attach the legs to the
table top
7.
The plastic fittings are provided to protect the stainless steel top when the tables are stacked.
8.
Caution : Do not store upside down as this can cause water ingress
Bolero, Fourth Way, Avonmouth, United Kingdom, BS11 8TB.
Stainless steel top
Leg tube
Locking nut
Hex socket bolt
The Bolero Helpline telephone number is 0845 146 2887
x 1
5.
Posi head screw
x 3
6.
Plastic fitting
x 6
1 x Allen Key
x 6
x 6
x 6
