Code U505 & CG837:- Bolero Square Stacking Table
The Bolero Helpline telephone number is 0845 146 2887
Bolero, Fourth Way, Avonmouth, United Kingdom, BS11 8TB.
Assembly Instructions:-
a.
Place 2 leg tubes together and line
up the holes on the two adjacent
upstanding legs
b.
Push a hex socket bolt (4) through
the lined up holes and fasten with a
locking nut (3), use the Allen key (7)
and suitable spanner to tighten
c.
Repeat steps 1 and 2 for the other
seven fixing points on the legs
d.
Place the table top face down on a
level floor (use protection to prevent
the surface from being scratched).
e.
Pass the screw (5) through the
plastic fitting (6) (with the curved
side of the fitting wrapped around
the table leg)
f.
With the holes in the upturned legs
lined up with the underside of the
table top, attach the legs to the
table top
g.
The plastic fittings are provided to
protect the stainless steel top when
the tables are stacked.
h.
Caution: Do not store upside down
as this can cause water ingress
