Polaris 3900 Tune Up Kit Installation Instructions Manual page 2

Page 2
ENGLISH
5. Set the cleaner on its side on the double wheels.
6. Loosen the three (3) screws on underside of
cleaner (Figure 4). Tilt the cleaner over and allow
screws to drop out.
2
Figure 4. Remove three (3) bottom housing
screws
7. Remove the bottom housing.
8. Set cleaner on its double side wheels and remove
three (3) screws in location marked "A" water
management system assembly (Figure 5).
1
Figure 5. Remove three (3) water management
system screws
Polaris 3900 Tune Up Kit
®
9.
1
3
Figure 6.
Figure 7.
2
10. Remove two (2) screws (Figure 8) to detach and
3
Figure 8.
NOTE: The left screw (1) is deeply recessed. To retrieve the
|
Installation Instructions
Remove the water management system with rear
housing attached by pulling straight out (Figures 6
and 7).
Pull firmly to remove water management
system and rear housing
Water management system and rear
housing removed
remove top housing (Figure 9).
Deeply
Recessed
Screw
1
Remove two (2) top housing screws
screw after loosening, turn the cleaner over and it will
fall out.
2
