Revision

Approvals：

__________________________________ ____________

Service Manual

RP56HD21

Description

Marketing

Engineering

Date

Table of Contents

Need help?

Do you have a question about the RP56HD21 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivitek RP56HD21

Page 1: Service Manual
Service Manual RP56HD21 Revision Description Date Approvals： __________________________________ ____________ __________________________________ ____________ Marketing Date __________________________________ ____________ __________________________________ ____________ Engineering Date...
Page 2: Table Of Contents
CONTENTS Engineering Specifications..........................1 Summary specifications ..........................1 Introduction..............................3 2.1. Digital Light Processing(DLP) by Texas Instruments ..............3 2.2. DCDi deinterlacing/enhancement chipset ..................3 2.3. Key Features ..........................3 2.3.1. Optical ..........................3 2.3.2. Mechanical ........................3 2.3.3. Electrical ...........................3 2.3.4. Power Supply ........................4 2.3.5. Packaging.........................4 2.4. Supplied Accessories .........................4 2.5.
Page 3 5.5. Clean Air Filters ........................25 5.6. Cooling system： ........................25 5.7. Acoustic noise：........................25 Safety ..............................25 6.1. Interlocks ..........................25 6.2. Labels............................25 On-Screen Display Function Control Description ..................26 Functional Requirements ........................26 OSD Flow chart .............................29 III. Circuit Description............................47 Circuit Description ..........................47 Hardware platform description ......................51 2.1.
Page 4: Engineering Specifications
Engineering Specifications 1. Summary specifications Performances Specification Display type One 0.8” 1280 x 720 DLP. Resolution supported VGA (640x480) expansion. SVGA (800x600) expansion. DTV(1280x720 p) native. HDTV (1920x1080 i). compression Colors 16.7M Bandwidth 80 MHz Weight < 130 Lb. Image size (diagonal) 56 inch.
Page 5 PC ： D-Sub 15pin x 1 and DVI x 1 AV ： S-Video x 2, Composite Video x 2,YPbPr x 2 RF ： F - TYPE x 1 (model name ： RP56HD21-A/T) I - TYPE x 1 (model name ： RP56HD21-C) Audio ：...
Page 6: Introduction
2. Introduction The DVR5610 is a Rear Projection multi purpose display unit integrating DLP(Digital Light Processing) technology that is targeted for multi media application and data processing applications. As such it will excel in displaying real time video and graphics. 2.1.
Page 7: Power Supply
Clean air filters Service center replacement parts Optical engine assembly. Electronics/Power supply module/Ballast module. Fans. RS232 download. 2.6. Safety UL/CUL FCC class B Locked rotor detection – auto shutdown CCC,BASEC/BS (model name ： RP56HD21-C) BSMI (model name ： RP56HD21-T) Page4 of 79...
Page 8: Optical
3. Optical The optical specifications are divided into component specifications and projector performance specifications. 3.1. Illumination & Imaging Optics 3.1.1. Projection Lens Specification Units Minimum Maximum Typical Notes Fixed lens Focal length 13.2 Distortion <1.0 MTF(36lp/mm) Center >80 Lateral color <1 pixel 3.1.2.
Page 9: Brightness,Uniformity,Contrast
3.2. Brightness,Uniformity,Contrast Specification Units Minimum Maximum Typical Notes White field nits Using ANSI 9 point avg. Uniformity Percent >80% >85% Using ANSI 9 point Brightest Dimmest Contrast ratio Ratio 1000 ： 1 Dark room measurement (full-on , full-off) Note ： Specifications TBD at prototype phase 3.3.
Page 10: Image
3.4. Image Specification Units Minimum Maximum Typical Notes Viewable screen size Inch 56”(16 ： 9) Diagonal Width 1381 Height 1113 Screen Two-part screen composed Type of a front UCS type lenticular and a back Gain fresnel lens. Viewing angle degree Relative to normal axis of Horizontal screen...
Page 11: Definitions
3.6. Definitions The full white pattern is defined as an all white screen produced by 0.7V video input to R,G,B. Note ： All measurements are done in a darkened room. Contrast measurements are done using a full white screen and a full black screen. Note ：...
Page 12 Specification Units Minimum Maximum Typical Notes Chrominance (Pr/Cr/R-Y) V p-p 75 ohm Audio input amplitude R/L audio input. V rms 47K ohm Frequency NTSC Video 640 x 480 interlace Horizontal 15.734 Vertical Video 640 x 480 interlace Horizontal 15.625 Vertical Components Video(1080i) 74.25...
Page 13 Horizontal Timing Intervals 0.700 volt 0.000 volt Video Trailing Border Leading Border Blanking Back Porch Front Porch Sync Sync polarity may be inverted for some modes Vertical Timing Intervals 0.700 volt 0.000 volt Video Trailing Border Leading Border Blanking Back Porch Front Porch Sync Sync polarity may be inverted for some modes...
Page 14: Video Compatibility & Re-Sizing
4.2. Video Compatibility & Re-sizing 4.2.1. Re-sizing Specification Units Minimum Maximum Typical Notes Total pixels per line Pixels 1920 1280 1280 displayed Active vertical lines # of HS 1080 720 displayed Resizing From Video NTSC/PAL/SECAM/YPbPr 4 ： 3 /YCbCr Full screen High TV 16 ：...
Page 15: Tvs Channel Table
4.2.4. NTSC TVs Channel Table CATV Picture Carrier (MHz) TV/STD CATV HRC CATV IRC 55.25 54.00 55.25 61.25 60.00 61.25 67.25 66.00 67.25 73.25 72.00 73.25 77.25 78.00 79.25 83.25 84.00 85.25 95/A-5 91.25 90.00 91.25 96/A-4 97.25 96.00 97.25 97/A-3 103.25 102.00...
Page 16 CATV Picture Carrier (MHz) TV/STD CATV HRC CATV IRC 34/U 283.25 282.00 283.25 35/V 289.25 288.00 289.25 36/W 295.25 294.00 295.25 37/AA 301.25 300.00 301.25 38/BB 307.25 306.00 307.25 39/CC 313.25 312.00 313.25 40/DD 319.25 318.00 319.25 41/EE 325.25 324.00 325.25 42/FF 331.25...
Page 17 CATV Picture Carrier (MHz) TV/STD CATV HRC CATV IRC 493.25 492.00 493.25 495.25 499.25 496.00 499.25 501.25 505.25 504.00 505.25 507.25 511.25 510.00 511.25 513.25 517.25 516.00 517.25 519.25 523.25 522.00 523.25 525.25 529.25 528.00 529.25 531.25 535.25 534.00 535.25 537.25 541.25 540.00...
Page 18 CATV Picture Carrier (MHz) TV/STD CATV HRC CATV IRC 609.25 613.25 612.00 613.25 615.25 619.25 618.00 619.25 621.25 625.25 624.00 625.25 627.25 631.25 630.00 631.25 633.25 637.25 636.00 637.25 639.25 643.25 642.00 643.25 645.25 649.25 648.00 649.25 651.25 655.25 654.00 655.25 657.25 661.25...
Page 19 777.25 781.25 780.00 781.25 783.25 787.25 786.00 787.25 789.25 793.25 792.00 793.25 795.25 799.25 798.00 799.25 801.25 4.2.5. PAL TVs Channel Table(model name：RP56HD21-C) PAL D/K CATV VIDEO SOUND CATV VIDEO SOUND 48.5-56.5 49.75 56.25 470-478 471.25 477.75 56.5-64.5 57.75 64.25 478-486 479.25...
Page 20 CATV VIDEO SOUND CATV VIDEO SOUND 199-207 200.25 206.75 542-550 543.25 549.75 207-215 208.25 214.75 550-558 551.25 557.75 215-223 216.25 222.75 558-566 559.25 565.75 111-119 112.25 118.75 566-574 567.25 573.75 119-127 120.25 126.75 574-582 575.25 581.75 127-135 128.25 134.75 582-590 583.25 589.75 135-143...
Page 21 CATV VIDEO SOUND CATV VIDEO SOUND 423-431 424.25 430.75 822-830 823.25 829.75 431-439 432.25 438.75 830-838 831.25 837.75 439-447 440.25 446.75 838-846 839.25 845.75 447-455 448.25 454.75 846-854 847.25 853.75 455-463 456.25 462.75 854-862 855.25 861.75 862-870 863.25 869.75 PAL-I: Cable channel Air channel Cable channel...
Page 22: User Interface
4.3. User interface 4.3.1. Hardware function ( Rear) AV IN 1&2：Audio and video input connector (2 sets, respectively) (a) AUDIO ： R input (Right channel of stereo sound; red color of RCA JACK) L input (Left channel of stereo sound; white color of RCA JACK) (b) VIDEO ：...
Page 23 DATA INPUT：Digital and analog video signal input connector (a)DVI ： 24pin digital only connector Digital data input connector (VESA DFP) Signal Pin Assignments： Signal Assignment Signal Assignment Signal Assignment T.M.D.S. Data 2- T.M.D.S. Data 1- T.M.D.S. Data 0- T.M.D.S. Data 2+ T.M.D.S.
Page 24 (b)VGA ： 15 pin D-sub analog video signal input connector 15 pin D-type connector Pin Assignments ： DDC2B+ or Standard VGA DDC1 Host DDC2B Host DDC1/2 Display DDC2AB Host Red Video Red Video Red Video Red Video Red Video Green Video Green Video Green Video Green Video...
Page 25: Side
4.3.2. Hardware function(SIDE)： AV IN：Audio and video input connector(1 set) (a)AUDIO ： R input (Right channel of stereo sound ; red color of RCA JACK) L input (Left channel of stereo sound ; white color of RCA JACK) (b)VIDEO ： Composite video signal input (yellow color of RCA JACK) (c)S-VIDEO ：...
Page 26: Remote Control Keypads
4.3.4. Remote control keypads Button on the C48 HEX Data Code Power MUTE Vol + Vol - CH + CH - INPUT LAST WIDE Up Arrow Down Arrow Left Arrow Right Arrow GUIDE INFO MENU EXIT Play Rewind Forward Record Stop Pause Page23 of 79...
Page 27: Mechanical
5. Mechanical 5.1. Outline Dimensions Units Maximum Minimum Typical Notes Specification Outside dimensions Width “ 1381 Height “ 1113 Length “ Weight Lb./kg 5.2. Environmental Specification Units Minimum Maximum Typical Notes Operation Temperature All performance ifitispecifications ℃ (Di)(Design) are maintained within this temperature range Operation Temp.
Page 28: Clean Air Filters
5.5. Clean Air Filters Note：Clean air filters are replaceable without opening main projector cover. 5.6. Cooling system： DVR5610 is a projection product which using UHP(ultra high pressure) lamp as light source, most of heat is generated from the UHP lamp, this feature leads to following thermal consideration. In DVR5610, forced convection is designed as the main cooling mechanism, fans are employeed as active cooling devices to circulate flow.
Page 29: On-Screen Display Function Control Description
TV ~ Front RGB DVI type Selector mode Video ~ Computer Pip input Selector mode AV ~ Front AV TV Tuner Setup Menu (model name ： RP56HD21-A) Antenna / Cable Selector mode Antenna ~ Cable Auto program channels 2 ~ 68 (Antenna) Channel...
Page 30 TV Tuner Setup Menu (model name ： RP56HD21-T) Antenna / Cable Selector mode Antenna ~ Cable Auto program channels 2 ~ 68 (Antenna) Channel Selector mode 2 ~ 125 (Cable) TV Tuner Setup Menu (model name ： RP56HD21-C) Auto program channels...
Page 31 Special Features Menu (model name ： RP56HD21-A) OSD H Position Slider Bar mode 0 ~ 100 OSD V Position Slider Bar mode 0 ~ 100 OSD Timeout Slider Bar mode 15 ~ 49 Color Temperature Selector mode Neutral ~ Warm ENGLISH ~ ESPA Ñ...
Page 32: Osd Flow Chart
2. OSD Flow chart Main Menu Flow Chart (Model Name : RP56HD21-A) ：UP or Down Key Event (select item) ：Enter Key Event (enter sub menu) PICTURE ADJUST ：Menu Key Event (disable OSD) PIP SETUP INPUT SETUP TV TUNER SETUP AUDIO ADJUST...
Page 33: Picture Adjust
Main Menu Flow Chart (Model Name : RP56HD21-T/C) ：UP or Down Key Event (select item) ：Enter Key Event (enter sub menu) PICTURE ADJUST ：Menu Key Event (disable OSD) PIP SETUP INPUT SETUP TV TUNER SETUP AUDIO ADJUST SPECIAL FEATURES Page30 of 79...
Page 34 Picture Adjust Menu (AV) Flow Chart Non-edit edit mode mode CONTRAST BRIGHTNESS COLOR TINT SHARPNESS WIDE FORMAT STRETCH STRETCH CENTER PANORAMIC ZOOM ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (in edit mode , select mode) ：Volume-up or Volume-down Key Event (in edit mode , adjust value) ：Menu Key Event (return main menu)
Page 35 Picture Adjust Menu (PC) Flow Chart Non-edit edit mode mode CONTRAST BRIGHTNESS H POSITION V POSITION AUTO CINFIG ADC CLOCK ADC PHASE STRETCH CENTER WIDE FORMAT STRETCH ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (in edit mode , select mode) ：Volume-up or Volume-down Key Event (in edit mode , adjust value)
Page 36 Pip Setup Menu Flow Chart Non-edit edit mode mode PIP STYLE SPLIT MAIN+3 MAIN+7 SCAN WIDE FORMAT 4：3 4：3 16：9 SIZE H POSITION V POSITION TRANSPARENCY ：UP or Down Key Event (select item ,only in pip mode) ：Enter Key Event (enter edit mode ,only in pip mode) ：Menu Key Event (exit edit mode ,only in pip mode) ：Volume-up or Volume-down Key Event (in edit mode ,adjust value ,only in pip mode) ：Enter Key Event (enter edit mode)
Page 37 Input Setup Menu Flow Chart Non-edit edit mode mode MAIN INPUT COMP1 COMP2 FRONT AV FRONT RGB DVI TYPE VIDEO VIDEO COMPUTER COMP1 COMP2 FRONT AV PIP INPUT ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (in edit mode , select mode) ：Menu Key Event (return main menu)
Page 38 TV Tuner Setup Menu Flow Chart (Model Name ： RP56HD21-A) Non-edit edit mode mode ANTENNA / CABLE CABLE ANTENNA CABLE AUTO PROGRAM CHANNELS CHANNEL SKIP CLOSE CAPTION AUTO AUTO CAPTION STYLE TEXT1 TEXT2 TEXT3 TEXT4 NOISE REDUCTION ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode)
Page 39 TV Tuner Setup Menu Flow Chart (Model Name ： RP56HD21-T) Non-edit edit mode mode ANTENNA / CABLE CABLE ANTENNA CABLE AUTO PROGRAM CHANNELS CHANNEL SKIP ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (in edit mode , select mode)
Page 40 TV Tuner Setup Menu Flow Chart (Model Name ： RP56HD21-C) Non-edit edit mode mode AUTO PROGRAM CHANNELS CHANNEL MANUAL SEARCH CHANNEL FINE TUNE CHANNEL EXCHANGE CHANNEL SKIP ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode)
Page 41 Channel Manual Search (Sub Menu) Flow Chart Non-edit edit mode mode FREQ CHANNEL MENORY Channel Fine Tune (Sub Menu) Flow Chart Non-edit edit mode mode FERQ OFFSET Channel Exchange (Sub Menu) Flow Chart Non-edit edit mode mode NOW CHANNEL OBJECT CHANNEL CONFIRM ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode)
Page 42 Audio Adjust Menu Flow Chart Non-edit edit mode mode BASS TREBLE BALANCE TV SOUND STEREO STEREO MONO INTERNAL SPEAKERS REAR AUDIO OUT FIXED FIXED VARIABLE SUB HPHONE VOL EFFECT VIVA HD3D EALA SIM STEREO ：UP or Down Key Event (select item) ：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (in edit mode ,adjust value)
Page 43 Parent Control Menu Flow Chart(model name ： RP56HD21-A) Non-edit edit mode mode (Press first (Press second (Press third (Press fourth number) number) number) number) ACCESS CODE ―――― Part A ＊＊＊＊＊――― ＊＊―― ＊＊＊― ＊＊＊＊：Enter Key Event (enter edit mode) ：Menu Key Event (exit edit mode) or password error...
Page 44 Part A Non-edit edit mode mode MPAA RATING TV RATING UNRATED ALLOWED (Press first (Press second (Press third (Press fourth number) number) number) number) CHANGE PASSWORD ―――― ＊＊＊＊＊――― ＊＊―― ＊＊＊― ＊＊＊＊ (Press first (Press second (Press third (Press fourth number) number) number)
Page 45 MPAA Rating Menu(Sub Menu) Flow Chart PG – 13 NC – 17 ：UP or Down Key Event (select item) ：Enter Key Event (change item sign) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (enable or disable) ：Menu Key Event (return Parent Control menu) Page42 of 79...
Page 46 TV Rating Menu （ Sub Menu ） Flow Chart TV – Y TV – Y7 Part B TV – G Part C TV – PG TV – 14 Part C TV – MA Part D ：UP or Down Key Event (select item) ：Enter Key Event (change item sign) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (enable or disable)
Page 47 Part B Part C ：UP or Down Key Event (select item) ：Enter Key Event (change item sign) ：Menu Key Event (exit edit mode) ：Volume-up or Volume-down Key Event (enable or disable) ：Menu Key Event (return Parent Control menu) ：Volume-down Key Event (return TV rating menu) Part D Page44 of 79...
Page 48 Special Features Menu Flow Chart(model name ： RP56HD21-A) Non-edit edit mode mode OSD H POSITION OSD V POSITION OSD TIMEOUT COLOR TEMPERATURE NEUTRAL NEUTRAL COOL WARM LANGUAGE ENGLISH FRANÇAIS ENGLISH ESPAÑOL SYSTEM INFO RESET ALL SETTINGS RESET LAMP TIMER SLEEP TIMER...
Page 49 Special Features Menu Flow Chart(model name ： RP56HD21-T/C) Non-edit edit mode mode OSD H POSITION OSD V POSITION OSD TIMEOUT COLOR TEMPERATURE NEUTRAL NEUTRAL COOL WARM LANGUAGE ENGLISH FRANÇAIS ENGLISH 中文 SYSTEM INFO RESET ALL SETTINGS RESET LAMP TIMER SLEEP TIMER...
Page 50: Circuit Description
III. Circuit Description 1. Circuit Description FRONT I/O BOARD AUDIO AMP. SUB- FRONT AV INPUT PT2313 TDA1308 HEADPHONE FRONT PC R L I2C3 PC R L AUDIO SWITCH AUDIO AMP. MAIN- DVI R L TEA6420 PT2313 TDA1308 HEADPHONE I2C2 COMP1 R L AUDIO/VIDEO COMP2 R L AV1 INPUT...
Page 51 SYSTEM BLOCK POWER KEYPAD BOARD AUDIO BOARD Control DRIVER BOARD BOARD BOARD TUNER Front I/O INTER FACE BOARD BOARD BOARD Page48 of 79...
Page 52 NTSC TUNER BOARD V-CHIP AND CC TUNER 1 TV1 R/L ANTA SPLITER V-CHIP AND CC TUNER 2 TV2 R/L (model name ： RP56HD21- C) PAL TUNER BOARD TUNER 1 SOUND TV1 R/L PROCESSOR TUNER 2 ANTA SOUND TV2 R/L PROCESSOR AV &...
Page 53: Control Board
CONTROL BOARD BUFFER HDCP FRONT PC MAIN DECODER COMP1 COMP2 SCALER VIDEO DE-INTERLACE DECODER VIDEO 1 LVDS LVDS OUT COMP1 DECODER COMP2 VIDEO DE-INTERLACE DECODER VIDEO 2 DMD DRIVE BOARD BUFFER VOLTAGE 0.8" 16:9 DMD LVDS DECODER DRIVER LVDS IN WXGA HD2 1280X720 COLOR...
Page 54: Hardware Platform Description
2. Hardware platform description 2.1. I/P board PCBA（Refer to picture 1） The I/P board PCBA contains circuitry that manages the major functions of the RPTV, including video , computer signal , deinterlacing,DCDi,PIP , HDCP and keypad IR signal processing. The 8052 microprocessor A 8052 CPU controls the projector system functions.
Page 55 RGB input from the VGA connector From the VGA input, a differential RGB signal goes to the input ADC (MST 9883). This chip looks at the vertical, horizontal. From there, the signal is converted to a 24 bit digital signal and sent to Scaler chip via the digital bus.
Page 56: Power Supply Pcba （Refer To Picture 2
2.2. Power supply PCBA （Refer to picture 2） The power supply provides DC electrical power to all the electrical components in the rear projection television . DVR-5610 also contains a ballast that provides high voltage 380V necessary to strike the lamp when the rear projection television is powered up.
Page 57 Location diagram of power board Audio power ACin EMI filter Standby power 380V Main power The power supply consists of the EMI filter, PFC , Standby power, Audio power and Main power. The system required voltage is converted from the Standby, Audio and Main power, and the high voltage DC 380V from PFC is applied to the lamp and Audio and Main power.
Page 58: A/V Board Pcba（Refer To Picture 3
Short circuit protection All voltage outputs shall have short circuit protection. Only 5Vs output shall be auto recovery after the short condition removed. Over voltage protection All voltage outputs shall have over voltage protection, besides –20V( 6.24V for 5.1V, 5Vs outputs, 14.9V for 12V, 12Vs outputs, 9.06V for 8V output, 25V for 20V output, 415V for 380V output ) Under voltage protection All voltage outputs shall have under voltage protection, besides +/-20V and 380V outputs( 4.12V for 5.1V, 5Vs...
Page 59: Keypad Eca & Ir Pcba（Refer To Picture 4
2.4. Keypad ECA & IR PCBA（Refer to picture 4） The keypad provides the user access to all of the controllable functions on the projector. It receives keypad signals from the keypad attached to the top case, and then processes them before passing the signals to the main board for command processing.
Page 60: Tuner Board Pcba（Refer To Picture 6
2.6. Tuner board PCBA（Refer to picture 6, 7） Model name ： RP56HD21-A/T PAL Tuner/BD (Picture 7) Model name ： RP56HD21-C Page57 of 79...
Page 61 Fans There are three fans in the RPTV. One fan, fastened to the top of the Lamp, exhausts warm air generated by the Lamp portion of the optical engine through the Rear housing. The 2nd fan, which fastens to the top of the perforated metal housing of power board to cooling power module and DMD module, 3 Fan which fastens to the CH top of the perforated metal housing of ballast board to cooling ballast module and lamp.
Page 62: Troubleshooting Flow Chart
Troubleshooting Flow Chart AC INPUT CHECK LED POWER AND YES PUSH POWER KEY LAMP ON CHECK LAMP SELET INPUT CHECK IMAGE AND AUDIO YES PUSH POWER KEY SYSTEM OFF REPLACE POWER BOARD AND CHECK INTERLOCK SWITCH POWER LED STATUS LIST FAIL 2 BLUE 1 AMBER...
Page 63 Table of Contents 1. NO POWER ( POWER AND LAMP ON/OFF LED ARE OFF) 2. NO PROJECTION LIGHT 3. OSD IS NOT OPERATING 4. NO VIDEO 5. NO AUDIO 6. NO TV 7. PROTECTION IMAGE IS ABNORMAL Page60 of 79...
Page 64: No Power ( Power Led Off)
3. NO POWER ( POWER LED OFF) Check AC input is correct or not ? Replace power/BD Check the lamp module cover switch Page61 of 79...
Page 65: No Projection Light ( No Picture)
4. NO PROJECTION LIGHT ( NO PICTURE) Check Lamp on ? Check Power LED 2 Blue 1 Amber 3 Blue 2 Amber 5 Blue 2 Amber Chech Fan connector or Check ballast input Replace DMD/BD or Fan fail 380 Vdc Replace lamp module Or Repalce Power B/D Repalce Control B/D...
Page 66: Osd Not Operating
5. OSD NOT OPERATING Check keypad or remote keypad remote Check battery or remote or Replace key B/D control panel 6. VIDEO NO IMAGE (CVBS ,S-VIDEO ,Y/Cb/Cr ,Y/Pb/Pr) Check RGB data ok or not Replace AV B/D Replace control B/D Page63 of 79...
Page 67: No Audio
7. NO AUDIO Check R or L speaker , check input level setting Speaker or speaker Replace audio B/D amplfier B/D 8. NO TV OR LOST SOME CHANNEL Check TV auto program or channel map or locked Re-setting Replace tunner B/D Page64 of 79...
Page 68: Protection Image Is Abnormal
9. PROTECTION IMAGE IS ABNORMAL Make sure abnormal image is caused by electrical or optical eletrical optical Check optical adjust autosync & tracking ,the Engine image can be improve or not Adjust autosync or Replace control B/D or phase compability Page65 of 79...
Page 69: Pcb Layout Diagram
IV. PCB Layout Diagram CN100 CN301 POWER BOARD CN204 CN308 AUDIO AMP CN207 CN205 CN206 TUNER BOARD BOARD CN305 CN309 BALLAST FRONT INTERFACE BOARD BOARD JF10 LAMP CN104 CN103 CN105 CN102 CN108 CN101 JM21 FAN1 JM12 AV BOARD CN109 JM23 CONTROL DMD DRIVER BOARD...
Page 70: Mechanical Assembly
V. Mechanical Assembly Page67 of 79...
Page 71 Page68 of 79...
Page 72 Page69 of 79...
Page 73 Page70 of 79...
Page 74 Page71 of 79...
Page 75 Page72 of 79...
Page 76: Adjustment Of Picture
VI. Adjustment of Picture ENTER FACTORY MODE Step1. Press “INFO” on remote or use OSD: MAIN MENU → SPECIAL FEATURES → SYSTEM INFO Step2. Press “VOL -” and ”CH -” and “OK” Simultaneously. Step3. Enter “ COLOR TEMPERATURE ” Step4. Enter “ TEST PATTERN ” Step5.
Page 77 Page74 of 79...
Page 78: Recommended Spare Parts List
VII. Recommended Spare parts list Model name ： RP56HD21-A DELTA P/N ： DESCRIPTION =================== ==================================== 3797048800 Lamp module assy(Philips) 3797036500 Optical module 5050001910 Projector Lens 3250308300 UV-IR 5059702081 DMD panel 3255003600 Hardcoat 3255003900 Screen Fresnel 3255004000 Screen Lenticular 3797047300 Ballast assy(Philips)
Page 79 Model name ： RP56HD21-T DELTA P/N ： DESCRIPTION =================== ==================================== 3797048800 Lamp module assy(Philips) 3797036500 Optical module 5050001910 Projector Lens 3250308300 UV-IR 5059702081 DMD panel 3255003600 Hardcoat 3255003900 Screen Fresnel 3255004000 Screen Lenticular 3797047300 Ballast assy(Philips) 5600200180 DMD Driver / BD...
Page 80 Model name ： RP56HD21-C DELTA P/N ： DESCRIPTION =================== ==================================== 3797048800 Lamp module assy(Philips) 3797200000 Optical module 5050001910 Projector Lens 3250308300 UV-IR 5059702081 DMD panel 3255003600 Hardcoat 3255003900 Screen Fresnel 3255004000 Screen Lenticular 3797047300 Ballast assy(Philips) 5600208006 DMD Driver / BD...
Page 81: Download Procedure (Use Rs-232)
VIII. Download Procedure (USE RS-232) Step1 ： use download device to connect after(as below an attached),pull out power cord. NOTEBOOK OR TABLE PC DVR-5610 D-SUB ADAPTER 12V Step2 ： start → program sets → communication → super terminate Step3 ： input link name,ex:5610. use link input source : choice link port Select : 57600, 8, N, 1, N(setup link port: as below attached) 57600...
Page 82 Step4 ： choice "transmit 傳送" ,then setup as below: Xmodem Page79 of 79...
