  • Page 5 20130719 K2 Dyno S User Manual...
  • Page 6 Contents K2 Dyno S User Manual 20130719...
  • Page 7 Contents 20130719 K2 Dyno S User Manual...
  • Page 8 Contents K2 Dyno S User Manual 20130719...
  • Page 9 • Attaches metadata to segments and clips • Sends clips to other devices for external storage or further editing The K2 Dyno S Replay System has two main components: A K2 system and a K2 Dyno S Replay Controller. The K2 system can be a K2 Summit Production Client or a K2 Solo Media Server. The K2 Summit system has four video channel connections.
  • Page 10 The Dyno S Replay Controller controls the K2 system video streams no matter how the K2 system is configured. Many of the functions of the K2 Dyno S Replay Controller are operated from the large touch screen. Three key elements of the touch screen are Tabs, Slots, and Bins.
  • Page 11 Introduction Slots: The numbered storage locations for elements viewable under tabs such as highlights and playlists. 20130719 K2 Dyno S User Manual...
  • Page 12 Bins: A collection of like items. A bin is similar to a PC Folder. You can have multiple bins with highlights, playlists, or search results. Additional bins are accessed on the touch screen by tapping the bar at the top of the screen that contains a bin name. K2 Dyno S User Manual 20130719...
  • Page 13 A segment of video selected and saved for future use. It can be used for individual playback or for addition to a playlist. It can be configured to save just one record stream or all streams being recorded at the points that defined it. 20130719 K2 Dyno S User Manual...
  • Page 14 Introduction K2 Dyno S User Manual 20130719...
  • Page 15 1. Power on the K2 Summit system. The power button is the round black button on the front plate. 2. Power on the K2 Dyno S Replay Controller. The power switch is located at the back to the right under the protection flap.
  • Page 16 SoftKey to share the local server. • If this is not the first time the K2 Summit system and the K2 Dyno S Replay Controller has been paired, K2 Dyno S Replay Controller gives you the option to reconnect to a local server.
  • Page 17 You can delete all non-essential Sessions from the Sessions list as follows: 1. Select the session from the list and tap the softkey. 20130719 K2 Dyno S User Manual...
  • Page 18 2. Tap The Sessions list page appears, listing all Sessions currently on the server. 3. Select the session you are deleting and tap You cannot delete an active session, indicated by the word in yellow. K2 Dyno S User Manual 20130719...
  • Page 19 On the Home screen, the Record Status section displays key information about the recording status of the Dyno. Status indicators are as follows: 20130719 K2 Dyno S User Manual...
  • Page 20 Red text indicates recording is underway. The time that has passed since the start of the recording. The actual amount of record time available, where this record time is divided across the number of record streams in the configuration. K2 Dyno S User Manual 20130719...
  • Page 21 3. Adjust audio output on the selected channels as follows: • Select or to change the audio output level. • Select to silence the audio output. • Select to restore both input and output audio to their default levels. 20130719 K2 Dyno S User Manual...
  • Page 22 • Select or to change the audio record level. • Select to restore both input and output audio to their default levels. 1. On the screen, tap the audio meters section. The Audio panel opens. K2 Dyno S User Manual 20130719...
  • Page 23 When Flying M/E is selected, you can preset effect transitions between playback channels. Effects are added when switching record streams during the replay of an item. 1. On the screen, select 2. To configure the effect for Flying M/E, select The Effects panel opens. 20130719 K2 Dyno S User Manual...
  • Page 24 It also allows access to the upper channels without using the key. On the screen, select When this setting is selected, any cued element is immediately played. On the screen, select K2 Dyno S User Manual 20130719...
  • Page 25 T-bar, as doing so changes the playback speed to the programmed speed of the T-bar. The T-bar can be preset with two playback speed configurations: default and alternate. The positions of bar operations can be fine-tuned. 1. On the screen, tap the T-bar section. The T-bar panel opens. 20130719 K2 Dyno S User Manual...
  • Page 26 3. Change default settings as follows: Advance the to set the maximum speed and tap the top box. Pull the back to the position of the desired minimum speed and tap the lower box. K2 Dyno S User Manual 20130719...
  • Page 27 T-bar. Move the T-bar to the lower limit and tap the lowest Set box. Select the adjacent speed button and enter a speed in percentage for this T-bar location, then press 20130719 K2 Dyno S User Manual...
  • Page 28 NOTE: You cannot lock player channels while channels are ganged. Only P1 or P2 can be selected for locking. Press the desired button, then on the screen, select the SoftKey labeled accordingly. K2 Dyno S User Manual 20130719...
  • Page 29 The Transfers panel opens. 2. To monitor the transfers functions, select any of the following softkeys: Displays the progress of incoming transfers and their location. Monitors transfers that are sent to another location. Shows all completed transfers. 20130719 K2 Dyno S User Manual...
  • Page 30 3. To manage the transfers functions, select any of the following softkeys: Moves selected transfer to the next position in the list of potential transfers. Press the function of the softkey to stop any selected transfer. K2 Dyno S User Manual 20130719...
  • Page 31 0 when the record starts. displays a timecode that can be internally or externally generated. enables additional keyboard functionality such as for marking an in point, for marking an out point and for quick cue. 20130719 K2 Dyno S User Manual...
  • Page 32 Configuration Screen This panel adjusts the controls of the K2 Dyno S Replay Controller. To access these settings, tap Affects the Jog Knob shuttle speed when the function is engaged. The multiplier increases the Fast Jog function by 5x, 10x or 20x.
  • Page 33 Provides a safety measure when deleting clips. sends the data from the deleted clip to the recycle bin. The bin must be emptied before the clip is permanently deleted. immediately and permanently deletes a clip selected for deletion. 20130719 K2 Dyno S User Manual...
  • Page 34 K2 Dyno S User Manual 20130719...
  • Page 35 Centers transitions at In and Out points, allowing video beyond the set points to be visible. Ensures the transition is completed within the marked points of the clip. This affects the length of the playlist. 20130719 K2 Dyno S User Manual...
  • Page 36 Creates a flash of the selected color between the two events in the list. The duration of the flash is determined by the effect duration. To select the color, tap the adjacent color box and choose a color from the palette. 1. On the screen, tap K2 Dyno S User Manual 20130719...
  • Page 37 To view the current configuration on record and play back channels and revise the current status, on the screen, tap To resets all configuration screens to their factory default settings, on the screen tap 20130719 K2 Dyno S User Manual...
  • Page 38 Configuration Screen You can save configuration settings and keywords tables to an external device. You can then load the settings and tables to another K2 Dyno S Replay Controller, or for use later on the same K2 Dyno S Replay Controller.
  • Page 39 • Jog Knob • button The K2 Dyno S Replay Controller has four playback options: button Plays a recorded element or record stream at 100%. This is the primary way to place any player channel into a playback state. This works on a playlist, on a highlight, and on the active record trains.
  • Page 40 Select buttons from the K2 Dyno S Replay Controller. b) Use the Jog Knob to cue the record train on the selected player. Jogging cues only the selected channel.
  • Page 41 1. To return to the record train at the point of the current record., select your player channel button. 2. Press the button on the Right Bank of buttons. This takes the player channel to the current available recording of the active angle. 20130719 K2 Dyno S User Manual...
  • Page 42 Playback K2 Dyno S User Manual 20130719...
  • Page 43 1. To create a point at the current point of the active record train regardless of the location of the Player Channel , press the button. 2. To view the marks, open the screen. 3. To add a mark to the point where the player is cued, press 20130719 K2 Dyno S User Manual...
  • Page 44 Press the right arrow button to move the selection down the screen to the newer or later timecoded marks. 5. To create a Highlight from Marks, select the mark and press the button. A clip with default duration is created. K2 Dyno S User Manual 20130719...
  • Page 45 Select the slot location for clip. c) Save the clip in the selected slot location. The clip is saved in a slot location you choose, rather than in the next available slot location only. 20130719 K2 Dyno S User Manual...
  • Page 46 You can save a clip by using either an In point only or an Out point only. 1. Select only an point. 2. Press the button or select a slot in the highlight bin to form a default duration clip. K2 Dyno S User Manual 20130719...
  • Page 47 The Clip panel opens. 2. Tap the number box to the right of A number key pad opens. 3. Type in the desired duration of a default clip. 4. Tap to save settings and close. 20130719 K2 Dyno S User Manual...
  • Page 48 Create clips K2 Dyno S User Manual 20130719...
  • Page 49 Restores the player channel to the preset Out point of the clip 1. Choose a player Channel, use either 2. To make the corresponding record stream visible on the selected player channel, press a different button or it's function for angles E-G. 20130719 K2 Dyno S User Manual...
  • Page 50 Cue replay K2 Dyno S User Manual 20130719...
  • Page 51 2. Tap the Bin title bar at the top of the screen. All available bins are displayed. 3. To open, double-tap a bin. The open bin is now the active bin on the screen. 20130719 K2 Dyno S User Manual...
  • Page 52 In point of the clip. 2. To additionally display keywords, tap 3. To hide the thumbnail and keywords and display only title and duration, tap again. 4. To return to the default view, tap again. K2 Dyno S User Manual 20130719...
  • Page 53 1. To recall a clip by slot number, use the keyboard and type the bin number, type the slot number, and then press 2. To recall a clip by Auto Cue, on the screen, select When this setting is selected, an item is automatically cued with one tap. 20130719 K2 Dyno S User Manual...
  • Page 54 1. To change the name of a clip, select the clip and then on the keyboard, press The clip title bar at the bottom of the screen is changed from the clip name to the word and a cursor appears. 2. Type the new name and press K2 Dyno S User Manual 20130719...
  • Page 55 1. Select the clip so that the slot is outlined in blue or cue it on a player channel. 2. Tap the clip title bar on the lower left of the touch screen. The first table of keywords opens. 20130719 K2 Dyno S User Manual...
  • Page 56 5 tabs across the top of the touch screen. 3. To name the tab, tap the softkey twice. a) To type the name of the selected tab, you can either use the touch screen keyboard or the standard Dyno keyboard. K2 Dyno S User Manual 20130719...
  • Page 57 Next to the keywords is the slot number with the Fkey designation in parenthesis. 4. Verify that the correct Fkey is assigned. 5. To save the changes to the Fkeys, deselect 20130719 K2 Dyno S User Manual...
  • Page 58 3. On the keyboard, press The Bin title tab at the bottom of the screen displays QuickKeys. 4. Type the new bin name. 5. On the keyboard, press to save the new bin name. K2 Dyno S User Manual 20130719...
  • Page 59 Each available angle thumbnail is displayed. The primary angle is indicated by the word displayed on the thumbnail. 3. To change the primary angle, select the thumbnail of an available angle and tap the SoftKey located under the thumbnail panel. 20130719 K2 Dyno S User Manual...
  • Page 60 This returns to the record train without the limitations of the clip In point or Out point and allows cueing beyond the guardbands of the clip. 1. Select and cue a clip on a player channel. 2. Press K2 Dyno S User Manual 20130719...
  • Page 61 Favorite screen. 1. Open the screen. 2. To add elements such as Highlights, Playlists and Bins, use functions. 3. Move your most useful elements to the top of the bin as desired. 20130719 K2 Dyno S User Manual...
  • Page 62 1. To open the Favorite bar, tap-and-drag downward from the Tabs row or the Bin title bar. 2. To open additional slots, tap the Favorite bar and drag left or right. You can drag clips from the Favorite bar into a playlist. 3. To close the Favorite bar, tap-and-drag upward. K2 Dyno S User Manual 20130719...
  • Page 63 2. Go to the tab that holds the source clips to be added either Highlight, Library or Search. 3. Select the clips to be added to the playlist. 4. Press to add events to the list. 20130719 K2 Dyno S User Manual...
  • Page 64 , then tap a series of clips in the order to be added to the playlist. 6. Release once all the clips are highlighted in blue. 7. To add all the highlighted clips in order from first to last to the active playlist, press K2 Dyno S User Manual 20130719...
  • Page 65 Open the screen. b) If the playlist to be edited is inactive, move the playlist to the active panel. c) Drag the event to be moved to the new location in the list. 20130719 K2 Dyno S User Manual...
  • Page 66 3. To cue the event in the list that you are editing, double-tap the event slot. The event is highlighted in orange. 4. Use the Jog Knob to cue the event within the clip to the new event In point or Out point. 5. Press respectively. K2 Dyno S User Manual 20130719...
  • Page 67 In point e) Press to expand the Out point. f) Use the Jog Knob to select a new Out point. g) Press to set new Out point. Changes are immediately put into effect. 20130719 K2 Dyno S User Manual...
  • Page 68 1. Open the screen. 2. Select the playlist to be edited so that it is visible on the playlist screen. 3. Cue a clip in the playlist to the point to be divided. K2 Dyno S User Manual 20130719...
  • Page 69 A number pad appears. 6. Enter the new speed as a percentage to be assigned to that specific event. 7. Select to assign a new playback speed to that clip. 20130719 K2 Dyno S User Manual...
  • Page 70 The new angle thumbnail appears in the slot of the event. Use the Clear In or Out to include the event guardbands in the playlist. 1. Open the screen. K2 Dyno S User Manual 20130719...
  • Page 71 2. While the list is playing, tap an event either farther down the list or before the playing event. The selected event is outlined in blue. 3. Press to immediately take the playback of the list to the event selected. 20130719 K2 Dyno S User Manual...
  • Page 72 To find the location of the cursor or selected element, tap the SoftKey at the top of screen. The screen advances to the location of the currently selected element. 1. Open the screen. K2 Dyno S User Manual 20130719...
  • Page 73 The screen changes view, showing playlists in a manner similar to the default view of the Highlight screen. 2. To take the view up one level to show all the playlist bins available, tap the title bar. 20130719 K2 Dyno S User Manual...
  • Page 74 1. Tap the tab. 2. Tap the Audio set up panel. 3. Tap the Aux Audio Panel from the bottom strip. 4. Tap the Audio channels where the Aux Audio is to appear. K2 Dyno S User Manual 20130719...
  • Page 75 Aux. The Main list is no longer visible as the Aux list fills the playlist column. 10. To keep Main and Aux lists tied together for editing, tap the SoftKey on the tab. 20130719 K2 Dyno S User Manual...
  • Page 76 Playlists K2 Dyno S User Manual 20130719...
  • Page 77 • Placing a clip in a local playlist from different K2 Summit system With the introduction of ShareFlex, there are two ways for multiple K2 Dyno S Replay Systems to share resources: either with the ShareFlex peer-to-peer mode or with a K2 SAN.
  • Page 78 5. Use the Jog Knob, T-bar, or Play button to control the channel. 6. Press buttons on the K2 Dyno S Replay Controller to return to local record trains. is selected to load remote record trains, local record trains and angles are still available under .
  • Page 79 • Open the screen to navigate to a shared Summit. 3. Select the desired session created by the remote K2 Dyno S Replay Controller. 4. Double-tap the record train to load the recording to a player channel. 5. Select an angle from which to create a clip.
  • Page 80 Open the screen to navigate to a shared K2 Summit system. b) Select the desired session created by the remote K2 Dyno S Replay Controller. c) Open the remote Highlight Bin and locate the desired clip. d) Select the clip in one of the following ways: •...
  • Page 81 4. Select the playlist in one of the following ways: • Double-tap the playlist • Tap the playlist and press the buttons on the K2 Dyno S Replay Controller. 5. Press the button three times to cue for playback. For future quick access, add the remote Highlight bins and Playlist bins to your local Favorites Bar.
  • Page 82 ShareFlex K2 Dyno S User Manual 20130719...
  • Page 83 2. Press the button to save the elements to the default bin in the V: drive. With the button, elements are always saved to the default bin. You cannot save elements to a different bin. 20130719 K2 Dyno S User Manual...
  • Page 84 2. Double-tap the bin title bar at the top of the screen to display all bins on the V: drive. 3. Double-tap the title bar again, to display all the bins on the K2 Dyno S Replay Controller. 4. Double-tap the title bar again to display all the servers on the network.
  • Page 85 3. Press The word appears in the properties box at the bottom of the touch screen. 4. Use the keyboard to enter the new name for the file. 5. Press to save the new name. 20130719 K2 Dyno S User Manual...
  • Page 86 Library Session folders are in the Dyno Folder, which is on the V: drive). On the screen, tap K2 Dyno S User Manual 20130719...
  • Page 87 2. Locate the preset search bin named 3 Stars which is presented as a default. 3. Double tap on the 3 Stars bin. When opened, the 3 Star bin contains all clips in the active highlight bin which have been assigned a 3 star rating. 20130719 K2 Dyno S User Manual...
  • Page 88 A simple search checks the name, tags, description, comments, and custom texts of the assets. 1. Go to the tab. 2. From the bottom strip, locate the shift function The display is changed to the criteria page. K2 Dyno S User Manual 20130719...
  • Page 89 Additional search criteria can be added to narrow the search results further. 1. Once you have added the first criteria before selecting softkey, select softkey to add a new search criteria line. 2. To select clips with either search criteria, select 20130719 K2 Dyno S User Manual...
  • Page 90 2. Select the clip(s) to be added to the playlist. 3. Once the clips are outlined in blue, select Clip(s) are now part of the active playlist. can also be used to place clips into the playlist. K2 Dyno S User Manual 20130719...
  • Page 91 The VGA Expansion screen provides a broadend view of the K2 Dyno S Replay Controller functions. The horizontal panel across the top of the screen provides a combination of functions defined on both the touch screen and the control panel. Tapping the Live, Cue, Take, Top, Bottom, and Send buttons performs the same functions as the respective K2 Dyno S Replay Controller buttons.
  • Page 92 This is cycled through playlists in the active bin, causing each list in succession to be active on the K2 Dyno S Replay Controller. 1. On the VGA screen, click either the Marks, Highlights, Library or Search tab and then select the bin containing the desired clip.
  • Page 93 It compresses the view of the current bin panel and adds another bin panel to the left side of the screen. 2. To remove the second Bin Panel, click the SoftKey at the top of the original bin or the SoftKey at the top of the new Bin Panel. 20130719 K2 Dyno S User Manual...
  • Page 94 In the scenario of two player channels, the original list is associated with and the new panel with 2. To hide the new panel, click the small at the top of the playlist panel. K2 Dyno S User Manual 20130719...
  • Page 95 SoftKey. This is the first step in shutting down the K2 Dyno S Replay Controller in three different modes. panel opens. The default shutdown mode is the Startup screen. 2. To exit to Startup screen, do the following: a) Open the panel, as instructed by the steps earlier in this procedure.
  • Page 96 SoftKey to the left of the blue box changes to c) Tap to abort the Exit command and return to the previous session. d) Tap to continue to exit. The K2 Dyno S Replay Controller powers off. K2 Dyno S User Manual 20130719...
  • Page 97 The computer leaves the Dyno mode and the Windows operating system desktop is displayed. e) To return to the Dyno mode from the Windows operating system desktop, double-tap the icon on the desktop. 1. Go to the Page. 20130719 K2 Dyno S User Manual...
  • Page 98 2. Reconnect to the Server containing the Session to be reactivated. 3. Select the Session from the list on the right side of the screen. 4. To launch the session and restore it's elements, select softkey. K2 Dyno S User Manual 20130719...
  • Page 99 Stores the selected item to a highlight. Match Moves the playback pointer to the position with the same timecode on the record train for the current angle. Cue Up Cues up to the selected item. 20130719 K2 Dyno S User Manual...
  • Page 100 Fast Fast Jog mode On/Off. Playback 100% speed. Open Opens the bin or playlist. Cues an asset. Stops the playback. Cues previous and continue. K2 Dyno S User Manual 20130719...
  • Page 101 Close, skip. In PGM/PVW mode push to air. T-Bar Moving the T-Bar permits playback speed control. Jog Knob Turning the Jog Knob permits scrubbing (forward and backwards playback). Functions when you press each quick keys are listed below: 20130719 K2 Dyno S User Manual...
  • Page 102 Appendix Functions for keyboard shortcuts are listed below: K2 Dyno S User Manual 20130719...
  • Page 103 Media Manager are either registered trademarks or trademarks of Grass Valley USA, LLC. in the United States and/or other countries. Grass Valley USA, LLC. products are covered by U.S. and foreign patents, issued and pending. Additional information regarding Grass Valley USA, LLC.
  • Page 104 Trademarks and Agreements K2 Dyno S User Manual 20130719...
