Summary of Contents for GRASS VALLEY KAH-MEG-5
- Page 1 KAH-MEG-5 GRAPHICAL USER INTERFACE CONTROLLER Quick Setup Guide 13-06530-010 2021-01-25...
-
Page 2: Fcc Compliance
Valley USA, LLC, or one of its a liates or subsidiaries. All other intellectual property rights are owned by GVBB Holdings SARL, Grass Valley USA, LLC, or one of its a liates or subsidiaries. All third party intellectual property rights (including logos or icons) remain the property of their respective owners. - Page 3 The presence of this symbol in or on Grass Valley equipment means that it has been tested and certified as complying with applicable Underwriters Laboratory (UL) regulations and recommendations for USA.
- Page 4 Notices The presence of this symbol in or on Grass Valley equipment means that it has been tested and certified as complying with applicable Intertek Testing Services regulations and recommendations for USA/Canada. The presence of this symbol in or on Grass Valley product means that it complies with all applicable European Union (CE) directives.
- Page 5 Kahuna MEG Quick Setup Guide Cautions A caution indicates a possible hazard to equipment that could result in equipment damage. Observe the following cautions when operating or working on this equipment: • This equipment is meant to be installed in a restricted access location. •...
- Page 6 Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. Before disposing of your Grass Valley equipment, please review the Disposal and Recycling Information at: http://www.grassvalley.com/assets/media/5692/Take-Back_Instructions.pdf...
- Page 7 électrique, de compatibilité électromagnétique et de conformité environnementale. Le symbole ci-contre sur un appareil Grass Valley ou à l’intérieur de l’appareil indique qu’il est conforme aux normes applicables en matière de sécurité laser. Avertissements Les avertissements signalent des conditions ou des pratiques susceptibles d’occasionner des blessures graves, voire fatales.
- Page 8 Notices • Dans le présent manuel, toutes les instructions qui nécessitent d’ouvrir le couvercle de l’équipement sont destinées exclusivement au personnel technique qualifié. • N’utilisez pas cet appareil dans un environnement humide. • Cet équipement est mis à la terre par le conducteur de mise à la terre des cordons d’alimentation.
- Page 9 équivalent recommandé par le fabricant. Disposez des piles usagées conformément aux instructions du fabricant. Avant de vous séparer de votre équipement Grass Valley, veuillez consulter les informations de mise au rebut et de recyclage à: http://www.grassvalley.com/assets/media/5692/Take-Back_Instructions.pdf Précautions pour les écrans LCD et TFT Regarder l’écran pendant une trop longue période de temps peut nuire à...
- Page 10 Grass Valley believes this environmental information to be correct but cannot guarantee its completeness or accuracy since it is based on data received from sources outside our company. All specifications are subject to change without notice.
-
Page 11: Safety And Emc Standards
Kahuna MEG Quick Setup Guide Safety and EMC Standards This equipment complies with the following standards: Safety Standards Information Technology Equipment - Safety Part 1 EN60950-1: 2006 Safety of Information Technology Equipment Including Electrical Business Equipment. UL1419 (4 Edition) Standard for Safety – Professional Video and Audio equipment (UL file number E193966) EMC Standards This unit conforms to the following standards: EN55032:2015 (Class A) - Page 12 EMC Performance of Cables and Connectors Grass Valley products are designed to meet or exceed the requirements of the appropriate European EMC standards. In order to achieve this performance in real installations it is essential to use cables and connectors with good EMC characteristics.
-
Page 13: Table Of Contents
Table of Contents FCC Compliance..............ii Patent Information . - Page 14 Table of Contents...
-
Page 15: Kahuna Meg
Kahuna MEG Kahuna MEG Overview Kahuna MEG is designed to work with an external touch screen Graphical User Interface. The metal bracket the MEG module attaches to, is designed to fit a VESA 75/100 stand, which allows the MEG to be situated on the right hand side of the monitor to align with the on-screen parameter controls. -
Page 16: Meg Ip Address Setup
Kahuna MEG MEG IP Address Setup MEG IP Address Setup IMPORTANT: Please make sure that the Kahuna system is running V9.4r1 software or greater before setting up and connecting the MEG module to the system. It is easier to setup the MEG module before attaching it to a monitor. The first thing to do is to setup the IP address of the MEG module so that Kahuna is able to communicate with it. - Page 17 Kahuna MEG Quick Setup Guide For example, if the Kahuna mainframe has an IP address of “178.162.20.86/19” then enter an IP address of “178.162.20.87” and a Subnet Mask of “255.255.224”. You can also give the panel an unique name if required. Finally click on the “Save”...
-
Page 18: Attaching The Meg Module To A Monitor
Kahuna MEG Attaching the MEG module to a Monitor Attaching the MEG module to a Monitor The mounting bracket that the MEG is mounted on is supplied in 3 pieces and includes the assembly screws: • VESA bracket • Spacer •... - Page 19 Kahuna MEG Quick Setup Guide With the spacer bar now fixed to the VESA bracket, the MEG bracket attaches to the spacer bar with 2x screws (as shown below). On the MEG bracket there are two horizontal slider slots that allow the MEG bracket to be moved and positioned forward or backward. Hold the MEG bracket to the spacer bar and attach.
- Page 20 Kahuna MEG Attaching the MEG module to a Monitor The cut-outs on the VESA bracket allow for different size stand brackets and monitors. When mounting the MEG and VESA bracket to the back of a monitor, the MEG module must be situated on the right side of the monitor.
-
Page 21: Connecting The Meg Module And Setup With Kahuna
Kahuna MEG Quick Setup Guide Connecting the MEG module and Setup with Kahuna IMPORTANT: Please make sure that the Kahuna system is running V9.4r1 software or greater before setting up and connecting the MEG module to the system. The RJ45 PoE/Network connector at rear of the MEG module is used to connected directly to a network switch. -
Page 22: When Powered Up And Working
Kahuna MEG Connecting the MEG module and Setup with Kahuna When Powered Up and Working When setup and working, the LEDs on the MEG module will light up according to the number of parameter controls in the current menu, 3 or 5. The “PSU ADAPTER” LED will light green and the “Status”... -
Page 23: Setting Up The Meg Module With Kahuna
Kahuna MEG Quick Setup Guide Setting up the MEG module with Kahuna Once the MEG module is connected to the Kahuna mainframe, the MEG module needs to be recognized by the Kahuna software. On the external GUI, touch the “Panel Config” button. In the Panel Config menu, touch the “Maverik Layout”... - Page 24 Kahuna MEG Setting up the MEG module with Kahuna Touch the “IP MAV Setup” button and you will see that the MEG module has been added to the system. The information contained in the list is the serial number of the MEG module and the IP address.
-
Page 25: Contact Us
1-800-547-8949 (US and Canada) or +1 530 478 4148. To obtain a local phone number for the support center nearest you, please consult the Contact Us section of Grass Valley’s website ( www.grassvalley.com An online form for e-mail contact is also available from the website.
