"Edgewood" LightHeaded™ Bed
Assembly Instructions
Part
Blister Pack
EQA
1168348 C
Model #20165Twin size, Cheshire Cherry
Model #20269Twin size, Black
Model #20161 Twin size, White
Before you begin:
• Consider enlisting a family member or friend to help; it will make assembly easier,
faster, and more fun.
• Layout all of the parts listed below.
• Save all packing materials until assembly is complete to avoid accidentally
discarding smaller parts or hardware.
• You will need a Phillips head screw driver (not included)
Description
Contains the hardware required to assemble your new Lightheaded Bed
EPY
Cam-lock
EPZ
Cam-bolt
EPM
Wood screw
EQC
Fender washer (2 extra)
LightHeaded™ headboard panel—ships with LightHeaded™ lighting component
EPN
kit already installed.
EQB
Caprail
EPO
Right headboard leg
EPP
Left headboard leg
EPQ
Footboard
EPR
Right side rail
EPS
Left side rail
EPT
Roll-out slats (12 pieces of wood connected with nylon straps)
LightHeaded™ TechBox (contains remote control, power cord, instructions for
EPU
use and image changing, and your coupon code for $20) (see separate
LightHeaded™ Lighting Assembly Instructions)
Parts s List
www.LightHeadedBeds.com
12/07/2015
Quantity
1
8
8
24
4
1
1
1
1
1
1
1
1
1
