"Montgomery" LightHeaded™ Headboard
Part
1168366
Model #20346 Twin size, Espresso
Model #20348 Twin size, Satin White
Before you begin:
• Layout all of the parts listed below.
• Save all packing materials until assembly is complete to avoid
accidentally discarding smaller parts or hardware.
• You will need a Phillips head screw driver (not included).
• Your LightHeaded™ Headboard is designed to be used with a free
standing metal bed frame (not included).
Parts List
Description
A
3/4" long machine screw (Part# 80000648)
B
Wood screw (Part# 80000650)
C
Allen wrench (Part# 80000651)
D
Headboard Caprail (Part# 80000652 Espresso, Part# 8000653 Satin White)
Headboard Center Panel (Part# 80000654, Espresso; Part# 80000655, Satin
E
White) ships with LightHeaded™ lighting component kit already installed.
F
Right headboard leg (Part# 80000668 Espresso; Part# 80000669 Satin White)
G
Left headboard leg (Part# 80000670 Espresso; Part# 80000671 Satin White)
H
Bed frame assembly hardware – Bolt (Part# 80000672 )
I
Bed frame assembly hardware – Metal Washer (Part# 80000673 )
J
Bed frame assembly hardware – Metal Lock Washer (Part# 80000674 )
K
Bed frame assembly hardware – Hex Nut (Part# 80000675 )
L
Wrench (Part #80000680 )
LightHeaded™ TechBox (Contains remote control, power cord, User Guide, and
M
most importantly your $20 coupon code for LightHeaded™ Beds.com) (Part#
80000152)
www.LightHeadedBeds.com
07-23-2015
Quantity
6
4
1
1
1
1
1
4
8
4
4
1
1
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LightHeaded 20346
Summary of Contents for LightHeaded 20346
- Page 1 • Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or hardware. • You will need a Phillips head screw driver (not included). • Your LightHeaded™ Headboard is designed to be used with a free standing metal bed frame (not included). Parts List...
- Page 2 HeadLight Image already in place. 3. Please refer to your LightHeaded™ Lighting User Guide in the TechBox (M) for information on how to power up your light, insert images, and trouble shoot. Please be sure to look for your remote control and $20 coupon for LightHeadedBeds.com in your TechBox (M).
- Page 3 07-23-2015 Step 4 1. Connect your assembled LightHeaded™ headboard to your metal bed frame (sold separately) with bolt (H) through lock washer (J), through metal washer (I), through metal bed frame (sold separately), through slot in wood headboard bed leg (F,G), through second metal washer (I), and tighten into hex nut (K) using the included wrench (L).
- Page 4 How to Obtain Warranty Service Please complete and return the product registration card. If you LightHeaded™ Beds warrants that for a period of one year from the have questions regarding this warranty or would like to obtain date of purchase, this product will be free from defects in material and warranty service, please call (800) 225-3865 or e-mail workmanship.
