3.4 Copy Project to SD Card

This is a custom utility for transferring Proficy Machine Edition View and Control projects
between compatible QuickPanel+ units via SD cards.
To copy a Machine Edition project to SD card
1. Ensure there is a blank SD card in the SD card port.
2. Double tap the Copy Project to SD Card icon on the desktop.
3. Tap Yes when the Copy Project Query confirmation dialog box appears.

3.5 Updating a Machine Edition Project

You can update a Machine Edition application currently stored on the QuickPanel+ with a
revision stored on a flash device, such as a SD card.
1. Insert the flash device containing an upgraded version of the Machine Edition project into
the appropriate port.
2. Reboot the machine
See the settings section below, as depending on options set, the update may or may not
be enabled, or may automatically update. If there is more than one flash device with a
valid project copy present, a Select Media confirmation dialog will appear allowing you to
choose which flash device to update with. Select the device from the list and select OK to
continue. When a valid project is found on the flash device, you will be prompted to install
the project or skip it. Tap OK to install or Cancel to skip the install and continue to boot. If
an invalid project is found, an error message appears in a dialog box. This dialog box
must be closed before boot will continue.
3. Remove the flash device from the port.
Chapter 3 QuickPanel+ Software
16
Ensure that the copy or update operation is complete (i.e., no
busy or wait cursor displays) b efore disconnecting power.
Copying a project while the Proficy Machine Edition runtimes
are active may cause an incomplete copy to be created if the
runtimes are also writing to files in the project folders. The
utility can detect this situation and will notify you to stop the
runtimes before making the backup. You will not be able to
create a backup while the runtimes are writing files.
QuickPanel+ User's Manual–November 2013
Caution
Caution
GFK-2847
